5. Exploded View & Part List
5. Exploded View & Part List
5-1. LA22B45*** Exploded View
M0027
M0174
M0013
M0014
M0115
T0175
T0447
M0215
T0003
5-1
5. Exploded View & Part List
5-1-1. LA22B45*** Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-10015E ASSY COVER P-FRONT;LB450 22,XY,ABS+PMMA, 1 S.A
M0013 BN96-10022C ASSY COVER P-REAR;LB450 22,XY,HIPS,HB,BK 1 S.A
M0215 BN07-00620A LCD-PANEL;V216B1-L01 1 S.A
M0014 BN94-02734A ASSY PCB MAIN;LA22B450C4MXXY 1 S.A
T0447 BN96-10033E ASSY BRACKET P-PANEL;LB450 22,SO,LO,CMO, 1 S.N.A
M0174 BN44-00232A IP BOARD;IP-54135T,L650,1.4~2.8mA,6.8~8. 1 S.A
T0175 BN96-06823E ASSY SPEAKER P;16ohm,4pin,3W,R:400 / L:2 1 S.A
M0027 BN96-06463F ASSY STAND P-BASE;22,26L450,ABS+PMMA,HB, 1 S.A
5-2
5. Exploded View & Part List
5-2. LA26B45*** Exploded View
M0014
M0013
M0254
M0027
T0531
M0174
M0115
M0146
M0146
M0215
T0175
T0003
5-3
5. Exploded View & Part List
5-2-1. LA26B45*** Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-10017D ASSY COVER P-FRONT;LB450 26,XY,ABS+PMMA, 1 S.A
M0013 BN96-10025B ASSY COVER P-REAR;LB450 26,XY,HIPS,HB,BK 1 S.A
M0215 BN07-00638A LCD-PANEL;T260XW02 VS 1 S.A
M0174 BN44-00259B IP BOARD-IP;B109-701GP,H26HD_9DF,0.12mA, 1 S.N.A
M0146 BN61-05176A BRACKET-PANEL TOP;26inch,SECC,T1.2 2 S.N.A
M0146 BN61-05177A BRACKET-PANEL SIDE;26inch,SECC,T1.2 2 S.N.A
M0014 BN94-02734B ASSY PCB MAIN;LA26B450C4MXXY 1 S.A
M0254 BN61-04799A HOLDER-SIDE AV;B450/B530,HIPS,HB,BK500,1 1 S.N.A
T0175 BN96-06822H ASSY SPEAKER P;16ohm,4pin,5W,R:150 / L:3 1 S.A
T0531 BN63-04269B COVER-BOTTOM;22,26,32L450,HIPS,HB,BK500 1 S.A
M0115 BN61-04772A BRACKET-STAND LINK;B450 26inch,SECC 1 S.N.A
M0027 BN96-06463F ASSY STAND P-BASE;22,26L450,ABS+PMMA,HB, 1 S.A
5-4
5. Exploded View & Part List
5-3. LA32B45*** Exploded View
M0013
M0014
M0254
M0027
T0531
M0174
M0115
M0146
M0215
T0175
T0003
5-5
5. Exploded View & Part List
5-3-1. LA32B45*** Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-10019D ASSY COVER P-FRONT;LB450 32,XY,ABS+PMMA, 1 S.A
M0013 BN96-10027B ASSY COVER P-REAR;LB450 32,XY,HIPS,HB,BK 1 S.A
M0215 BN07-00674B LCD-PANEL;LTF320AP04 1 S.A
M0174 BN44-00260C IP BOARD;FSP118_3PI01,H32HD_9FS,0.12mA,1 1 S.A
M0146 BN61-04980A BRACKET-PANEL TOP;B550-3 32,SECC,T1.2 2 S.N.A
M0014 BN94-02734C ASSY PCB MAIN;LA32B450C4MXXY 1 S.A
M0254 BN61-04799A HOLDER-SIDE AV;B450/B530,HIPS,HB,BK500,1 1 S.N.A
T0175 BN96-09463A ASSY SPEAKER P;8ohm,4pin,10W,R:200 / L:4 1 S.A
T0531 BN63-05326B COVER-BOTTOM;LB450 32,HIPS,HB,BK500 1 S.A
M0115 BN61-04820A BRACKET-STAND LINK;B650-32,SECC,T1.2 1 S.N.A
M0027 BN96-06464A ASSY STAND P-BASE;32L450,,ABS+PMMA,HB,BK 1 S.A
5-6
5. Exploded View & Part List
5-4. LA22B45*** Parts List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
LA22B450C4DXXY LA22B450C4D,N65B/22AC4-G4C,22,LCD-TV,AUS
0.1 M0216 BN90-01510A ASSY STAND;22L450,UO,,, 1 S.N.A
..2 M0027 BN96-06463F ASSY STAND P-BASE;22,26L450,ABS+PMMA,HB, 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.N.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
...3 BN61-02954A BRACKET-STAND BOTTOM;23,26 BORDEAUX PLUS 1 S.N.A
...3 T0920 BN61-03680C GUIDE-STAND;22,26L450,ABS,V0(NT),BLK 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
...3 T0004 BN63-03122A COVER-STAND BASE;23,26R81,ABS+PMMA,-,-,- 1 S.N.A
...3 M0126 BN73-00052C RUBBER-FOOT;LCD TV,CR RUBBER,T2.0 DIA19, 4 S.N.A
0.1 M0001 BN90-02021E ASSY COVER FRONT;LB450 22 1 S.N.A
..2 T0175 BN96-06823E ASSY SPEAKER P;16ohm,4pin,3W,R:400 / L:2 1 S.A
..2 T0003 BN96-10015E ASSY COVER P-FRONT;LB450 22,XY,ABS+PMMA, 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0279 AA63-01637A FELT;50P9,FELT,0.5,10,80 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.47 S.N.A
...3 M0112 BN63-05234E COVER-FRONT;LB450 22,XY,ABS+PMMA,HB,BK23 1 S.N.A
...3 T0059 BN64-00379A INDICATOR LED;ROME-II,23,PC,CLEAR 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,VIOLET 1 S.N.A
...3 T0022 BN64-00755A KNOB-CONTROL;32L450,ABS,V0,BK07 1 S.N.A
...3 BN96-06792C ASSY HOLDER P-BOSS;22L450,HIPS,HB,BLK 1 S.N.A
....4 BN61-03261B BOSS-TAPE;Tulip,ACRYL,T1.1,W20mm,GRAY,TA 0.38 S.N.A
....4 BN61-03752C HOLDER-BOSS BOTTOM;22L450,HIPS,HB,BLK 1 S.N.A
...3 M0145 BN96-07269A ASSY BOARD P-FUNCTION;LN40A450C1D,CT5000 1 S.A
...3 T0714 BN96-10362B ASSY BOARD P-IR;LE46B530,1299-01201-02,F 1 S.A
...3 BN64-00986C DECORATION-BOTTOM;22,LB450,PC CLEAR 1 S.N.A
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.001 S.N.A
...3 CCM1 BN63-05199J COVER-SHEET;AMBER,PE,T0.08,W105mm,200M,C 1.98 S.N.A
0.1 M0002 BN90-02028C ASSY COVER REAR;LB450 22 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 3 S.N.A
..2 M0013 BN96-10022C ASSY COVER P-REAR;LB450 22,XY,HIPS,HB,BK 1 S.A
...3 T0069 AA60-00091M SPACER-FELT;-,FELT,35X10,-,-,BLK,T0.5,-, 4 S.N.A
...3 M0113 BN61-01581A BRACKET-VESA;BI17/19BS,SECC,T1.0 2 S.N.A
...3 M0006 BN63-05240C COVER-REAR;LB450 22,HIPS,HB,BK500 1 S.N.A
...3 T0071 BN64-01020C INLAY-TERMINAL;LB450 22,SO(DTV),PS SHEET 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,-,-,BLK,- 1 S.N.A
...3 T0069 AA63-00099E SPACER-FELT;L6,FELT,10,BLK,T0.5,20 4 S.N.A
0.1 M0019 BN91-03433B ASSY LCD;LN22B650T6FXZA 1 S.N.A
..2 M0215 BN07-00620A LCD-PANEL;V216B1-L01 1 S.A
0.1 M0017 BN91-03912A ASSY CHASSIS;LA22B450C4MXXY 1 S.N.A
..2 M0014 BN94-02734A ASSY PCB MAIN;LA22B450C4MXXY 1 S.A
...3 T0245 0202-001521 SOLDER-WIRE FLUX;ECO SOLDER RMA98 SUP,-, 0.25 S.N.A
5-7
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
...3 CN5001 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 CN330 3711-004379 HEADER-BOARD TO CABLE;BOX,4P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
...3 CN330 3711-004712 HEADER-BOARD TO CABLE;BOX,9P,1R,2mm,STRA 1 S.N.A
...3 CN330 3711-006715 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 S.N.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA333 3722-002143 JACK-PIN;5P,NI,GRN/BLU/RED/WHT/RED,STRAI 1 S.A
...3 CN6001 3722-002516 JACK-USB;4P/1C,AU30U,BLK,STRAIGHT,A TYPE 1 S.A
...3 JA333 3722-002691 JACK-PIN;2P,Ni,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002699 JACK-PIN;3P,Ni,YEL/WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002703 JACK-PIN;3P,Ni,GRN/BLU/RED,STRAIGHT 1 S.A
...3 CIS3 BN40-00137A TUNER;DNOQ403SH151A(S),DNOQ403SH151A(S), 1 S.A
...3 HDCP BN97-00688A ASSY HDCP;BN46-00018A,PS-42V6S,D73A,GENE 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-03281A ASSY SMD;LA22B450C4MXXY 1 S.N.A
