Image preview - the first page of the document
>> Download Samsung SGH-G800 service manual documenatation <<
Text preview - extract from the document
GSM TELEPHONE
SGH-G800
GSM TELEPHONE CONTENTS
1. Safety Precautions
2. Specification
3. Product Function
4. Array course control
5. Exploded View and Parts list
6. MAIN Electrical Parts List
7. Disassembly and Assembly
Instructions
8. Block Diagrams
9. PCB Diagrams
10. Chart of Troubleshooting
11. Reference data
GSPN (Global Service Partner Network)
Country Web Site
North America service.samsungportal.com
Latin America latin.samsungportal.com
CIS cis.samsungportal.com
Europe europe.samsungportal.com
China china.samsungportal.com
Asia asia.samsungportal.com
Mideast & Africa mea.samsungportal.com
This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law. 2007. 11. Rev.1.0
1. Safety Precautions
1-1. Repair Precaution
Repair in Shield Box, during detailed tuning.
Take specially care of tuning or test,
because specipicty of cellular phone is sensitive for surrounding interference(RF noise).
Be careful to use a kind of magnetic object or tool,
because performance of parts is damaged by the influence of manetic force.
Surely use a standard screwdriver when you disassemble this product,
otherwise screw will be worn away.
Use a thicken twisted wire when you measure level.
A thicken twisted wire has low resistance, therefore error of measurement is few.
Repair after separate Test Pack and Set because for short danger (for example an
overcurrent and furious flames of parts etc) when you repair board in condition of
connecting Test Pack and tuning on.
Take specially care of soldering, because Land of PCB is small and weak in heat.
Surely tune on/off while using AC power plug, because a repair of battery charger is
dangerous when tuning ON/OFF PBA and Connector after disassembing charger.
Don't use as you pleases after change other material than replacement registered on SEC
System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.
1-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Safety Precautions
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easilly by static electricity. Such parts are called by
ESD(Electrostatically Sensitive Devices), for example IC,BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity
prevention string on wrist.
Use earthed soldering steel when you connect or disconnect ESD.
Use soldering removing tool to break static electricity. , otherwise ESD will be damaged by
static electricity.
Don't unpack until you set up ESD on product. Because most of ESD are packed by box
and aluminum plate to have conductive power,they are prevented from static electricity.
You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or a circuit board.
