Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
5. Exploded View & Part List
5. Exploded View & Part List
5-1. LE26A33*J** Exploded View
M0027
M0013
M0115
T0764
M0014
M0254
T0447
M0215
T0003
5-1
5. Exploded View & Part List
5-1-2. LE26A33*J** Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-04750J ASSY COVER P-FRONT;26L330,EO(iDTV),ABS+P 1 S.A
M0215 BN07-00364A LCD-PANEL;V260B1-L04 1 S.A
T0175 BN96-04769A ASSY SPEAKER P;16ohm,4pin,5W,Jasmine 23" 1 S.A
M0115 BN61-02931A BRACKET-STAND LINK;JASMINE 26,SECC,T1.6 1 S.A
M0254 BN61-04267A HOLDER-SIDE AV;L330,HIPS HB , EO,BK500 1 S.N.A
M0146 BN61-02205B BRACKET-PANEL TOP;Bordeaux 26,SECC,T1.2 1 S.N.A
M0014 BN94-01758A ASSY PCB MAIN;LE26A336J1DXXC 1 S.A
T0764 BN44-00191B SMPS-LCDTV;MK32P3,SEM,AC/DC,180W,AC100 ~ 1 S.A
M0013 BN96-04820H ASSY COVER P-REAR;26L330,EO(iDTV),HIPS,H 1 S.A
M0027 BN96-04745A ASSY STAND P-BASE;-,22,23,26S81,-,ABS+PM 1 S.A
5-2
5. Exploded View & Part List
5-2. LE32A33*J** Exploded View
M0027
M0013
M0115
T0764
M0014
M0254
M0107
T0447
M0215
T0003
5-3
5. Exploded View & Part List
5-2-1. LE32A33*J** Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-04694R ASSY COVER P-FRONT;32L330,EO(iDTV),ABS+P 1 S.A
BN07-00534A
M0215 LCD-PANEL;V315B1-L01 C4 1 S.A
BN07-00538A
T0175 BN96-04770A ASSY SPEAKER P;8ohm,4pin,10W,Jasmine 32" 1 S.A
M0115 BN61-02947A BRACKET-STAND LINK;JASMINE 32",SECC,T1.6 1 S.N.A
M0254 BN61-04267A HOLDER-SIDE AV;L330,HIPS HB , EO,BK500 1 S.N.A
T0447 BN96-04681A ASSY BRACKET P-PANEL;-,32R81,-,-,-,-,AM, 1 S.N.A
M0146 BN61-02970A BRACKET-PANEL TOP;32 BORDEAUX PLUS,SECC, 1 S.N.A
T0764 BN44-00192B SMPS-LCDTV;MK32P3,DYREL,AC/DC,180W,AC100 1 S.A
M0013 BN96-04698G ASSY COVER P-REAR;32L330,EO(iDTV),HIPS,H 1 S.A
M0027 BN96-04697B ASSY STAND P-BASE;-,32S8,-,ABS+PMMA,BK23 1 S.A
5-4
5. Exploded View & Part List
5-3. LE37A33*J** Exploded View
M0027
M0013
M0146
M0115
T0764
M0014
M0254
M0107
M0146
M0215
T0003
5-5
5. Exploded View & Part List
5-3-1. LE37A33*J** Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-04826F ASSY COVER P-REAR;37L330,EO,HIPS,HB,BK50 1 S.A
M0215 BN07-00393A LCD-PANEL;T370XW02 1 S.A
T0175 BN96-04770B ASSY SPEAKER P;8ohm,4pin,10W,600/1250mm, 1 S.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.A
M0254 BN61-04267A HOLDER-SIDE AV;L330,HIPS HB , EO,BK500 1 S.N.A
T0447 BN96-04680E ASSY BRACKET P-PANEL;-,37S86,EO,-,-,-,-, 1 S.N.A
M0146 BN61-02971A BRACKET-PANEL TOP;37 BORDEAUX PLUS,SECC, 1 S.N.A
M0014 BN94-01759C ASSY PCB MAIN;LE37A330J1XXC 1 S.A
T0764 BN44-00216A SMPS-LCDTV;MK37P5T,SEM,AC/DC,171W,AC100 1 S.A
M0013 BN96-04826G ASSY COVER P-REAR;37L330,EO(iDTV),HIPS,H 1 S.A
M0027 BN96-04754A ASSY STAND P-BASE;37,40S81,W/W,ABS+PMMA, 1 S.A
5-6
5. Exploded View & Part List
5-4. LE40A33*J** Exploded View
M0027
M0013
M0115
M0146
T0764
M0014
M0254
M0107
M0146
M0215
T0003
5-7
5. Exploded View & Part List
5-4-1. LE40A33*J** Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-07880E ASSY COVER P-FRONT;40L330,EO(iDTV),ABS+P 1 S.A
M0215 BN07-00515A LCD-PANEL;T400XW01 V5 1 S.A
T0175 BN96-04770B ASSY SPEAKER P;8ohm,4pin,10W,600/1250mm, 1 S.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.A
M0146 BN61-02972A BRACKET-PANEL TOP;40 BORDEAUX PLUS,SECC, 1 S.N.A
M0014 BN94-01971D ASSY PCB MAIN-AUO;LE40A336J1DXXC 1 S.A
M0125 BN96-05490A ASSY INLET P;LE52M87BDX,XEC,300,300,150m 1 S.A
M0254 BN61-04267A HOLDER-SIDE AV;L330,HIPS HB , EO,BK500 1 S.N.A
M0013 BN96-04822E ASSY COVER P-REAR;40L330,EO(iDTV),HIPS,H 1 S.A
M0027 BN96-04754A ASSY STAND P-BASE;37,40S81,W/W,ABS+PMMA, 1 S.A
5-8
5. Exploded View & Part List
5-5. LE32A33*J*N** Exploded View
M0027
M0014
M0115
M0013
M0107
M0215
T0003
5-9
5. Exploded View & Part List
5-5-1. LE32A33*J*N** Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-08138B ASSY COVER P-FRONT;HANARO 32,EO(iDTV),AB 1 S.A
M0215 BN07-00603A LCD-PANEL;T320HA01-BA 1 S.A
M0115 BN61-02947A BRACKET-STAND LINK;JASMINE 32",SECC,T1.6 1 S.N.A
M0014 BN94-01971X ASSY PCB MAIN-AAQ;LE32A336J1NXXC,OEM 1 S.A
M0107 BN63-04837A SHIELD-COVER;HANARO 32" EO,SPTE,T0.3,PAL 1 S.N.A
M0013 BN96-08137A HANARO 32,EO(iDTV),HIPS,HB,BK500 1 S.A
M0027 BN96-04697C HANARO,32,W/W,ABS+PMMA,HB,BK23,H/GLOSSY 1 S.A