....4 D3244 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D9006 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D5002 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D5005 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D5010 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D6009 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D6011 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D7028 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D7030 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D7031 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D7032 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D6100 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D9001 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D9002 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D9004 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D9005 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D9015 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D9016 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D10001 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D4001 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5001 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5003 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5004 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5006 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5007 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5008 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5009 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5011 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5012 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5013 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5014 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5016 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
5-8
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 D5017 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5100_FA 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5101_FA 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D6001 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D6002 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D6631 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7004 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7008 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7009 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7012 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7014 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7016 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7020_AUS 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7105 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7106 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7116 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D7202 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D9003 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D0254 0404-001271 DIODE-SCHOTTKY;SSA34,40V,3000mA,SMA,TP 1 S.A
....4 D6030 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 1 S.A
....4 D6005 0406-001299 DIODE-TVS;CM1224-04MR,MSOP-10 1 S.A
....4 D6007 0406-001299 DIODE-TVS;CM1224-04MR,MSOP-10 1 S.A
....4 D6032 0407-000114 DIODE-ARRAY;-,80V,100mA,CA2-3,SOT-23,TP 1 S.N.A
....4 D6034 0407-000114 DIODE-ARRAY;-,80V,100mA,CA2-3,SOT-23,TP 1 S.N.A
....4 Q1004 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q1005 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q1010 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q1011 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q1012 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q1013 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3002 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3109 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q4003_ANA 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q6003 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q7003 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q7006 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q7008 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q9005 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q7005 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 S.A
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 S.A
....4 IC104 0801-002198 IC-CMOS LOGIC;74LVC14,INVERTER,SOP,14P,1 1 S.A
....4 IC104 0801-002779 IC-CMOS LOGIC;74LVC1G125,BUS BUFFER,SOT- 1 S.N.A
....4 IC8002_DE 1006-001266 IC-LINE TRANSCEIVER;SP3232EEY,TSSOP,16P, 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-001441 IC-EEPROM;24C1024,1Mbit,128Kx8,SOP,8P,4. 1 S.A
....4 IC8005 1105-001931 IC-DDR2 SDRAM;K4T51163Q,DDR2-800,512Mbit 1 S.N.A
....4 IC8006 1105-001931 IC-DDR2 SDRAM;K4T51163Q,DDR2-800,512Mbit 1 S.N.A
5-9
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 IC115 1107-001777 IC-FLASH MEMORY;MX25L6405DMI-12G,64Mbit, 1 S.A
....4 T0085 1201-002487 IC-AUDIO AMP;MAX9728A,QFN,12P,3x3mm,DUAL 1 S.A
....4 T0124 1201-002797 IC-POWER AMP;NTP-3200,QFN,56P,8x8mm,DUAL 1 S.A
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,-,PLA 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC3002 1203-004363 IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P, 1 S.A
....4 IC9003 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC150 1203-005113 IC-SWITCH REG.;SPN030039Y,MSOP,10P,3x3mm 1 S.A
....4 IC150 1203-005113 IC-SWITCH REG.;SPN030039Y,MSOP,10P,3x3mm 1 S.A
....4 T0170 1203-005463 IC-SWITCH VOL. REG.;MIC2605YML,MLF,8P,2x 1 S.A
....4 IC4010 1204-002999 IC-DECODER;SEMS12-LF,LFBGA,375P,21x21mm, 1 S.A
....4 IC1002 1205-003479 IC-SWITCH;TPS2051BDBVR,SOT-23,5P,2.9x1.6 1 S.A
....4 IC6500 1205-003479 IC-SWITCH;TPS2051BDBVR,SOT-23,5P,2.9x1.6 1 S.A
....4 D3236 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3237 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3238 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D5015 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D5018 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D5019 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D5020 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D7007 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D7013 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D7022 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D7024 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D7025 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 R1072 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1073 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1011 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1012 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1014 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1055 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1060 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1063 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1081 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1201 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R3500 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R3501 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R6800 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1200 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
