Image preview - the first page of the document
Samsung SGH-E480 service manual


>> Download Samsung SGH-E480 service manual documenatation <<

Text preview - extract from the document
                GSM TELEPHONE
                SGH-E480




GSM TELEPHONE                     CONTENTS


                  1.    Safety Precautions

                  2.    Specification

                  3.    Product Function

                  4.    Array course control

                  5.    Exploded View/Disassembly
                        and Assembly Instructions

                  6.    MAIN Electrical Parts List

                  7.    Block Diagrams

                  8.    PCB Diagrams

                  9.    Flow Chart of Troubleshooting

                  10.   Reference data
                                                   CONTENTS


1. Safety Precautions
  1-1. Repair Precaution......................................................................................................1-1
  1-2. ESD(Electrostatically Sensitive Devices) Precaution...............................................1-2


2. Specification
  2-1. GSM General Specification.......................................................................................2-1
  2-2. GSM Tx Power Class...............................................................................................2-2


3. Product Function

4. Array course control
  4-1. Software Adjustments................................................................................................4-1
  4-2. Software Downloading...............................................................................................4-2


5. Exploded View/Disassembly & Assembly Instructions
  5-1. Cellular phone Exploded View..................................................................................5-1
  5-2. Cellular phone Parts list............................................................................................5-2
  5-3. Disassembly & Assembly Instructions......................................................................5-4


6. MAIN Electrical Parts List

7. Block Diagrams

8. PCB Diagrams
                                                     CONTENTS


9. Flow Chart of Troubleshooting
 9-1. Power On..................................................................................................................9-1
 9-2. Initial...........................................................................................................................9-4
 9-3. Charging Part.............................................................................................................9-6
 9-4. Sim Part.....................................................................................................................9-7
 9-5. Microphone Part.........................................................................................................9-9
 9-6. Speaker Part(MPC/SPK)..........................................................................................9-11
 9-7. Key Data Input........................................................................................................9-13
 9-8. Receiver Part...........................................................................................................9-14
 9-9. LCD Part..................................................................................................................9-16
 9-10. Camera Part...........................................................................................................9-18
 9-11. Trans Flash Card Part..........................................................................................9-20
 9-12. Bluetooth Part........................................................................................................9-22
 9-13. Main Key LED Part...............................................................................................9-23
 9-14. GSM Receiver........................................................................................................9-24
 9-15. GSM Transmitter....................................................................................................9-25
 9-16. DCS Receiver........................................................................................................9-26
 9-17. DCS Transmitter....................................................................................................9-27
 9-18. PCS Receiver.........................................................................................................9-28
 9-19. PCS Transmitter.....................................................................................................9-29


10. Reference data
1. Safety Precautions

1-1. Repair Precaution


 Repair in Shield Box, during detailed tuning.
   Take specially care of tuning or test,
   because specipicty of cellular phone is sensitive for surrounding interference(RF noise).


 Be careful to use a kind of magnetic object or tool,
   because performance of parts is damaged by the influence of magnetic force.


 Surely use a standard screwdriver when you disassemble this product,
   otherwise screw will be worn away.


 Use a thicken twisted wire when you measure level.
   A thicken twisted wire has low resistance, therefore error of measurement is few.


 Repair after separate Test Pack and Set because for short danger (for example an
   overcurrent and furious flames of parts etc) when you repair board in condition of
   connecting Test Pack and tuning on.


 Take specially care of soldering, because Land of PCB is small and weak in heat.


 Surely tune on/off while using AC power plug, because a repair of battery charger is
   dangerous when tuning ON/OFF PBA and Connector after disassembling charger.


 Don't use as you pleases after change other material than replacement registered on SEC System.
  Otherwise engineer in charge isn't charged with problem that you don't keep this rules.




                                                   1-1
                         SAMSUNG Proprietary-Contents may change without notice
                       This Document can not be used without Samsung's authorization
Safety Precautions




1-2. ESD(Electrostatically Sensitive Devices) Precaution

Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
 (Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
 You can prevent from ESD damage by static electricity.


 Remove static electricity remained your body before you touch semiconductor or parts with
   semiconductor. There are ways that you touch an earthed place or wear static electricity
   prevention string on wrist.


 Use earthed soldering steel when you connect or disconnect ESD.


 Use soldering removing tool to break static electricity. , otherwise ESD will be damaged by
   static electricity.


 Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
   aluminum plate to have conductive power,they are prevented from static electricity.


 You must maintain electric contact between ESD and place due to be set up until ESD is connected
   completely to the proper place or a circuit board.




                                                      1-2
                          SAMSUNG Proprietary-Contents may change without notice
                         This Document can not be used without Samsung's authorization
2. Specification

2-1. GSM General Specification


                       G SM 90 0      EG SM 9 00      DCS1800
                                                                      PCS1900
                       Ph ase 1        Ph ase 2       Ph ase 1
      Fr eq.
                       8 90~915        8 80~915       17 10~178 5     185 0~1910
   Band[MHz]
                       9 35~960        9 25~960       18 05~188 0     193 0~1990
 Uplin k/Down link

                                       0~124 &
  ARF CN ra nge         1~124                          5 12~885        51 2~810
                                      97 5~1023

 T x/Rx spacing         45MHz           45MHz           95MHz           8 0MHz


 Mo d. Bit r ate/    270 .833kb ps   270 .833kb ps   270 .833kb ps   270 .833kb ps
  Bit Period           3 .692u s       3 .692u s       3 .692u s       3. 692us

   Ti me Slo t
                       5 76.9u s       5 76.9u s       5 76.9u s       57 6.9us
  Pe rio d/Fr am e
                       4. 615ms        4. 615ms        4. 615ms        4.6 15ms
      Per iod

   Modula tion        0 .3G M SK      0 .3G MSK       0 .3G M SK      0. 3G MSK


   MS Power          33d Bm~5dBm     33d Bm~5dBm     30d Bm~0dBm     30d Bm~0dBm

  Powe r Class       5pcl ~ 19pcl     5pcl ~ 19pcl    0pcl ~ 15pcl    0pcl ~ 15pcl

    Se nsitivity      -10 2dBm         -10 2dBm        -10 0dBm        -100 dBm

   TDMA Mu x              8                8               8               8

   Cell Radiu s         35Km            35Km             2Km               -




                                               2-1
Speclflcation




2-2. GSM Tx Power Class

  TX Power                   TX Power                     TX Power
                 GSM900                       DCS1800                    PCS1800
 control level              control level                control level

       5         33