1-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
2. Specification
2-1. GSM/DCS1800/PCS1900/WCDMA2100 General Specification
2-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Specification
2-2. GSM TX power class
2-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
3. Product Function
Main Function
- 3G
- RSS reader
- Camera and camcorder
- Synchronisation with Windows Media Player
- Music player
- FM radio
- Image editor
- Digital data printing
- Bluetooth
- File viewer
- Web browser
3-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
4. Array course control
Test Jig (GH80-03307A)
(GH80-03308A)
Test Cable (GH39-00890A)
RF Test Cable (GH39-00397A)
4-
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Array course control
Software Downloading
4-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Array course control
4-3
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Array course control
4-4
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Array course control
4-5
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Array course control
4-6
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Array course control
4-7
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
5. Exploded View and Parts List
5-1. Cellular phone Exploded View
QFR01
QCR57
QMW01 QKP01
QSP01
QME01
QFU01 QVK01
QMP01 QCA02
QMI01
QCA10 QAN05
QKP02
QAN02
QCR06
QLC01
QSH01
QCA01 QSH02
QAR01
QMO01
QCR84
QPC02 QCR05
QCR57
QCK01
QPC01
QIF01
QSD01 QCR06
QRE01
QFL01
QHI05
QCR83 QCH01 QRF01
QHI01 QCW01
QCW02
QBA01
QCW01 QCH01 QCR84 QCW02
QBA00
5-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Exploded View and Parts List
5-2. Cellular phone Parts list
Design LOC Description SEC CODE
QAN02 INTENNA-SGHG800 GH42-01422A
QAN05 ASSY MEC-INTENNA CONTACT GH75-08168A
QAR01 AUDIO-RECEIVER 3009-001292
QBA00 ASSY COVER-BATT GH98-06263A
QBA01 INNER BATTERY PACK-1000MAH,BLK GH43-02971A
QCA01 UNIT-SGHG800 VGA CAMERA GH59-04718A
QCA02 KEY FPCB-CAMERA KEY GH59-04957A
QCA10 CAMERA MODULE-SGHG800 5M GH59-04965A
QCH01 ASSY HINGE-CAMERA MODULE GH98-06574A
QCK01 PMO KEY-(VOL+CAM) GH72-44288A
QCR05 SCREW-MACHINE 6001-001478
QCR06 SCREW-MACHINE 6001-001155
QCR06 SCREW-MACHINE 6001-001155
QCR57 SCREW-MACHINE 6001-002001
QCR57 SCREW-MACHINE 6001-002001
QCR83 SCREW-MACHINE 6001-002121
QCR84 SCREW-SPECIAL 6009-001540
QCW01 ASSY COVER-CAMERA DOOR GH98-06439A
QCW02 ASSY COVER-CAMERA DOOR GH98-06758A
QFL01 ASSY CASE-LOWER GH98-06258A
QFR01 ASSY CASE-FRONT GH98-06259A
QFU01 ASSY CASE-UPPER GH98-06257A
QHI01 ASSY HINGE GH98-06262A
QHI05 ASSY COVER-LINK UNIT GH98-06573A
QIF01 PMO COVER-IF GH72-44289A
QKP01 ASSY KEYPAD-MAIN(OPEN/SIL) GH98-06264A
QKP02 ASSY KEYPAD-SUB(OPEN/SIL) GH98-06265A
QLC01 LCD-MODULE SGHG800 GH07-01200A
