Image preview - the first page of the document
>> Download Samsung SGH-A100 service manual documenatation <<
Text preview - extract from the document
DUAL BAND Mobile
Cellular Phone
SGH-A100
SERVICE Manual
Dual Band Mobile Cellular Phone CONTENTS
1. Electrical Parts List
2. Exploded Views and Parts List
3. Block Diagram
4. PCB Views
5. Schematic Diagrams
C
3DEF
1 2 ABC
6MNO
4 GHI 5 JKL
9WXYZ
7 PQRS 8 TUV
0
1. Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
0 SGH-A100GA/XEG
1 6001-001148 SCREW-MACHINE BH, *, M2, L5, ZPC(BLK), SM20C, FDP
1 GH68-00641B LABEL(P)-COLOR STICKER(GOLD) SGH-800, ART(100G),
1 GH68-00718A LABEL(P)-SHIP(GERM) SGH-A100, CRP, 250X120, 100G,
1 GH68-30963A LABEL(R)-BAR CODE SP-D300, PR, 34X6.5, T0.1, WHT
1 GH71-00077A NPR-ANT.CONTACT SGH-A100, KSP5202, T0.1, AU
1 GH71-00219A NPR-SHIELD PLATE(C) SGH-A100, C5210TS, -, AU
1 GH72-00515A PMO-LCD WINDOW SGH-A100, TRP ACRYL, GRY, -, -
1 GH73-00158A RMO-R.F COVER SGH-A100, URETHAN, -, D/GRY, -
1 GH73-00159A RMO-BUZZER HOLDER SGH-A100, RUBBER, -, BLK, -
1 GH73-00160A RMO-MIC HOLDER SGH-A100, RUBBER, -, BLK, -
1 GH73-00243A RMO-HINGE RUBBER SCH-A200, RUBBER, 4X6XT1.2,
1 GH73-00270A RMO-CONTACT RUBBER SGH-A100, RUBBER,
1 GH74-00342A MPR-WINDOW TAPE SGH-A100, VINYL, T0.1, TRP, -
1 GH75-00223A MEC-HANGER ROPE SGH-2300, -, GRY
1 GH92-00724A PBA MAIN-SGH-2300 SGH-2300, -, USA, -, -, -, -
1 GH96-00894A ELA ETC-SGHA100 EAR-MIC SGH-A100, -, USA,
1 GH97-01483A MEA FRONT-COVER SGH-A100, -, GERM, GLD, -, -, -
2 6001-000876 SCREW-MACHINE CH, +, M1.7, L2, ZPC(BLK), SWRCH18
2 GH72-00510A PMO-VOLUME KEY SGH-A100, -, D/GRY, -, -
2 GH72-00511A PMO-SHIELD COVER SGH-A100, ABS, -, CR, -
2 GH73-00156A RMO-KEY PAD SGH-A100, RUBBER, -, -, -
2 GH74-00342A MPR-WINDOW TAPE SGH-A100, VINYL, T0.1, TRP, -
2 GH74-00435A MPR-SHIELD TAPE SGH-A100, COPPER TAPE,
2 GH74-00436A MPR-SHIELD SPONGE SGH-A100, -, 13X6.5XT1.2, SIL, -
2 GH74-00529A MPR-SHIELD SPONGE(B) SGH-A100, -, 6.5X6.5X1.2, SIL, -
2 GH74-00637A MPR-SHIELD SPONGE(C) SGH-A100, -, 6X10XT1.5, SIL, -
2 GH74-00639A MPR-SHIELD TAPE SGH-A100, -, 17X3XT0.1, SIL, -
2 GH75-00316A MEC-SUA.FRONT COVER SGH-A100, -, GLD
3 GH72-00505A PMO-FRONT COVER SGH-A100, PC, GLD, -, -
3 GH72-00506A PMO-REFLECTOR LED SGH-A100, ACRYL, -, -, -
3 GH72-00509A PMO-HINGE DUMMY SGH-A100, POM, BLK, -, -
3 GH75-00147A MEC-SUA. HINGE SCH-A100, -, BLK
4 GH70-00020A IPR-SPRING HINGE SCH-A100, STS304,
4 GH72-00290A PMO-HOUSING HINGE SCH-A100, PC, BLK, -, -
SAMSUNG Proprietary-Contents may change without notice
1-1
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
4 GH72-00291A PMO-SHAFT HINGE SCH-A100, POM, BLK, -, -
4 GH72-00292A PMO-CAM HINGE SCH-A100, POM, BLK, -, -
3 GH75-00319A MEC-SUA.FOLDER LOWER SGH-A100, -, GLD
4 GH71-00074A NPR-FOLDER BRACKET(R) SGH-A100, C5210SS-H, T0.5,
4 GH71-00075A NPR-FOLDER BRACKET(L) SGH-A100, C5210SS-H, T0.5,
4 GH72-00508A PMO-FOLDER LOWER SGH-A100, PC, GLD, -, -
4 GH73-00263A RMO-FOLD HOLDER SGH-A100, RUBBER, -, D/GRY, -
4 GH74-00257A MPR-TAPE WINDOW LCD SGH-A100, TESA, T0.2, TRP, -
4 GH74-00258A MPR-TAPE MOTOR SGH-A100, TESA, T0.4, BLK, -
4 GH74-00259A MPR-TAPE MAGNETIC SGH-A100, TESA, T0.2, TRP, -
4 GH74-00260A MPR-MAGNETIC COVER SGH-A100, PC SHEET,
4 GH74-00261A MPR-TAPE LCD SGH-A100, TESA, T0.4, BLK, -
4 GH74-00343A MPR-SPONGE FOLDER SGH-A100, SPONGE, T1.0, BLK, -
2 GH75-00318A MEC-SUA.FOLDER UPPER SGH-A100, -, GLD
3 GH72-00507A PMO-FOLDER UPPER SGH-A100, PC, GLD, -, -
3 3001-001126 SPEAKER -, 150 ohm, 90dB, -
3 GH31-00003A MOTOR-SCH990 SCH-990, 3.0 V, -, 10-55HZ, -, -
1 GH97-01484A MEA REAR-COVER SGH-A100, -, GERM, D/GRY, -, -, -
2 GH71-00076A NPR-ANT.BUSHING SGH-A100, ZN GOLD PLT, -, AU(24K)
2 GH71-00172A NPR-SHIELD PLATE(A) SGH-A100, C5210TS, T0.1, AU
2 GH71-10639A NPR-SHIELD STRIP(A) SCH-1100, C1720S-1/2H, T0.1,
2 GH71-10640A NPR-SHIELD STRIP(B) SCH-1100, C1720S-1/2H, T0.1,
2 GH71-10643A NPR-SHIELD STRIP(D) SCH-1100, C1720S-1/2H, T0.1,
2 GH71-10651A NPR-SHIELD STRIP(E) SCH-550, KS D5202, T0.1,
2 GH74-00638A MPR-SHIELD SPONGE(D) SGH-A100, -, 9X13XT3, SIL, -
2 GH75-00320A MEC-SUA.REAR COVER SGH-A100, -, D/GRY
3 GH68-00640A LABEL(R)-R.F SHEET SGH-A100, PC SHEET, -, T0.2,
3 GH70-00006A IPR-SIM SPRING SGH-2200, STEEL, -, -
3 GH70-00021A IPR-SPRING LOCKER SCH-A100, STS304, T3.3, -
3 GH72-00299A PMO-LOCKER SCH-A100, PC, GRY, -, G5295
3 GH72-00512A PMO-REAR COVER SGH-A100, PC, D/GRY, -, -
3 GH72-00513A PMO-SIM LOCKER SGH-A100, PC, D/GRY, -, -
3 GH72-00514A PMO-IRDA WINDOW SGH-A100, PC, VIO, -, -
3 GH73-00157A RMO-EARPHONE COVER SGH-A100, URETHAN, -,
1 GH99-02189A PAA MAIN-SGH2300 SGH-A100, -, GERM, -, -, -, -
SAMSUNG Proprietary-Contents may change without notice
1-2
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 GG68-10705A LABEL(P)-SEAL SP-R912, CRP, 65.0x95.0, -, ORG
2 GH68-00518A LABEL(P)-SEAL LABEL(VOD) SGH-600, ART PAPER,
2 GH68-00619A LABEL(R)-MAIN SGH-A100, MAT, 46.5X36, T0.05, SIL