....4 R4592 2007-000121 R-CHIP;820ohm,5%,1/10W,TP,1608 1 S.N.A
....4 R1302 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 1 S.N.A
....4 R1303 2007-000122 R-CHIP;1.2Kohm,5%,1/10W,TP,1608 1 S.N.A
....4 R3010 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3018 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3021 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3046 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3210 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3292 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4036 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
5-10
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R4301 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4302 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4640_NON_ 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5003 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5005 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5006 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5022 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5023 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5042 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7200_AUS 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8036_DE 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8037_DE 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9177 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3293 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3294 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6012 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3100 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4076 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4082 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5019 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5020 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1057 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1071_22 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3052 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3101 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3102 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3103 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3108 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4666_HD 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4668_2DDR 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5090 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6017 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6064 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7079 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7086 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9028 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9030 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9031 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9032 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9033 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7019 2007-000146 R-CHIP;6.8Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R10136 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R10200 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R11089 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3014 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3015 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3051 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3059 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3060 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3066 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
5-11
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R3160 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3410 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4081 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4104_ANA 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4106_ANA 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4130 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4140 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4200_ANA 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4475 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4484 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4489 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4490 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4491 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4541 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4544 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4626 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4627 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5017 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5018 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5024 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5025 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5068 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6026 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6028 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6029 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6065 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7023 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7025 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7039 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7063 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7064 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9019 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9025 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9001 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 R9002 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 R7058 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1051 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1052 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1056 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1061 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4555 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4556 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7057 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1010 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1064 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4045 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 1 S.N.A
....4 R11118_JEI 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R11126 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R11127 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1301_ANA 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4700 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
