5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LE23R71B / LE23R71W Exploded View
M0013
T0071
M0006
T0101
M0014
M0107 T0064
M0019
T0003
T0175
M0013
T0175
T0004
T0132
T0023 M0112
T0056
T0060
T0054
5-1
5 Exploded View & Parts List
5-2 LE23R71B Parts List
Location.No CODE-NO SPECIFICATION & DESCRIPTION Q'TY SA/SNA
T0003 BN96-03368E ASSY COVER P-FRONT;23R71,EO(HOTEL),ABS+P 1 S.A
T0023 BN64-00342A KNOB POWER;ROME,40,PC,VIOLET 1 S.N.A
T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 S.N.A
T0056 BN63-02464B COVER-DECORATION;23R71,HIPS,HB,GR503,BLM 1 S.N.A
M0112 BN63-02465E COVER-FRONT;23R71,EO,ABS+PMMA,-,-,-,HB,- 1 S.N.A
M0145 BN96-03404A ASSY BOARD P-FUNCTION&KNOB;Bordeaux,CT50 1 S.A
M0019 BN92-01981H ASSY LABEL;LE23R71BX/* 1 S.N.A
T0175 BN96-03335A ASSY SPEAKER P;16ohm,Bordeuax, 23,Left,3 1 S.A
T0175 BN96-03336A ASSY SPEAKER P;16ohm,Bordeuax, 23,Right, 1 S.A
M0107 BN63-02176A SHIELD-COVER;MGM,SPTE,0.5 1 S.N.A
M0014 BN94-00847B ASSY PCB MAIN;LE23R71BX/* 1 S.A
M0013 BN96-04061A ASSY COVER P-REAR;23R71,EO,-,ABS+PMMA,HB 1 S.A
M0006 BN63-02714A COVER-REAR;23R71,EO,ABS+PMMA,-,-,-,HB,-, 1 S.N.A
T0101 BN61-02058A BRACKET-WALL;23,27,MGM,SECC,T1.6 2 S.N.A
T0071 BN64-00514A INLAY-TERMINAL;BORDEAUX 23EO,PS SHEET,T0 1 S.N.A
T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
M0013 BN96-03017A ASSY STAND P-BASE;26R71,ABS+PMMA,HB,BK23 1 S.A
T0004 BN63-02335A COVER-STAND BASE;26R71,ABS+PMMA,HB,BK23, 1 S.N.A
T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 S.N.A
5-2
5 Exploded View & Parts List
5-3 LE23R71W Parts List
Location.No CODE-NO SPECIFICATION & DESCRIPTION Q'TY SA/SNA
T0003 BN96-03368G ASSY COVER P-FRONT;23R71,EO,ABS+PMMA,HB, 1 S.A
T0023 BN64-00480A KNOB POWER;BORDEAUX,PC+ACRYL,T3,WHITE 1 S.N.A
T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 S.N.A
T0056 BN63-02464C COVER-DECORATION;23R71,HIPS,HB,GR503,RDM 1 S.N.A
M0112 BN63-02465G COVER-FRONT;23R71,EO,ABS+PMMA,HB,WH12,S/ 1 S.N.A
M0145 BN96-03403A ASSY BOARD P-FUNCTION&KNOB;Bordeaux,CT50 1 S.A
M0019 BN92-01981Z ASSY LABEL;LNS5296DX/XAA 1 S.N.A
T0175 BN96-03335A ASSY SPEAKER P;16ohm,Bordeuax, 23,Left,3 1 S.A
T0175 BN96-03336A ASSY SPEAKER P;16ohm,Bordeuax, 23,Right, 1 S.A
M0107 BN63-02176A SHIELD-COVER;MGM,SPTE,0.5 1 S.N.A
M0014 BN94-00847B ASSY PCB MAIN;LE23R71BX/* 1 S.A
M0013 BN96-04061C ASSY COVER P-REAR;23R71,EO,(WHITE),ABS+P 1 S.A
M0006 BN63-02714C COVER-REAR;23R71,EO,(WHITE),ABS+PMMA,HB, 1 S.N.A
T0101 BN61-02058A BRACKET-WALL;23,27,MGM,SECC,T1.6 2 S.N.A
T0071 BN64-00514B INLAY-TERMINAL;BORDEAUX 23,PS SHEET,T0.5 1 S.N.A
T0064 BN65-00002B CLAMPER CORE;BORDEAUX,PP,V0,WHITE 1 S.N.A
M0013 BN96-03017B ASSY STAND P-BASE;26R71,ABS+PMMA,HB,WH12 1 S.A
T0004 BN63-02335B COVER-STAND BASE;26R71,ABS+PMMA,HB,WH12, 1 S.N.A
T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 S.N.A
5-3
5 Exploded View & Parts List
Memo
5-4
