Image preview - the first page of the document

>> Download Samsung SGH-E890 service manual documenatation <<

Text preview - extract from the document

GSM TELEPHONE
SGH-E890

GSM TELEPHONE CONTENTS

1. Safety Precautions

2. Specification

3. Product Function

4. Array course control

5. Exploded View/Disassembly
and Assembly Instructions

6. MAIN Electrical Parts List

7. Block Diagrams

8. PCB Diagrams

9. Flow Chart of Troubleshooting

10. Reference data
This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law. 2006. 12. Rev.1.0
CONTENTS

1. Safety Precautions
1-1. Repair Precaution......................................................................................................1-1
1-2. ESD(Electrostatically Sensitive Devices) Precaution...............................................1-2

2. Specification
2-1. GSM General Specification.......................................................................................2-1
2-2. GSM Tx Power Class...............................................................................................2-2

3. Product Function

4. Array course control
4-1. Software Adjustments................................................................................................4-1
4-2. Software Downloading...............................................................................................4-2

5. Exploded View/Disassembly & Assembly Instructions
5-1. Cellular phone Exploded View...................................................................................5-1
5-2. Cellular phone Part list...............................................................................................5-2
5-3. Disassembly & Assembly Instructions........................................................................5-4

6. MAIN Electrical Parts List

7. Block Diagrams
7-1. RF Solution Block Diagrams.....................................................................................7-1
7-2. Base Band Block Diagrams......................................................................................7-3

8. PCB Diagrams
CONTENTS

9. Flow Chart of Troubleshooting
9-1. Power On...................................................................................................................9-1
9-2. Initial ..........................................................................................................................9-4
9-3. Charging Part.............................................................................................................9-7
9-4. Sim Part.....................................................................................................................9-8
9-5. Microphone Part .....................................................................................................9-10
9-6. Speaker Part(MP3/Spk)...........................................................................................9-12
9-7. Key Data Input........................................................................................................9-14
9-8. Receiver Part...........................................................................................................9-15
9-9. LCD Part..................................................................................................................9-16
9-10. Camera Part...........................................................................................................9-18
9-11. Trans Flash Card Part..........................................................................................9-20
9-12. TV OUT..................................................................................................................9-22
9-13. Bluetooth Part........................................................................................................9-23
9-14. Main Key LED Part...............................................................................................9-25
9-15. GSM900 Receiver..................................................................................................9-26
9-16. GSM900 Transmitter..............................................................................................9-27
9-17. DCS Receiver........................................................................................................9-28
9-18. DCS/PCS Transmitter............................................................................................9-29
9-19. PCS Receiver.........................................................................................................9-30

10. Reference data
1. Safety Precautions

1-1. Repair Precaution
Repair in Shield Box, during detailed tuning.
Take specially care of tuning or test,
because specipicty of cellular phone is sensitive for surrounding interference(RF noise).

Be careful to use a kind of magnetic object or tool,
because performance of parts is damaged by the influence of magnetic force.

Surely use a standard screwdriver when you disassemble this product,
otherwise screw will be worn away.

Use a thicken twisted wire when you measure level.
A thicken twisted wire has low resistance, therefore error of measurement is few.

Repair after separate Test Pack and Set because for short danger (for example an
overcurrent and furious flames of parts etc) when you repair board in condition of
connecting Test Pack and tuning on.

Take specially care of soldering, because Land of PCB is small and weak in heat.

Surely tune on/off while using AC power plug, because a repair of battery charger is
dangerous when tuning ON/OFF PBA and Connector after disassembling charger.

Don't use as you pleases after change other material than replacement registered on SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.

1-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Safety Precautions

1-2. ESD(Electrostatically Sensitive Devices) Precaution

Several semiconductor may be damaged easily by static electricity. Such parts are called by ESD
(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.

Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity
prevention string on wrist.

Use earthed soldering steel when you connect or disconnect ESD.

Use soldering removing tool to break static electricity. , otherwise ESD will be damaged by
static electricity.

Don't unpack until you set up ESD on product. Because most of ESD are packed by box and
aluminum
plate to have conductive power,they are prevented from static electricity.

You must maintain electric contact between ESD and place due to be set up until ESD is
connected
completely to the proper place or a circuit board.

1-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
2. Specification

2-1. GSM General Specification
GSM900 EG SM 900 DCS1800
PCS1900
Phas e 1 Ph ase 2 Phas e 1

Fr eq. Band[MHz] 890~915 880~915 1710~1785 1850~1910
Uplink/ Downli nk 935~960 925~960 1805~1880 1930~1990

0~124 &
ARFCN r ange 1~124 512~885 512~810
975~1023

Tx/ Rx s paci ng 45MHz 45MHz 95MHz 80MHz

Mod. Bit r ate 270.833kbps 270.833kbps 270.833kbps 270.833kbps
/ Bit Pe r iod 3.692us 3.692us 3.692us 3.692us

T ime Slot Period 576.9us 576.9us 576.9us 576.9us
/ F rame Peri od 4.615ms 4.615ms 4.615ms 4.615ms

Modulati on 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK

MS Power 33dBm~5dBm 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm

Power Cl a ss 5pcl ~ 19pcl 5pcl ~ 19pcl 0pcl ~ 15pcl 0pcl ~ 15pcl

Sensit ivit y - 102dBm -102dBm - 100dBm - 100dBm

TDMA Mux 8 8 8 8

Cell Radius 35Km 35Km 2Km -

2-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Specification

2-2. GSM TX power class

TX Power TX Power TX Power
GSM900 DCS1800 PCS1900
control level control level control level

5 33
