Image preview - the first page of the document
>> Download 10_Exploded View & Part List documenatation <<
Text preview - extract from the document
5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LA15S51BP Exploded View
T0003
M0014
M0174
M0013
M0013
5-1
5 Exploded View & Parts List
5-2 LA15S51BP Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-01864B ASSY COVER P-FRONT;SP15EO,ABS,V0,GR70,SV 1 SA
M0174 BN44-00112B IP BOARD;SSIP-15-SP,Venice,3.0mA,6.7mA,5 1 SA
M0014 BN94-00747R ASSY PCB MAIN-ATZ;LA15S51BPX/SHI,PL215KE 1 SNA
M0013 BN96-01865D ASSY COVER P-REAR;SP15SO,HIPS,V0,GR86 1 SA
M0013 BN96-01867A ASSY STAND P-BASE;SPARTA 15,HIPS,HB,GR86 1 SA
5-2
5 Exploded View & Parts List
5-3 LS17M24CP Exploded View
T0003
M0215
M0174
M0013
M0014
M0003
5-3
5 Exploded View & Parts List
5-4 LS17M24CP Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-02097H ASSY COVER P-FRONT;PLUS,17EO,ABS,V0,BK19 1 SA
M0215 BN07-00214A LCD-PANEL;LTM170EU-L15,VENICE,6BIT FRC,3 1 SA
M0174 BN44-00125A IP BOARD;FSP049_2PI01,MH17ES,3.6~4.4mA,6 1 SA
M0014 BN94-00747W ASSY PCB MAIN-STZ;LS17M24CPX/SAP,PL17KE( 1 SNA
M0013 BN96-01256G ASSY COVER P-REAR;VC17SO,ABS V0,BK19 1 SA
M0003 BN96-01335A ASSY STAND P;VC17**,ABS HB 1 SA
5-4
5 Exploded View & Parts List
5-5 LA20S51BP Exploded View
T0003
M0215
M0014
M0174
M0013
M0013
5-5
5 Exploded View & Parts List
5-6 LA20S51BP Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-01625D ASSY COVER P-FRONT;SP20EO,SO(AUO),ABS,V0 1 S.A
M0215 BN07-00314A LCD-PANEL;A201SN02 V5,GY,6bit + FRC,448* 1 S.A
M0174 BN44-00115C IP BOARD;IP-51135T(V),Venice 20,4.0mA,6. 1 S.A
M0014 BN94-00987H ASSY PCB MAIN-ATZ;PL20*,AU PANEL 1 S.N.A
M0013 BN96-01624D ASSY COVER P-REAR;SP20SO,HIPS,V0,GR86 1 S.A
M0013 BN96-01626A ASSY STAND P-BASE;SPARTA 20,HIPS,HB,GR86 1 S.A
5-6
