Image preview - the first page of the document
>> Download Samsung SGH-A288 service manual documenatation <<
Text preview - extract from the document
DUAL BAND Mobile
ELECTRONICS
Cellular Phone
SGH-A288
SERVICE Manual
DUAL BAND MOBILE CELLULAR PHONE CONTENTS
1. Exploded Views and Parts List
2. PCB Diagrams
3. Electrical Parts List
4. Block Diagrams
5. Flow chart of trouble shooting
F
C DE
C
AB MN
O
L
JK YZ
WX
I
GH V
TU
S
PQR
ELECTRONICS
Samsung Electronics Co.,Ltd.
Printed in Korea
03/2001 Rev 1.0
GH68-01895A
1. Exploded Views and Parts List
1-1 Main
1-2 Main Parts List
1-3 Travel Adapter
1-4 Travel Adapter Parts List
1-5 Ciger Light Adapter
1-6 Ciger Light Adapter Parts List
1-7 Test Jig
1-8 Wearable EAR Microphone
1-9 Data Kit
1-10 Battery Charger
2. PCB Diagrams
2-1 Main Top
2-2 Main Bottom
3. Electrical Parts List
3-1 Main Parts List Top
3-2 Main Parts List Bottom
4. Block Diagrams
4-1 Main Base Band
4-2 Main RF
4-2-1 RF Tx Part
4-2-2 RF Rx Part
5. Flow chart of trouble shooting
5-1 Power ON
5-2 Initial
5-3 Charging Part
5-4 Sim Part
5-5 Microphone Part
5-6 Speaker Part
5-7 Key Data Input
5-8 Alert tone
5-9 Ring Indicator
5-10 Back Light
5-11 GSM Receiver
5-12 GSM Transmit
5-13 DCS Receiver
5-14 DCS Transmit
1. Exploded Views and Parts List
1-1 Main
7 8
3-1
3-3
3
1-2 3-4 3-2
3-5
1
1-1
3-6 11 36
10
1-3
15
21 20
19 9
17
22
16 5-2
5-1
22 6
18 5
2-3
24 28
2-9
2-7 2-5 29
2-8 2-1 27
2-11 4-3
30 4-6
2-10
2
2-2 4-2 33
2-4 4-7
4-4 4 37
2-6
12 4-8
4-5 4-1 4-9
13 14
26 23
25 32 31
34
35
Exploded Views and Parts List 1-1
1-2 Main Parts List
NO SEC CODE DESCRIPTION COLOR SVC Q`TY REMARKS
1 GH75-00925A MEC-FOLDER UPPER WHITE SA 1
1-1 GH72-02098A PMO-FOLDER UPPER SNA 1
1-2 GH74-00307A MPR-TAPE WATCH WINDOW SNA 1
1-3 GH74-01114A MPR-SPONGE WATCH LCD SNA 1
2 GH75-00926A MEC-FOLDER LOWER WHITE SA 1
2-1 GH70-00039A ICT-MAGNETIC SNA 1
2-2 GH72-02099A PMO-FOLDER LOWER SNA 1
2-3 GH74-00309A MPR-SPONGE MAIN LCD SNA 1
2-4 GH74-00310A MPR-TAPE MAIN LCD SNA 1
2-5 GH74-00311A MPR-TAPE VIBRATOR SNA 1
2-6 GH74-00312A MPR-TAPE SPEAKER COVER SNA 1
2-7 GH74-00580A MPR-EMI MESH SPEAKER SNA 1
2-8 GH74-00721A MPR-SPONGE COIL SNA 1
2-9 GH74-01240A MPR-SPONGE SPEAKER SNA 1
2-10 GH74-01241A MPR-TAPE BUZZER SNA 1
2-11 GH75-00928A MEC-HINGE SA 1
3 GH75-00924A MEC-FRONT COVER WHITE SA 1
3-1 GH72-00636A PMO-HINGE DUMMY SNA 1
3-2 GH72-02097A PMO-FRONT COVER SNA 1
3-3 GH72-02394A PMO-REFLECTOR LED SNA 1
3-4 GH73-00266B RMO-DAMPER(L) SNA 2
3-5 GH74-00445A MPR-SPONGE CMIC SNA 1
3-6 GH74-01296A MPR-SHIELD FOAM SNA 2
4 GH75-00927A MEC-REAR COVER WHITE SA 1
4-1 GH61-00008A SPRING-LOCKER SNA 1
4-2 GH61-00011A SPRING-SIM LOCKER SNA 2
4-3 GH71-00380A NPR-BRACKET ANT SNA 1
4-4 GH72-02102A PMO-REAR COVER WHITE SNA 1
4-5 GH72-02103A PMO-LOCKER BATT WHITE SNA 1
4-6 GH72-02104A PMO-EAR JACK COVER LIGHT/GRAY SNA 1
