Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LE23R71B Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LE23R71BX/NWT LE23R71B,Q50K/23R70-GBU,23,LCD-TV,UKRAIN 0
0.1 M0216 BN90-00848A ASSY STAND;26R71,BORDEAUX 1 S.N.A
..2 M0013 BN96-03017A ASSY STAND P-BASE;26R71,ABS+PMMA,HB,BK23 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,B,M4,L10,ZPC(YEL),SWR 4 S.A
...3 T0920 BN61-02192A GUIDE-STAND;26,32R71,ABS,V0,BLK 1 S.A
....4 T0514 BN61-02367A BRACKET-SUPPORT;BORDEAUX 32,SECC,T2.0 1 S.N.A
...3 BN61-02202A BRACKET-STAND BOTTOM;BORDEAUX 26,SECC,T2 1 S.N.A
...3 BN61-02204A HOLDER-SWIVEL RING;26,32R71,ACETAL,BLK 1 S.N.A
...3 BN61-02232A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,T 1 S.N.A
...3 BN61-02233A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,B 1 S.N.A
...3 BN61-02236A BRACKET-HINGE SWIVEL;BORDEAUX 32,SECC,T1 1 S.N.A
...3 BN63-02322A COVER-STAND SUB;32R71,ABS+PMMA,HB,BK23,H 1 S.N.A
...3 T0004 BN63-02335A COVER-STAND BASE;26R71,ABS+PMMA,HB,BK23, 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
..2 T0524 6902-000241 BAG PE;NITRON/HDPE,T0.5/T0.012,W600,L600 1 S.N.A
0.1 M0001 BN90-00911E ASSY COVER FRONT;23R71,EO,-,ABS+PMMA,HB, 1 S.N.A
..2 T0175 BN96-03335A ASSY SPEAKER P;16ohm,Bordeuax, 23,Left,3 1 S.A
..2 T0175 BN96-03336A ASSY SPEAKER P;16ohm,Bordeuax, 23,Right, 1 S.A
..2 T0003 BN96-03368E ASSY COVER P-FRONT;23R71,EO(HOTEL),ABS+P 1 S.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.94 S.N.A
...3 T0056 BN63-02464B COVER-DECORATION;23R71,HIPS,HB,GR503,BLM 1 S.N.A
...3 M0112 BN63-02465E COVER-FRONT;23R71,EO,ABS+PMMA,-,-,-,HB,- 1 S.N.A
...3 T0023 BN64-00342A KNOB POWER;ROME,40,PC,VIOLET 1 S.N.A
...3 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
...3 T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 S.N.A
...3 M0146 BN96-03405B ASSY BOARD P-POWER;BORDEAUX23,CT5000-414 1 S.A
...3 M0145 BN96-03404A ASSY BOARD P-FUNCTION&KNOB;Bordeaux,CT50 1 S.A
....4 T0022 BN64-00442A KNOB CONTROL;26,32,40R71,PC,BLK,ACRYL CL 1 S.N.A
....4 M0145 BN96-03045A ASSY BOARD P-FUNCTION;BORDEAUX,FUNCTION 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,B,M4,L10,YEL,SWRCH18A 2 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,B,M4,L10,YEL,SWRCH18A 2 S.N.A
0.1 M0002 BN90-01034B ASSY COVER REAR;23R71,EO,ABS+PMMA,HB,BK2 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 11 S.A
..2 M0013 BN96-04061A ASSY COVER P-REAR;23R71,EO,-,ABS+PMMA,HB 1 S.A
...3 T0101 BN61-02058A BRACKET-WALL;23,27,MGM,SECC,T1.6 2 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.5 S.N.A
...3 M0006 BN63-02714A COVER-REAR;23R71,EO,ABS+PMMA,-,-,-,HB,-, 1 S.N.A
...3 T0071 BN64-00514A INLAY-TERMINAL;BORDEAUX 23EO,PS SHEET,T0 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
0.1 M0017 BN91-01005G ASSY CHASSIS;LE23R71BX/* 1 S.N.A
..2 M0014 BN94-00847B ASSY PCB MAIN;LE23R71BX/* 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.01 S.N.A
...3 FT230 2904-001179 FILTER-SAW;36.125MHz,-,32.65-39.6MHz/0.5 1 S.A
...3 JA722 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-005942 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,STR 1 S.A
...3 JA710_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA711_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA332 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001938 JACK-PIN;3P,-,AU,GRN/BLU/RED,- 1 S.A
...3 JA333 3722-002063 JACK-PIN;3P,AU,YEL/WHT/RED,STRAIGHT 1 S.A
...3 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 2 S.N.A
...3 M0131 AA63-01304A GASKET;TORINO,Conductive Fabric,1mm,14mm 1 S.N.A
...3 CIS3 BN40-00072A TUNER;TECH0949PG46A(S),TECH0949PG46A(S), 1 S.A
...3 M0107 BN63-02176A SHIELD-COVER;MGM,SPTE,0.5 1 S.N.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
...3 MICOM3 BN97-00688A ASSY HDCP;BN46-00018A,PS-42V6S,D73A,GENE 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-00807B ASSY SMD;LE23R71BX/* 1 S.N.A
....4 CIS5 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
