Image preview - the first page of the document
>> Download Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LE32S62BX Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
LE32S62BX/XEH LE32S62B,Q62A/32S60-GSA,32,LCD-TV,HUNGAR
0.1 M0001 BN90-00858U ASSY COVER FRONT;32T70,EO,ABS+PMMA,HB,BK 1 S.N.A
..2 M0081 6006-001096 SCREW-TAPTITE;BH,+,WP,B,M4.0,L12,ZPC(BLK 4 S.N.A
..2 T0003 BN96-03628Q ASSY COVER P-FRONT;32T70,EO,ABS+PMMA,HB, 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0162 6502-001067 CABLE CLAMP;DAFC-1300,ID2.2,T5.2,NYLIN6/ 2 S.N.A
...3 T0069 AA63-60001Q SPACER-FELT;-,FELT,-,-,-,BLK,T0.35,-,150 1 S.N.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 BN63-01151D FELT-NON WOVEN;SP20UO,FELT,T0.5,10,90 4 S.N.A
...3 BN63-01925A FELT-VIBRATION;42D5,FELT,T0.35,10,370 6 S.N.A
...3 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 1.65 S.N.A
...3 T0056 BN63-02413B COVER-DECORATION;SONOMA,32,HIPS,HB,GR503 1 S.N.A
...3 M0112 BN63-02551J COVER-FRONT;32T70,EO,ABS+PMMA,HB,BK23,S/ 1 S.N.A
...3 T0059 BN64-00379A INDICATOR LED;ROME-II,23,PC,CLEAR 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 S.N.A
...3 T0022 BN64-00467A KNOB CONTROL;SONOMA26,32,40,ABS,-,-,-,V0 1 S.N.A
...3 T0054 BN64-00477A KNOB-DECORATION;SONOMA26,32,40,ABS,HB,GR 1 S.N.A
...3 M0146 BN96-03438A ASSY BOARD P-POWER & IR;BORDEAUX2,CT5000 1 S.A
...3 M0145 BN96-03466A ASSY BOARD P-FUNCTION;SONOMA,SJ06-01-008 1 S.A
...3 T0023 BN64-00476F KNOB POWER;07,SONOMA,26,32,40,HIPS,HB,GR 1 S.N.A
..2 T0175 BN96-05397A ASSY SPEAKER P;8ohm,2pin,Left,10W,Sniper 1 S.A
..2 T0175 BN96-05398A ASSY SPEAKER P;8ohm,3pin,Right,10W,Snipe 1 S.A
0.1 M0002 BN90-00879Q ASSY COVER REAR;32S70,EO,HIPS,HB,BK500,S 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 9 S.A
..2 M0013 BN96-03838D ASSY COVER P-REAR;32T70,EO,-,HIPS,HB,BK5 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
...3 BN63-01151A FELT-NON WOVEN;MM17NS,T0.5,393,10,BLACK 2 S.N.A
...3 M0006 BN63-02659D COVER-REAR;32T70,EO,HIPS,-,-,-,HB,-,BK50 1 S.N.A
...3 T0071 BN64-00444A INLAY-TERMINAL;26R71,PS SHEET,T0.5,-,-,B 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
...3 T0101 BN61-02032A BRACKET-WALL;32,MGM,SECC,T1.6 2 S.N.A
0.1 M0216 BN90-00967D ASSY STAND;32S70,EO,SO,-,ABS+PMMA,HB,BK2 1 S.N.A
..2 T0524 6902-000520 BAG PE;HDPE/NITRON(DOUBLE),T0.015/T0.5(D 1 S.N.A
..2 M0027 BN96-03698B ASSY STAND P-BASE;SONOMA,32,ABS+PMMA,HB, 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 3 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 6 S.A
...3 BN61-01812A BRACKET-STAND BOTTOM;32 MILANO,SECC,T2.0 1 S.N.A
...3 T0920 BN61-02360B GUIDE-STAND;SONOMA,32,HIPS,V0,BK500,NON 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.34 S.N.A
...3 T0004 BN63-02697A COVER-STAND BASE;GML32,ABS+PMMA,HB,BK23, 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,CR Rubber Gray,T1.5 6 S.N.A
0.1 M0017 BN91-01558E ASSY CHASSIS;LE32S62BX/* 1 S.N.A
..2 M0014 BN94-01304F ASSY PCB MAIN-AMLCD;LE32S62BX/* 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 JA306 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 CN330 3711-004379 HEADER-BOARD TO CABLE;BOX,4P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-005606 HEADER-BOARD TO CABLE;BOX,30P,2R,2mm,STR 1 S.A
...3 CN330 3711-005942 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,STR 1 S.A
...3 JA202_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA207_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA332 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002363 JACK-PIN;3P,Sn,YEL/WHT/RED,STRAIGHT 1 S.A
...3 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 2 S.N.A
...3 CIS3 BN40-00079A TUNER;TCPW3001PD32S(H),TCPW3001PD32S(H), 1 S.A
...3 M0107 BN63-01847A SHIELD-COVER;ROME,SECC,T0.3,49.5,79.5,HE 1 S.N.A
...3 CCMM1 BN73-00024D SILICON/RUBBER;BORDEAUX,SILICON,28x28XT6 1 S.N.A
...3 HDCP BN97-00688A ASSY HDCP;BN46-00018A,PS-42V6S,D73A,GENE 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-01594F ASSY SMD;LE32S62BX 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45##,96.5Sn/ 2.724 S.N.A
....4 D101 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D102 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D103 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D105 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D304 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D305 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D311 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D312 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D313 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D314 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D315 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D316 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D317 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D318 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D803 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D804 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D104 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D207 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D211 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D225 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D306_27 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D307_27 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D321_27 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D331 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D332 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D333 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D334 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D335 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D336 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D337 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D504 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D801 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D301 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D501 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D106 0403-001425 DIODE-ZENER;BZX84C33,31-35V,350mW,SOT-23 1 S.A
....4 D201 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D202 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D203_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D204 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D205_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D206 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D208 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D209 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D210 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D212 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D213_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
6-2
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 D214 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D215 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D216 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D217_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D218 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D219 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D221 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D222 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D223 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D224 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D226_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D227_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D302_27 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D303_27 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D308_27 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D309_27 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D310_27 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D319 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D320 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D322_27 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D323_27 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D324 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D325 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D328 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D329 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D330 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D338 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D339 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D326 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D327 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D503 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 Q505 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q508 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q804 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q805 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q101 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q105 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q202 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q203 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q205 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q206 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q301 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q302 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q501 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q701 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q801 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q802 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q803 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q806 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q102 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q103 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q104 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q504 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q506 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q507 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q509 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 S.A
