Image preview - the first page of the document
>> Download Samsung SGH-T629 service manual documenatation <<
Text preview - extract from the document
GSM TELEPHONE
SGH-T629
GSM TELEPHONE CONTENTS
1. Safety Precautions
2. General Introduction
3. Specification
4. Product Funtion
5. Circuit Description
6. Test Command & Test Procedure
7. Array course control
8. Exploded View and its Parts list
9. MAIN Electrical Parts List
10. Flow Chart of Troubleshooting and
Circuit Diagrams
11. PCB Diagrams
12. Block Diagrams
13. Reference data
This Service Manual is a property of Samsung Electronics Co.,Ltd. Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law. Code No.: GH68-12035A
2006. 08. Rev.1.0
Contents
1. Safety Precautions
1-1. Repair Precaution ...........................................................................1-1
1-2. ESD(Electrostatically Sensitive Devices) Precaution ...........................1-2
2. General Introduction
3. Specification
3-1. GSM General Specification ..............................................................3-1
3-2. GSM TX Power class ......................................................................3-2
3-3. EDGE TX Poser Level .....................................................................3-3
4. Product Function
4-1. Main Function ................................................................................4-1
5. Circuit Description
6. TEST Command & Test Procedure
6-1. Calibration Equipment ....................................................................6-1
6-2. Calibration Program .......................................................................6-1
6-3. TX Power Tune up procedure .........................................................6-2
7. Array course control
7-1. Downloading Binary Files ................................................................7-2
7-2. Pre-requsite for Downloading ..........................................................7-2
7-3. S/W Downloader Program ...............................................................7-3
7-4. How to Download ..........................................................................7-5
8. Exploded View and its Parts list
8-1. Cellular phone Exploded View .........................................................8-1
8-2. Cellular phone parts list .................................................................8-2
8-3. Disassembly ..................................................................................8-4
8-4. Assembly ......................................................................................8-7
Contents
9. MAIM Electrical parts list
10. Flow Chart of Troubleshooting and Circuit Diagrams
10-1. Baseband
10-1-1. Power on ..............................................................................10-1
10-1-2. Initial ....................................................................................10-3
10-1-3. Sim Part ...............................................................................10-4
10-1-4. Charging Part ........................................................................10-5
10-1-5. Microphone Part .....................................................................10-7
10-1-6. Speaker Part .........................................................................10-9
10-1-7. Camera Part ........................................................................10-13
10-2. RF
10-2-1. GSM850/EGSM900 RX ..........................................................10-15
10-2-2. PCS RX ...............................................................................10-16
10-2-3. DCS RX ...............................................................................10-17
10-2-4. GSM850/EGSM900 TX ...........................................................10-18
10-2-5. DCS/PCS TX ........................................................................10-19
10-2-6. BLUETOOTH .........................................................................10-20
11. PCB Diagrams
12. Block Diagrams
12-1. RF Solution Block Diagram ..........................................................12-1
12-2. Base Band Solution Block Diagram ..............................................12-2
13. Reference data
1. Safety Precautions
1-1. Repair Precaution
Repair in Shield Box, during detailed tuning.
Take specially care of tuning or test,
because specipicty of cellular phone is sensitive for surrounding interference(RF noise).
Be careful to use a kind of magnetic object or tool,
because performance of parts is damaged by the influence of magnetic force.
Surely use a standard screwdriver when you disassemble this product,
otherwise screw will be worn away.
Use a thicken twisted wire when you measure level.
A thicken twisted wire has low resistance, therefore error of measurement is few.
Repair after separate Test Pack and Set because for short danger (for example an
overcurrent and furious flames of parts etc) when you repair board in condition of
connecting Test Pack and tuning on.
Take specially care of soldering, because Land of PCB is small and weak in heat.
Surely tune on/off while using AC power plug, because a repair of battery charger is
dangerous when tuning ON/OFF PBA and Connector after disassembing charger.
Don't use as you pleases after change other material than replacement registered on
SEC System.
Otherwise engineer in charge isn't charged with problem that you don't keep this rules.
1-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Safety Precautions
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Several semiconductor may be damaged easily by static electricity. Such parts are called by
ESD(Electrostatically Sensitive Devices), for example IC, BGA chip etc. Read Precaution below.
