Image preview - the first page of the document
>> Download Product Specification documenatation <<
Text preview - extract from the document
2. Product Description
1. Specifications
HT-X20
5.1ch speaker system
Speaker system
Front/Center/Rear speaker Subwoofer speaker
S Impedance 3 x 5 3
P Frequency range 140Hz~20KHz 35Hz~160Hz
E Output sound pressure level 82dB/W/M 85dB/W/M
A Rated input 80W 100W
K Maximum input 160W 200W
E
Front/Rear 90 x 152x 90 mm 175 x 320 x 381 mm
R Dimensions (W x H x D)
Center 200 x 90 x 92 mm
Front/Rear 0.5 Kg/0.4 Kg
Weights 5.1 kg
Center 0.6 Kg
Samsung Electronics 2-1
2. Notes on discs
DVD (Digital Versatile Disc) offers fantastic audio and video, thanks to Dolby Digital sur-
VIDEO
round sound and MPEG-2 video compression technology. Now you can enjoy these realistic
effects in the home, as if you were in a movie theater or concert hall.
1 ~ 6 DVD players and the discs are coded by region. These regional codes must match in order
for the disc to play. If the codes do not match, the disc will not play.
The Region Number for this player is given on the rear panel of the player.
(Your DVD player will only play DVDs that are labeled with identical region codes.)
Playable Discs
Disc Type Mark (Logo) Recorded Signals Disc Size Max. Playing Time
Approx. 240 min. (single-sided)
12cm
Approx. 480 min. (double-sided)
DVD Audio + Video
Approx. 80 min. (single-sided)
8cm
Approx. 160 min. (double-sided)
COMPACT
12cm 74 min.
VIDEO-CD Audio + Video
DIGITAL VIDEO
8cm 20 min.
COMPACT 12cm 74 min.
AUDIO-CD Audio
DIGITAL AUDIO 8cm 20 min.
Do not use the following types of disc!
