Image preview - the first page of the document

>> Download Disassembly & Reassembly documenatation <<

Text preview - extract from the document

3. Disassembly and Reassembly

3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LE**C650 LCD TV.
WARNING: This LCD TV contains electrostatically sensitive devices. Use caution when handling these components.

3-1. Disassembly and Reassembly
Cautions: 1. Disconnect the LCD TV from the power source before disassembly.
2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.

Description Picture Description Screws
1. Place LCD TV face down on cushioned table.
Remove screws from the Stand.
Remove stand.

Be cautious not to scratch the rear cover
when you working with screws. 6003-001003
(M4, L12, Tapping)

3-1
3. Disassembly and Reassembly

Description Picture Description Screws
2. Remove the screws of rear-cover.

6003-001003
(M4, L12, Tapping)

3. Lift up the rear-cover.

3-2
3. Disassembly and Reassembly

Description Picture Description Screws
4. Remove the screws of IP and main board.

6001-002284
(M4, L6, Machine)

5. Remove the speakers and screws of inlet
socket.

6001-002284
(M4, L6, Machine)

3-3
3. Disassembly and Reassembly

Description Picture Description Screws
6. Remove the screws of Stand BKLT.
Lift up the Stand BKLT.

7. Remove the Side AV Ass'y. (only 46")

3-4
3. Disassembly and Reassembly

Description Picture Description Screws
8-1. Remove the screws of bracket. (32")

8-2. Remove the screws of bracket. (40")

Reassembly procedures are in the reverse order of disassembly procedures.