5-10
5. Exploded View & Part List
5-6. LE26A33*J** Parts List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
LE26A336J1DXXC LE26A336J1D,N51A/26S80-GJE,26,LCD-TV,SPA
0.1 M0001 BN90-01201M ASSY COVER FRONT;26L330,EO(iDTV) 1 S.N.A
..2 T0003 BN96-04750J ASSY COVER P-FRONT;26L330,EO(iDTV),ABS+P 1 S.A
...3 M0081 6003-001024 SCREW-TAPTITE;RWH,+,-,B,M4,L12,ZPC(WHT), 4 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.A
...3 M0162 6502-001067 CABLE CLAMP;DAFC-1300,ID2.2,T5.2,NYLIN6/ 2 S.N.A
...3 T0069 AA60-00091J SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.5,- 2 S.N.A
...3 T0069 AA60-00171N SPACER-FELT;61L3,FELT,620,T0.5,10 2 S.N.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 BN61-03261C BOSS-TAPE;Tulip,ACRYL,T1.1,W24mm,GRAY,TA 0.6 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.559 S.N.A
...3 M0112 BN63-03172G COVER-FRONT;26L330,EO(iDTV),ABS+PMMA,HB, 1 S.N.A
...3 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
...3 T0022 BN64-00467E KNOB CONTROL;37S62,SONOMA26,32,40,ABS,HB 1 S.N.A
...3 T0023 BN64-00589A KNOB POWER;32S81,PC,-,-,-,-,VIOLET,-,- 1 S.N.A
...3 T0054 BN64-00590A KNOB-DECORATION;JASMINE 32,ABS,-,-,-,HB, 1 S.N.A
...3 BN64-00826A DECORATION-BOTTOM;L330 26INCH,HIPS,HB,BK 1 S.N.A
...3 M0145 BN96-03466A ASSY BOARD P-FUNCTION;SONOMA,SJ06-01-008 1 S.A
...3 T0175 BN96-04769A ASSY SPEAKER P;16ohm,4pin,5W,Jasmine 23" 1 S.A
...3 M0146 BN96-04884B ASSY BOARD P-POWER & IR;LNT3242HX/XAA,CT 1 S.A
...3 T0069 AA63-60001Q SPACER-FELT;-,FELT,-,-,-,BLK,T0.35,-,150 1 S.N.A
0.1 M0002 BN90-01207L ASSY COVER REAR;26L330,EO(iDTV) 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 11 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
..2 M0013 BN96-04820H ASSY COVER P-REAR;26L330,EO(iDTV),HIPS,H 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.A
...3 T0101 BN61-03346A BRACKET-WALL;LCD TV,SECC,T1.2 4 S.N.A
...3 M0006 BN63-03194F COVER-REAR;26L330,EO(iDTV),HIPS,HB,BK500 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,-,-,BLK,- 1 S.N.A
...3 T0071 BN64-00872A INLAY-TERMINAL;L330L,PS SHEET,T0.5,-,-,B 1 S.N.A
0.1 M0216 BN90-01212A ASSY STAND;26S81 1 S.N.A
..2 M0027 BN96-04745A ASSY STAND P-BASE;-,22,23,26S81,-,ABS+PM 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 4 S.A
...3 T0920 BN61-03024A GUIDE-STAND;JASMINE 26,ABS,-,-,-,BK500,V 1 S.N.A
...3 BN61-03028A BRACKET-STAND BOTTOM;JASMINE 26",SECC,T1 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.2 S.N.A
...3 T0004 BN63-03178A COVER-STAND BASE;JASMINE 26",ABS+PMMA,HB 1 S.N.A
...3 M0126 BN73-00052C RUBBER-FOOT;LCD TV,CR RUBBER,T2.0 DIA19, 4 S.N.A
..2 T0524 6902-000561 BAG PE;HDPE+NITRON(DOUBLE),T0.015+T0.5,W 1 S.N.A
0.1 T0852 BN91-01180K ASSY LCD-CMO;LE26R32BX/* 1 S.N.A
..2 M0215 BN07-00364A LCD-PANEL;V260B1-L04 1 S.A
5-11
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
0.1 M0112 BN91-02221A ASSY SHIELD;LE26A336J1DXXC 1 S.N.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 6 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 6 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 2 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 2 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 M2893 BH39-00362G LEAD CONNECTOR;SONOMA,UL1007#26,5PIN,100 1 S.A
..2 T0076 BN39-00615D CBF HARNESS;BORDEAUX,1617#22,3P,1P,RING, 1 S.A
..2 M2893 BN39-00802A LEAD CONNECTOR;LE32R86BDX,UL1007#26,UL/C 1 S.A
..2 M0146 BN61-02207A BRACKET-PANEL SIDE;Bordeaux 26,SECC,T1.2 4 S.N.A
..2 M0115 BN61-02931A BRACKET-STAND LINK;JASMINE 26,SECC,T1.6 1 S.A
..2 M0107 BN63-03039A SHIELD-COVER;MURANO40,PCM,T0.5,IDTV 1 S.N.A
..2 T0764 BN44-00191B SMPS-LCDTV;MK32P3,SEM,AC/DC,180W,AC100 ~ 1 S.A
..2 M0251 BN96-07611B ASSY CABLE P;CORAL,FFC CABLE,235MM,30PIN 1 S.A
..2 M2893 BN39-00849B LEAD CONNECTOR;LNT4681FX/XAA,UL1007 #26, 1 S.A
..2 M0412 BN96-07539B ASSY BRACKET P-PCB;26L330,SECC,JADE,NEW 1 S.N.A
...3 M0146 BN61-02205B BRACKET-PANEL TOP;Bordeaux 26,SECC,T1.2 1 S.N.A
...3 BN61-02210A BRACKET-GUIDE POWER;Bordeaux 26,SECC,T1. 1 S.N.A
...3 BN61-02966A BRACKET-GUIDE POWER;23 BORDEAUX PLUS,SEC 1 S.N.A
...3 BN61-02973B BRACKET-PANEL BOTTOM;26R81,SECC,T1.2,AUO 1 S.N.A