5-12
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R4701 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4702 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4703 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5910_FA 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5911_FA 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7110_450 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6016 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8306 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8307 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8323 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8325 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8326 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8333 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8335 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8336 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8349 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8355 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8357 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8358 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8404 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8430 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8438 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8496 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8638 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3290 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3291 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3402 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3403 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4005 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4006 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4017 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4021 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4022 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4590 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4591 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5015 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5016 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5028 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5029 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5031 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5055 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5056 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6034 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6035 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7034 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7035 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7036 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1075_22 2007-000242 R-CHIP;1.5Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5064 2007-000640 R-CHIP;270ohm,1%,1/10W,TP,1608 1 S.A
....4 R5067 2007-000640 R-CHIP;270ohm,1%,1/10W,TP,1608 1 S.A
....4 R1083 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
5-13
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R1203 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R9020 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R9021 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R9022 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R9023 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 S.A
....4 R5571 2007-000763 R-CHIP;330ohm,1%,1/10W,TP,1608 1 S.N.A
....4 R1205 2007-000772 R-CHIP;33Kohm,1%,1/10W,TP,1608 1 S.A
....4 R4587 2007-000821 R-CHIP;390ohm,1%,1/10W,TP,1608 1 S.N.A
....4 R1013 2007-000869 R-CHIP;4.7Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 R5087 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7043 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7077 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9080 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7054 2007-001217 R-CHIP;82ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6055 2007-001285 R-CHIP;5.6ohm,5%,1/16W,TP,1005 1 S.A
....4 R6056 2007-001285 R-CHIP;5.6ohm,5%,1/16W,TP,1005 1 S.A
....4 R4132 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4133 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4134 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4142 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4143 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4144 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4401 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4402 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4403 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4404 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4405 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4406 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4407 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4408 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4409 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4410 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4411 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4412 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7055 2007-001298 R-CHIP;51ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R8017 2007-001306 R-CHIP;150ohm,5%,1/16W,TP,1005 1 S.A
....4 R8117 2007-001306 R-CHIP;150ohm,5%,1/16W,TP,1005 1 S.A
....4 R7052 2007-001307 R-CHIP;180ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5013 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5014 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R9079 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5021 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5026 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5027 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5034 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7030 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7032 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7067 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7068 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R1022 2007-002425 R-CHIP;1ohm,5%,1/10W,TP,1608 1 S.N.A
....4 R1015 2007-002899 R-CHIP;10ohm,1%,1/10W,TP,1608 1 S.A
5-14
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R1202 2007-002899 R-CHIP;10ohm,1%,1/10W,TP,1608 1 S.A
....4 R1082 2007-002900 R-CHIP;11Kohm,1%,1/10W,TP,1608 1 S.A
....4 R5043 2007-002906 R-CHIP;200Kohm,1%,1/10W,TP,1608 1 S.A
....4 R6001 2007-002906 R-CHIP;200Kohm,1%,1/10W,TP,1608 1 S.A