2 GH68-11057A LABEL(P)-MS BAR CODE SCH-1900, ART, 100X155, T0.1,
2 GH68-11067A LABEL(P)-BAR CODE SCH-300S, ART, 65X13, 100G, WHT
2 GH69-00421A CUSHION-PULP MOLD CASE SGH-A100, -, 186X126X57.5
2 GH69-00422A CUSHION-PULP MOLD COVER SGH-A100, PULP,
2 GH69-00449A BOX(P)-JEWEL PRESS PS -, SGH-A100, PRESS+PS,
2 GH69-00470A BOX(P)-CARTON MAIN GERM, SGH-A100, SW3,
2 GH69-00472A BOX(P)-UNIT MAIN GERM, SGH-A100, ST240G+E(KOL),
2 GH69-30503A BAG-STD BATT. PE, T0.06, 70X170, SCH-1011
1 GH42-00042A ANT. ANTENNA-SGHA100 SGH-A100, 880-915/925-
2 3002-001062 AU1 BUZZER-MAGNETIC 88dB, 3.6 V, 90mA, 2.731KHz, TP
1 4302-001081 BACKUP BAT. BATTERY-LI(2ND) -, .25MAH, COIN, 0.03MA, -, -
2 4302-001081 BAT1 BATTERY-LI(2ND) -, .25MAH, COIN, 0.03MA, -, -
1 GH43-00155A BATT. BATTERY-915M, GLD, ENG, MAIN 3.6 V, 915mA, -, -, -
1 GH43-00199A BATT. BATTERY-540M, GLD, ENG, MAIN 3.7 V, 540mAH, -,
2 2203-005509 C101 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2404-001105 C102 C-TA, CHIP 10 UF, 20 %, 6.3 V, GP, TP, 2012
2 2203-000359 C103 C-CERAMIC, CHIP 0.15nF, 5 %, 50 V, NP0, TP, 1005
2 2203-001432 C104 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-005509 C105 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-000359 C106 C-CERAMIC, CHIP 0.15nF, 5 %, 50 V, NP0, TP, 1005
2 2203-001432 C107 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-000233 C108 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2404-001100 C111 C-TA, CHIP 33 uF, 20 %, 6.3 V, GP, TP, 3719, -
2 2203-001432 C112 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-000278 C113 C-CERAMIC, CHIP 0.01nF, 0.5pF, 50 V, NP0, TP, 1005
2 2203-005158 C114 C-CERAMIC, CHIP 0.0022nF, 0.25pF, 50 V, NP0, TP, 1005
2 2203-002443 C115 C-CERAMIC, CHIP 0.33nF, 10 %, 50 V, X7R, TP, 1005
2 2203-001432 C116 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-000330 C117 C-CERAMIC, CHIP 0.012nF, 5 %, 50 V, NP0, TP, 1005
2 2203-001432 C119 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-001432 C122 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-001432 C123 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
SAMSUNG Proprietary-Contents may change without notice
1-3
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2203-001432 C126 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-001432 C127 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-000359 C128 C-CERAMIC, CHIP 0.15nF, 5 %, 50 V, NP0, TP, 1005
2 2203-001432 C129 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-005509 C130 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2404-001100 C131 C-TA, CHIP 33 uF, 20 %, 6.3 V, GP, TP, 3719, -
2 2203-001432 C135 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-000278 C136 C-CERAMIC, CHIP 0.01nF, 0.5pF, 50 V, NP0, TP, 1005
2 2203-000278 C137 C-CERAMIC, CHIP 0.01nF, 0.5pF, 50 V, NP0, TP, 1005
2 2203-000359 C201 C-CERAMIC, CHIP 0.15nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005509 C202 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-000359 C203 C-CERAMIC, CHIP 0.15nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005509 C204 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-005509 C205 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-000359 C206 C-CERAMIC, CHIP 0.15nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005509 C207 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-005065 C208 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2203-005509 C209 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-000359 C210 C-CERAMIC, CHIP 0.15nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000679 C212 C-CERAMIC, CHIP 0.027nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000679 C213 C-CERAMIC, CHIP 0.027nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005061 C250 C-CERAMIC, CHIP 100nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-000233 C301 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000233 C302 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005446 C303 C-CERAMIC, CHIP 0.0027nF, 0.1pF, 50 V, NP0, TP, 1005
2 2203-005446 C304 C-CERAMIC, CHIP 0.0027nF, 0.1pF, 50 V, NP0, TP, 1005
2 2203-000233 C306 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000233 C307 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000425 C308 C-CERAMIC, CHIP 0.018nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000628 C309 C-CERAMIC, CHIP 0.022nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000836 C310 C-CERAMIC, CHIP 390pF, 10 %, 50 V, X7R, TP, 1005, -
2 2203-000812 C311 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000940 C312 C-CERAMIC, CHIP 470pF, 10 %, 50 V, X7R, TP, 1005, -
2 2203-000812 C313 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C314 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
SAMSUNG Proprietary-Contents may change without notice
1-4
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2301-001230 C315 C-FILM, CHIP 10nF, 5 %, 16 V, TP, 2012, -
