>> Download www.thinksrs.com-SG300_comparison documenatation <<Text preview - extract from the document A Technical and Pricing Overview of Four RF Signal Generators
Manufacturer SRS Agilent SRS Agilent
Model SG384 N5171B-503 SG394 N5172B-503
Front panel image
Frequency range DC to 4.05 GHz 9 kHz to 3 GHz DC to 4.05 GHz 9 kHz to 3 GHz
Frequency extension to 6 GHz Yes (SG386) Yes (N5171B-506) Yes (SG396) Yes (N5172B-506)
Frequency resolution 0.000001 Hz 0.01 Hz 0.000001 Hz 0.01 Hz
Frequency switching speed 8 ms 5 ms 8 ms 5 ms
Output power range +13 to -110 dBm +18 to -144 dBm +13 to -110 dBm +18 to -144 dBm
Output power resolution 0.01 dB 0.01 dB 0.01 dB 0.01 dB
Phase adjustment resolution at 1 GHz 0.1 degree 0.1 degree 0.1 degree 0.1 degree
Phase noise (1 GHz, 10 Hz offset) -80 dBc/Hz -62 dBc/Hz -80 dBc/Hz -62 dBc/Hz
Phase noise (1 GHZ, 20 kHz offset) -116 dBc/Hz -122 dBc/Hz -116 dBc/Hz -122 dBc/Hz
Spurs (> 10 kHz offset, referenced to 1 GHz) -75 dBc -72 dBc -75 dBc -72 dBc
Standard timebase (temperature stability) OCXO (
