Image preview - the first page of the document
>> Download Samsung SGH-2400 service manual documenatation <<
Text preview - extract from the document
DUAL BAND Mobile
Cellular Phone
SGH-2400
SERVICE Manual
DUAL BAND Mobile Cellular Phone CONTENTS
1. Exploded Views and Parts List
2. Electrical Parts List
3. Block Diagrams
4. PCB Diagrams
5. Schematic Diagrams
6. Troubleshooting
1
2ABC
4 GHI 3 DEF
5 JKL
7PQRS 6MNO
8TUV
9WXYZ
0
ELECTRONICS
Samsung Electronics Co.,Ltd.
Printed in Korea
11/1999 Rev 1.0
GH68-00844A
1. Exploded Views and Parts List
1-1 Main
1
2
9
3
4
5
6
10
7
11
8
13 12
14
15
17
16
18
21
19
20
22 26
27
23
28
24
29
25 30
31
35
33 32
36
34
37
38
39
40
Exploded Views and Parts List 1-1
1-2 Main Parts List
NO DESCRIPTION SEC.CODE Q'TY REMARK
1 BADGE 1
2 FLIP COVER 1
3 KEY VOLUMN 1
4 PUBBER-KEY 1
5 FRONT COVER 1
6 SPONGE S/W 1
7 HINGE ASS'Y 2
8 KEY-MAIN 1
9 LED LENS 1
10 SUA. WINDOW 1
11 LCD 1
12 LCD FRAME 1
13 RUBBER-BUZZER 1
14 SUPPORT BUZZER 1
15 SUPPORT-SPK 1
16 SUPPORT-CON. 1
17 KEY-PCB 1
18 HOLDER-MIC 1
19 SPONGE-MIC 1
20 SHIELD-FRAME 1
21 JACK-COVER 1
22 PCB 1
23 COVER-CONNECTOR
24 EAR-COVER
25 REAR COVER 1
26 MOTOR 1
27 TAPE-MOTOR 1
28 ANT.BRAKET 1
29 ANTENNA 1
30 RUBBER CAP 1
31 SIM COVER 1
32 SPRING-SIM 1
33 SPRING-LOCKER 1
34 LOCKER-MAIN 1
35 SCREW MACHINE 1
36 MAIN LABEL 1
37 SLIM BATT. 1
38 STD BATT.
1-2 Exploded Views and Parts List
NO DESCRIPTION SEC.CODE Q'TY REMARK
39 EXT.BATT
40 ULTRA EXT. BATT
Exploded Views and Parts List 1-3
1-3 Travel Adapter
A B
C
1-4 Travel Adapter Parts List
TYPE SEC CODE REMARK
A GH96-01143A CHINA
B GH96-01146A EUROPE
C GH96-01095A UNITED KINGDOM
1-4 Exploded Views and Parts List
1-5 Desk Top Charger
SEC CODE : GH44-00090A
1
2
6
3
4 5
7
8
9
10
11
Exploded Views and Parts List 1-5
1-6 Desk Top Charger Parts List
NO DESCRIPTION SEC.CODE Q'TY REMARK
1 UPPER CASE 1
2 HANGER SPRING (L) 1
3 SCREW TAPPING 4
4 HANGER SPRING (R) 1
5 SCREW TAPPING 3
6 BATT. HOUSING 1
7 PCB 1
8 LOWER BASE 1
9 SCREW TAPPING 4
10 BUMPON 4
11 LABEL 1
1-6 Exploded Views and Parts List
1-7 Ciger Light Adapter
1-8 Ciger Light Adapter Parts List
DESCRIPTION SEC CODE REMARK
Ciger Light Adapter Code GH44-00040A BLACK
Exploded Views and Parts List 1-7
1-8
Phone
1-9 Hands Free Kit
Micro Phone
SEC CODE : GH96-00800A
Yellow(Ignition)
