Image preview - the first page of the document
www.thinksrs.com-UGAPM vs PPR


>> Download www.thinksrs.com-UGAPM vs PPR documenatation <<

Text preview - extract from the document
Comparison with PPR
                UGAPM                                    PPR
Range           20 ~ 0.001 torr                          10, 1, 0.1, 0.01 torr
                4 steps w/ proper capillary              4 steps w/ proper pinhole
                Extra port for high vacuum               <10-5 torr w/ hi-Vac valve
Sample inlet    Single point analysis                    Single point analysis
                Multi points analysis
                Full range analysis
Response time   <1.5 sec @ 0.1                           2 sec @ 0.1 torr
System          Integrated                               Individual
Functions