2 2203-000386 C316 C-CERAMIC, CHIP 0.015nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000254 C317 C-CERAMIC, CHIP 10nF, 10 %, 16 V, X7R, TP, 1005, -
2 2203-000438 C318 C-CERAMIC, CHIP 1nF, 10 %, 50 V, X7R, TP, 1005, -
2 2404-001105 C319 C-TA, CHIP 10 UF, 20 %, 6.3 V, GP, TP, 2012
2 2203-000812 C321 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000254 C324 C-CERAMIC, CHIP 10nF, 10 %, 16 V, X7R, TP, 1005, -
2 2203-001239 C325 C-CERAMIC, CHIP 0.082nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000233 C326 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000254 C327 C-CERAMIC, CHIP 10nF, 10 %, 16 V, X7R, TP, 1005, -
2 2203-000254 C328 C-CERAMIC, CHIP 10nF, 10 %, 16 V, X7R, TP, 1005, -
2 2203-000233 C329 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000311 C330 C-CERAMIC, CHIP 0.12nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000311 C331 C-CERAMIC, CHIP 0.12nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005158 C332 C-CERAMIC, CHIP 0.0022nF, 0.25pF, 50 V, NP0, TP, 1005
2 2203-000812 C333 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2404-001088 C334 C-TA, CHIP 2.2 uF, 20 %, 6.3 V, GP, TP, 2012, -
2 2203-005158 C337 C-CERAMIC, CHIP 0.0022nF, 0.25pF, 50 V, NP0, TP, 1005
2 2404-001099 C338 C-TA, CHIP 68 uF, 20 %, 6.3 V, GP, TP, 4035, -
2 2404-001088 C339 C-TA, CHIP 2.2 uF, 20 %, 6.3 V, GP, TP, 2012, -
2 2203-000836 C342 C-CERAMIC, CHIP 390pF, 10 %, 50 V, X7R, TP, 1005, -
2 2203-000940 C343 C-CERAMIC, CHIP 470pF, 10 %, 50 V, X7R, TP, 1005, -
2 2203-001017 C344 C-CERAMIC, CHIP 0.004nF, 0.25pF, 50 V, NP0, TP, 1005
2 2301-001230 C346 C-FILM, CHIP 10nF, 5 %, 16 V, TP, 2012, -
2 2203-001017 C347 C-CERAMIC, CHIP 0.004nF, 0.25pF, 50 V, NP0, TP, 1005
2 2203-000425 C348 C-CERAMIC, CHIP 0.018nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000438 C349 C-CERAMIC, CHIP 1nF, 10 %, 50 V, X7R, TP, 1005, -
2 2203-000330 C350 C-CERAMIC, CHIP 0.012nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C351 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005061 C352 C-CERAMIC, CHIP 100nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-002443 C354 C-CERAMIC, CHIP 0.33nF, 10 %, 50 V, X7R, TP, 1005
2 2203-000254 C401 C-CERAMIC, CHIP 10nF, 10 %, 16 V, X7R, TP, 1005, -
2 2203-000233 C402 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000359 C403 C-CERAMIC, CHIP 0.15nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005065 C404 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
SAMSUNG Proprietary-Contents may change without notice
1-5
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2203-000359 C405 C-CERAMIC, CHIP 0.15nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005065 C406 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2404-001100 C407 C-TA, CHIP 33 uF, 20 %, 6.3 V, GP, TP, 3719, -
2 2203-005509 C408 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-005065 C409 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2203-005562 C410 C-CERAMIC, CHIP 10000nF, +80-20 %, 10 V, Y5 V, TP,
2 2203-005509 C411 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-005509 C412 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-005065 C413 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2404-001100 C414 C-TA, CHIP 33 uF, 20 %, 6.3 V, GP, TP, 3719, -
2 2203-000628 C420 C-CERAMIC, CHIP 0.022nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005065 C421 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2404-001083 C422 C-TA, CHIP 220 uF, 20 %, 6.3 V, LZ, TP, 7132
2 2203-000995 C423 C-CERAMIC, CHIP 0.047nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C424 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C425 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2404-001099 C427 C-TA, CHIP 68 uF, 20 %, 6.3 V, GP, TP, 4035, -
2 2203-000812 C501 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C502 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-001432 C505 C-CERAMIC, CHIP 47nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-000628 C506 C-CERAMIC, CHIP 0.022nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000233 C510 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2404-001088 C511 C-TA, CHIP 2.2 uF, 20 %, 6.3 V, GP, TP, 2012, -
2 2203-000628 C512 C-CERAMIC, CHIP 0.022nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000995 C515 C-CERAMIC, CHIP 0.047nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000278 C516 C-CERAMIC, CHIP 0.01nF, 0.5pF, 50 V, NP0, TP, 1005
2 2203-000628 C519 C-CERAMIC, CHIP 0.022nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005395 C520 C-CERAMIC, CHIP 0.0047nF, 0.1pF, 50 V, NP0, TP, 1005
2 2203-001385 C523 C-CERAMIC, CHIP 0.0015nF, 0.25pF, 50 V, NP0, TP, 1005
2 2703-001798 C524 INDUCTOR-SMD 2.2 NH, 0.3 NH, 1.0X0.5X0.5MM
2 2203-000696 C525 C-CERAMIC, CHIP 0.002nF, 0.25pF, 50 V, NP0, TP, 1005
2 2203-000628 C526 C-CERAMIC, CHIP 0.022nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000438 C527 C-CERAMIC, CHIP 1nF, 10 %, 50 V, X7R, TP, 1005, -