QME01 UNIT-SGHG800 3X4 DOME SHEET 12 GH59-04676A
QMI01 MICROPHONE-ASSY-SGHG800 GH30-00423A
QMO01 MOTOR DC-SGHG800 GH31-00400A
QMP01 PBA MAIN-SGHG800 GH92-03759A
QMW01 PMO WINDOW-MAIN GH72-44284A
QPC01 FPC-SGHG800 SLIDE FPCB GH41-01789A
QPC02 FPC-SGHG800 VGA FPCB GH41-01898A
QRE01 ASSY CASE-REAR GH98-06261A
QRF01 TAPE-SHEET RF JACK GH74-35277A
QSD01 PMO COVER-SD GH72-44287A
QSH01 NPR SHIELD-CAN A GH71-07770A
QSH02 NPR SHIELD-CAN B GH71-07771A
QSP01 SPEAKER 3001-002246
QVK01 KEY FPCB-SIDE VOL 2 KEY FPCB GH59-04678A
5-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Exploded View and Parts List
Description SEC CODE
BAG PE 6902-000634
CBF INTERFACE-DLC APCBS10BSE ( GH39-00922B
ADAPTOR-ATADS10ESE,SIL,EU GH44-01702B
S/W CD-SGHG800 PC STUDIO 3.2 GH46-00555A
EARPHONE-B-TYPE GH59-04557B
LABEL(P)-UNIT SEAL GH68-00518B
LABEL(P)-IMEI GH68-01335D
LABEL(R)-WATER SOAK GH68-09361A
MANUAL USERS-EU ENGLISH GH68-16188A
MANUAL USERS-EU DUTCH GH68-16189A
LABEL(R)-MAIN(EU) GH68-16381A
BOX(P)-UNIT MAIN(EU_NEW) GH69-06157A
CUSHION-CASE_EU_SLIM GH69-06194A
TAPE INSU GH74-35281A
SPONGE-SIM PLATE GH74-35290A
VINYL-UPPER PROTECTION GH74-35331A
VINYL-BOHO LCD PROTECTION GH74-35373A
TAPE-SUN BLOCK GH74-35489A
TAPE GASK-LCD GH74-35644A
TAPE GASK-LCD DOMESHEET GH74-35645A
TAPE-ABSORBER MAIN BOT GH74-36060A
TAPE INSU-BOT GH74-36061A
TAPE INSU-ABSORBER GH74-36062A
TAPE GASK-LOGIC GH74-36483A
TAPE GASK-T-FLASH GH74-36623A
VINYL-BOHO MAIN WINDOW GH74-36624A
TAPE GASK-FRONT GH74-36712A
5-3
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Exploded View and Parts List
5-4
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
6. MAIN Electrical Parts List
SEC CODE Design LOC Discription STATUS
0403-001547 ZD603 DIODE-ZENER SA
0403-001547 ZD604 DIODE-ZENER SA
0404-001172 D300 DIODE-SCHOTTKY SA
0404-001172 D301 DIODE-SCHOTTKY SA
0404-001172 D302 DIODE-SCHOTTKY SA
0406-001241 ZD600 DIODE-TVS SA
0406-001241 ZD601 DIODE-TVS SA
0406-001254 ZD501 DIODE-TVS SA
0407-001002 D400 DIODE-ARRAY SA
0504-001113 TR300 TR-DIGITAL SA
0504-001113 TR400 TR-DIGITAL SA
0601-002268 LED600 LED SA
0601-002268 LED601 LED SA
0904-002262 U301 IC-USC SA
1001-001438 U300 IC-ANALOG SWITCH SA
1001-001447 U605 IC-ANALOG MULTIPLEX SA
1009-001032 U701 IC-HALL EFFECT S/W SA
1108-000106 UME300 IC-MCP SA
1201-002531 PAM200 IC-POWER AMP SA
1201-002570 PAM100 IC-POWER AMP SA
1201-002615 U501 IC-AUDIO AMP SA
1203-003523 U700 IC-POSI.FIXED REG. SA
1203-003688 U609 IC-POSI.FIXED REG. SA
1203-003715 U601 IC-MULTI REG. SA
1203-003737 U600 IC-POSI.FIXED REG. SA
1203-003787 U607 IC-POSI.FIXED REG. SA
1203-004338 U608 IC-POSI.FIXED REG. SA
1203-004373 U503 IC-POSI.FIXED REG. SA
1203-004428 U604 IC-MULTI REG. SA
1203-004460 U603 IC-MULTI REG. SA
1203-004518 U401 IC-BATTERY SA