....4 R5004 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5008 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5009 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5010 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5011 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5012 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5044 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7010 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7014 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7015 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7056 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4594 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R5046 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R9016 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R9017 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R1204 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R2016 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R4095 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R4352 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R2037 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5899 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5570 2007-007297 R-CHIP;110ohm,1%,1/10W,TP,1608 1 S.A
....4 R4105_ANA 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R4316 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R8329 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R8330 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R8363 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R8364 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R9190 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R2022 2007-007319 R-CHIP;390ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R2027 2007-007650 R-CHIP;274ohm,1%,1/10W,TP,1608 1 S.A
....4 R2026 2007-007721 R-CHIP;560ohm,1%,1/10W,TP,1608 1 S.A
....4 R4094 2007-007791 R-CHIP;9.1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R4351 2007-007791 R-CHIP;9.1Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 RA3007 2011-000515 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, 1 S.N.A
....4 RA4004 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 RA4005 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 RA1100 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 RA1101 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 RA3001 2011-001011 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 RA4102 2011-001011 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 R3024 2011-001093 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 R3025 2011-001093 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 RA3002 2011-001093 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 RA3003 2011-001093 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 RA3004 2011-001093 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 RA3005 2011-001093 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
5-15
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 RA3006 2011-001093 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 RA4101 2011-001093 R-NETWORK;100ohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 RA4014 2011-001261 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8321 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8322 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8324 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8327 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8401 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8402 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8403 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8405 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8406 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8407 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8408 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8409 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8410 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8433 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8434 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8435 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8436 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8437 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 R8504 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 RA9000 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 S.A
....4 C9047 2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,- 1 S.A
....4 C9048 2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,- 1 S.A
....4 C9049 2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,- 1 S.A
....4 C9050 2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,- 1 S.A
....4 C5027 2203-000221 C-CER,CHIP;100nF,20%,50V,Y5V,TP,3216 1 S.A
....4 C7003 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C9096 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C3006 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C4041 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C4322 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C4353 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C4422 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C8023_DE 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C8024_DE 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C8332 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C8367 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C9075 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C9400 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C4456 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,1608 1 S.A
....4 C4457 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,1608 1 S.A
....4 C3010 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.N.A
....4 C3011 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.N.A
....4 C9033 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 1 S.A
....4 C9034 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 1 S.A
....4 C9035 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 1 S.A
....4 C9036 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 1 S.A
....4 C9010 2203-000995 C-CER,CHIP;0.047nF,5%,50V,C0G,1005 1 S.A
....4 C9014 2203-000995 C-CER,CHIP;0.047nF,5%,50V,C0G,1005 1 S.A
5-16
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 C1015 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,1608 1 S.N.A
....4 C1103 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,1608 1 S.N.A
....4 C1036 2203-001242 C-CER,CHIP;0.082nF,5%,50V,NP0,1608 1 S.A
....4 C1104 2203-001242 C-CER,CHIP;0.082nF,5%,50V,NP0,1608 1 S.A
....4 C4038 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 1 S.N.A
....4 C4039 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 1 S.N.A
....4 C4492 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 1 S.N.A