White(Stereo Mute)
Red(Vehicle Battery)
Black(GND)
Exploded Views and Parts List
1-10 Test Jig
TEST JIG GH80-10508A
DATA CABLE GH39-30532A
1-11 Earphone
EARPHONE GH96-00830A
Exploded Views and Parts List 1-9
2 Electrical Parts List
2-1 Main Parts List
REFERENCE SEC.CODE DESCRIPTIONS
D401,D801 0401-001033 Diode-Switching,25V,200mA
D253,D255,D808 0404-001044 Diode-Schottky,20V,1A,SMD
D400 0404-001054 Diode-Schottky,70V,15mA,SOT-143
D600 0405-001051 Diode-Varactor,4.7V,50nA,SOT-23
D101,D102,D176,D820,D903 0406-001084 ESD Diode
D252 0407-001002 Diode-Array,80V,300mA,CA2-3
D901,D902 0407-001006 Diode-Array,20V,100mA,C2-3
D251 0407-001007 Diode-Array,80V,25mA,CA4-2
Q958 0501-000162 TR-SMALL SIGNAL,PNP,200mW,SOT-323
Q951 0501-002011 TR-SMALL SIGNAL,NPN,200mW,SOT-23
Q300 0501-002037 TR-SMALL SIGNAL,MPN,55mW,SOT-434
Q601,Q604 0501-002196 TR-SMALL SIGNAL,NPN,280mW,SOT-323
U307 0501-002205 TR-SMALL SIGNAL,NPN,SOT-343
Q151,Q153,Q255 0504-000167 TR-Digital,NPN,100mW,10K10Kohm
Q256,Q257 0504-000168 TR-Digital,NPN,100mW,47K47Kohm
Q500 0505-000110 FET-SILICON,60V,115mA,200mW
U501,U502 0505-001131 FET-SILICON,-12V,-500mA,690mohm
Q950,Q957 0505-001332 FET-SILICON
Q600 0506-000173 TR-ARRAY,NPN,80mW,SOT-363
U128,U252,U302,U303,U400,U403,U412,U813 0506-001004 TR-ARRAY,NPN/PNP,50V,-100mA
LED100 0601-000276 LED/CHIP
U902,U903 0801-000022 IC-CMOS LOGIC,NANDGATE,SOP,5P
U900,U901,U904,U906 0801-000794 IC-CMOS LOGIC,ANDGATE,SOT-25,5P
U905 0801-002345 IC-CMOS LOGIC,INVERATER,SOP,5P
U413,U414 0801-002349 IC-CMOS LOGIC
U962,U963 1001-001088 ANALOG SWITCH
U969 1003-001226 IC-POWER DRIVER,SOP,8P,120MIL
U203 1103-001090 IC-EEPROM,16Kx8Bit,SOP,8P,150MIL
U105 1106-001287 IC-SRAM
U103 1107-001111 IC-Flash memory
U104 1107-001164 IC-Flash memory
U406 1201-001018 IC-OP AMP,SOT-23,5P,Single,70dB
U127 1201-001212 IC-OP AMP,SOP,14P,15V/Mv
U604 1201-001248 IC-CASCADE AMP,SOT-143,4P,2.7V
U402 1201-001299 IC-POWER Amp,RF-K,8P,SINGLE,8V
U408 1201-001411 IC-POWER Amp
U960 1202-001022 IC-VOLTAGE COMP,SSOP,8P,110MIL,7V
U801,U803,U805,U806,U810,U811 1203-001285 IC-SWITCH VOL REG,SOT-23,5P,150MIL
2-1 Electrical Parts List
REFERENCE SEC.CODE DESCRIPTIONS
U809 1203-001511 IC-Reset,SOT-23,3P
U253 1203-001515 IC-BATTERY,SSOP,16P,150MIL
U804 1203-001592 IC-VOLTAGE REGULATOR,SOT-23,5P
