Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LE23R86BD Exploded View
M0107
M0014
M0013
M0115
M0146
M0107 M0013
M0215
T0175
T0003
5-1
5 Exploded View & Parts List
5-2 LE23R86BD Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04660B ASSY COVER P-FRONT;23R81,EO(IDTV),-,ABS+ 1 S.A
T0175 BN96-04767A ASSY SPEAKER P;16ohm,4pin,5W,Bordeaux Pl 1 S.A
M0215 BN07-00365A LCD-PANEL;T230XW01,8bit,23inch,16.7M,16: 1 S.A
M0107 BN63-03039A SHIELD-COVER;MURANO40,PCM,T0.5,IDTV 1 S.N.A
M0107 BN61-03037A BRACKET-PCB;23 BORDEAUX PLUS,SECC,T1.0 1 S.N.A
M0146 BN61-03060A BRACKET-PANEL SIDE;BORDEAUX PLUS 23,SECC 2 S.N.A
M0115 BN61-02965A BRACKET-STAND LINK;32 BORDEAUX PLUS,SECC 1 S.N.A
M0014 BN94-01121E ASSY PCB MAIN;LE23R86BDX/* 1 S.A
M0013 BN96-04663A ASSY STAND P-BASE;23,26R81,NORMAL,-,ABS+ 1 S.A
M0013 BN96-04673A ASSY COVER P-REAR;23R81,EO(IDTV),-,ABS+P 1 S.A
5-2
5 Exploded View & Parts List
5-3 LE26R86BD Exploded View
M0107
M0014
M0013
M0115
T0447
M0215
T0175
M0013
T0003
5-3
5 Exploded View & Parts List
5-4 LE26R86BD Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04659B ASSY COVER P-FRONT;26R81,EO(IDTV),-,ABS+ 1 S.A
T0175 BN96-04767A ASSY SPEAKER P;16ohm,4pin,5W,Bordeaux Pl 1 S.A
M0215 BN07-00367A LCD-PANEL;LTA260W2-L13,-,8bit,26inch,16. 1 S.A
T0447 BN96-04682A ASSY BRACKET P-PANEL;26R81,AMLCD,-,-,-,- 1 S.N.A
M0115 BN61-02965A BRACKET-STAND LINK;32 BORDEAUX PLUS,SECC 1 S.N.A
M0014 BN94-01121B ASSY PCB MAIN;LE26R86BDX/* 1 S.A
M0107 BN63-03039A SHIELD-COVER;MURANO40,PCM,T0.5,IDTV 1 S.N.A
M0013 BN96-04663A ASSY STAND P-BASE;23,26R81,NORMAL,-,ABS+ 1 S.A
M0013 BN96-04672A ASSY COVER P-REAR;26R81,EO(IDTV),-,ABS+P 1 S.A
5-4
5 Exploded View & Parts List
5-5 LE32R86BD Exploded View
M0013
M0115
T0447
M0215
T0003
M0013
5-5
5 Exploded View & Parts List
5-6 LE32R86BD Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04658D ASSY COVER P-FRONT;32R81,EO,-,ABS+PMMA,H 1 S.A
T0175 BN96-04768B ASSY SPEAKER P;8ohm,4pin,10W,150/650,Bor 1 S.A
M0215 BN07-00348A LCD-PANEL;V315B1-L01,8bit,31.5inch,16.7M 1 S.A
T0447 BN96-04681G ASSY BRACKET P-PANEL;32R81,CMO,PAL,SPACE 1 S.N.A
M0115 BN61-02965A BRACKET-STAND LINK;32 BORDEAUX PLUS,SECC 1 S.N.A
M0014 BN94-01325A ASSY PCB MAIN-CMO;LE32R81BX/* 1 S.N.A
M0013 BN96-04662A ASSY STAND P-BASE;32R81,M81,SWIVEL,-,ABS 1 S.A
M0013 BN96-04671B ASSY COVER P-REAR;32R81,EO,ABS+PMMA,HB,B 1 S.A
5-6
5 Exploded View & Parts List
5-7 LE37R88BD Exploded View
M0014
M0107
M0146
M0013
M0146
M0115
T0447
M0215
T0003
M0013
5-7
5 Exploded View & Parts List
5-8 LE37R88BD Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04657F ASSY COVER P-FRONT;37R88,EO(IDTV),ABS+PM 1 S.A
T0175 BN96-04768A ASSY SPEAKER P;8ohm,4pin,10W,Bordeaux Pl 1 S.A
M0215 BN07-00393A LCD-PANEL;T370XW02,8bit,37inch,16.7M,16: 1 S.A
T0447 BN96-04680A ASSY BRACKET P-PANEL;BORDEAUX PLUS37 1 S.N.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
M0014 BN94-01121C ASSY PCB MAIN;LE37R86BDX/* 1 S.A
M0146 BN61-02241A BRACKET-PANEL SIDE;Bordeaux 37,SECC,T1.2 1 S.N.A
M0146 BN61-02242A BRACKET-PANEL SIDE;Bordeaux 37,SECC,T1.2 1 S.N.A
M0013 BN96-04661A ASSY STAND P-BASE;37,40R81,SWIVEL,-,ABS+ 1 S.A
M0013 BN96-04670A ASSY COVER P-REAR;37R81,EO(IDTV),-,ABS+P 1 S.A
5-8
5 Exploded View & Parts List
5-9 LE40R88BD Exploded View
M0014
M0107
M0146
M0013
M0146
T0447
M0215
T0003
M0013
5-9
5 Exploded View & Parts List
5-10 LE40R88BD Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-05168A ASSY COVER P-FRONT;40R87,EO(IDTV),ABS+PM 1 S.A
T0175 BN96-04768A ASSY SPEAKER P;8ohm,4pin,10W,Bordeaux Pl 1 S.A
M0215 BN07-00387A LCD-PANEL; LTA400WT-L06,8bit,40inch,16.7 1 S.A
T0447 BN96-04679D ASSY BRACKET P-PANEL;40R81,IP BOARD,SPAC 1 S.N.A
M0107 BN63-03039A SHIELD-COVER;MURANO40,PCM,T0.5,IDTV 1 S.N.A
M0146 BN61-02256B BRACKET-PANEL SIDE;Bordeaux 40,SECC,T1.2 1 S.N.A
M0146 BN61-02257B BRACKET-PANEL SIDE;Bordeaux 40,SECC,T1.2 1 S.N.A
M0013 BN96-04661A ASSY STAND P-BASE;37,40R81,SWIVEL,-,ABS+ 1 S.A
M0013 BN96-04669A ASSY COVER P-REAR;40R81,EO(IDTV),-,ABS+P 1 S.A
5-10