1203-004548 U602 IC-DC/DC CONVERTER SA
1203-004926 U400 IC-POWER SUPERVISOR SA
1204-002746 U502 IC-TUNER SA
1205-002686 U606 IC-SWITCH SA
1205-002942 U100 IC-TRANSCEIVER SA
6-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
1205-003285 U200 IC-TRANSCEIVER SA
1205-003342 UCP300 IC-MODEM SA
1404-001224 VR300 THERMISTOR-NTC SA
1405-001110 VR704 VARISTOR SA
1405-001133 VR400 VARISTOR SA
1405-001133 VR700 VARISTOR SA
1405-001133 VR701 VARISTOR SA
1405-001133 VR702 VARISTOR SA
1405-001133 VR703 VARISTOR SA
1405-001133 VR705 VARISTOR SA
1405-001133 VR706 VARISTOR SA
1405-001133 VR708 VARISTOR SA
1405-001133 VR709 VARISTOR SA
1405-001133 VR710 VARISTOR SA
1405-001133 VR711 VARISTOR SA
1405-001177 VR401 VARISTOR SA
1405-001177 VR402 VARISTOR SA
2007-000138 R703 R-CHIP SA
2007-000138 R704 R-CHIP SA
2007-000138 R705 R-CHIP SA
2007-000138 R706 R-CHIP SA
2007-000138 R717 R-CHIP SA
2007-000143 R330 R-CHIP SA
2007-000143 R331 R-CHIP SA
2007-000144 R404 R-CHIP SA
2007-000145 R333 R-CHIP SA
2007-000148 R309 R-CHIP SA
2007-000148 R311 R-CHIP SA
2007-000148 R340 R-CHIP SA
2007-000148 R341 R-CHIP SA
2007-000148 R402 R-CHIP SA
2007-000148 R510 R-CHIP SA
2007-000148 R713 R-CHIP SA
2007-000151 R427 R-CHIP SA
2007-000157 R403 R-CHIP SA
2007-000157 R606 R-CHIP SA
6-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2007-000157 R615 R-CHIP SA
2007-000162 R411 R-CHIP SA
2007-000162 R423 R-CHIP SA
2007-000162 R425 R-CHIP SA
2007-000162 R508 R-CHIP SA
2007-000162 R509 R-CHIP SA
2007-000164 R112 R-CHIP SA
2007-000165 R413 R-CHIP SA
2007-000169 R424 R-CHIP SA
2007-000170 R113 R-CHIP SA
2007-000171 R101 R-CHIP SA
2007-000171 R110 R-CHIP SA
2007-000171 R114 R-CHIP SA
2007-000171 R303 R-CHIP SA
2007-000171 R342 R-CHIP SA
2007-000171 R343 R-CHIP SA
2007-000171 R347 R-CHIP SA
2007-000171 R348 R-CHIP SA
2007-000171 R400 R-CHIP SA
2007-000171 R401 R-CHIP SA
2007-000171 R408 R-CHIP SA
2007-000171 R428 R-CHIP SA
2007-000171 R504 R-CHIP SA
2007-000171 R701 R-CHIP SA
2007-000171 R702 R-CHIP SA
2007-000171 R715 R-CHIP SA
2007-000171 R718 R-CHIP SA
2007-000171 R719 R-CHIP SA
2007-000171 R720 R-CHIP SA
2007-000172 R332 R-CHIP SA
2007-000242 R500 R-CHIP SA
2007-000242 R501 R-CHIP SA
2007-000982 R426 R-CHIP SA
2007-001119 R514 R-CHIP SA
2007-001119 R515 R-CHIP SA
2007-001285 R200 R-CHIP SA
6-3
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2007-001285 R204 R-CHIP SA
2007-001292 R607 R-CHIP SA
2007-001292 R608 R-CHIP SA
2007-001298 R105 R-CHIP SA
2007-001298 R407 R-CHIP SA
2007-001305 R107 R-CHIP SA
2007-001305 R108 R-CHIP SA
2007-003006 R506 R-CHIP SA
2007-003006 R507 R-CHIP SA
2007-007009 R208 R-CHIP SA
2007-007014 R412 R-CHIP SA
2007-007014 R414 R-CHIP SA
2007-007135 R336 R-CHIP SA
2007-007306 R103 R-CHIP SA
2007-007306 R104 R-CHIP SA
