Image preview - the first page of the document
>> Download Samsung SGH-D600 service manual documenatation <<
Text preview - extract from the document
GSM TELEPHONE
SGH-D600
GSM TELEPHONE CONTENTS
1. Specification
2. Circuit Description
3. Exploded Views and Parts List
4. Electrical Parts List
5. Block Diagrams
6. PCB Diagrams
7. Flow Chart of Troubleshooting
This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd. September. 2005
Any unauthorized use of Manual can be punished under applicable Printed in Korea.
International and/or domestic law.
Code No.: GH68-08500A
BASIC.
1. Specification
1-1. GSM General Specification
GSM850 GSM900 EGSM 900 DCS1800
phase1 PCS1900
Phase 1 P h as e 2 Phase 1
Fr eq.
Ba nd[MHz] 824~849 890~915 880~915 1710~1785 1850~1910
Upli nk/Downl in 869~894 935~960 925~960 1805~1880 1930~1990
k
0~124 &
ARFCN r ange 128~251 1~124 512~885 512~810
975~1023
Tx/ Rx s pacing 45MHz 45MHz 45MHz 95MHz 80MHz
Mod. Bit rate/ 270.833kbps 270.833kbps 270.833kbps 270.833kbps 270.833kbps
Bit Period 3.692us 3.692us 3.692us 3.692us 3.692us
Ti me Slot
576.9us 576.9us 576.9us 576.9us 576.9us
Period/ Frame
4.615ms 4.615ms 4.615ms 4.615ms 4.615ms
Per iod
Modulat ion 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK
MS Power 33dBm~13dBm 33dBm~13dBm 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm
Power Class 5pcl ~ 15pcl 5pcl ~ 15pcl 5pcl ~ 19pcl 0pcl ~ 15pcl 0pcl ~ 15pcl
Sensit ivit y - 102dBm -102dBm -102dBm -100dBm - 100dBm
TDMA Mux 8 8 8 8 8
Cell Radius 35Km 35Km 35Km 2Km -
1-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used with out Samsung's authorization
Specification
1-2. GSM TX power class
TX TX TX TX
Power Power Power ower
GSM850 GSM900 DCS1800 PCS1900
control control control control
level level level level