2 2203-000628 C528 C-CERAMIC, CHIP 0.022nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000489 C529 C-CERAMIC, CHIP 2.2nF, 10 %, 50 V, X7R, TP, 1005, -
SAMSUNG Proprietary-Contents may change without notice
1-6
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2203-005509 C531 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-005509 C532 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-000138 C533 C-CERAMIC, CHIP 1.5nF, 10 %, 50 V, X7R, TP, 1005, -
2 2203-005509 C534 C-CERAMIC, CHIP 330nF, +80-20 %, 10 V, Y5 V, TP, 1005
2 2203-001153 C535 C-CERAMIC, CHIP 0.068nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000995 C536 C-CERAMIC, CHIP 0.047nF, 5 %, 50 V, NP0, TP, 1005
2 2203-001153 C537 C-CERAMIC, CHIP 0.068nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C539 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000254 C541 C-CERAMIC, CHIP 10nF, 10 %, 16 V, X7R, TP, 1005, -
2 2203-000254 C542 C-CERAMIC, CHIP 10nF, 10 %, 16 V, X7R, TP, 1005, -
2 2203-000812 C543 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000233 C544 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C545 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000438 C546 C-CERAMIC, CHIP 1nF, 10 %, 50 V, X7R, TP, 1005, -
2 2203-000812 C547 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000278 C548 C-CERAMIC, CHIP 0.01nF, 0.5pF, 50 V, NP0, TP, 1005
2 2203-000995 C549 C-CERAMIC, CHIP 0.047nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000254 C550 C-CERAMIC, CHIP 10nF, 10 %, 16 V, X7R, TP, 1005, -
2 2203-000725 C551 C-CERAMIC, CHIP 3.9nF, 10 %, 50 V, X7R, TP, 1005, -
2 2203-000696 C552 C-CERAMIC, CHIP 0.002nF, 0.25pF, 50 V, NP0, TP, 1005
2 2404-001100 C553 C-TA, CHIP 33 uF, 20 %, 6.3 V, GP, TP, 3719, -
2 2203-002759 C554 C-CERAMIC, CHIP 15nF, +80-20 %, 50 V, Y5 V, TP, 1005, -
2 2203-000628 C555 C-CERAMIC, CHIP 0.022nF, 5 %, 50 V, NP0, TP, 1005
2 2203-001405 C557 C-CERAMIC, CHIP 22nF, +80-20 %, 25 V, Y5 V, TP, 1005
2 2203-000466 C558 C-CERAMIC, CHIP 0.001nF, 0.25pF, 50 V, NP0, TP, 1005
2 2404-001100 C559 C-TA, CHIP 33 uF, 20 %, 6.3 V, GP, TP, 3719, -
2 2203-000233 C560 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000233 C561 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000233 C562 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000233 C563 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C564 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000233 C565 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000233 C569 C-CERAMIC, CHIP 0.1nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000466 C570 C-CERAMIC, CHIP 0.001nF, 0.25pF, 50 V, NP0, TP, 1005
2 2203-000466 C571 C-CERAMIC, CHIP 0.001nF, 0.25pF, 50 V, NP0, TP, 1005
SAMSUNG Proprietary-Contents may change without notice
1-7
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2203-001383 C572 C-CERAMIC, CHIP 0.0005nF, 0.25pF, 50 V, NP0, TP, 1005
2 2203-005065 C573 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2203-000254 C600 C-CERAMIC, CHIP 10nF, 10 %, 16 V, X7R, TP, 1005, -
2 2404-001100 C604 C-TA, CHIP 33 uF, 20 %, 6.3 V, GP, TP, 3719, -
2 2203-005065 C606 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2203-005065 C607 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2203-000812 C608 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005065 C610 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2203-005061 C611 C-CERAMIC, CHIP 100nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-005061 C612 C-CERAMIC, CHIP 100nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-005065 C613 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2203-005061 C615 C-CERAMIC, CHIP 100nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-005061 C616 C-CERAMIC, CHIP 100nF, +80-20 %, 16 V, Y5 V, TP, 1005
2 2203-005065 C617 C-CERAMIC, CHIP 1000nF, +80-20 %, 10 V, Y5 V, TP, 1608
2 2203-005583 C618 C-CERAMIC, CHIP 10000nF, +80-20 %, 16 V, Y5 V, TP,
2 2404-001100 C619 C-TA, CHIP 33 uF, 20 %, 6.3 V, GP, TP, 3719, -
2 2404-001020 C620 C-TA, CHIP 10 uF, 20 %, 10 V, GP, TP, 3216, 3.2
2 2203-005682 C624 C-CERAMIC, CHIP 0.033nF, 5 %, 25 V, NP0, TP, 0603
2 2203-005683 C625 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005682 C626 C-CERAMIC, CHIP 0.033nF, 5 %, 25 V, NP0, TP, 0603
2 2203-005683 C628 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005683 C629 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005683 C630 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005682 C631 C-CERAMIC, CHIP 0.033nF, 5 %, 25 V, NP0, TP, 0603
2 2203-005683 C632 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005683 C633 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005683 C634 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005683 C635 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005683 C636 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005683 C637 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005683 C638 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005683 C639 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-005682 C640 C-CERAMIC, CHIP 0.033nF, 5 %, 25 V, NP0, TP, 0603