2007-007317 R502 R-CHIP SA
2007-007317 R511 R-CHIP SA
2007-007317 R512 R-CHIP SA
2007-007321 R102 R-CHIP SA
2007-007468 R410 R-CHIP SA
2007-007741 R611 R-CHIP SA
2007-007766 R323 R-CHIP SA
2007-008045 R207 R-CHIP SA
2007-008045 R210 R-CHIP SA
2007-008045 R211 R-CHIP SA
2007-008045 R212 R-CHIP SA
2007-008045 R716 R-CHIP SA
2007-008045 R722 R-CHIP SA
2007-008045 R723 R-CHIP SA
2007-008055 R416 R-CHIP SA
2007-008419 R601 R-CHIP SA
2007-008419 R602 R-CHIP SA
2007-008419 R604 R-CHIP SA
2007-008419 R605 R-CHIP SA
2007-008483 R417 R-CHIP SA
2007-008483 R418 R-CHIP SA
6-4
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2007-008483 R419 R-CHIP SA
2007-008483 R420 R-CHIP SA
2007-008483 R421 R-CHIP SA
2007-008516 R106 R-CHIP SA
2007-008516 R304 R-CHIP SA
2007-008516 R305 R-CHIP SA
2007-008516 R312 R-CHIP SA
2007-008516 R313 R-CHIP SA
2007-008516 R337 R-CHIP SA
2007-008516 R609 R-CHIP SA
2007-008531 R205 R-CHIP SA
2007-008542 R209 R-CHIP SA
2007-008542 R338 R-CHIP SA
2007-008542 R616 R-CHIP SA
2007-008542 R617 R-CHIP SA
2007-008542 R708 R-CHIP SA
2007-008542 R721 R-CHIP SA
2007-008544 R206 R-CHIP SA
2007-008548 R603 R-CHIP SA
2007-008588 R307 R-CHIP SA
2007-008588 R308 R-CHIP SA
2007-008647 R202 R-CHIP SA
2007-008774 R201 R-CHIP SA
2007-008774 R203 R-CHIP SA
2007-008806 R213 R-CHIP SA
2007-008806 R321 R-CHIP SA
2007-009084 R300 R-CHIP SA
2007-009115 R306 R-CHIP SA
2007-009167 R334 R-CHIP SA
2007-009212 R335 R-CHIP SA
2007-009408 R109 R-CHIP SA
2203-000233 C412 C-CER,CHIP SA
2203-000233 C526 C-CER,CHIP SA
2203-000278 C120 C-CER,CHIP SA
2203-000278 C123 C-CER,CHIP SA
2203-000278 C346 C-CER,CHIP SA
6-5
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2203-000278 C347 C-CER,CHIP SA
2203-000278 C506 C-CER,CHIP SA
2203-000278 C508 C-CER,CHIP SA
2203-000386 C124 C-CER,CHIP SA
2203-000386 C406 C-CER,CHIP SA
2203-000386 C407 C-CER,CHIP SA
2203-000438 C531 C-CER,CHIP SA
2203-000812 C439 C-CER,CHIP SA
2203-000812 C440 C-CER,CHIP SA
2203-000812 C442 C-CER,CHIP SA
2203-000812 C504 C-CER,CHIP SA
2203-000812 C507 C-CER,CHIP SA
2203-000812 C515 C-CER,CHIP SA
2203-000812 C537 C-CER,CHIP SA
2203-000812 C538 C-CER,CHIP SA
2203-000812 C539 C-CER,CHIP SA
2203-000812 C540 C-CER,CHIP SA
2203-000854 C400 C-CER,CHIP SA
2203-000854 C501 C-CER,CHIP SA
2203-000854 C503 C-CER,CHIP SA
2203-000854 C511 C-CER,CHIP SA
2203-000854 C516 C-CER,CHIP SA
2203-000940 C122 C-CER,CHIP SA
2203-000995 C709 C-CER,CHIP SA
2203-000995 C723 C-CER,CHIP SA
2203-002709 C332 C-CER,CHIP SA
2203-002709 C409 C-CER,CHIP SA
2203-002709 C410 C-CER,CHIP SA
2203-002709 C434 C-CER,CHIP SA
2203-002709 C435 C-CER,CHIP SA
2203-002709 C436 C-CER,CHIP SA
2203-002709 C437 C-CER,CHIP SA
2203-002709 C534 C-CER,CHIP SA
2203-002709 C535 C-CER,CHIP SA
