Image preview - the first page of the document
TV_Features_Network_and_3D_Year_2012_Training_Manual.part1


>> Download TV_Features_Network_and_3D_Year_2012_Training_Manual.part1 documenatation <<

Text preview - extract from the document
2012 TV Features plus Network & 3D Operation & Troubleshooting




                                                                 1
The 2011 & 2012 LED Comparison Lineup is shown with some special items
highlighted in Blue
They include the new Interactive Smart TV Voice Motion Control for the LED E7500
& E8000 TVs.
New to 2012 is the LED Hybrid EH Models also shown.




                                                                                   2
The 2012 LED TVs include models with the new built in Camera/ Mic called the moIP
Module for Interactive Smart TV, Also shown are models with 3D Bluetooth, Built in WiFi,
Smart Web Browsing, Micro Dimming and other specifications.




                                                                                           3
2011 & 2012 PDP Comparison Lineup
Highlights:
E8000 has built in moIP (Camera/Mic), Hand Motion / Voice Control/ Facial Recognition for
signing into Samsung Web Account
E550 has new PenTile Plasma Screen.




                                                                                            4
The 2012 Plasma TV Features include models with Interactive Smart TV &
the built in moIP Camera/Mic Module, ...those with built in Wi-Fi, Allshare,
                                                            Wi-
and other features and specifications




                                                                               5
Important Model Code Information....
Product Type, Size, Year, Series... New for 2012: Hybrid "H" Slim "S"




                                                                        6
Important Serial Number Info
Model Code, Product, Factory, Production Line, Year/Month...
 "C" for 2012




                                                               7
A list of 2012 Models with significant changes...




                                                    8
An External Kit called Evolution is projected to be available in 2013 expanding E8000 LED &
Plasma TV capabilities




                                                                                              9
2012 Samsung TV Features




                           10
The moIP (mobile communications over internet protocol):