2 2203-005683 C643 C-CERAMIC, CHIP 0.008nF, 0.5pF, 25 V, NP0, TP, 0603
2 2203-000812 C644 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
SAMSUNG Proprietary-Contents may change without notice
1-8
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2203-000812 C645 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C646 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C647 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-005682 C650 C-CERAMIC, CHIP 0.033nF, 5 %, 25 V, NP0, TP, 0603
2 2203-005367 C652 C-CERAMIC, CHIP 6800nF, +80-20 %, 25 V, Y5 V, TP, 3225
2 2203-000254 C655 C-CERAMIC, CHIP 10nF, 10 %, 16 V, X7R, TP, 1005, -
2 2203-000812 C657 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 2203-000812 C658 C-CERAMIC, CHIP 0.033nF, 5 %, 50 V, NP0, TP, 1005
2 3709-001137 CN401 CONNECTOR-CARD EDGE 6P, 2.54MM, SMD-S, AU15U
2 3705-001163 CN501 CONNECTOR-COAXIAL SMC, JACK, 100 Mohm, 50 ohm,
2 3710-001547 CN601 CONNECTOR-SOCKET 14P, 1R, 1MM, SMD-A, AU15U
2 3711-004419 CN602 CONNECTOR-HEADER BOX, 30P, 2R, 0.5mm, SMD-S,
2 3708-001396 CN603 CONNECTOR-FPC/FC/PIC 22P, 0.5MM, SMD-A, SN
2 3722-001172 CN604 JACK-AC POWER 2P, 2.6PI, AU, BLK, NO
2 0401-001033 D201 DIODE-SWITCHING MCL4154, 25 V, 200mA, M-MELF, TP
2 0405-001057 D301 DIODE-VARACTOR SMV1234-004, 15 V, 50NA, SOT-23, TP
2 0407-001002 D501 DIODE-ARRAY DAN222, 80 V, 300mA, CA2-3, EM3, TP
2 0407-000115 D602 DIODE-ARRAY DAN202U, 80 V, 100mA, CA2-3, SC-70,
2 0407-001006 D603 DIODE-ARRAY DA221, 20 V, 100mA, C2-3, EM3, TR
2 2904-001165 F301 FILTER-SAW 400MHZ, .28MHZ, +-70KHZ, TP, 6.5DB, -
2 2903-001211 F302 FILTER-CERAMIC BP, 14.6MHz, 300KHz, 6dB, 1dB, TP, -
2 2904-001124 F501 FILTER-SAW 947.5MHz, 25MHz, +-12.5MHz/1.4dB, TP,
2 2904-001096 F502 FILTER-SAW 1.8425GHz, 75MHz, +-37.5MHz/2.5dB, TP,
2 GH59-00018A KEY MODULE UNIT-SGH2300 KEA PAD SGH-2300, HUW9512-010010, -,
2 2703-000310 L101 INDUCTOR-SMD 1.8 uH, 10 %, 0.8x1.6x0.8mm
2 2703-001543 L303 INDUCTOR-SMD 33 nH, 5 %, 1.8x1.12x1.02mm
2 2703-001543 L304 INDUCTOR-SMD 33 nH, 5 %, 1.8x1.12x1.02mm
2 2703-001545 L307 INDUCTOR-SMD 47 nH, 5 %, 1.8x1.12x1.02mm
2 2703-001600 L308 INDUCTOR-SMD 6.8 nH, 10 %, 1.6x0.8x0.8mm
2 2703-001600 L309 INDUCTOR-SMD 6.8 nH, 10 %, 1.6x0.8x0.8mm
2 2703-001600 L310 INDUCTOR-SMD 6.8 nH, 10 %, 1.6x0.8x0.8mm
2 2703-001600 L311 INDUCTOR-SMD 6.8 nH, 10 %, 1.6x0.8x0.8mm
2 2703-001232 L313 INDUCTOR-SMD 1.5 uH, 10 %, 1.6x0.8x0.8mm
2 2703-001547 L314 INDUCTOR-SMD 10 nH, 5 %, 1.8x1.12x1.02mm
2 2703-001547 L315 INDUCTOR-SMD 10 nH, 5 %, 1.8x1.12x1.02mm
SAMSUNG Proprietary-Contents may change without notice
1-9
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2703-001297 L316 INDUCTOR-SMD 10 nH, 10 %, 1.6x0.8x0.8mm
2 2703-001854 L401 INDUCTOR-SMD 22 uH, 20 %, 4.8X4.8X1.8MM
2 2703-001595 L402 INDUCTOR-SMD 47 nH, 5 %, 1.0x0.5x0.5mm
2 3301-001208 L403 CORE-FERRITE BEAD AB, 1.6x0.8x0.8mm, -, -
2 2703-001297 L502 INDUCTOR-SMD 10 nH, 10 %, 1.6x0.8x0.8mm
2 2703-001172 L503 INDUCTOR-SMD 100 nH, 5 %, 1.6x0.8x0.8mm
2 2703-001172 L504 INDUCTOR-SMD 100 nH, 5 %, 1.6x0.8x0.8mm
2 2703-001708 L505 INDUCTOR-SMD 5.6 nH, 10 %, 1.0x0.5x0.5mm
2 2703-001207 L506 INDUCTOR-SMD 6.8 nH, 5 %, 1.6x0.8X0.8mm
2 2703-001206 L509 INDUCTOR-SMD 4.7 nH, 0.3 nH, 1.6x0.8X0.8mm
2 2703-001513 L510 INDUCTOR-SMD 100 nH, 5 %, 1.8x1.12x1.02mm
2 2703-001513 L511 INDUCTOR-SMD 100 nH, 5 %, 1.8x1.12x1.02mm
2 2703-001798 L512 INDUCTOR-SMD 2.2 nH, 0.3 NH, 1.0X0.5X0.5MM
2 2703-001853 L601 INDUCTOR-SMD 10 uH, 20 %, 6X6X1.8MM
2 2007-001292 L605 R-CHIP 33 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2703-000175 L606 INDUCTOR-SMD 270 nH, 10 %, 0.8x1.6x0.8mm
2 3301-001208 L607 CORE-FERRITE BEAD AB, 1.6x0.8x0.8mm, -, -
2 3301-001208 L608 CORE-FERRITE BEAD AB, 1.6x0.8x0.8mm, -, -
2 GH96-00808A LCD ASS'Y ELA ETC-SGH2300 LCD SGH-2300, -, -, LCD MODULE, -,
2 0604-001146 LED2 PHOTO-IRDA -, 875NM, 500M W, 30DEG, TP
1 3003-001041 MIC MIC-CONDENSOR 2 V, 0.5mA, -40dB+-3dB, 2.2Kohm
2 2801-003695 OSC101 CRYSTAL-SMD 19.5MHz, 10ppm, 28-ABK, 10.2pF, 20
2 2801-003747 OSC201 CRYSTAL-SMD .032768MHZ, 30PPM, 28-ACM, 9PF,
2 2806-001191 OSC301 OSCILLATOR-VCO 1258-1360MHZ, -, 50 ohm, TP, 2.7 V,
2 GH41-00047A PCB PCB-SGHA100 SGH-A100, FR-4, -, 0.8T, 90.3X117.8
2 0505-001237 Q401 FET-SILICON MGSF3442 V, N, 20 V, 4A, 0.07 ohm, 2 W,
2 0501-002202 Q406 TR-SMALL SIGNAL MMBT2222AWT1, NPN, 150m W,
2 0504-001012 Q501 TR-DIGITAL DTC114YE, NPN, 150M W, 10K/47K, EMT3, TP
2 0504-001012 Q502 TR-DIGITAL DTC114YE, NPN, 150M W, 10K/47K, EMT3, TP
2 0504-001012 Q503 TR-DIGITAL DTC114YE, NPN, 150M W, 10K/47K, EMT3, TP
2 0504-000168 Q605 TR-DIGITAL RN1104, NPN, 100M W, 47K/47K, SSM, TP
