5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LE26M51B
M 0013
M 0113
M 0112
M 0014
M 0114
M 0006
T0447
M 0131
M 0131
T0175 M 0131
T0060
T0023
T0120
T0069 M 0131
M 0112
M 0013
T0175
T0081
M 0146
M 0111
T0023
T0022
T0132
T0603 M 0013
T0003
5-1
5 Exploded View & Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-02209B ASSY COVER P-FRONT;MILANO,26EO,ABS,HB,BK 1
M0112 BN63-01927B COVER-FRONT;MILANO,26EO,ABS,HB,BK23,STEA 1 S.N.A
T0069 BN63-01928A COVER-MIDDLE;MILANO,26,ABS,V0,GR70,SV012 1 S.N.A
T0603 BN64-00343A WINDOW-RMC;ROME,40,PC,CLEAR 1 S.N.A
T0022 BN64-00375A KNOB CONTROL;MILANO,26,ABS+PC,GR70,SVM-3 1 S.N.A
T0023 BN96-02244A ASSY COVER P-KNOB POWER;MILANO,26,ABS,V0 1 S.N.A
T0023 BN64-00376A KNOB POWER;MILANO,26,ABS,V0,GR70,AL,H/ST 1 S.N.A
T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1
T0023 BN64-00376A KNOB POWER;MILANO,26,ABS,V0,GR70,AL,H/ST 1 S.N.A
T0081 BN61-01821A GUIDE-POWER;MILANO,26,ACRYL,SMOG 1 S.N.A
T0175 BN96-02189B ASSY SPEAKER P;16ohm,Right,5W,DTV Ready, 1
M0215 BN07-00239A LCD-PANEL;LTA260W2-L11,8bit,626.0*373.0* 1
T0120 BN94-00699D ASSY PCB POWER;ROME,32",Free Volt,CIS,## 1
T0175 BN96-02188B ASSY SPEAKER P;16ohm,Left,5W,DTV Ready,M 1
M0131 AA63-01216A GASKET;GSJ26KU,Conductive Fabric,1mm,30m 1 S.N.A
M0131 AA63-01217A GASKET;GSJ26KU,Conductive Fabric,27mm,15 1 S.N.A
M0014 BN94-00736A ASSY PCB MAIN-AMLCD;LE26M51BX/* 1
M0013 BN96-02206B ASSY COVER P-REAR;MILANO,26,HIPS,HB,GR50 1
M0114 BN61-01605A HOLDER-WIRE;FIRENZE 46,HIPS HB,GR503 1 S.N.A
M0006 BN63-01929B COVER-REAR;MILANO,26,HIPS,HB,GR503 1 S.N.A
M0113 BN61-01302A BRACKET-VESA;32,DUOMO,SECC,T1.6 1 S.N.A
M0013 BN96-02203A ASSY STAND P-BASE;26 MILANO,ABS HB,BK07, 1
M0111 BN63-01946A COVER-STAND;26 MILANO,ABS,HB,BK07,BKM150 1 S.N.A
T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 6 S.N.A
5-2
5 Exploded View & Parts List
5-2 LE32M51B, LE32M61B
M 0452
M 0014
T0175
M 0013
M 0112
T0120
T0447
T0852
M 0013
T0175
T0023
T0003
5-3
5 Exploded View & Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-02208C ASSY COVER P-FRONT;MILANO,32EO,ABS,HB,BK 1
T0023 BN96-02244A ASSY COVER P-KNOB POWER;MILANO,26,ABS,V0 1 S.N.A
T0175 BN96-02191C ASSY SPEAKER P;8ohm,Right,10W,DTV Ready, 1
M0215 BN07-00243A LCD-PANEL;LTA320W2-L03,8bit,760*450*50.0 1
T0447 BN96-02551A ASSY BRACKET P-PANEL;32 MILANO,SECC,READ 1 S.N.A