4-7 GH72-02330A PMO-SIM KNOB WHITE SNA 1
4-8 GH74-01236A MPR-TAPE EARPHONE WHITE SNA 1
4-9 GH74-01237A MPR-TAPE MOBILE WHITE SNA 1
5 GH75-01022A MEC-SHIELD COVER SA 1
5-1 GH72-02101A PMO-SHIELD COVER SNA 1
5-2 GH74-01238A MCT-SHIELD GASKET SNA 1
6 GH07-00051A LCD-SGHA288 SA 1
7 GH72-00640A PMO-WATCH WINDOW SA 1
8 GH72-00940A PMO-KNOB VOLUME SA 1
9 GH73-00504A RMO-HOLDER MIC SA 1
10 GH73-00580A RMO-KEY PAD SA 1
11 GH74-00587A MPR-DUMMY SHEET SA 1
12 6001-000464 SCREW-MACHINE SA 2 PH,+,M1.4,L4,BLK
13 6001-001402 SCREW-MACHINE SA 2 PH,+,M1.4,L3,WHT
14 GH74-00611B MPR-SCREW CAP WHITE SA 2
15 GH74-00770A MPR-ESD SHEET SA 1
16 GH74-00979A MPR-SHEET SPEAKER SA 1
17 GH74-01254A MPR-SPONGE EARJACK SA 1
1-2 Exploded Views and Parts List
NO SEC CODE DESCRIPTION COLOR SVC Q`TY REMARKS
18 GH74-01294A MPR-CLOTH BUZZER SA 1
19 GH74-01295A MPR-SPONGE VIB SPEAKER SA 1
20 GH74-01297A MPR-SHIELD FOAM CONN SA 1
21 GH74-01332A MPR-GASKET LOWER SA 1
22 GH74-40518A MCT-BACKUP TAPE SA 2
23 6001-000464 SCREW-MACHINE SA 4
24 GH71-00095A NPR-CONTACT ANT SA 1
25 GH72-00602A PCT-WINDOW LCD SA 1
26 GH72-00647B PMO-SPEAKER COVER SA 1
27 GH73-00578A RMO-CONNECTOR COVER SA 4
28 GH73-00579A RMO-MOBILE CAP SA 1
29 GH73-00667A RMO-ANT.CONTACT RUBBER SA 1
30 GH74-40518A MCT-BACKUP TAPE SA 1
31 GH68-01684A LABEL(R)-MAIN(CHNA) SNA 1
32 GH68-01685A LABEL(R)-MAIN(A288) SNA 1
33 GH42-00076B ANTENNA-SGHA288 SA 1
34 GH43-00283A BATTERY-SLIM-SGHA288 SA 1
35 GH43-00305A BATTERY-STD-SGHA288 SA 1
36 GH97-01829A MEA FRONT-TOTAL(WHT) SNA 1
37 GH97-01830A MEA REAR-TOTAL(WHT) SNA 1
Exploded Views and Parts List 1-3
1-3 Travel Adapter
A B
C D
1-4 Travel Adapter Parts List
TYPE SEC CODE REMARK
A GH44-00171A CHINA
B GH44-00184A EUROPE
C GH44-00171C UNITED KINGDOM
D Gh44-00171E TAIWAN
1-4 Exploded Views and Parts List
1-5 Ciger Light Adapter
1-6 Ciger Light Adapter Parts List
DESCRIPTION SEC CODE REMARK
Ciger Light Adapter Code GH44-00170A BLACK
Exploded Views and Parts List 1-5
1-7 Test Jig
TEST JIG GH80-10508A
TEST JIG CABLE GH39-00079A
RF JIG CABLE GH39-00089A
1-6 Exploded Views and Parts List
DM CABLE GH39-00080A
1-7-1 Test Jig
DC
POWER
SUPPLY
8922 or 8960
WIRELESS COMMVNCATIONS
TEST SET
RF JIG CABLE
C F
DE
TE ABC
MN
O
ST GHI
JKL
WXY
Z
JIG
TUV
PQRS
232 CABLE
TEST JIG CABLE
Exploded Views and Parts List 1-7
1-8 Wearable EAR Microphone
Wearable EAR Microphone GH59-00168A
1-9 Data Kit
DATA KIT GH39-00078A
1-8 Exploded Views and Parts List
1-10 Battery Charger
BATTERY CHAGER GH44-00177A
Exploded Views and Parts List 1-9
2. PCB Diagrams
2-1 Main Top
2-1 PCB Diagrams
2-1-1 Main RF Top
PCB Diagrams 2-2
2-1-2 Main Base Band Top
2-3 PCB Diagrams
2-2 Main Bottom
PCB Diagrams 2-4
2-2-1 Main RF Bottom
2-5 PCB Diagrams
2-2-2 Main Base Band Bottom
PCB Diagrams 2-6
3. Electrical Parts List
3-1 Main Parts List Top
SEC CODE Reference Part Description Vendor Part No.