2 0504-000168 Q606 TR-DIGITAL RN1104, NPN, 100M W, 47K/47K, SSM, TP
2 0504-000168 Q607 TR-DIGITAL RN1104, NPN, 100M W, 47K/47K, SSM, TP
2 0501-002202 Q608 TR-SMALL SIGNAL MMBT2222AWT1, NPN, 150m W,
2 0504-000168 Q609 TR-DIGITAL RN1104, NPN, 100M W, 47K/47K, SSM, TP
SAMSUNG Proprietary-Contents may change without notice
1-10
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2007-000172 R101 R-CHIP 10 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R102 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007197 R103 R-CHIP 3.3 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007197 R104 R-CHIP 3.3 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R105 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007468 R106 R-CHIP 121 kohm, 1 %, 1/16 W, DA, TP, 1005
2 2007-007092 R107 R-CHIP 1.1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R108 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007771 R110 R-CHIP 0 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007092 R112 R-CHIP 1.1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007197 R114 R-CHIP 3.3 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007197 R115 R-CHIP 3.3 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000775 R116 R-CHIP 33 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000173 R117 R-CHIP 22 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R201 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000148 R202 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000148 R204 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000148 R205 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000148 R206 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000148 R207 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000170 R212 R-CHIP 1 Mohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007771 R213 R-CHIP 0 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000138 R214 R-CHIP 100 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001298 R301 R-CHIP 51 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007001 R302 R-CHIP 3.9 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000172 R303 R-CHIP 10 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000143 R304 R-CHIP 4.7 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001298 R305 R-CHIP 51 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001323 R306 R-CHIP 3 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001323 R307 R-CHIP 3 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000172 R308 R-CHIP 10 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R309 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000173 R310 R-CHIP 22 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000172 R312 R-CHIP 10 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000146 R313 R-CHIP 6.8 kohm, 5 %, 1/16 W, DA, TP, 1005
SAMSUNG Proprietary-Contents may change without notice
1-11
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2007-000143 R314 R-CHIP 4.7 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000172 R321 R-CHIP 10 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000138 R322 R-CHIP 100 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000138 R323 R-CHIP 100 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000173 R325 R-CHIP 22 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000172 R326 R-CHIP 10 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001298 R327 R-CHIP 51 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001298 R328 R-CHIP 51 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007001 R329 R-CHIP 3.9 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000162 R401 R-CHIP 100 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000143 R402 R-CHIP 4.7 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007771 R403 R-CHIP 0 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007833 R406 R-CHIP 0.68 ohm, 2 %, 1/10 W, DA, TP, 2012
2 2007-000148 R409 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000141 R417 R-CHIP 2.2 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000138 R418 R-CHIP 100 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007771 R419 R-CHIP 0 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007771 R420 R-CHIP 0 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000172 R501 R-CHIP 10 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000148 R503 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000148 R504 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000137 R505 R-CHIP 2 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000137 R507 R-CHIP 2 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R509 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000148 R510 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007470 R512 R-CHIP 7.5 kohm, 1 %, 1/16 W, DA, TP, 1005
2 2007-007312 R513 R-CHIP 20 kohm, 1 %, 1/16 W, DA, TP, 1005