...3 BN61-03878A BRACKET-GUIDE MAIN;L450 26INCH,SECC,T1.0 1 S.N.A
...3 M0131 BN63-02950A GASKET;LE32M73BDX,Conductive Fabric,300m 1 S.N.A
...3 M0131 BN63-02958A GASKET;LE32M71BX,Conductive Fabric,10mm, 1 S.N.A
..2 M0254 BN61-04267A HOLDER-SIDE AV;L330,HIPS HB , EO,BK500 1 S.N.A
0.1 M0017 BN91-02225A ASSY CHASSIS;LE26A336J1DXXC 1 S.N.A
..2 M0014 BN94-01758A ASSY PCB MAIN;LE26A336J1DXXC 1 S.A
...3 0202-001557 SOLDER-CREAM;LST57-A,D38-63,42SN/57BI/1A 11 S.N.A
...3 T0245 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 S.N.A
...3 JA3004 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 CN330 3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN 1 S.A
...3 CN330 3711-004379 HEADER-BOARD TO CABLE;BOX,4P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
...3 CN330 3711-004712 HEADER-BOARD TO CABLE;BOX,9P,1R,2mm,STRA 1 S.A
...3 CN330 3711-005842 HEADER-BOARD TO CABLE;BOX,24P,2R,2MM,STR 1 S.A
...3 JA3205_330 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA333 3722-002523 JACK-PIN;3P,NI,YEL/WHT/RED,STRAIGHT 1 S.A
...3 M0107 BN63-04528A SHIELD-COVER;450 EO,SPTE,T0.3,PAL NORMA 1 S.N.A
...3 HDCP BN97-00688A ASSY HDCP;BN46-00018A,PS-42V6S,D73A,GENE 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
5-12
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
...3 T0174 BN97-02141A ASSY SMD;LE26A336J1DXXC 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45##,96.5Sn/ 3.137 S.N.A
....4 D2001 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D2002 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D2003 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D2009 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D2012 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D2015 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1004 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3003 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3004 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3006 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3007 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3008 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3009 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3010 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3011 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3012 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3013 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3016 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3017 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3019 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3021 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3022 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3023 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3024 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3025 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3026 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3027 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3045 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3046 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3047 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3061 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3062 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3064 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3066 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3202 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3203 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3204 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3205 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3206 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3207 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3217 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3218 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3219 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1002 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D2019 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D3063 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D3065 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D3067 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D3077 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