1 D301 0404-001054 TR-SMALL SIGNAL;HSMS-2805-L31 HSMS-2805-L31
2 D102,D104 0407-001002 TR-SMALL SIGNAL;DAN222TL DAN222TL
3 D107 0407-001007 TR-SMALL SIGNAL;UMN1 UMN1
4 Q108 0501-000162 TR-SMALL SIGNAL;2SA1576FRT106 2SA1576FRT106
5 Q103 0501-000218 TR-SMALL SIGNAL;2SC4081BRT106 2SC4081BRT106
6 Q102,Q107 0501-002011 TR-SMALL SIGNAL;2SD2114KT146V 2SD2114KT146V
7 U111 0501-002202 TR-SMALL SIGNAL;MMBT2222AWT1 MMBT2222AWT1
8 U445 0504-000167 TR-SMALL SIGNAL;DTC114EE/TR DTC114EE/TR
9 Q304,Q305 0504-000168 TR-SMALL SIGNAL;DTC144EE/TR DTC144EE/TR
10 Q101,Q301 0504-001012 TR-SMALL SIGNAL;DTC114YE DTC114YE
11 Q306 0504-001016 TR-SMALL SIGNAL;DTA114EE-TL DTA114EE-TL
12 U443 0504-001021 TR-SMALL SIGNAL;DTB113ZK DTB113ZK
13 U104,U124 0504-001042 TR-SMALL SIGNAL;BCR10PN BCR10PN
14 U309,U314 0504-001058 TR-SMALL SIGNAL;BCR08PN BCR08PN
15 U114 0505-001332 TR-SMALL SIGNAL;FDG6301N FDG6301N
16 U101,U310 0505-001423 TR-SMALL SIGNAL;FDG6323L FDG6323L
17 U301 0506-000151 LED;UMZ1N-TR UMZ1N-TR
18 U644 0801-000794 IC;TC7S08FUTE85L TC7S08FUTE85L
19 U646 0801-002345 IC;TC7S04FU(TE85L) TC7S04FU(TE85L)
20 U642,U643 0801-002510 IC;TC7W74FK(TE85L) TC7W74FK(TE85L)
21 U103 0801-002540 IC;NC7SZ19P6X NC7SZ19P6X
22 U113,U115 1001-001145 IC;MAX4599EXT-T NC7SZ19P6X
23 U109 1106-001301 IC;LRS1337 LRS1337
24 U306 1201-001018 IC;LM7131ACM5 LM7131ACM5
25 U118 1202-001022 IC;TC75W56FU-TE12L TC75W56FU-TE12L
26 U457 1203-002142 IC;MM1448CYFE MM1448CYFE
27 U645 1203-002187 IC;MAX6326 MAX6326
28 U108 1205-001881 IC;VP40575 VP40575
29 U305 1205-001935 IC;HD155128TF HD155128TF
30 U302 1209-001337 IC;SI4133-MLP28 SI4133-MLP28
31 TH101 1404-001005 IC;NTH5G40B473J01TE NTH5G40B473J01TE
32 R331 2007-000138 R-CHIP;100,5% RK73K1ETP101J
33 R174,R177 2007-000139 R-CHIP;220,5% ERJ2GEJ221X
34 R141,R303,R305,R308 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
35 R313,R315,R319 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
36 R681,R683 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
37 R686 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
38 R696 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
39 R700 2007-000143 R-CHIP;4.7K,5% RK73K1ETP472J
3-1 Electrical Parts List
SEC CODE Reference Part Description Vendor Part No.
40 R103,R105,R106,R114 2007-000148 R-CHIP;10K,5% RK73K1ETP103J
41 R121,R125,R154,R155 2007-000148 R-CHIP;10K,5% RK73K1ETP103J
42 R156,R159,R161,R162 2007-000148 R-CHIP;10K,5% RK73K1ETP103J
43 R163,R165,R178,R182 2007-000148 R-CHIP;10K,5% RK73K1ETP103J
44 R332,R344,R347,R673 2007-000148 R-CHIP;10K,5% RK73K1ETP103J
45 R678,R694 2007-000148 R-CHIP;10K,5% RK73K1ETP103J
46 R136 2007-000152 R-CHIP;20K,5% RK73K1ETP203J
47 R144,R170 2007-000157 R-CHIP;47K,5% RK73K1ETP473J
48 R187 2007-000159 R-CHIP;56K,5% ERJ2GEJ563X
49 R108,R109,R116,R146 2007-000162 R-CHIP;100K,5% RK73K1ETP104J
50 R149,R151,R157,R166 2007-000162 R-CHIP;100K,5% RK73K1ETP104J
51 R167,R168,R169 2007-000162 R-CHIP;100K,5% RK73K1ETP104J
52 R181,R565,R567,R695 2007-000162 R-CHIP;100K,5% RK73K1ETP104J
53 R702,R706,R647,R648 2007-000162 R-CHIP;100K,5% RK73K1ETP104J
54 R184,R185,R186 2007-000170 R-CHIP;1M,5% ERJ2GEJ105X
55 R312 2007-000172 R-CHIP;10,5% ERJ2GEJ100X
56 R369,R370 2007-000173 R-CHIP;22,5% ERJ2GEJ220X
57 R371 2007-000174 R-CHIP;47,5% ERJ2GEJ470X