T0120 BN94-00699D ASSY PCB POWER;ROME,32",Free Volt,CIS,## 1
M0013 BN96-02205B ASSY COVER P-REAR;MILANO,32,HIPS,HB,GR50 1
T0175 BN96-02190C ASSY SPEAKER P;8ohm,Left,10W,DTV Ready,M 1
M0013 BN96-02202A ASSY STAND P-BASE;32 MILANO,ABS HB,BK07, 1
M0014 BN94-00736B ASSY PCB MAIN-AMLCD;LE32M51BX/* 1
M0452 BN96-02438C ASSY COVER P-HOLDER AV;MILANO,32,57EO,AB 1 S.N.A
M0013 BN96-02202A ASSY STAND P-BASE;32 MILANO,ABS HB,BK07, 1
5-4
5 Exploded View & Parts List
5-3 LE40M51B, LE40M61B
M0452
M0014
T0175
M0013
M0112
T0120
T0447
M0013
T0852
T0175
T0023
T0003
5-5
5 Exploded View & Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-02349C ASSY COVER P-FRONT;MILANO,40EO,ABS,HB,BK 1
T0023 BN96-02244A ASSY COVER P-KNOB POWER;MILANO,26,ABS,V0 1 S.N.A
T0175 BN96-02191D ASSY SPEAKER P;8ohm,Right,10W,DTV Ready, 1
T0852 BN91-00833E ASSY LCD-SPZ;RE40EO*AM LCD 1 S.N.A
T0447 BN96-02511B ASSY BRACKET P-PANEL;MILANO,40,SECC,READ 1 S.N.A
T0120 BN94-00622J ASSY PCB POWER;ROME,40",FREE VOLT,CIS,CH 1
M0112 BN96-01797A ASSY SHIELD P-PCB;40" ROME,SECC,T0.5,REA 1 S.N.A
M0013 BN96-02348B ASSY COVER P-REAR;MILANO,40,HIPS,HB,GR50 1
T0175 BN96-02190D ASSY SPEAKER P;8ohm,Left,10W,DTV Ready,M 1
M0014 BN94-00736C ASSY PCB MAIN-AMLCD;LE40M51BX/* 1
M0452 BN96-02447C ASSY COVER P-HOLDER AV;MILANO,40,46EO,AB 1 S.N.A
M0013 BN96-02350A ASSY STAND P-BASE;MILANO,40,ABS HB,BK07, 1
5-6
5 Exploded View & Parts List
5-4 LE46M5
T0003
T0023
M 0146
T0175
T0175
M 0019
M 0412
M 0452
M 0014
M 0112
M 0013
M 0013
5-7
5 Exploded View & Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-02052C ASSY COVER P-FRONT;MILANO,46EO,ABS,HB,BK 1
T0023 BN96-02244A ASSY COVER P-KNOB POWER;MILANO,26,ABS,V0 1 S.N.A
M0146 BN96-02401A ASSY BOARD P-POWER & IR;LNR329DX/XAA,CT5 1
T0175 BN96-02077D ASSY SPEAKER P;8ohm,Left,15W,400mm,Milan 1
T0175 BN96-02078D ASSY SPEAKER P;8ohm,Right,15W,400mm,Mila 1
M0019 BN07-00187A LCD;LTA460W2-L03,8BIT,1082.0*627.0*56.5, 1
M0412 BN96-02412C ASSY BRACKET P-PCB;MILANO,46,SECC T2.0,R 1 S.N.A
M0452 BN96-02447C ASSY COVER P-HOLDER AV;MILANO,40,46EO,AB 1 S.N.A
M0014 BN94-00736D ASSY PCB MAIN-AMLCD;LE46M51BX/* 1
M0112 BN96-02411C ASSY SHIELD P-PCB;46MILANO,SECC,T0.5,REA 1 S.N.A
M0013 BN96-02053B ASSY STAND P-BASE;46 MILANO,ABS HB,BK07, 1
M0013 BN96-02200B ASSY COVER P-REAR;46 MILANO,HIPS,HB,GR50 1
