Image preview - the first page of the document
>> Download Disassembly & Reassembly documenatation <<
Text preview - extract from the document
3. Disassembly and Reassemble
3. Disassembly and Reassemble
This section of the service manual describes the disassembly and reassembly procedures for the LE26A33*J** LCD TV.
WARNING: This monitor contains electrostatically sensitive devices. Use caution when handling these components.
3-1. Disassembly (LE26A33*J**)
Cautions: 1. Disconnect the monitor from the power source before disassembly.
2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.
Description Picture Description Screws
1. Place monitor face down on cushioned table.
Remove the screws from the Stand.
Remove stand.
x 12
x1
x4
3-1
3. Disassembly and Reassemble
Description Picture Description Screws
2. Lift up rear cover and remove the stand.
3. Remove Screw from the stand BRKT and lift
up the stand BRKT.
x2
3-2
3. Disassembly and Reassemble
Description Picture Description Screws
4. Disonnect cable from the boards.
5. Remove the screws of Scaler board's
shield case and boards.
x 10
3-3
3. Disassembly and Reassemble
Description Picture Description Screws
6. Remove screws and Lift up the Lod panel.
x 10
x4
Reassembly procedures are in the reverse order of disassembly procedures.
3-4
3. Disassembly and Reassemble
3-2. Disassembly(LE32A33*J*N**)
Cautions: 1. Disconnect the monitor from the power source before disassembly.
2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.
Description Picture Description Screws
1. Place monitor face down on cushioned table.
Remove the screws from the Rear cover.
Remove the screws from the Stand.
x 11
x1
x4
2. Remove the stand.
Lift up the rear cover.
3-5
3. Disassembly and Reassemble
Description Picture Description Screws
3. Remove Screw from the stand BRKT.
Lift up the stand BRKT.
x4
3-6
3. Disassembly and Reassemble
Description Picture Description Screws
4. Disconnect a cable from the Main&IP boards.
Remove a Cable.
5. Remove the screws of the Main & IP boards.
Remove the Main & IP boards.
x4
x5
x2
3-7
3. Disassembly and Reassemble
Description Picture Description Screws
6. Remove the Screw from Front Assy.
Lift up the Panel BRKT.
x 10
7. Remove the screws from Panel BRKT.
Remove the Panel BRKT.
x9
Reassembly procedures are in the reverse order of disassembly procedures.
3-8