58 R310,R301 2007-000242 R-CHIP;1.5K,5% ERJ2GEJ152X
59 R115 2007-000982 R-CHIP;5.6K,5% ERJ2GEJ562X
60 R329 2007-001119 R-CHIP;680,5% ERJ2GEJ681X
61 R314,R360 2007-001298 R-CHIP;51,5% ERJ2GEJ510X
62 R110,R175,R176,R323 2007-002796 R-CHIP;510,5% ERJ2GEJ511X
63 R324 2007-002797 R-CHIP;560,5% ERJ2GEJ561X
64 R304 2007-007021 R-CHIP;75K,5% ERJ2GEJ753X
65 R333 2007-007135 R-CHIP;18K,1% ERJ2RKF1802X
66 R322 2007-007137 R-CHIP;1.2K,1% ERJ2GEF122X
67 R368 2007-007309 R-CHIP;12K,1% RK73H1ETP1202F
68 R321 2007-007310 R-CHIP;8.2K,1% RK73H1ETP8201F
69 R326 2007-007311 R-CHIP;22K,1% RK73H1ETP2202F
70 R338,R339,R340,R341 2007-007313 R-CHIP;6.8K,1% RK73H1ETP6801F
71 R361 2007-007315 R-CHIP;3.9K,1% RK73H1ETP3901F
72 R120,R122,R123,R126 2007-007317 R-CHIP;2.2K,1% RK73H1ETP3901F
73 R130,R134,R140,R143 2007-007318 R-CHIP;1K,1% RK73H1ETP1001F
74 R327 2007-007318 R-CHIP;1K,1% RK73H1ETP1001F
75 R153 2007-007480 R-CHIP;130K,1% RK73H1ETP1303F
76 R318 2007-007588 R-CHIP;1.8K,1% RK73H1ETP1801F
77 R362 2007-008117 R-CHIP;2.7Kohm,1% RK73H1ETP2701F
78 R158,R302 2007-007771 R-CHIP;0,5% ERJ2GEJ0R0E
79 R311,R351,R357 2007-007771 R-CHIP;0,5% ERJ2GEJ0R0E
80 R358,R372,R587 2007-007771 R-CHIP;0,5% ERJ2GEJ0R0E
81 R705 2007-007771 R-CHIP;0,5% ERJ2GEJ0R0E
82 R152 2007-007981 R-CHIP;180K,1% ERJ2GEJ0R0E
Electrical Parts List 3-2
SEC CODE Reference Part Description Vendor Part No.
83 R101 2011-001345 R-CHIP;EXB28V103JX EXB28V103JX
84 C129,C135,C138 2203-000233 C-CERAMIC,CHIP;C101J,100PF,50V GRM36C0G101J50PT
85 C333,C351,C695 2203-000233 C-CERAMIC,CHIP;C101J,100PF,50V GRM36C0G101J50PT
86 C706,C725 2203-000233 C-CERAMIC,CHIP;C101J,100PF,50V GRM36C0G101J50PT
87 C107,C119,C147 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
88 C151,C164,C171,C181 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
89 C183,C197,C306 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
90 C319,C320,C321,C366 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
91 C374,C382,C549 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
92 C550,C551 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
93 C724 2203-000278 C-CERAMIC,CHIP;C100D,10PF,50V GRM36C0G100D50PT
94 C313,C314 2203-000330 C-CERAMIC,CHIP;C120J,12PF,50V GRM36C0G120J50PT
95 C300 2203-000359 C-CERAMIC,CHIP;C151J,150PF,50V GRM36C0G151J50PT
96 C348 2203-000425 C-CERAMIC,CHIP;C180J,18PF,50V GRM36C0G180J50PT
97 C302,C307,C324,C325 2203-000438 C-CERAMIC,CHIP;C102K,1NF,50V GRM36X7R102K50PT
98 C326,C327,C330,C338 2203-000438 C-CERAMIC,CHIP;C102K,1NF,50V GRM36X7R102K50PT
99 C344,C349,C358,C360 2203-000438 C-CERAMIC,CHIP;C102K,1NF,50V GRM36X7R102K50PT
100 C362,C373,C357 2203-000438 C-CERAMIC,CHIP;C102K,1NF,50V GRM36X7R102K50PT
101 C406 2203-000585 C-CERAMIC,CHIP;C221K,220PF,50V GRM36X7R221K50PT
102 C353 2203-000628 C-CERAMIC,CHIP;C220J,22PF,50V GRM36COG220J50PT
103 C152,C153,C158 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
104 C159,C161,C165,C167 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
105 C337,C339 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
106 C345,C356,C369 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
107 C394,C709 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
108 C118,C121,C134,C141 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