U812 1203-001702 IC-DC/DC CONVERTER,SOP,10P,112MIL
U102 1203-001740 IC-DC/DC CONVERTER,SOP,16P,150MIL
U301 1204-001006 IC-IP SYSTEM,SOP,20P,205MIL
U300,U305 1205-001307 IC-MIXER,SOP,16P,197MIL
U200 1205-001643 IC-KERNEL
U950 1205-001697 IC-VOCODER,QFP,80P,3V
U202 1206-001009 IC-TIMER,SOP,8P,173MIL
U603 1209-001220 IC-PLL SYSTEM,SOP,20P,173MIL
U500 1209-001233 IC-PLL SYSTEM,SSOP,28P
TH1 1404-001005 THERMISTOR,47Kohm,5%,4054K,20mW
D179 1405-001018 Varistors
D103,D104,D819 1405-001019 Varistors
R184 2007-000070 R-CHIP,0ohm,5%,1/16W,DA,TP,1608
R105,R129,R135,R163,R177,R178,R179,R180,R181
2007-000138 R-CHIP,100ohm,5%,1/16W,DA,TP,1005
R182,R183,R185,R186,R187,R188,R621,R653
R644,R978 2007-000139 R-CHIP,220ohm,5%,1/16W,DA,TP,1005
R220,R221,R264,R529,R611,R646,R811,R951,R954 2007-000140 R-CHIP,1Kohm,5%,1/16W,DA,TP,1005
R640 2007-000141 R-CHIP,2.2Kohm,5%,1/16W,DA,TP,1005
R309,R609 2007-000142 R-CHIP,2.7Kohm,5%,1/16W,DA,TP,1005
R351 2007-000143 R-CHIP,4.7Kohm,5%,1/16W,DA,TP,1005
R606,R628 2007-000145 R-CHIP,6.2Kohm,5%,1/16W,DA,TP,1005
R603 2007-000146 R-CHIP,6.8Kohm,5%,1/16W,DA,TP,1005
R104,R152,R205,R210,R232,R235,R238,R253,R256,R363
R418,R419,R605,R630,R637,R906,R907,R952,R962,R963 2007-000148 R-CHIP,10Kohm,5%,1/16W,DA,TP,1005
R984,R985,R996,R255
R300 2007-000152 R-CHIP,20Kohm,5%,1/16W,DA,TP,1005
R622 2007-000153 R-CHIP,22Kohm,5%,1/16W,DA,TP,1005
R126,R208,R218,R219,R352,R353 2007-000157 R-CHIP,47Kohm,5%,1/16W,DA,TP,1005
R257 2007-000159 R-CHIP,56Kohm,5%,1/16W,DA,TP,1005
R100,R101,R102,R151,R153,R162,R209,R212,R213,R214
2007-000162 R-CHIP,100Kohm,5%,1/16W,DA,TP,1005
R222,R231,R251,R252,R254,R263,R528,R812,R972,R980
R610,R639 2007-000164 R-CHIP,150Kohm,5%,1/16W,DA,TP,1005
R215,R312,R326,R361,R505,R531,R631,R647,R968,R986 2007-000171 R-CHIP,0ohm,5%,1/16W,DA,TP,1005
R308,R500,R501,R502,R503,R504,R517,R524,R527,R601
2007-000172 R-CHIP,10ohm,5%,1/16W,DA,TP,1005
R602,R607,R633,R638,R650
R651,R654 2007-000173 R-CHIP,22ohm,5%,1/16W,DA,TP,1005
R515,R516,R518 2007-000932 R-CHIP,470ohm,5%,1/16W,DA,TP,1005
R130,R136,R417 2007-001119 R-CHIP,680ohm,5%,1/16W,DA,TP,1005
R428 2007-001217 R-CHIP,82ohm,5%,1/16W,DA,TP,1005
Electrical Parts List 2-2
REFERENCE SEC.CODE DESCRIPTIONS
R304,R623,R625,R627 2007-001288 R-CHIP,18ohm,5%,1/16W,DA,TP,1005
R431 2007-001295 R-CHIP,39ohm,5%,1/16W,DA,TP,1005
