Image preview - the first page of the document
SCX5312-Service Manual


>> Download SCX5312-Service Manual documenatation <<

Text preview - extract from the document
                     DIGITAL LASER MFP
                     SCX-5312F
                     SCX-5112




SERVICE                     MANUAL


 DIGITAL LASER MFP                       CONTENTS

                        1. Precautions

                        2. Specifications

                        3. Disassembly

                        4. Troubleshooting

                        5. Exploded Views and Parts List

                        6. Block Diagram

                        7. Connection Diagram
                                                                                                  Precautions




1. Precautions
Follow these safety, ESD, and servicing precautions to prevent personal injury and equipment damage.


1-1 Safety Precautions
1. Be sure that all built-in protective devices are in   6. Observe the original lead dress, especially near
   place. Restore any missing protective shields.           sharp edges, AC, and high voltage power sup-
                                                            plies. Always inspect for pinched, out-of-place,
2. Make sure there are no cabinet openings                  or frayed wiring. Do not change the spacing
   through which people-particularly children- might        between components and the printed circuit
   insert fingers or objects and contact dangerous          board.
   voltages.
                                                         7. Product Safety Notice:Some electrical and
3. When re-installing chassis and assemblies, be            mechanical parts have special safety-related
   sure to restore all protective devices, including        characteristics which might not be obvious from
   control knobs and compartment covers.                    visual inspection. These safety features and the
                                                            protection they provide could be lost if a replace-
4. Design Alteration Warning:Never alter or add to          ment component differs from the original. This
   the mechanical or electrical design of this equip-       holds true, even though the replacement may be
   ment, such as auxiliary connectors, etc. Such            rated for higher voltage, wattage, etc.
   alterations and modifications will void the manu-
   facturer's warranty.                                  8. Components critical for safety are indicated in
                                                            the parts list with symbols .
5. Components, parts, and wiring that appear to             Use only replacement components that have the
   have overheated or are otherwise damaged                 same ratings, especially for flame resistance and
   should be replaced with parts which meet the             dielectric specifications. A replacement part that
   original specifications. Always determine the            does not have the same safety characteristics as
   cause of damage or overheating, and correct any          the original may create shock, fire, or other
   potential hazards.                                       safety hazards.


1-2 Precautions on Disassembly and Reassembly
Very careful precautions should be taken when            5. Do not force to open or fasten plastic material
replacing parts. Before replacing, please check             components.
cables because you cannot put the cables that you        6. Be careful that small parts such as screws
removed for replacing parts into the proper place if        should not get in the printer.
you would not make sure of where they were con-          7. When disassembling, assembling, also observe
nected and in which condition.                              small components are located in place.
                                                         8. If you uncover and turn the machine over to
Please do the following before disassembling for a          replace some parts, toner or paper particles may
repair or replacement of parts.                             contaminate the LSU window. Protect the LSU
                                                            window with clean paper.
1. Pull out paper cassette, printer cartridge
   installed. Especially careful not to be scratched     Releasing Plastic Latches
   by the surface of developer or not to expose
   them to light.                                        Many of parts are held in
2. Turn the power switch off.                            place with plastic latches.
3. Take out the power plug, printer cable from the       The latches break easily :
   printer.                                              release them carefully.
4. Use only the same type of part as original when       To remove such parts,
   replacing parts.                                      press the hook end of the
                                                         latch away from the part to
                                                         which it is latched.