109 C148,C177,C182 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
110 C193 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
111 C711,C712 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
112 C334,C627 2203-000995 C-CERAMIC,CHIP;C470J,47PF,50V GRM36C0G470J50PT
113 C334,C627 2203-000995 C-CERAMIC,CHIP;C470J,47PF,50V GRM36C0G470J50PT
114 C361 2203-001072 C-CERAMIC,CHIP;0.056nF,5% GRM36C0G560J50PT
115 C178,C180 2203-001201 C-CERAMIC,CHIP;0.007nF,0.5pF,50V GRM36C0G070D50PT
116 C323 2203-001221 C-CERAMIC,CHIP;C821K,820PF,50V GRM36X7R821K50PT
117 C312 2203-001383 C-CERAMIC,CHIP;C0R5C,0.5PF,50V GRM36C0G0R5C50PT
118 C301,C315 2203-002525 C-CERAMIC,CHIP;C561K,560PF,50V GRM36X7R561K50PT
119 C403 2203-002687 C-CERAMIC,CHIP;C122K,1.2NF,50V GRM36X7R122K50PT
120 C155,C168,C170 2203-003054 C-CERAMIC,CHIP;C090C,9PF,50V GRM36C0G090C50PT
121 C400 2203-005054 C-CERAMIC,CHIP;C4R7C,4.7PF,50V GRM36C0G4R7C50PT
122 C404,C340 2203-005056 C-CERAMIC,CHIP;C6R8C,6.8PF,50V GRM36C0G6R8D50PT
123 C378,C379 2203-005057 C-CERAMIC,CHIP;C8R2C,8.2PF,50V GRM36C0G8R2D50PT
124 C102,C106,C114,C116 2203-005061 C-CERAMIC,CHIP;C104Z,100NF,16V GRM36Y5V104Z16PT
125 C163,C173,C174,C186 2203-005061 C-CERAMIC,CHIP;C104Z,100NF,16V GRM36Y5V104Z16PT
3-3 Electrical Parts List
SEC CODE Reference Part Description Vendor Part No.
126 C205,C303,C304 2203-005061 C-CERAMIC,CHIP;C104Z,100NF,16V GRM36Y5V104Z16PT
127 C308,C316 2203-005061 C-CERAMIC,CHIP;C104Z,100NF,16V GRM36Y5V104Z16PT
128 C705 2203-005061 C-CERAMIC,CHIP;C104Z,100NF,16V GRM36Y5V104Z16PT
129 C104,C125 2203-005065 C-CERAMIC,CHIP;C105Z,1UF,10V GRM39Y5V105Z10PT
130 C702,C743 2203-005065 C-CERAMIC,CHIP;C105Z,1UF,10V GRM39Y5V105Z10PT
131 C352 2203-005138 C-CERAMIC,CHIP;C182K,1.8NF,50V GRM36X7R182K50PT
132 C309,C310 2203-005382 C-CERAMIC,CHIP;C060B,6PF,50V GRM36C0G060B50PT
133 C364 2203-005446 C-CERAMIC,CHIP;C2R7B,2.7PF,50V GRM36C0G2R7B50PT
134 C335 2203-005450 C-CERAMIC,CHIP;C5R6B,5.6PF,50V GRM36C0G5R6B50PT
135 C187,C188 2203-005480 C-CERAMIC,CHIP;C333K,33NF,10V GRM36X7R333K10PT
136 C184 2203-005481 C-CERAMIC,CHIP;C473K,47NF,10V GRM36X7R473K10PT
137 C146,C149 2203-005503 C-CERAMIC,CHIP;C1801J,180PF,25V GRM36C0H181J25PT
138 C117,C124 2203-005664 C-CERAMIC,CHIP;C475K,4.7UF,6.3V GRM40034X5R475K6.3PT
139 C710 2404-000318 C-TA,CHIP;6.8UF/16V TCSCS1C685MBAR
140 C105 2404-001105 C-TA,CHIP;10UF/6.3V TAJR106M006R
141 C204 2404-001162 C-TA,CHIP;F950G476MAAJZTQ2 F950G476MAAJZTQ2
142 L325 2703-001174 INDUCTOR-SMD;LL1608-FH33NJ LL1608-FH33NJ
143 L305,L306 2703-001293 INDUCTOR-SMD;HK1608-82NJ-T HK1608-82NJ-T
144 L308 2703-001514 INDUCTOR-SMD;0603CS-68NXJBC 0603CS-68NXJBC
145 L310 2703-001685 INDUCTOR-SMD;0603CS-82NXJBC 0603CS-82NXJBC
146 L385 2703-001708 INDUCTOR-SMD;HK1005-5N6K-T HK1005-5N6K-T
147 L316 2703-001726 INDUCTOR-SMD;LL1005-FH27NJ LL1005-FH27NJ
148 L323,L324 2703-001727 INDUCTOR-SMD;LL1005-FH22NJ LL1005-FH22NJ
149 L635 2703-001730 INDUCTOR-SMD;LL1005-FH15NJ LL1005-FH15NJ
150 L318,L634 2703-001734 INDUCTOR-SMD;LL1005-FH6N8J LL1005-FH6N8J
151 L301 2703-001750 INDUCTOR-SMD;LL1005-FH2N2S LL1005-FH2N2S
152 L101 2703-001752 INDUCTOR-SMD;LL1005-FH39NJ LL1005-FH39NJ
153 L304 2703-001786 INDUCTOR-SMD;LL1005-FH10NJ LL1005-FH10NJ
154 L637,L638 2703-001798 INDUCTOR-SMD;HK1005-2N2S HK1005-2N2S