2203-002709 C536 C-CER,CHIP SA
2203-002709 C708 C-CER,CHIP SA
6-6
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2203-005234 C253 C-CER,CHIP SA
2203-005234 C254 C-CER,CHIP SA
2203-005234 C255 C-CER,CHIP SA
2203-005288 C101 C-CER,CHIP SA
2203-005383 C718 C-CER,CHIP SA
2203-005383 C719 C-CER,CHIP SA
2203-005481 C514 C-CER,CHIP SA
2203-005481 C518 C-CER,CHIP SA
2203-005482 C339 C-CER,CHIP SA
2203-005482 C340 C-CER,CHIP SA
2203-005482 C441 C-CER,CHIP SA
2203-005482 C505 C-CER,CHIP SA
2203-005482 C510 C-CER,CHIP SA
2203-005482 C532 C-CER,CHIP SA
2203-005482 C615 C-CER,CHIP SA
2203-005482 C618 C-CER,CHIP SA
2203-005482 C620 C-CER,CHIP SA
2203-005482 C621 C-CER,CHIP SA
2203-005482 C626 C-CER,CHIP SA
2203-005682 C100 C-CER,CHIP SA
2203-005682 C107 C-CER,CHIP SA
2203-005682 C108 C-CER,CHIP SA
2203-005682 C109 C-CER,CHIP SA
2203-005682 C110 C-CER,CHIP SA
2203-005682 C126 C-CER,CHIP SA
2203-005682 C242 C-CER,CHIP SA
2203-005682 C349 C-CER,CHIP SA
2203-005682 C445 C-CER,CHIP SA
2203-005682 C446 C-CER,CHIP SA
2203-005682 C447 C-CER,CHIP SA
2203-005682 C448 C-CER,CHIP SA
2203-005682 C449 C-CER,CHIP SA
2203-005682 C450 C-CER,CHIP SA
2203-005682 C602 C-CER,CHIP SA
2203-005682 C603 C-CER,CHIP SA
2203-005682 C703 C-CER,CHIP SA
6-7
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2203-005682 C704 C-CER,CHIP SA
2203-005719 C112 C-CER,CHIP SA
2203-005719 C333 C-CER,CHIP SA
2203-005725 C210 C-CER,CHIP SA
2203-005725 C219 C-CER,CHIP SA
2203-005725 C224 C-CER,CHIP SA
2203-005725 C234 C-CER,CHIP SA
2203-005725 C251 C-CER,CHIP SA
2203-005725 C252 C-CER,CHIP SA
2203-005725 C604 C-CER,CHIP SA
2203-005725 C605 C-CER,CHIP SA
2203-005725 C606 C-CER,CHIP SA
2203-005726 C214 C-CER,CHIP SA
2203-005726 C245 C-CER,CHIP SA
2203-005727 C204 C-CER,CHIP SA
2203-005727 C243 C-CER,CHIP SA
2203-005729 C231 C-CER,CHIP SA
2203-005736 C111 C-CER,CHIP SA
2203-005736 C218 C-CER,CHIP SA
2203-005736 C225 C-CER,CHIP SA
2203-005736 C250 C-CER,CHIP SA
2203-005736 C348 C-CER,CHIP SA
2203-005736 C405 C-CER,CHIP SA
2203-005736 C408 C-CER,CHIP SA
2203-005739 C352 C-CER,CHIP SA
2203-005739 C353 C-CER,CHIP SA
2203-005740 C208 C-CER,CHIP SA
2203-005740 C232 C-CER,CHIP SA
2203-005742 C206 C-CER,CHIP SA
2203-005742 C207 C-CER,CHIP SA
2203-005806 C211 C-CER,CHIP SNA
2203-005806 C230 C-CER,CHIP SNA
2203-005806 C240 C-CER,CHIP SNA
2203-005806 C301 C-CER,CHIP SNA
2203-005806 C302 C-CER,CHIP SNA
2203-005806 C306 C-CER,CHIP SNA
6-8
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2203-005806 C309 C-CER,CHIP SNA
2203-005806 C310 C-CER,CHIP SNA
2203-005806 C311 C-CER,CHIP SNA
2203-005806 C312 C-CER,CHIP SNA
2203-005806 C313 C-CER,CHIP SNA
2203-005806 C318 C-CER,CHIP SNA
2203-005806 C319 C-CER,CHIP SNA
2203-005806 C324 C-CER,CHIP SNA
2203-005806 C328 C-CER,CHIP SNA