Samsung Electronics                                                                                        1-1
Precautions




1-3 ESD Precautions

1. Certain semiconductor devices can be easily                  4. Use only a grounded tip soldering iron to solder
   damaged by static electricity. Such components                  or desolder ESDs.
   are commonly called "Electrostatically Sensitive                Use only an "anti-static" solder removal device.
   (ES) Devices", or ESDs. Examples of typical                     Some solder removal devices not classified as
   ESDs are: integrated circuits, some field effect                "anti-static" can generate electrical charges suffi-
   transistors, and semiconductor "chip" compo-                    cient to damage ESDs.
   nents.
                                                                5.    Do not use Freon-propelled chemicals. When
      The techniques outlined below should be fol-                   sprayed, these can generate electrical charges
      lowed to help reduce the incidence of component                sufficient to damage ESDs.
      damage caused by static electricity.
                                                                6. Do not remove a replacement ESD from its pro-
      CAUTION : Be sure no power is applied to the chassis         tective packaging until immediately before install-
                or circuit, and observe all other safety pre-      ing it. Most replacement ESDs are packaged
                cautions.                                          with all leads shorted together by conductive
                                                                   foam, aluminum foil, or a comparable conductive
2. Immediately before handling a semiconductor                     material.
   component or semiconductor-equipped assem-
   bly, drain off any electrostatic charge on your              7. Immediately before removing the protective
   body by touching a known earth ground. Alterna-                 shorting material from the leads of a replace-
   tively, employ a commercially available wrist                   ment ESD, touch the protective material to the
   strap device, which should be removed for your                  chassis or circuit assembly into which the device
   personal safety reasons prior to applying power                 will be installed.
   to the unit under test.
                                                                8.    Maintain continuous electrical contact between
3. After removing an electrical assembly equipped                    the ESD and the assembly into which it will be
   with ESDs, place the assembly on a conductive                     installed, until completely plugged or soldered
   surface, such as aluminum or copper foil, or con-                 into the circuit.
   ductive foam, to prevent electrostatic charge
   buildup in the vicinity of the assembly.                     9. Minimize bodily motions when handling unpack-
                                                                   aged replacement ESDs. Normal motions, such
                                                                   as the brushing together of clothing fabric and
                                                                   lifting one's foot from a carpeted floor, can gener-
                                                                   ate static electricity sufficient to damage an ESD.




1-4 Super Capacitor or Lithium Battery Precautions
1. Exercise caution when replacing a super capaci-              3. Super capacitor or Lithium batteries contain toxic
   tor or Lithium battery. There could be a danger of              substances and should not be opened, crushed,
   explosion and subsequent operator injury and/or                 or burned for disposal.
   equipment damage if incorrectly installed.

2. Be sure to replace the battery with the same or              4. Dispose of used batteries according to the manu-
   equivalent type recommended by the manufac-                      facture's instructions.
   turer.




1-2                                                                                             Samsung Electronics
                                                                                                   Precautions




1-5 Tools for Troubleshooting

The following tools are recommended for safe and smooth troubleshooting described in this service manual.



 1 DVM(Digital Volt Meter)                              3 Driver
 Standard: Indicates more than 3 digits.                Standard: "-" type, "+" type (M3 long, M3 short, M2
                                                        long, M2 short).




                                                        4 Pinset
                                                        Standard: For general home use, small type.




 2 Electronic Scale                                     5 Cotton Swab
 Standard: Equipment to check the weight of consum-     Standard: For general home use, for medical service.
 ables(toner cartridge) supplied by Samsung Electron-
 ics. (The gram unit can be measured.)




                                                        6 Cleaning Equipments a IPA(Isopropyl
                                                          Alcohol)dry cloth or a soft stuff neutral
                                                          detergent.


                                                        7 Software(Driver) installation CD ROM




                                                         Note : Mind your hands not to be touched when you
                                                                disassemble and reassemble PBA ASS'Y,
                                                                such as the main board, SMPS, HVPS.




Samsung Electronics                                                                                           1-3
                                                                                                     Specification



2. Specification
Specifications are correct at the time of printing. Product specifications are subject to change without notice.
See below for product specifications.

2-1 General Specifications

                   Item                                                Description

 Type of Unit                            Desktop

 Operation System                        Win95/98/ME/ NT /2000/XP

 Duplex Printing                         Yes(Default)

 Interface                               IEEE1284(Nibbel/ECP)

                                         USB(without HUB mode)

 CPU                                     66 MHz(KS32C61200)

 Emulation                               PCL6

 Warming up Time                         41 Sec (Stand-By), 25