2 2007-000148 R514 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000144 R516 R-CHIP 5.1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007771 R517 R-CHIP 0 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000170 R518 R-CHIP 1 Mohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001298 R519 R-CHIP 51 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000144 R520 R-CHIP 5.1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001305 R521 R-CHIP 120 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001305 R522 R-CHIP 120 ohm, 5 %, 1/16 W, DA, TP, 1005
SAMSUNG Proprietary-Contents may change without notice
1-12
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2007-000140 R523 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000139 R524 R-CHIP 220 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007095 R525 R-CHIP 390 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-003001 R526 R-CHIP 12 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-002965 R527 R-CHIP 15 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001306 R528 R-CHIP 150 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001308 R529 R-CHIP 200 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007193 R530 R-CHIP 5.1 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000151 R531 R-CHIP 15 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R532 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001298 R533 R-CHIP 51 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000157 R534 R-CHIP 47 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000148 R535 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000142 R601 R-CHIP 2.7 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000148 R603 R-CHIP 10 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000162 R609 R-CHIP 100 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000168 R611 R-CHIP 470 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000153 R613 R-CHIP 22 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001119 R614 R-CHIP 680 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000162 R631 R-CHIP 100 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001306 R633 R-CHIP 150 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R634 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007875 R637 R-CHIP 160 kohm, 1 %, 1/16 W, DA, TP, 1005
2 2007-000162 R638 R-CHIP 100 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007592 R639 R-CHIP 270 kohm, 1 %, 1/16 W, DA, TP, 1005
2 2007-000162 R640 R-CHIP 100 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000162 R641 R-CHIP 100 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000165 R642 R-CHIP 200 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000775 R643 R-CHIP 33 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-007309 R644 R-CHIP 12 kohm, 1 %, 1/16 W, DA, TP, 1005
2 2007-000636 R645 R-CHIP 270 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001333 R646 R-CHIP 18 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000149 R647 R-CHIP 12 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R648 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000142 R649 R-CHIP 2.7 kohm, 5 %, 1/16 W, DA, TP, 1005
SAMSUNG Proprietary-Contents may change without notice
1-13
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 2007-007008 R650 R-CHIP 300 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R651 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R652 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-002797 R653 R-CHIP 560 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000140 R654 R-CHIP 1 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000162 R655 R-CHIP 100 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-001307 R656 R-CHIP 180 ohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000758 R680 R-CHIP 330 kohm, 5 %, 1/16 W, DA, TP, 1005
2 2007-000758 R681 R-CHIP 330 kohm, 5 %, 1/16 W, DA, TP, 1005
1 GH44-00103A TA ADAPTOR-SGHA100 TA SGH-A100, AC/DC, -, 85~265VAC
2 1205-001708 U101 IC-CODEC 20420, BGA, 100P, -, PLASTIC, 2.7 V, -,
2 0902-001231 U201 IC-MICROPROCESSOR 46, 16BIT, BGA, 180P, -,
2 1203-001917 U202 IC-VOLTAGE REGULATOR 5213, SOT-23, 5P, 50MIL,
2 1205-001647 U301 IC-TRANSCEIVER RF137, TQFP, 48P, 275MIL, PALSTIC,
2 1203-001703 U401 IC-VOLTAGE REGULATOR 20436, TQFP, 48P, 275MIL,
2 2909-001084 U501 FILTER-DUPLEXER 942.5MHZ, 897.5MHZ, 1/1.2DB, TP, -, -
2 1201-001420 U502 IC-IF/RF AMP RF210, TSSOP, 20P, 255MIL, -, -, PLASTIC,
2 4709-001144 U503 COUPLER-DIRECTION 897.5/1747.5MHZ, 19DB/14DB,
2 0504-001042 U504 TR-DIGITAL BCR10PN, NPN/PNP, 250m W, 10K/10K,
2 0504-001042 U505 TR-DIGITAL BCR10PN, NPN/PNP, 250m W, 10K/10K,
2 0504-001042 U506 TR-DIGITAL BCR10PN, NPN/PNP, 250m W, 10K/10K,
2 1109-001135 U507 IC-ETC. MEMORY 1342, 128KX16BIT, CSP, 72P, -, 100NS,
2 0801-002015 U508 IC-CMOS LOGIC 4S81, AND GATE, SOP, 5P, 63MIL, SIN
2 1209-001219 U509 IC-SENSOR LM60C, SOT-23, 3P, 115MIL, PLASTIC