155 L303 2703-001944 INDUCTOR-SMD;LL1055-F27NJ LL1055-F27NJ
156 L639,L613 2703-001954 INDUCTOR-SMD;2.7nH HK1005-2N7S-T
157 L636 2703-001992 INDUCTOR-SMD;MLK1005S1N0ST MLK1005S1N0ST
158 OSC101 2801-003856 COMP-SMD;MC-146(32.768KHz,20ppm) MC-146
159 U303 2809-001237 COMP-SMD;KT16-KEU28L-13.000M KT16-KEU28L-13.000M
160 F306 2901-001116 COMP-SMD;NFM39R12C471T1 NFM39R12C471T1
161 U601 2903-001266 COMP-SMD;MKFC225.000MBA701X-TC11 MKFC225.000MBA701X- TC11
162 F303 2904-001226 COMP-SMD;B4121 B4121
163 F302 2904-001228 COMP-SMD;B4133 B4133
164 U603 2904-001235 COMP-SMD;FAR-G6CH-1G8425-L218 FAR-G6CH-1G8425-L218
165 U318 4709-001174 COMP-SMD;LDC15D140A0001 DC15D140A0001
166 ZD105 1405-001082 IC;VC040205X150R VC040205X150R
Electrical Parts List 3-4
3-2 Main Parts List Bottom
SEC CODE Reference Part Description Vendor Part No.
1 J301 3705-001239 COMP-SMD;MHC-175 MHC-175
2 L302 2703-001772 INDUCTOR-SMD;18NH,5%,1.0X0.5X0.5MM MLK1005S18NJT
3 F307 2901-001116 COMP-SMD;NFM39R12C471T1 FM39R12C471T1
4 R330 2007-001305 R-CHIP;120,5% ERJ2GEJ121X
5 C747 2203-005057 C-CERAMIC,CHIP;C8R2C,8.2PF,50V GRM36C0G8R2D50PT
6 C402 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
7 C756 2404-001105 C-TA,CHIP;10UF/6.3V TAJR106M006R
8 C396 2404-001210 C-TA,CHIP;220UF/6.3V 952D227X06R3U2T
9 U304 2909-001126 COMP-SMD;SHS-L090DE SHS-L090DE
10 U312 1201-001689 IC;PF08107B-TB PF08107B-TB
11 L311,L314 2703-001723 INDUCTOR-SMD;LL1005-FH33NJ LL1005-FH33NJ
12 R335,R366 2007-002965 R-CHIP;15,5% RK73K1ETP150J
13 R364 2007-007009 R-CHIP;75ohm,5% ERJ2GEJ750X
14 R365,R346 2007-001288 R-CHIP;18,5% ERJ2GEJ180X
15 R363 2007-003022 R-CHIP;62,5% ERJ2GEJ620X
16 C697 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
17 C387 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
18 C387 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
19 C377 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
20 R667 2007-000138 R-CHIP;100,5% RK73K1ETP101J
21 C383 2203-000278 C-CERAMIC,CHIP;C100D,10PF,50V GRM36C0G100D50PT
22 R666 2007-000174 R-CHIP;47,5% ERJ2GEJ470X
23 R337 2007-001313 R-CHIP;330,5% ERJ2GEJ331X
24 C755 2203-000995 C-CERAMIC,CHIP;C470J,47PF,50V GRM36C0G470J50PT
25 C754 2203-000995 C-CERAMIC,CHIP;C470J,47PF,50V GRM36C0G470J50PT
26 ZD107 1405-001082 IC;VC040205X150R VC040205X150R
27 C169 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
28 C122 2203-005444 C-CERAMIC,CHIP;C030B,3PF,50V GRM36C0G470J112PT
29 J101 3722-001587 COMP-SMD;02-828D0-53BKA 02-828D0-53BKA
30 ZD108 0406-001083 TR-SMALL SIGNAL;ESDA6V1W5 ESDA6V1W5
31 V105 1405-001019 IC;VC060305A150R VC060305A150R
32 ZD102 1405-001082 IC;VC040205X150R VC040205X150R
33 C723 2203-005444 C-CERAMIC,CHIP;C030B,3PF,50V GRM36C0G470J112PT
34 C719 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
35 C752 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
36 C722 2203-005444 C-CERAMIC,CHIP;C030B,3PF,50V GRM36C0G470J112PT
37 ZD101 1405-001082 IC;VC040205X150R VC040205X150R
38 C718 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
39 V102 1405-001019 IC;VC060305A150R IC;VC060305A150R
40 R674 2007-000148 R-CHIP;10K,5% RK73K1ETP103J
41 R675 2007-000148 R-CHIP;10K,5% RK73K1ETP103J
42 U640 0801-002540 IC;NC7SZ19P6X NC7SZ19P6X
3-5 Electrical Parts List
SEC CODE Reference Part Description Vendor Part No.