2203-005806 C329 C-CER,CHIP SNA
2203-005808 C233 C-CER,CHIP SA
2203-006048 C113 C-CER,CHIP SA
2203-006048 C116 C-CER,CHIP SA
2203-006048 C118 C-CER,CHIP SA
2203-006048 C524 C-CER,CHIP SA
2203-006048 C525 C-CER,CHIP SA
2203-006048 C527 C-CER,CHIP SA
2203-006048 C528 C-CER,CHIP SA
2203-006194 C239 C-CER,CHIP SA
2203-006194 C241 C-CER,CHIP SA
2203-006194 C246 C-CER,CHIP SA
2203-006194 C307 C-CER,CHIP SA
2203-006194 C308 C-CER,CHIP SA
2203-006194 C316 C-CER,CHIP SA
2203-006194 C350 C-CER,CHIP SA
2203-006318 C127 C-CER,CHIP SA
2203-006318 C128 C-CER,CHIP SA
2203-006324 C238 C-CER,CHIP SA
2203-006348 C403 C-CER,CHIP SA
2203-006348 C438 C-CER,CHIP SA
2203-006399 C114 C-CER,CHIP SA
2203-006399 C323 C-CER,CHIP SA
2203-006399 C327 C-CER,CHIP SA
2203-006399 C426 C-CER,CHIP SA
2203-006399 C427 C-CER,CHIP SA
2203-006423 C217 C-CER,CHIP SA
6-9
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2203-006423 C220 C-CER,CHIP SA
2203-006423 C221 C-CER,CHIP SA
2203-006423 C222 C-CER,CHIP SA
2203-006423 C226 C-CER,CHIP SA
2203-006423 C227 C-CER,CHIP SA
2203-006423 C228 C-CER,CHIP SA
2203-006423 C229 C-CER,CHIP SA
2203-006423 C303 C-CER,CHIP SA
2203-006423 C304 C-CER,CHIP SA
2203-006423 C305 C-CER,CHIP SA
2203-006423 C314 C-CER,CHIP SA
2203-006423 C315 C-CER,CHIP SA
2203-006423 C317 C-CER,CHIP SA
2203-006423 C320 C-CER,CHIP SA
2203-006423 C321 C-CER,CHIP SA
2203-006423 C322 C-CER,CHIP SA
2203-006423 C325 C-CER,CHIP SA
2203-006423 C326 C-CER,CHIP SA
2203-006423 C330 C-CER,CHIP SA
2203-006423 C344 C-CER,CHIP SA
2203-006423 C414 C-CER,CHIP SA
2203-006423 C416 C-CER,CHIP SA
2203-006439 C212 C-CER,CHIP SNA
2203-006439 C213 C-CER,CHIP SNA
2203-006462 C334 C-CER,CHIP SA
2203-006466 C608 C-CER,CHIP SA
2203-006556 C106 C-CER,CHIP SA
2203-006562 C216 C-CER,CHIP SA
2203-006562 C338 C-CER,CHIP SA
2203-006562 C341 C-CER,CHIP SA
2203-006562 C342 C-CER,CHIP SA
2203-006562 C343 C-CER,CHIP SA
2203-006562 C351 C-CER,CHIP SA
2203-006562 C417 C-CER,CHIP SA
2203-006562 C443 C-CER,CHIP SA
2203-006562 C521 C-CER,CHIP SA
6-10
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2203-006562 C530 C-CER,CHIP SA
2203-006562 C533 C-CER,CHIP SA
2203-006562 C600 C-CER,CHIP SA
2203-006562 C601 C-CER,CHIP SA
2203-006562 C612 C-CER,CHIP SA
2203-006562 C613 C-CER,CHIP SA
2203-006562 C614 C-CER,CHIP SA
2203-006562 C617 C-CER,CHIP SA
2203-006562 C623 C-CER,CHIP SA
2203-006562 C625 C-CER,CHIP SA
2203-006562 C627 C-CER,CHIP SA
2203-006562 C628 C-CER,CHIP SA
2203-006562 C701 C-CER,CHIP SA
2203-006562 C706 C-CER,CHIP SA
2203-006562 C707 C-CER,CHIP SA
2203-006562 C724 C-CER,CHIP SA
2203-006620 C200 C-CER,CHIP SNA
2203-006620 C201 C-CER,CHIP SNA
2203-006620 C202 C-CER,CHIP SNA
2203-006620 C203 C-CER,CHIP SNA
2203-006668 C335 C-CER,CHIP SA
