Image preview - the first page of the document



>> Download Disassembly & Reassembly documenatation <<

Text preview - extract from the document

                                                                          11 Disassembly and Reassembly



11 Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LE26M51B
/LE32M51B / LE32M61B / LE40M51B / LE40M61B / LE46M51B LCD TV.
    WARNING: This monitor contains electrostatically sensitive devices. Use caution
             when handling these components.

11-1 Disassembly
   Cautions: 1. Disconnect the monitor from the power source before disassembly.
             2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.
             3. R/Cover opening jig : BH81-00001A




1. Place LCD TV face down on cushioned table. Remove 10 screws from the rear cover.
   Remove 4 screws from grip on the stand. and remove the stand.




2. Remove 3 screws from the Jack-cover.




                                                                                                          11-1
11 Disassembly and Reassembly




3. Remove screws from the Shield-cover and disconnect cables.




4. Remove screws from the boards and lift up the boards.




5. Remove 2 screws from the side-jack and remove screws from the BRKT.




11-2
                                                                     5 Disassembly and Reassembly




6. Remove 4 screws from the side-BRKT.




11-2 Reassembly
Reassembly procedures are in the reverse order of dissasembly procedures, place the lamp wire
correctly in the locator groove so that the wire will not bind or interfere with rear cover.




                                                                                                11-3
11 Disassembly and Reassembly


Memo




11-4