5-13
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 D3079 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D3070 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D3216 0403-000607 DIODE-ZENER;VLZ16C,15.69/16.51V,500mW,SO 1 S.A
....4 D3229 0403-000607 DIODE-ZENER;VLZ16C,15.69/16.51V,500mW,SO 1 S.A
....4 D3002 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3015 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3042 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5002 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3001 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D3014 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D5201 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D1005 0403-001425 DIODE-ZENER;BZX84C33,31-35V,350mW,SOT-23 1 S.A
....4 D0254 0404-001271 DIODE-SCHOTTKY;SSA34,40V,3000mA,SMA,TP 1 S.A
....4 D3053 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3054 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3055 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3056 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3057 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3058 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3068 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3069 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3212 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3213 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3214 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3215 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3220 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3221 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3222 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3223 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3224 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3225 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3226 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3227 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D3228 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D2013 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D3071 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D3072 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D7201 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D7202 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D7203 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D7204 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D7205 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D7206 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 Q7001 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23, 1 S.A
....4 Q7002 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150MW,SOT-23, 1 S.A
....4 Q7402 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q1001 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q1002_L 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q2001 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q2002 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q2003 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
5-14
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 Q2004 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q2007 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q2008 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q2009 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3006 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3007 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3207 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3208 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q5002 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q5201 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q5202 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q6003_L 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q2005 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q2006 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q3202 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q3205 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q1004_L 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q3201 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q3203 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q3204 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q3206 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-001165 FET-SILICON;SI3443BDV,P,-20V,+-4.4A,65mo 1 S.A