43 R119 2007-007771 R-CHIP;0,5% ERJ2GEJ0R0E
44 C753 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
45 CN105 3710-001428 COMP-SMD;AXK5F24335J AXK5F24335J
46 U200 2806-001239 COMP-SMD;V0F1748C28KRD V0F1748C28KRD
47 C391 2203-005065 C-CERAMIC,CHIP;C105Z,1UF,10V GRM36C0G470J101PT
48 C392 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
49 R343 2007-007771 R-CHIP;0,5% ERJ2GEJ0R0E
50 R331 2007-000138 R-CHIP;100,5% RK73K1ETP101J
51 C365 2301-001232 C-CERAMIC,CHIP;470PF,50V GRM36C0G470J125PT
52 R325 2007-001290 R-CHIP;24,5% RK73K1ETP240J
53 C359 2301-001199 C-CERAMIC,CHIP;22NF,16V GRM36C0G470J124PT
54 C750 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
55 C749 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
56 C748 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
57 R698 2007-000147 R-CHIP;8.2K,5% ERJ2GEJ822X
58 C751 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
59 CN102 3709-001144 COMP-SMD;1318723-6 1318723-6
60 C744 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
61 R183 2007-000157 R-CHIP;47K,5% RK73K1ETP473J
62 C192 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
63 R171 2007-000162 R-CHIP;100K,5% RK73K1ETP104J
64 C157 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
65 C115 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
66 C732 2203-001221 C-CERAMIC,CHIP;C821K,820PF,50V GRM36C0G470J58PT
67 C727 2203-001221 C-CERAMIC,CHIP;C821K,820PF,50V GRM36C0G470J58PT
68 C729 2203-001221 C-CERAMIC,CHIP;C821K,820PF,50V GRM36C0G470J58PT
69 R684 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
70 C730 2203-001221 C-CERAMIC,CHIP;C821K,820PF,50V GRM36C0G470J58PT
71 R688 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
72 R680 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
73 R682 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
74 R685 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
75 R687 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
76 C734 2203-001221 C-CERAMIC,CHIP;C821K,820PF,50V GRM36C0G470J58PT
77 C726 2203-001221 C-CERAMIC,CHIP;C821K,820PF,50V GRM36C0G470J58PT
78 C728 2203-001221 C-CERAMIC,CHIP;C821K,820PF,50V GRM36C0G470J58PT
79 C731 2203-001221 C-CERAMIC,CHIP;C821K,820PF,50V GRM36C0G470J58PT
80 C733 2203-001221 C-CERAMIC,CHIP;C821K,820PF,50V GRM36C0G470J58PT
81 C699 2404-001105 C-TA,CHIP;10UF/6.3V GRM36C0G470J127PT
82 R164 2007-001308 R-CHIP;200,5% ERJ2GEJ201X
83 C209 2404-001134 C-TA,CHIP;100UF/6.3V GRM36C0G470J134PT
84 U117 1203-001702 IC;MAX1676EUB-T MAX1676EUB-T
Electrical Parts List 3-6
SEC CODE Reference Part Description Vendor Part No.
85 L102 2703-002025 INDUCTOR-SMD;BTC-0309-470 BTC-0309-470
86 F307 2203-005065 C-CERAMIC,CHIP;C105Z,1UF,10V GRM36C0G470J101PT
87 C328 2404-001105 C-TA,CHIP;10UF/6.3V GRM36C0G470J127PT
88 U463 1203-002227 IC;R5320G002-TR R5320G002-TR
89 D108 0402-001331 TR-SMALL SIGNAL;CRS04-TE85L CRS04-TE85L
90 C746 2203-003054 C-CERAMIC,CHIP;C090C,9PF,50V GRM36C0G470J73PT
91 C704 2203-005061 C-CERAMIC,CHIP;C104Z,100NF,16V GRM36C0G470J84PT
92 R671 2007-007107 R-CHIP;100K,1% ERJ2RKF1003X
93 C555 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
94 C700 2404-001105 C-TA,CHIP;10UF/6.3V GRM36C0G470J127PT
95 C535 2203-005065 C-CERAMIC,CHIP;C105Z,1UF,10V GRM36C0G470J101PT
96 C708 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
97 C424 2203-001432 C-CERAMIC,CHIP;C473K,47NF,16V GRM36C0G470J69PT
98 R699 2007-007771 R-CHIP;0,5% ERJ2GEJ0R0E
99 R320 2007-007590 R-CHIP;82K,1% RK73H1ETP8202F
100 U649 1203-001903 IC;LTC1986ES6 LTC1986ES6
