Image preview - the first page of the document
Product Specification


>> Download Product Specification documenatation <<

Text preview - extract from the document
                                                                                             2. Product specifications

2. Product specifications
2-1. Feature & Specifications
               Model                                                  LE26A33*J**

                                                        Feature

   Digital TV(LE26A336J**), RF, 2-HDMI, 1-Component, 1-AV, D-SUB
   Brightness : 500cd/m2
   Contrast Ratio : 800:1
   Response time : 8ms
   Dynamic contrast

                                                     Specifications

               Item                                                   Description
LCD Panel                      TFT-LCD panel, RGB vertical stripe, SPVA mode, normaly black,
                               26-Inch viewable, 0.4215(H) x 0.4215(W) x 3 mm pixel pitch
Scanning Frequency             Horizontal : 30 kHz ~ 80 kHz (Automatic)
                               Vertical : 56 Hz ~ 75 Hz (Automatic)
Display Colors                 16.7 million colors
Maximum resolution             Horizontal : 1366 Pixels
                               Vertical : 768 Pixels
Input Signal                   Analog 0.7 Vp-p
