Image preview - the first page of the document
>> Download Samsung Spinpoint F1 III documenatation <<
Text preview - extract from the document
Desktop Edition
Product Guide
Spinpoint F1
160GB / 250GB / 320GB / 400GB / 500GB / 750GB / 1TB
imagine a new era of Tera Byte storage
World's First Three-disk Solution
for Terabyte Storage
Better Reliability, Less Energy Special Features for High-density
Consumption than Other Options Applications
The Samsung Spinpoint F1 is the first three-disk Servers, high-end desktops, RAID systems and
hard drive delivering a whopping 1TB of capacity DVRs are among the applications well suited to the
along with sophisticated recording technology. Spinpoint F1 drive. The F1 Series is offered in
With its compact, lightweight package and desktop PC or RAID reliability. The RAID reliability
advanced design, the F1 drive offers many mean time between failures is up to 1.2 million
advantages for high-density applications hours. A rotational vibration sensor enables the
compared to using two 500GB drives or a four- or drive to operate more efficiently in a RAID
five-disk solution. Compared to a five-disk 1TB environment.
solution, the F1 Series consumes 13-16% less For consumer applications, a power-saving code
power and offers up to 20% faster performance. reduces power consumption while AV-optimized
This 3.0Gbps SATA drive has a maximum of firmware cuts time delays during AV data
334GB of formatted capacity per disk while also recording. In general, the Samsung drive offers a
featuring Samsung's industry-leading NoiseGuardTM superior combination of density, recording quality
and SilentSeekTM technologies to eliminate and reliability.
acoustic noise. The Spinpoint F1 utilizes Samsung
perpendicular recording technology, which helps
the drive set new records in both areal density and Key Features
platter capacity. ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