....4 IC801 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 S.A
....4 IC107 1002-001482 IC-D/A CONVERTER;WM8521H9GED/R,16bit,SOI 1 S.A
....4 IC107 1002-001482 IC-D/A CONVERTER;WM8521H9GED/R,16bit,SOI 1 S.A
6-3
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 IC107 1002-001482 IC-D/A CONVERTER;WM8521H9GED/R,16bit,SOI 1 S.A
....4 IC108 1002-001483 IC-A/D CONVERTER;WM8775SEDS/R,24Bit,SSOP 1 S.A
....4 IC110 1006-001076 IC-DRIVER/RECEIVER;MAX232ECWE+T,SOP,16P, 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-001023 IC-EEPROM;24C08,8Kbit,1Kx8Bit,SOP,8P,5x4 1 S.A
....4 IC112 1103-001279 IC-EEPROM;24C32,32Kbit,4Kx8Bit,SOP,8P,5x 1 S.A
....4 IC502 1105-001715 IC-VIDEO RAM;M13S128168,K4D261638,GDDR,1 1 S.A
....4 IC503 1105-001715 IC-VIDEO RAM;M13S128168,K4D261638,GDDR,1 1 S.A
....4 DU410 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 S.A
....4 T0085 1201-002367 IC-AUDIO AMP;YDA138-EZ,SSOP,42P,17.5x8.4 1 S.A
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,-,PLA 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 T0087 1203-002855 IC-POSI.FIXED REG.;MC33269DTRK-5.0,DPRK, 1 S.A
....4 T0087 1203-002974 IC-POSI.FIXED REG.;AP1117D-25A,TO-252,3P 1 S.A
....4 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 S.A
....4 IC012 1203-003544 IC-POSI.ADJUST REG.;RT9173BPS,SOP-8,8P,5 1 S.A
....4 T0087 1203-003703 IC-POSI.FIXED REG.;AP1117E-18A,SOT-223,3 1 S.A
....4 IC507 1203-004363 IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P, 1 S.A
....4 IC508 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC807 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC118 1204-002651 IC-VIDEO PROCESS;MT8202EG,BGA,388P,27x27 1 S.A
....4 IC704 1205-003067 IC-RECEIVER;MT8293,LQFP,128P,14x14mm,PLA 1 S.A
....4 R885_OP 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216 1 S.A
....4 R886_OP 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216 1 S.A
....4 R524 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R826 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R830 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R847 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R855 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R860 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R611 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.A
....4 32_ 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R123 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R222 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R231 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R233 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R239 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R260_EU 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R306_27 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R307_27 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R308_27 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R317 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R330_27 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R331_27 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R332_27 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R333_27 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R607 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R608 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R616 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R618 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R642 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R644 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R701 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R706 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R716 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R717 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R719 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R720 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R721 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R722 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R723 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R724 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
6-4
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R725 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R726 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R730 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R746 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R883 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R366 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R374 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R617 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R620 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R621 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R622 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R624 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R625 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R643 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R738 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R739 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R740 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R741 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R742 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R743 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R744 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R745 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R117 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R118 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R343 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R344 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R365 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R367 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R857 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R858 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R125 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R129 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R202_EU 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R204_EU 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R214 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R245 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R246 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R247 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R252 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R259 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R303 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R326 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R329 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R345 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R372 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R504 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R505 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R507 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R508 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R509 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R510 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R511 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R512 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R513 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R514 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R526 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R528 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R542 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R632 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R633 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R649 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R702 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R736 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R737 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
6-5
