Image preview - the first page of the document



>> Download Troubleshooting documenatation <<

Text preview - extract from the document

4. TROuBLESHOOTING

4-1. ERROR ITEMS AND DIAGNOSTIC CODES
AnoccurrenceofanErrorwillmakeasoundoferrormelodyfor5secandcontinuouslyshowoneoftheErrorDisplays
fromthefollowingerrors.

  Error Display                    Trigger                               Action Taken
                                                         Checkfor:
                  TheThermistorresistanceisverylowor     - Cloggedlintscreen.
       tE
                  high.                                  - Restricted vent system.
                                                         - CheckThermistorresistance.
                                                         Checkfor:
                                                         - Closethedoor,andrunthedryer.
       dE         Runningthedryerwithdooropen.
                                                         - LooseoropenwireterminalsinDoorSense
                                                           circuit.
                                                         Checkfor:
      bE2         Invalidstateofkey.
                                                         - DisplayPCBkeycircuitshortornot.
                                                         Checkfor:
       fE         InvalidpowersourceFrequency.           - Notusingregularpowersourcefrequency.
                                                         - Invalidpowerfrequencysensecircuit.
                                                         Checkfor:
                  ElectronicControlProblem.
      9E1                                                - CheckPCBandWireharness.
                  (OverVoltageError)
                                                         - CheckPowersupply.
                                                         Checkfor:
                  ElectronicControlProblem.
       AE                                                - CheckPCBandWireharness.
                  (CommunicationError)
                                                         - ReplacePCB.
                                                         Checkfor:
      EEE         InvalidstateofEepromcommunication.
                                                         - PCBwithEepromcircuit.
                                                         Checkfor:
       df         Invaliddoor.                           - LooseoropenwireterminalsinDoorSense
                                                           circuit.
                                                         Checkfor:
       HE         InvalidheatingTempinrunningthedryer.
                                                         - Callcustomerservice.




26 _ Troubleshooting
4-2. TEST MODE

 Data Display Mode
How to Enter:
DV455*
