Image preview - the first page of the document



>> Download Samsung-GT-I8190-Service-Manual-r1-0 documenatation <<

Text preview - extract from the document

                GSM TELEPHONE
                GT-I8190




GSM TELEPHONE                       CONTENTS


                  1.   Safety Precautions
                  2.   Specification
                  3.   Product Function
                  4.   Exploded View and Parts list
                  5.   MAIN Electrical Parts List
                  6.   Level 1 Repair
                  7.   Level 2 Repair
                  8.   Level 3 Repair
                  9.   Reference data
                  Notice: All functionality, features, specifications, and
                  other product information provided in this document,
                  including but not limited to, benefits, design, pricing,
                  components, performance, availability, and capabiliti
                  -es of the product are subject to change without
                  notice. Samsung reserves the right to alter this doc
                  -ument or the product described herein at anytime,
                  without obligation to provide notification of such
                  changes.
1. Safety Precautions

1-1. Repair Precaution

   Before attempting any repair or detailed tuning, shield the device from RF noise or static
   electricity discharges.

   Use only demagnetized tools that are specifically designed for small electronic repairs,
   as most electronic parts are sensitive to electromagnetic forces.

   Use only high quality screwdrivers when servicing products. Low quality screwdrivers can
   easily damage the heads of screws.

   Use only conductor wire of the properly gauge and insulation for low resistance, because of
   the low margin of error of most testing equipment.
   We recommend 22-gauge twisted copper wire.

   Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily
   damaged, even with relatively low heat. Never use a soldering iron with a power rating of
   more than 100 watts and use only lead-free solder with a melting point below 250