2 1201-001421 U510 IC-IF/RF AMP RF142, TSSOP, 20P, 255MIL, -, 15DB,
2 1201-001422 U511 IC-POWER AMP RM008, MCM, 16P, 457MIL, -, -, PALSTIC,
2 0801-002015 U512 IC-CMOS LOGIC 4S81, AND GATE, SOP, 5P, 63MIL, SIN
2 1103-001090 U513 IC-EEPROM 24C128, 16Kx8BIT, SOP, 8P, 150MIL,
2 0801-002399 U514 IC-CMOS LOGIC TC7S86FU, EX-OR GATE, SSOP, 5P, 11
2 2806-001192 U515 OSCILLATOR-VCO 902.5/1747.5MHZ, -, -, TP, 2.7 V, 50MA
2 0504-001042 U516 TR-DIGITAL BCR10PN, NPN/PNP, 250m W, 10K/10K,
2 1201-001462 U602 IC-AUDIO AMP 4864, MSOP, 8P, 118MIL, -, -, PLASTIC, 6 V,
2 0504-001071 U604 TR-DIGITAL UMD9N, NPN/PNP, 150m W, 4.7, UMT6, TP
2 1203-001515 U605 IC-BATTERY 1510, SSOP, 16P, 150MIL, PLASTIC, 3
2 0801-002399 U606 IC-CMOS LOGIC TC7S86FU, EX-OR GATE, SSOP, 5P, 11
SAMSUNG Proprietary-Contents may change without notice
1-14
Electrical Parts List
Level SEC CODE Design LOC DESCRIPTIONS Remark
2 0506-001052 U607 TR-ARRAY UMH9N, NPN, 2, 150M W, SC-88, TP, 68-
2 0506-001052 U608 TR-ARRAY UMH9N, NPN, 2, 150M W, SC-88, TP, 68-
2 0506-001052 U609 TR-ARRAY UMH9N, NPN, 2, 150M W, SC-88, TP, 68-
2 0407-001002 U616 DIODE-ARRAY DAN222, 80 V, 300mA, CA2-3, EM3, TP
2 1405-001082 V401 VARISTOR 5.6 V, 20A, 1x0.5x0.6mm, TP
2 1405-001082 V601 VARISTOR 5.6 V, 20A, 1x0.5x0.6mm, TP
2 1405-001082 V602 VARISTOR 5.6 V, 20A, 1x0.5x0.6mm, TP
2 1405-001082 V603 VARISTOR 5.6 V, 20A, 1x0.5x0.6mm, TP
2 1405-001082 V604 VARISTOR 5.6 V, 20A, 1x0.5x0.6mm, TP
2 1405-001082 V75 VARISTOR 5.6 V, 20A, 1x0.5x0.6mm, TP
2 1405-001082 V76 VARISTOR 5.6 V, 20A, 1x0.5x0.6mm, TP
2 1405-001082 V77 VARISTOR 5.6 V, 20A, 1x0.5x0.6mm, TP
2 1405-001082 V78 VARISTOR 5.6 V, 20A, 1x0.5x0.6mm, TP
2 1405-001082 V79 VARISTOR 5.6 V, 20A, 1x0.5x0.6mm, TP
2 0404-001044 ZD402 DIODE-SCHOTTKY UPS5817, 20 V, 1A, SMD, TP
2 0404-001044 ZD406 DIODE-SCHOTTKY UPS5817, 20 V, 1A, SMD, TP
2 0404-000108 ZD407 DIODE-SCHOTTKY RB705D, 20 V, 30mA, SOT-23, TP
2 0404-000108 ZD408 DIODE-SCHOTTKY RB705D, 20 V, 30mA, SOT-23, TP
2 0406-001051 ZD605 DIODE-TVS SMS05C, 6 V, 300 W, SOT-23-6
2 0406-001051 ZD606 DIODE-TVS SMS05C, 6 V, 300 W, SOT-23-6
2 0404-001044 ZD608 DIODE-SCHOTTKY UPS5817, 20 V, 1A, SMD, TP
2 0404-001044 ZD609 DIODE-SCHOTTKY UPS5817, 20 V, 1A, SMD, TP
SAMSUNG Proprietary-Contents may change without notice
1-15
2. Exploded View and its Parts List
2-1 Cellular phone Exploded View
SAMSUNG Proprietary-Contents may change without notice
2-1
Exploded view and its Part List
2-2 Cellular phone Parts List
SEC.CODE
No Description Remark
Silver Gold Black
1 SCREW-MACHINE 6001-000876 6001-000876 6001-000876
2 FOLDER-UPPER GH72-00507B GH72-00507A GH72-00507C
3 DISPLAY-LCD GH96-00808A GH96-00808A GH96-00808A
4 MOTOR GH31-00003A GH31-00003A GH31-00003A
5 SPEAKER 3001-001126 3001-001126 3001-001126
6 WINDOW-LCD GH72-00515A GH72-00515A GH72-00515B
7 FOLDER LOWER GH72-00508B GH72-00508A GH72-00508C
8 FRONT CASE GH72-00505B GH72-00505A GH72-00505C
9 VOLUME KEY GH72-00510B GH72-00510A GH72-00510C
10 KEY PAD-RUBBER GH73-00156A GH73-00156A GH73-00156A
11 KEY PAD BORD GH59-00018A GH59-00018A GH59-00018A
12 SHIELD-COVER GH72-00511A GH72-00511A GH72-00511A
13 MAIN-BORD GH92-00724A GH92-00724A GH92-00724A
14 ANTENNA BUSHING GH71-00076A GH71-00076A GH71-00076A
15 ANTENNA GH42-00042B GH42-00042A GH42-00042C
16 REAR-COVER GH75-00320B GH75-00320A GH75-00320C
16-1 EAR-JACK GH73-00157A GH73-00157A GH73-00157B
17 SCREW-MACHINE 6001-001148 6001-001148 6001-001148
18 BATTERY GH43-00200A GH43-00199A GH43-00218A Slim
GH43-00156A GH43-00155A GH43-00217A Standard
SAMSUNG Proprietary-Contents may change without notice
2-2
Exploded view and its Part List
2-3 Test Jig (GH80-00161A)
SWITCH
MODE AUTO SDS DOWNLOAD DEBUG SDS DEBUG
S/W S/W S/W D/L
D/L HIGH LOW HIGH LOW CONNECT N.C
CAL HIGH LOW LOW HIGH CONNECT N.C
SAMSUNG Proprietary-Contents may change without notice
2-3
Exploded view and its Part List
2-4 RF Cable (GH39-00002A) 2-5 Test Cable (GH39-00042A)
2-6 Cigarette Lighter Adaptor 2-7 Travel Adaptor (GH44-00103A)
(GH44-00112A)
SAMSUNG Proprietary-Contents may change without notice
2-4
Exploded view and its Part List
2-8 Test Connection Method
Battery should be over 3.8 V
HP8960 SERIES
SGH-A100
POWER SUPPLY
CAL, Download
SDS D/L :
3.8V
JIG
SAMSUNG Proprietary-Contents may change without notice
2-5
3. Block Diagrams
V /V
CCD BAT VCCA1/ V / V c
CCD Os
VSYN VRF
Spk r+ M4 6 20420 T FS4 00 B 7
Spk r-
RF13 7 (SA W RF21 0
Led_ct l Rxmxo 4 00 M Hz)
LCD Vbat
ERA I
C MC
RX O
M R i f i n+
f Hi ghband ( M
Rx_E
46)
n1 ( 20420)
Lcd_Se IFN
I + UT
O 2 IN2 FI RST
CS LCD EL
3/ _S FI LTER I F 2+
I 385. 4M z
H Rx_G n0 ( 20420)
ai
M r _En M TO N
i R i f i n-
f M XER
I
CON . O R_E
Cl k_Rqs t CLK_RQST R F_P
X_I
R _I f +
x
R _I f -
x ( 14. 6M z ) I
H
I F 2-
F
I
20+
i
m xer &
Amp
I FI N- UT
O 1 IN1
& -
SAW FI L TER
Res et _B Res et _B RE T_B
SE R F_M
X_I I F20-
- KS0 723( ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