R305,R364,R410,R420,R511,R519,R520,R648,R649 2007-001298 R-CHIP,51ohm,5%,1/16W,DA,TP,1005
R445 2007-001301 R-CHIP,68ohm,5%,1/16W,DA,TP,1005
R404,R406,R617 2007-001305 R-CHIP,120ohm,5%,1/16W,DA,TP,1005
R430,R432 2007-001306 R-CHIP,150ohm,5%,1/16W,DA,TP,1005
R306,R311,R316,R317 2007-001307 R-CHIP,180ohm,5%,1/16W,DA,TP,1005
R613,R805 2007-001308 R-CHIP,200ohm,5%,1/16W,DA,TP,1005
R128,R134 2007-001311 R-CHIP,270ohm,5%,1/16W,DA,TP,1005
R356,R357,R365,R525,R526,R950,R953 2007-001313 R-CHIP,330ohm,5%,1/16W,DA,TP,1005
R612 2007-001316 R-CHIP,820ohm,5%,1/16W,DA,TP,1005
R507,R512 2007-001317 R-CHIP,910ohm,5%,1/16W,DA,TP,1005
R629 2007-001323 R-CHIP,3Kohm,5%,1/16W,DA,TP,1005
R354,R608 2007-001325 R-CHIP,3.3Kohm,5%,1/16W,DA,TP,1005
R618,R643 2007-001339 R-CHIP,180Kohm,5%,1/16W,DA,TP,1005
R413 2007-002797 R-CHIP,560ohm,5%,1/16W,DA,TP,1005
R301 2007-003020 R-CHIP,4.3Kohm,5%,1/16W,DA,TP,1005
R427,R429 2007-003030 R-CHIP,91ohm,5%,1/16W,DA,TP,1005
R407 2007-007001 R-CHIP,3.9Kohm,5%,1/16W,DA,TP,1005
R521 2007-007090 R-CHIP,11Kohm,5%,1/16W,DA,TP,1005
R510 2007-007095 R-CHIP,390ohm,5%,1/16W,DA,TP,1005
R362 2007-007096 R-CHIP,160ohm,5%,1/16W,DA,TP,1005
R132,R137,R259 2007-007107 R-CHIP,100Kohm,1%,1/16W,DA,TP,1005
R265 2007-007133 R-CHIP,300ohm,1%,1/16W,DA,TP,1005
R261 2007-007135 R-CHIP,18K,1%,1/16W,DA,TP,1005
R434,R619,R900,R903,R905 2007-007137 R-CHIP,1.2Kohm,1% ,1/16W,DA,TP,1005
R522 2007-007141 R-CHIP,240ohm,5%,1/16W,DA,TP,1005
R904,R987 2007-007142 R-CHIP,10Kohm,1%,1/16W,DA,TP,1005
R514,R523,R626,R645,R652 2007-007195 R-CHIP,3.9ohm,5%,1/16W,DA,TP,1005
R262,R416 2007-007309 R-CHIP,12Kohm,1%,1/16W,DA,TP,1005
R266,R414 2007-007310 R-CHIP,8.2Kohm,1%,1/16W,DA,TP,1005
R412 2007-007311 R-CHIP,22Kohm,1%,1/16W,DA,TP,1005
R409 2007-007316 R-CHIP,3.3Kohm,1%,1/16W,DA,TP,1005
R200,R201,R202,R203 2007-007317 R-CHIP,2.2Kohm,1%,1/16W,DA,TP,1005
R121,R127,R133,R303,R313,R415,R994,R995 2007-007318 R-CHIP,1Kohm,1%,1/16W,DA,TP,1005
R435,R655 2007-007588 R-CHIP,1.8Kohm,1%,1/16W,DA,TP,1005
R258 2007-007590 R-CHIP,82Kohm,1%,1/16W,DA,TP,1005
R260 2007-007592 R-CHIP,270K,1%,1/16W,DA,TP,1005
R979,R981 2007-007627 R-CHIP,16Kohm,1%,1/16W,DA,TP,1005
R983 2007-007630 R-CHIP,14Kohm,1%,1/16W,DA,TP,1005
R355,R902 2007-007788 R-CHP,332ohm,1%,1/16W,DA,TP,1005