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R875 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R101 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R703 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R731_OP 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R206 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R207 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R209 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R210 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R253 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R255 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R322 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R325 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R341 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R342 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R368 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R369 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R525 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R529 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R533 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R534 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R535 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R539 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R709 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R817 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R828 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R842 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R859 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R891 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R115_OP 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R119_OP 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R212 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R311 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R316 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R360 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R536 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R538 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R602 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R647 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R712 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R714 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R867 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R868 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R377 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R378 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R710 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R711 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R861 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R862 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R863 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R893 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R871 2007-000083 R-CHIP;3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R872 2007-000083 R-CHIP;3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R108 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R112 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R131 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R133 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R230 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R263 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R364 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R373 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R375 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R376 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R379 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
6-6
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R380 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R381 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R382 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R383 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R501 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R502 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R503 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R516 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R517 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R518 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R519 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R522 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R540 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R604 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R605 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R615 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R619 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R626 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R627 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R631 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R708 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R715 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R735 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R814 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R816 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R833 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R836 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R840 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R866 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R870 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R878 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R890 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R892 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R837 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 1 S.A
....4 R841 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 1 S.A
....4 R843 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 1 S.A
....4 R845 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 1 S.A
....4 R848 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 1 S.A
....4 R850 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 1 S.A
....4 R852 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 1 S.A
....4 R853 2007-000086 R-CHIP;5.6Kohm,5%,1/10W,TP,1608 1 S.A
....4 R873 2007-000088 R-CHIP;7.5Kohm,5%,1/10W,TP,1608 1 S.A
....4 R874 2007-000088 R-CHIP;7.5Kohm,5%,1/10W,TP,1608 1 S.A
....4 R103 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R104 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R114 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R313 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R339 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R340 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R362 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R363 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R506 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R646 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R707 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R811 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R812 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R827 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R829 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R831 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R832 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R880 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R894 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R895 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R896 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
6-7
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R897 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R612 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 1 S.A
....4 R613 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 1 S.A
....4 R120 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 1 S.A
....4 R121 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 1 S.A
....4 R113 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R208_EU 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R211_EU 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R256 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R257 2007-000094 R-CHIP;22Kohm,5%,1/10W,TP,1608 1 S.A
....4 R530 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 1 S.A
....4 R543 2007-000096 R-CHIP;30Kohm,5%,1/10W,TP,1608 1 S.A
....4 R130 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
....4 R201_EU 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
....4 R203_EU 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
....4 R250 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
....4 R251 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
....4 R312 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
....4 R889 2007-000097 R-CHIP;47Kohm,5%,1/10W,TP,1608 1 S.A
....4 R541 2007-000098 R-CHIP;56Kohm,5%,1/10W,TP,1608 1 S.A
....4 R102 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R111 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R127 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R601 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R603 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R801 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R802 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R803 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R804 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R805 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R806 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R807 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R808 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R818 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R819 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R820 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R821 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R822 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R823 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R824 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R825 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R122 2007-000106 R-CHIP;220Kohm,5%,1/10W,TP,1608 1 S.A
