Image preview - the first page of the document



>> Download MDD5N40-MagnaChip documenatation <<

Text preview - extract from the document

                                                                                                                                              MDI5N40 N-channel MOSFET 400V
                                                                                 MDI5N40/MDD5N40
                                                                       N-Channel MOSFET 400V, 3.4 A, 1.6

        General Description                                                  Features
        The MDI5N40 / MDD5N40 use advanced                                    VDS = 400V
        Magnachip's MOSFET Technology, which provides                         ID = 3.4A                   @VGS = 10V
        low on-state resistance, high switching performance                   RDS(ON)  1.6                @VGS = 10V
        and excellent quality.

        MDI5N40 is suitable device for SMPS, HID and
        general purpose applications.                                        Applications
                                                                              Power Supply
                                                                              PFC
                                                                              Ballast




                                                                                                                          D




                                                                  I-PAK
                                                            GDS   (TO-251)
                                                                                                   G




                                                                                                                          S




    Absolute Maximum Ratings (Ta = 25oC)
    Characteristics                                                                                    Symbol          Rating      Unit
      Drain-Source Voltage                                                                                VDSS           400            V
      Gate-Source Voltage                                                                                 VGSS