C524 2203-000151 C-CHIP,1.5nF,5%,50V,TP,2012
2-3 Electrical Parts List
REFERENCE SEC.CODE DESCRIPTIONS
C215,C216,C217,C218,C303,C318,C337,C362,C368,C411,C416
2203-000233 C-CHIP,100pF,5%,50V,TP,1005
C501,C502,C503,C508,C509,C516,C521,C623,C628,C635,C642
C348,C512 2203-000278 C-CHIP,10pF,5%,50V,TP,1005
C445 2203-000311 C-CHIP,120pF,5%,50V,TP,1005
C310,C539,C604 2203-000330 C-CHIP,12pF,5%,50V,TP,1005
C625 2203-000359 C-CHIP,150pF,5%,50V,TP,1005
C316,C431,C514,C951,C958,C959,C968,C969,C970,C991,C993 2203-000386 C-CHIP,15pF,5%,50V,TP,1005
C127,C135,C207,C311,C351,C352,C354,C356,C361,C371,C373
2203-000438 C-CHIP,1nF,10%,50V,TP,1005
C375,C379,C504,C522,C621,C627,C637,C641,C966,C967
C624 2203-000455 C-CHIP,1nF,5%,50V,TP,2012
C409 2203-000585 C-CHIP,220pF,10%,50V,TP,1005
C950,C956 2203-000604 C-CHIP,22nF,10%,25V,TP,1608
C305,C330,C374,C376,C378,C415,C505,C506,C515,C611,C617 2203-000628 C-CHIP,22pF,5%,50V,TP,1005
C405,C418,C423,C428,C454,C457,C458,C459,C460,C510,C511
2203-000679 C-CHIP,27pF,5%,50V,TP,1005
C517,C520,C529,C530,C632,C633,C639
C346 2203-000696 C-CHIP,2pF,5%,50V,TP,1005
C128,C136,C609 2203-000725 C-CHIP,3.9nF,10%,50V,TP,1005
C614 2203-000800 C-CHIP,33nF,10%,25V,TP,1608
C302,C306,C319 2203-000812 C-CHIP,33pF,5%,50V,TP,1005
C610 2203-000836 C-CHIP,390pF,10%,50V,TP,1005
C325 2203-000854 C-CHIP,39pF,5%,50V,TP,1005
C304,C357,C810,C819,C862,C867 2203-000940 C-CHIP,470pF,10%,50V,TP,1005
C321,C350,C353,C377,C647 2203-001017 C-CHIP,4pF,5%,50V,TP,1005
C1004 2203-001033 C-CHIP,5.6nF,10%,25V,TP,1005
C518,C519 2203-001072 C-CHIP,56pF,5%,50V,TP,1005
C165,C166,C167,C168 2203-001101 C-CHIP,6.8nF,10%,25V,1005
C507,C513 2203-001153 C-CHIP,68pF,5%,50V,TP,1005
C300,C307,C315,C540,C606 2203-001178 C-CHIP,6pF,5%,50V,TP,1005
C314,C339 2203-001201 C-CHIP,7pF,5%,50V,TP,1005
C410,C430 2203-001221 C-CHIP,820pF,10%,50V,TP,1005
C613 2203-001259 C-CHIP,8pF,5%,50V,TP,1005
C169 2203-001402 C-CHIP,220nF,+80-20%,16V,TP,1608
C523 2203-001408 C-CHIP,270pF,5%,50V,TP,1608
C429 2203-002525 C-CHIP,560pF,10%,50V,TP,1005
C313 2203-002668 C-CHIP,0.5pF,0.1pF,50V,TP,1005
C317,C954,C964,C990,C996,C997,C1008 2203-003054 C-CHIP,9pF,5%,50V,TP,1005
C341 2203-005050 C-CHIP,1.8pF,5%,50V,TP,1005
C210,C528,C603,C644 2203-005054 C-CHIP,4.7pF,5%,50V,TP,1005
C100,C102,C106,C107,C117,C126,C134,C141,C201,C204,C205
