20080328124348671_06_Wiring_Diagram


>> Download 20080328124348671_06_Wiring_Diagram documenatation <<

Text preview - extract from the document
                      6. Wiring Diagram

6. Wiring Diagram
6-1. Wiring Diagram




                                   6-1
6. Wiring Diagram




6-2
                      6. Wiring Diagram

6-2. Wiring Picture




                                   6-3
6. Wiring Diagram

6-3. Connector Functions

              Connector                                    Functions
Panel <-> CN6105_51P        The LVDS signal transfered Panel to Main Board.
          CN6103_41P        * defective symptom : No pcture but normal sound

IP, SMPS <-> CN6104         Supply dimming power from IP,SMPS to Main Board.
                            * defective symptom : No pcture, repeat power On/Off

IP, SMPS <-> CN101          Supply main power from IP,SMPS to Main Board.
                            * defective symptom : No picture, diable Power On/Off

IP, SMPS <-> Panel Driver   Supply power and signal from IP, SMPS to Panel Driver.
                            * defective symptom : No picture but normal sound

CN3115_SIDE <-> CN105       The signal transfered from Main Board to Side-AV, HDMI, S-Video, USB,
                            Headphone
                            * defective symptom : cannot any fuctions of SIDE Jack




6-4
                                                                                  6. Wiring Diagram

6-4. Cables
Code     BN96-07161K (LVDS_46inch)   BN96-07161L (LVDS_52inch)      BN96-07518A (LVDS_32inch)








Code     BN96-07161J (LVDS_40inch)   BN39-00886A (14P_37inch)       BN39-00849C (14P_32inch)








Code     BH39-00362D (5P_52inch)     BN39-00789A (5P_46inch)        BN39-00674A (5P_40inch)






Code     BH39-00362B (5P_37inch)     BH39-00362G (5P_32inch)        BN39-00802Q (24P_52 inch)






Code     BN39-00802G (24P_46 inch)   BN39-00802F (24P_37,40 inch)   BN39-00802A (24P_32inch)






         BN39-00948E                 BN96-05167A
Code
         (Side HDMI Cable_350mm)     (Side AV_350mm)








                                                                                                6-5
6. Wiring Diagram