101 C211 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
102 C208 2404-001105 C-TA,CHIP;10UF/6.3V GRM36C0G470J127PT
103 C423 2203-005061 C-CERAMIC,CHIP;C104Z,100NF,16V GRM36C0G470J84PT
104 R428 2007-003028 R-CHIP;750K,5% ERJ2GEJ754X
105 R421 2007-000170 R-CHIP;1M,5% ERJ2GEJ105X
106 C745 2404-001105 C-TA,CHIP;10UF/6.3V GRM36C0G470J127PT
107 Q303 0501-002346 TR-SMALL SIGNAL;2SB1427 2SB1427
108 U116 1203-002077 IC;LP2985AIM5-3.3 LP2985AIM5-3.3
109 C190 2203-000233 C-CERAMIC,CHIP;C101J,100PF,50V GRM36C0G101J50PT
110 C111 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
111 R328 2007-000142 R-CHIP;2.7K,5% ERJ2GEJ272X
112 F307 3301-001208 COMP-SMD;BLM11P600SPT BLM11P600SPT
113 U639 1203-002127 IC;LTC1734ES6-4.2#TR LTC1734ES6-4.2#TR
114 BAT101 4302-001119 COMP-SMD;MS414 FL26N MS414 FL26N
115 D110 0402-001331 TR-SMALL SIGNAL;CRS04-TE85L CRS04-TE85L
116 R701 2007-000140 R-CHIP;1K,5% RK73K1ETP102J
117 C713 2203-000254 C-CERAMIC,CHIP;C103K,10NF,16V GRM36X7R103K16PT
118 R703 2007-007771 R-CHIP;0,5% ERJ2GEJ0R0E
119 R703 1405-001082 IC;VC040205X150R VC040205X150R
120 C721 2203-005057 C-CERAMIC,CHIP;C8R2C,8.2PF,50V GRM36C0G470J80PT
121 C717 2203-000812 C-CERAMIC,CHIP;C330J,33PF,50V GRM36C0G330J50PT
122 ZD109 1405-001082 IC;VC040205X150R VC040205X150R
123 CN503 3711-004234 COMP-SMD;connector AXK6F24335P
124 ZD205 1405-001082 IC;VC040205X150R VC040205X150R
125 C738 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G470J84PT
126 ZD203 0406-001083 TR-SMALL SIGNAL;ESDA6V1W5 ESDA6V1W5
3-7 Electrical Parts List
SEC CODE Reference Part Description Vendor Part No.
127 R209 2011-001344 R-CHIP;CRB2A4E101JT CRB2A4E101JT
128 F201 2901-001116 COMP-SMD;NFM39R12C471T1 NFM39R12C471T1
129 F200 2901-001116 COMP-SMD;NFM39R12C471T1 NFM39R12C471T1
130 ZD201 0406-001104 TR-SMALL SIGNAL;ESDA6V1-5W6 ESDA6V1-5W6
131 R207 2011-001344 R-CHIP;CRB2A4E101JT CRB2A4E101JT
132 C210 2203-005061 C-CERAMIC,CHIP;C104Z,100NF,16V GRM36C0G470J84PT
133 C714 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
134 C201 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
135 L200 2703-001752 INDUCTOR-SMD;LL1005-FH39NJ LL1005-FH39NJ
136 C740,C741 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
137 V205,V206 1405-001082 IC;VC040205X150R VC040205X150R
138 C739 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
139 ZD202 0406-001104 TR-SMALL SIGNAL;ESDA6V1-5W6 ESDA6V1-5W6
140 R203 2007-007771 R-CHIP;0,5% ERJ2GEJ0R0E
141 C715 2203-000679 C-CERAMIC,CHIP;C270J,27PF,50V GRM36C0G270J50PT
142 CN502 3710-001599 COMP-SMD;1004-0018-305 1004-0018-305
Electrical Parts List 3-8
4-1
SIM CARD
BB INTERFACE
Serial Data
Interface
Battery
Type
VIBRATOR I/O
4-1 Main Base Band
Interface
MIC Battery
Voltage
4. Block Diagrams
SPEAKER Battery
A/D
Temperature
ONE C Interface
RF INTERFACE
SYSTEM CLOCK
(13MHz)
AGC,AFC
SRAM 3VTXRX
PLL
FLASH1 XVCC
Li-Ion Battery
(Slim, Standard
FLASH2 Long)
3VBRIGHT
EEPROM RTC_3V3 LDO
DC/DC
Charging CONVERTER
RTC_CLOCK Circuit
(32.768KHz) AVcc LDO
Vcc LDO
KEY_BOARD
LCD
Block Diagrams
CH 62 : 1172.4MHz
Block Diagrams
Mixer 1 CH 698 : 1617.2MHz
1805~1880MHz U604
C617, L608
4-2 Main RF
(CH 698 : 1842.2MHz) Rx U601
LNA SAW Mixer 2
filter I
IF SAW LC -I
925~960MHz U606 Filter Filter PGA I&Q Demo.
(225MHz) (45MHz) Q
(CH 62 : 947.4MHz) Rx
-Q
LNA SAW
filter
45MHz
CLK
Serial data
Dual SDATA
bias circuit interface
SAW LE
Filter
(U603)
SI4133-MLP28
(U612) GSM : 1150~1185MHz
DCS : 1580~1655MHz
270MHz
90 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