C206,C214,C254,C258,C259,C260,C261,C358,C363,C372,C500
2203-005061 C-CHIP,100nF,+80-20%,16V,TP,1005
C608,C618,C634,C851,C853,C855,C869,C874,C901,C902,C903
C904,C905,C961,C971,C972,C973,C974,C1005
Electrical Parts List 2-4
REFERENCE SEC.CODE DESCRIPTIONS
C170,C171,C172,C173,C257,C364,C533,C534,C536,C638
2203-005065 C-CHIP,1uF,+80-20%,10V,TP,1608
C669,C800,C830,C831,C872
C177,C342,C645 2203-005158 C-CHIP,2.2pF,5%,50V,TP,1005
C629 2203-005195 C-CHIP,10nF,5%,25V,TP,3216
C349 2203-005234 C-CHIP,1.2pF,5%,50V,TP,1005
C602,C646 2203-005444 C-CHIP,3pF,5%,50V,TP,1005
C178,C179,C180,C181 2203-005480 C-CHIP,33nF,10%,10V,TP,1005
C957 2203-005481 C-CHIP,47nF,10%,10V,TP,1005
C365,C616 2203-005562 C-CHIP,10uF,+80-20%,10V,TP,3216
C108,C131,C139,C200,C211,C262,C333,C359,C360,C433
C435,C531,C600,C601,C605,C607,C612,C615,C620,C622
2203-005607 C-CHIP,10nF,10%,16V,TP,1005
C626,C630,C636,C801,C828,C850,C852,C854,C859,C870
C979,C1006,C1007
C464,C871 2404-001083 Cap-Tantal,220uF,6.3V,20%,TP,7125
C203 2404-001086 Cap-Tantal,4.7uF,6.3V,20%,TP,2012
C103,C104,C805,C806,C816,C817,C826,C827,C832,C845
2404-001105 Cap-Tantal,10uF,6.3V,20%,TP,2012
C860,C861,C868
C873 2404-001152 Cap-Tantal , 220uF,20%,6.3V
C953 2404-001162 Cap-Tantal,47uF
C253 2404-001164 Cap-Tantal, 10uF,20%,16V
L126,L128 2703-000217 Inductor,470uH/10%,2012
L127,L129 2703-001071 Inductor,330uH/10%,2012
L302 2703-001172 Inductor,100nH/5%,1608
L401 2703-001174 Inductor,33nH/5%,1608
L607 2703-001178 Inductor,3.3nH/0.3nH,1005
L327 2703-001179 Inductor,10nH/5%,1005
L175 2703-001290 Inductor,2.7nH/0.3nH,1608
L502,L503 2703-001308 Inductor,68nH/5%,1608
L177,L308,L600 2703-001409 Inductor,12nH/10%,1005
L320 2703-001544 Inductor,39nH/5%,1608
L250 2703-001595 Inductor,47nH/5%,1005
L300 2703-001685 Inductor,82nH/5%,1608
L326,L402 2703-001708 Inductor,5.6nH/5%,1005
L800 2703-001716 Inductor,22uH,1608
L323,L500 2703-001722 Inductor,18nH/5%,1005
L321,L322,L405,L406,L504,L505 2703-001723 Inductor,33nH/5%,1005
L507 2703-001726 Inductor,27nH/5%,1005
L324,L328,L329,L602 2703-001727 Inductor,22nH/5%,1005
L604 2703-001728 Inductor,1.5nH/0.3nH,1005
L301,L303,L501 2703-001732 Inductor,56nH/5%,1608
L305,L310 2703-001733 Inductor,8.2nH/5%,1005
L309,L325 2703-001734 Inductor,6.8nH/5%,1005
2-5 Electrical Parts List