You can prevent from ESD damage by static electricity.
Remove static electricity remained your body before you touch semiconductor or parts with
semiconductor. There are ways that you touch an earthed place or wear static electricity
prevention string on wrist.
Use earthed soldering steel when you connect or disconnect ESD.
Use soldering removing tool to break static electricity. otherwise ESD will be damaged by
static electricity.
Don't unpack until you set up ESD on product. Because most of ESD are packed by box
and aluminum plate to have conductive power,they are prevented from static electricity.
You must maintain electric contact between ESD and place due to be set up until ESD is
connected completely to the proper place or a circuit board.
1-2
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
2. General Introduction
The SGH-T629 Quad Band phone functions as digital phone working in GSM
(Global System for Mobile communications)850,EGSM900, DCS1800 and
PCS(PersonalCommunication System)1900 modes.
Dimension : 99 x 51 x 13.9 mm (with Standard Battery)
Weight : 99g (with Standard Battery)
LCD : LCD 262K TFT Color LCD (176 x 220) 2.1"
R/F band : GSM850 / EGSM 900 / DCS1800 / PCS1900
Vocoder : EFR + FR + HR + AMR
Antenna : Fixed type
SIM : 3 Voltage operation
BLUETOOTH : VER 1.2
MS Class : Class B
GPRS Phase : GSM Phase II+
Multi-slot : GPRS/EGPRS Class 10 (2 Up-link, 4 Down-link, 5 Sum)
SMG : SMG #31
Coding scheme : CS1 - CS4(GPRS), MCS5 - MCS9(EGPRS) support
Power class : GSM850 - Class 4 (2W)
EGSM900 - Class 4 (2W)
DCS1800 - Class 1 (1W)
PCS1900 - Class 1 (1W)
WAP 2.0 Browser
SIM AT(Application Toolkit)
40 Polyphonic Ringtone
< Basic Package >
Handset + Standard Battery + Ear Microphone + User Guide
< Option Item >
Travel Adapter
Bluetooth Headset
Bluetooth Hands Free Kit
Car Charger/Adapter
2-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
3. Specification
3-1. GSM General Specification
GSM850 EGSM900 DCS1800 PCS1900
F r e q . Ba n d [ M Hz ] 824~849 880~915 1710~1785 1850~1910
Uplink/ Downlink 869~894 925~960 1805~1880 1930~1990
0~124&
A RFCN rang e 128~251 512~885 512~810
975~1023
T x /Rx s pacing 45 MHz 45 MHz 95 MHz 80 M Hz
270.833 Kb ps 270.833 Kb ps 270.833 Kb ps 270.833 Kbp s
GP RS
Mod. Bit 3. 692 us 3. 692 us 3. 692 us 3.692 us
r ate/
Bit P eriod 812.5 K b ps 812.5 K b ps 812.5 K b ps 812.5 K bp s
EDGE
3. 692 us 3. 692 us 3. 692 us 3.692 us
Time Slot 576. 9 u s 576. 9 u s 576. 9 u s 576.9 u s
Period/ Fr ame Period 4.615 ms 4.615 ms 4.615 ms 4.615 ms
GP RS 0.3 G M SK 0.3 G M SK 0.3 G M SK 0.3 G MS K
Modu lation
EDGE 8 PSK 8 PSK 8 PSK 8 PSK
GP RS 33 d Bm~5 d Bm 33 d Bm~5 d Bm 30 d Bm~0 d Bm 30 dBm~0 d Bm
M S P o wer
ED G E 27~5 dBm 27~5 dBm 26~0 dBm 26~0 dBm
GP RS 5~19(class4) 5~19(class4) 0~15(class1) 0~15(class1)
P ower L evel
ED G E 8~19( class E 2) 8~19( class E 2) 2~15(class E2) 2~15(class E2)
Sens itivity - 102 dBm - 102 dBm - 100 dBm -102 d Bm
T D MA Mux 8 8 8 8
Cell Radius 35 Km 35 Km 2 Km 2 Km
3-1
SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Specification
3-2. GSM TX power class
TX TX TX TX
Power Power Power Power
GSM850 EGSM900 DCS1800 control PCS1900
control control control
level level level level