....4 C5001 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 1 S.N.A
....4 C5005 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 1 S.N.A
....4 C5007 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 1 S.N.A
....4 C5009 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 1 S.N.A
....4 C5010 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 1 S.N.A
....4 C7025 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 1 S.N.A
....4 C7035 2203-001412 C-CER,CHIP;0.03nF,5%,50V,NP0,TP,1005 1 S.N.A
....4 C2015 2203-001596 C-CER,CHIP;2200nF,+80-20%,50V,Y5V,2012 1 S.A
....4 C2020 2203-001596 C-CER,CHIP;2200nF,+80-20%,50V,Y5V,2012 1 S.A
....4 C4025 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C4026 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C4029 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C4030 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C4031 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C4032 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C4034 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C4046 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C4047 2203-001598 C-CER,CHIP;2200nF,+80-20%,16V,Y5V,2012 1 S.N.A
....4 C3005 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C7036 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C7037 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C7040 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C7041 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C5008 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C5012 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C5013 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C5015 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C7011 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C7013 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C7026 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C7027 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 1 S.N.A
....4 C11050 2203-002720 C-CER,CHIP;10nF,10%,25V,X7R,1005 1 S.N.A
....4 C9023 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.N.A
....4 C9027 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.N.A
....4 C9028 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.N.A
....4 C9029 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.N.A
....4 C9018 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C9025 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C9026 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C9030 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C9039 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C9040 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C9041 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C9042 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
5-17
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 C9043 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C9044 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C9045 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C9046 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 1 S.N.A
....4 C1016 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 1 S.N.A
....4 C1051 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 1 S.N.A
....4 C1105 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 1 S.N.A
....4 C1200 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 1 S.N.A
....4 C1201 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 1 S.N.A
....4 C3500 2203-005384 C-CER,CHIP;4700nF,+80-20%,10V,Y5V,TP,201 1 S.N.A
....4 C1026 2203-005809 C-CER,CHIP;1000nF,10%,16V,X7R,-,2012 1 S.A
....4 C1058 2203-005809 C-CER,CHIP;1000nF,10%,16V,X7R,-,2012 1 S.A
....4 C1065 2203-005809 C-CER,CHIP;1000nF,10%,16V,X7R,-,2012 1 S.A
....4 C1083 2203-005809 C-CER,CHIP;1000nF,10%,16V,X7R,-,2012 1 S.A
....4 C1082 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C1100 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C2509 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C2510 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C2511 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C2590 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C5028 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C5030 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C7028 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C7029 2203-005834 C-CER,CHIP;22000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C4004 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4005 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4007 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4009 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4014 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4018 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4019 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4021 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4312 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4313 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4319 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4320 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4321 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C4323 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
....4 C3241 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C4035 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C4400_ANA 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C9003 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C9004 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C9012 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C9077 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 1 S.N.A
....4 C10033 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C10035 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C10037 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C1014 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C1102 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C2002 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
5-18
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 C2017 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C2019 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C2048 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C2053 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C2070 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C2082 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C2084 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C2086 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C2089 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C3002 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C3007 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