REFERENCE SEC.CODE DESCRIPTIONS
L306,L319 2703-001735 Inductor,3.9nH/10%,1005
L307,L603,L606 2703-001737 Inductor,2.7nH/0.3nH,1005
L251 2703-001740 Inductor,10uH/20%,1608
L601 2703-001794 Inductor,120nH/2%,1608
L318 2703-001798 Inductor, 2.2nH/5%,1005
L801 2703-001904 Inductor,4.7mH
X201 2801-003847 Crystal
X600 2806-001190 DUAL VCO,1171~1216MHz,3V,8mA,TP
X501 2806-001194 DCS TX VCO
X500 2806-001199 GSM TX VCO
X601 2809-001220 VCTCXO-13MHz
F305 2903-001203 Ceramic Filter
F303 2904-001093 Filter-SAW,1842.5MHz,75MHz
F300 2904-001146 Filter-SAW-AV,246MHz
F301 2904-001147 Filter-SAW-AV,942.5MHz
F304 2904-001170 DCS Filter
F302 2904-001175 GSM RX SAW
U401 2909-001086 ANTENNA SWITCH,942.5MHz,897.5MHz
F200,F201 3301-001208 Core-Ferrite Bead
J100 3709-001121 SIM CONNECTOR,6P,2.54mm,SMD-S
M950 3710-001105 CONNECTOR-SOCKET,2P,1.27mm,SMD-S
J176 3710-001302 I/F Connector,18P,0.5mm
J151 3710-001428 BTB Connector,24P,0.5mm
J901 3722-001380 Earphone jack,6P
U405 4709-001174 Directional Coupler,890-915/1710-1785MHz
R360,R359,R604,R615,R632,R989,R990,C130,C138,C176
"SOT,NC"
C370,C380,C367,C369,C535,C643,C962,C963,L176,L311,L605
C863 4302-001081 BATT/CAP250uAH 3.3V
J180 GH07-00023A LCD
motor GH31-10004A Vibrator motor
W176 GH39-00041A Semirigid Cable
PCB GH41-00065A SGH-2400 PCB
GH42-00038A ANTENNA
GH59-00067A KEYPAD ASS'Y
A176 GH71-00156A ANTENNA CLIP
JIG GH80-10508A SGH-2400 TEST JIG
CABLE GH39-30532A SGH-2400 TEST JIG CABLE
TA GH44-30549A SGH-2400 TRAVEL ADAPTOR( EUROPE )
TA GH44-30547A SGH-2400 TRAVEL ADAPTOR( U.K )
TA CABLE GH39-10504A SGH-2400 TA CABLE
CLA GH44-00040A SGH-2400 CLA
DTC GH44-00090A DESK TOP CHARGE
Electrical Parts List 2-6
REFERENCE SEC.CODE DESCRIPTIONS
SLIM BATTERY 500mAh ( GREY )
SLIM BATTERY 500mAh ( BLACK )
STANDARD BATTERY GH43-00143A 750mAh ( GREY )
STANDARD BATTERY GH43-00143B 750mAh ( BLACK )
EXTENDED BATTERY 1000mAh ( GREY )
EXTENDED BATTERY 1000mAh (BLACK )
ULTRA EXTENDED BATTERY 1600mAh ( GREY )
ULTRA EXTENDED BATTERY 1600mAh ( BLACK )
DATA KIT GH96-00774A SGH-2400 DATA KIT
HFK HANDS FREE KIT
EAR PHONE GH96-00830A EAR PHONE
2-7 Electrical Parts List
RxEGSM
(925~960MHz) DEMODEN
VMID
GSMTX2 DCSTX2 RxEN_FEGSM
Block Diagrams
U300 IRXP
F305
3-1 Main RF
GSM F301 F302 F300
O◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
