Image preview - the first page of the document
>> Download Samsung SGH-E350E service manual documenatation <<
Text preview - extract from the document
1. Specification
1-1. GSM General Specification
GSM900 EGSM 900 DCS1800
PCS1900
Phas e 1 Phas e 2 Phas e 1
Fr eq. Band[MHz] 890~915 880~915 1710~1785 1850~1910
Uplink/ Downli nk 935~960 925~960 1805~1880 1930~1990
0~124 &
ARFCN r ange 1~124 512~885 512~810
975~1023
Tx/ Rx s paci ng 45MHz 45MHz 95MHz 80MHz
Mod. Bit r ate 270.833kbps 270.833kbps 270.833kbps 270.833kbps
/ Bit Pe r iod 3.692us 3.692us 3.692us 3.692us
T ime Slot Period 576.9us 576.9us 576.9us 576.9us
/ F rame Peri od 4.615ms 4.615ms 4.615ms 4.615ms
Modulati on 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK
MS Power 33dBm~5dBm 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm
Power Cl a ss 5pcl ~ 19pcl 5pcl ~ 19pcl 0pcl ~ 15pcl 0pcl ~ 15pcl
Sensit ivit y - 102dBm -102dBm - 100dBm - 100dBm
TDMA Mux 8 8 8 8
Cell Radius 35Km 35Km 2Km -
1-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used with out Samsung's authorization
Specification
1-2. GSM TX power class
TX Power TX Power TX Power
GSM900 DCS1800 PCS1900
control level control level control level