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 S.A
....4 IC104 0801-002095 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP 1 S.A
....4 IC104 0801-002172 IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI 1 S.A
....4 IC104 0801-002172 IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI 1 S.A
....4 IC104 0801-002172 IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI 1 S.A
....4 IC104 0801-002432 IC-CMOS LOGIC;74LVC244,8BIT BUFFER/DRIVE 1 S.N.A
....4 IC104 0801-002630 IC-CMOS LOGIC;74AHCT1G08,2-INPUT AND GAT 1 S.A
....4 IC104 0801-003239 IC-CMOS LOGIC;74LVC1G00,2-input NAND Gat 1 S.A
....4 IC104 0801-003239 IC-CMOS LOGIC;74LVC1G00,2-input NAND Gat 1 S.A
....4 IC2002 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 S.A
....4 IC5203 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 S.A
....4 IC106 1001-001082 IC-VIDEO SWITCH;BA7657F,-,SOP,24P,300MIL 1 S.A
....4 IC3011 1001-001109 IC-ANALOG SWITCH;FST3125M,BUS SWITCH & C 1 S.A
....4 IC106 1001-001440 IC-VIDEO SWITCH;SiI9185CTU,QFP,80P,3.3V, 1 S.A
....4 IC107 1002-001482 IC-D/A CONVERTER;WM8521H9GED/R,16bit,SOI 1 S.A
....4 IC110 1006-001076 IC-DRIVER/RECEIVER;MAX232ECWE+T,SOP,16P, 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
5-15
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 IC112 1103-001385 IC-EEPROM;AT24C256,256Kbit,32Kx8,SOP,8P, 1 S.A
....4 IC112 1103-001410 IC-EEPROM;S-24CS08AFJ-TB-1GE,8Kbit,1Kx8, 1 S.A
....4 IC113 1105-001712 IC-DRAM;HYB25D256163CE,DDR,256Mbit,16Mx1 1 S.A
....4 IC5201 1105-001838 IC-DDR SDRAM;EM6A9160TS0A-5G,DDR SDRAM,1 1 S.A
....4 DU410 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 S.A
....4 DU410 1201-000541 IC-OP AMP;062,SOP,8P,153MIL,DUAL,6V/mV,P 1 S.A
....4 DU410 1201-000541 IC-OP AMP;062,SOP,8P,153MIL,DUAL,6V/mV,P 1 S.A
....4 T0085 1201-002487 IC-AUDIO AMP;MAX9728A,QFN,12P,3x3mm,DUAL 1 S.A
....4 T0124 1201-002677 IC-POWER AMP;NTP3100,QFN56,56P,8x8mm,DUA 1 S.A
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,-,PLA 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 T0087 1203-002974 IC-POSI.FIXED REG.;AP1117D-25A,TO-252,3P 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 S.A
....4 IC7206 1203-003394 IC-POWER SUPERVISOR;MIC2544-1YM,SOP,8P,4 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 IC5002 1203-004363 IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P, 1 S.A
....4 IC2005 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC6003_L26 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC7402 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 T0087 1203-004816 IC-POSI.FIXED REG.;KIA78D015F,DPAK,3P,6. 1 S.A
....4 IC7001 1204-002861 IC-DECODER;UPD61211GM-104-GAA-A,QFP,216P 1 S.A
....4 IC109 1205-003432 IC-LCD CONTROLLER;SEMS01,LQFP,256P,30x30 1 S.A
....4 IC3012 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 IC3013 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 IC3014_3H 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 R110 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000066 R-CHIP;20Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
5-16
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
5-17
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
5-18
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000146 R-CHIP;6.8Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
5-19
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
5-20
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
5-21
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.A
....4 R110 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