....4 R128_OP 2007-000106 R-CHIP;220Kohm,5%,1/10W,TP,1608 1 S.A
....4 R609 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R610 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R628 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R629 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R630 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R634 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R635 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R636 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R637 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R638 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R639 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R640 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R641 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R810 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R813 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R815 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R834 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R835 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R839 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R844 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R846 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
6-8
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R851 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R864 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R865 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R869 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
....4 R531 2007-000120 R-CHIP;680ohm,5%,1/10W,TP,1608 1 S.A
....4 R105 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.A
....4 R106 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.A
....4 R107 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.A
....4 R109 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R523 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R537 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R705 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R614 2007-000127 R-CHIP;9.1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R527 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608 1 S.A
....4 R221 2007-000287 R-CHIP;100OHM,1%,1/10W,TP,1608 1 S.A
....4 R223 2007-000287 R-CHIP;100OHM,1%,1/10W,TP,1608 1 S.A
....4 R228 2007-000287 R-CHIP;100OHM,1%,1/10W,TP,1608 1 S.A
....4 R232 2007-000287 R-CHIP;100OHM,1%,1/10W,TP,1608 1 S.A
....4 R238 2007-000287 R-CHIP;100OHM,1%,1/10W,TP,1608 1 S.A
....4 R240 2007-000287 R-CHIP;100OHM,1%,1/10W,TP,1608 1 S.A
....4 R350 2007-000287 R-CHIP;100OHM,1%,1/10W,TP,1608 1 S.A
....4 R354 2007-000287 R-CHIP;100OHM,1%,1/10W,TP,1608 1 S.A
....4 R357 2007-000287 R-CHIP;100OHM,1%,1/10W,TP,1608 1 S.A
....4 R243 2007-000293 R-CHIP;100ohm,5%,1/4W,TP,3216 1 S.A
....4 R318 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R319 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R320 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R321 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R323 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R324 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R327 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R328 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R623 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608 1 S.A
....4 R215 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608 1 S.A
....4 R258 2007-000458 R-CHIP;18Kohm,5%,1/10W,TP,1608 1 S.A
....4 R879 2007-000882 R-CHIP;4.7ohm,5%,1/10W,TP,1608 1 S.A
....4 R884 2007-000882 R-CHIP;4.7ohm,5%,1/10W,TP,1608 1 S.A
....4 R887 2007-000882 R-CHIP;4.7ohm,5%,1/10W,TP,1608 1 S.A
....4 R888 2007-000882 R-CHIP;4.7ohm,5%,1/10W,TP,1608 1 S.A
....4 R732 2007-000903 R-CHIP;430ohm,1%,1/10W,TP,1608 1 S.A
....4 R213_EU 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R216 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R218 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R220 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R225 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R227 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R235 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R237 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R241 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R262_EU 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R301 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R302 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R314 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R315 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R348 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R351 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R352 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R355 2007-000950 R-CHIP;47ohm,5%,1/4W,TP,3216 1 S.A
....4 R370 2007-001002 R-CHIP;510ohm,5%,1/10W,TP,1608 1 S.A
....4 R371 2007-001002 R-CHIP;510ohm,5%,1/10W,TP,1608 1 S.A
....4 R124 2007-001010 R-CHIP;51Kohm,5%,1/10W,TP,1608 1 S.A
....4 R346 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608 1 S.A
....4 R347 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608 1 S.A
....4 R384 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608 1 S.A
6-9
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R385 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608 1 S.A
....4 R606_EU 2007-001134 R-CHIP;68ohm,5%,1/10W,TP,1608 1 S.A
....4 R126 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R217 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R219 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R224 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R226 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R229_EU 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R234 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R236 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R242_EU 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R244 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R264_EU 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R309_27 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R310_27 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R334_27 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R532 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R349 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
....4 R353 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
....4 R356 2007-001167 R-CHIP;75ohm,5%,1/10W,TP,1608 1 S.A
....4 R116 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R854 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R856 2007-001179 R-CHIP;8.2Kohm,5%,1/10W,TP,1608 1 S.A
....4 RA606 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA608 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA609 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA610 2011-000002 R-NET;22ohm,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 R734 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA602 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA603 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA604 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA605 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA611 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA612 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA613 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA614 2011-000585 R-NET;47ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 R747 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 R748 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA601 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA607 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA615 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA701 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA702 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA703 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA704 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA705 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA706 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 RA707 2011-000881 R-NET;33ohm,5%,1/16W,L,CHIP,8P,TP,3.2x1. 1 S.A
....4 R515 2011-001011 R-NET;10Kohm,5%,1/16W,L,CHIP,8P,TP,3.2x1 1 S.A
....4 R733 2011-001011 R-NET;10Kohm,5%,1/16W,L,CHIP,8P,TP,3.2x1 1 S.A
....4 R838 2011-001011 R-NET;10Kohm,5%,1/16W,L,CHIP,8P,TP,3.2x1 1 S.A
....4 R849 2011-001011 R-NET;10Kohm,5%,1/16W,L,CHIP,8P,TP,3.2x1 1 S.A
....4 RA501 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA502 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA503 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA504 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA505 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA506 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA507 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA508 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA509 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA510 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA511 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
....4 RA512 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 1 S.A
6-10
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 RA513 2011-001093 R-NET;100OHM,5%,1/16W,L,CHIP,8P,TP,3216 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
