Image preview - the first page of the document
>> Download SAMSUNG_SDC_007 documenatation <<
Text preview - extract from the document
2. Specifications
System Specifications
CCD Progressive 1.08M pixel
Number of pixels 1152 x 864 pixel (XGA)
Color Depth 24 bits True Color
Memory capacity Extra (smart media card 4MB/3.3V)
Image Capacity Standard (quality-about 20/high quality-about 10)
Lens Dual fixed focus F:2.8f = 6.6
Focus Length Normal (50cm ~ ) Macro (5 ~ 50cm)
View Finder OVF (optical view finder) & color LCD
Shutter Speed Electric Shutter (1/8 ~ 1/2000)
Exposure Auto / Manual
White Balance Auto
Video Out Both NTSC type & PAL type
Power Source Hydro-Nickel charger, AA type battery (Alkaline)
PC Interface Serial Transmission (RS 232C : Max 115.2kbps)
Compression Standard JPEG
Support O/S MS-Windows 95, 98
S/W CD-Rom (TWAIN Driver, iPhotoExpress)
Dimensions 62 x 100 x 40 (Length x Height x Width)
Net Weigh Less than 206g (not including battery pack)
Standard Shooting Full Size Shooting : 1152 x 864 (SQ/HQ)
Basic Shooting
General Shooting VGA Size Shooting : 640 x 480 (SQ/HQ)
Mode
B/W Shooting Full Size B/W : 1152 x 854 (SQ/HQ)
Full Size Division : 1152x 864 (SQ/HQ)
Multi Shooting
Special Shooting - 4 ~ 16 Images Division
Mode Continuous VGA Size continuation : 640 x 480 (SQ/HQ)
Shooting - 3 ~ 6 Images Division
Normal Playback One Image at a time, full size playback
Magnified Playback 4 times magnified playback by parts
Play Mode
Multi Playback 6 images-divided multi playback
Automatic Playback Automatic interval playback
Selective Erase Erase selected images among divided images
Erase Mode Full Erase Erase all the memories
Erase Prevention Prevent accidental erase of precious images
Setting Mode Menu bar type control for each status
Transmission Mode PC interfacing only mode
- Direct interfacing mode
Others - Manual adjust mode : adjusting exposure
- Navigation key control : 4-direction movement and selection
1 The technical specifications and design may be changed without notice.
Samsung Electronics 2-1
Specifications
MEMO
2-2 Samsung Electronics