2203-006681 C401 C-CER,CHIP SA
2203-006681 C444 C-CER,CHIP SA
2203-006681 C522 C-CER,CHIP SA
2203-006681 C607 C-CER,CHIP SA
2203-006824 C402 C-CER,CHIP SA
2203-006824 C404 C-CER,CHIP SA
2203-006824 C431 C-CER,CHIP SA
2203-006824 C432 C-CER,CHIP SA
2203-006824 C433 C-CER,CHIP SA
2203-006839 C105 C-CER,CHIP SA
2203-006839 C428 C-CER,CHIP SA
2203-006839 C429 C-CER,CHIP SA
2203-006839 C430 C-CER,CHIP SA
2203-006839 C523 C-CER,CHIP SA
2203-006839 C609 C-CER,CHIP SA
6-11
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2203-006839 C702 C-CER,CHIP SA
2203-006872 C115 C-CER,CHIP SA
2203-006872 C117 C-CER,CHIP SA
2203-006872 C119 C-CER,CHIP SA
2203-006872 C209 C-CER,CHIP SA
2203-006872 C300 C-CER,CHIP SA
2203-006872 C418 C-CER,CHIP SA
2203-006872 C419 C-CER,CHIP SA
2203-006872 C422 C-CER,CHIP SA
2203-006872 C423 C-CER,CHIP SA
2203-006872 C424 C-CER,CHIP SA
2203-006872 C502 C-CER,CHIP SA
2203-006872 C509 C-CER,CHIP SA
2203-006872 C529 C-CER,CHIP SA
2203-006872 C624 C-CER,CHIP SA
2203-006872 C700 C-CER,CHIP SA
2203-006872 C711 C-CER,CHIP SA
2203-006872 C712 C-CER,CHIP SA
2203-006872 C714 C-CER,CHIP SA
2203-006872 C715 C-CER,CHIP SA
2203-006872 C716 C-CER,CHIP SA
2203-006979 C237 C-CER,CHIP SA
2203-006979 C705 C-CER,CHIP SA
2203-006994 C215 C-CER,CHIP SA
2203-007147 C411 C-CER,CHIP SA
2203-007165 C205 C-CER,CHIP SA
2203-007165 C413 C-CER,CHIP SA
2203-007165 C415 C-CER,CHIP SA
2203-007165 C420 C-CER,CHIP SA
2203-007165 C421 C-CER,CHIP SA
2203-007165 C425 C-CER,CHIP SA
2203-007165 C610 C-CER,CHIP SA
2203-007165 C611 C-CER,CHIP SA
2203-007165 C616 C-CER,CHIP SA
2203-007165 C619 C-CER,CHIP SA
2203-007165 C622 C-CER,CHIP SA
6-12
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Main Electrical Parts List
SEC CODE Design LOC Discription STATUS
2203-007165 C710 C-CER,CHIP SA
2404-001381 TA100 C-TA,CHIP SA
2404-001381 TA200 C-TA,CHIP SA
2404-001381 TA600 C-TA,CHIP SA
2404-001381 TA602 C-TA,CHIP SA
2404-001381 TA603 C-TA,CHIP SA
2404-001411 TA601 C-TA,CHIP SA
2703-001749 L206 INDUCTOR-SMD SA
2703-002495 L604 INDUCTOR-SMD SA
2703-002506 L114 INDUCTOR-SMD SA
2703-002506 L205 INDUCTOR-SMD SA
2703-002649 L104 INDUCTOR-SMD SNA
2703-002649 L105 INDUCTOR-SMD SNA
2703-002795 L103 INDUCTOR-SMD SNA
2703-002795 L106 INDUCTOR-SMD SNA
2703-002798 L200 INDUCTOR-SMD SNA
2703-002798 L201 INDUCTOR-SMD SNA
2703-002870 L100 INDUCTOR-SMD SA
2703-002900 L109 INDUCTOR-SMD SA
2703-002907 L101 INDUCTOR-SMD SNA
2703-002907 L102 INDUCTOR-SMD SNA
2703-002917 L202 INDUCTOR-SMD SA
2703-002917 L204 INDUCTOR-SMD SA
2703-002919 L203 INDUCTOR-SMD SA
2703-003273 L606 INDUCTOR-SMD SA
2703-003292 L400 INDUCTOR-SMD SA
2703-003292 L401 INDUCTOR-SMD SA
2703-003292 L402 INDUCTOR-SMD SA
2801-004455 OSC100 CRYST◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
