Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
5. Exploded View & Part List
5. Exploded View & Part List
5-1. LE32C650L1 Exploded View
R001A
T0101
T0101
T0101
T0910 T0101
T0764
INVER M0014
PANEL
TCON T0920
F001A M0027
T0175
T0175
5-1
5. Exploded View & Part List
5-2. LE32C650L1 Parts List
Location No. Code No. Description & Specification Q'ty SA/SNA Remark
F001A BN96-12750B ASSY COVER P-FRONT;32,LC650,EO,PC+PC,V2, 1 SA
INVER BN81-04437A A/S-INV T315HW04 V3;T315HW04 V3 1 SA
M0014 BN94-03454A ASSY PCB MAIN-AAE;LE32C650L1WX* 1 SA
M0027 BN96-12761A ASSY STAND P-BASE;32,EXPORT,TEMPERED GLA 1 SA
PANEL BN07-00827A LCD-PANEL;T315HW04 V3,AU31H43,8bit,31.5, 1 SA
R001A BN96-12765D ASSY COVER P-REAR;32,LC650,EO,PCM,T0.5,B 1 SA
T0101 BN61-05996A BRACKET-WALL;LC650 40,SECC,T1.2 4 SNA
T0175 BN96-12871A ASSY SPEAKER P;6ohm,4pin,10W,L:530 R:170 1 SA
T0910 BN96-13341A ASSY BRACKET P-STAND LINK;LC530 32,SECC, 1 SNA
T0920 BN61-06002A GUIDE-STAND;32,LC650,PC+G/F,20%,V2,BK000 1 SNA
TCON BN81-04408A A/S-T CON T315HW04_V3;T315HW04 V3 1 SA
5-2
5. Exploded View & Part List
5-2-1. LE32C650L1 Parts List
Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
0.1 BN90-02437B ASSY COVER FRONT;32,LC650,EO 1 SNA
..2 F001A BN96-12750B ASSY COVER P-FRONT;32,LC650,EO,PC+PC,V2, 1 SA
...3 BN60-00163A SPACER-FOAM;LC650-32",FOAM,400,0.5,25,Bo 2 SNA
...3 BN60-00163F SPACER-FOAM;LC650-32",FOAM,750,T 0.5,22, 1 SNA
...3 AB326 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 4 SNA
...3 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE 0.37 SNA
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.04,900mm,20 0.31 SNA
...3 CCM1 BN63-05199P COVER-SHEET;AMBER,PE,T0.08,W1000,200M,CL 0.28 SNA
...3 F001 BN63-06330B COVER-FRONT;32,LC650,EO,PC+PC,V2,TP0010+ 1 SNA
...3 BN64-01222A DECORATION;32,LC650,PC,V2,RD0045(RED) 1 SNA
...3 M0125 BN96-13226B ASSY BOARD P-TOUCH FUNCTION&IR;LC650,129 1 SA
...3 BN61-06019B HOLDER-BOSS BOTTOM;32,LC650,ABS,HB,BK002 1 SNA
...3 BN60-00162C SPACER-FOAM;FOAM,50000mm,Dark Gray,0.5T, 0.2 SNA
..2 T0175 BN96-12871A ASSY SPEAKER P;6ohm,4pin,10W,L:530 R:170 1 SA
0.1 S001A BN90-02442B ASSY STAND;32,LC650,W/W,2COAT,ROSE BLACK 1 SNA
..2 M0027 BN96-12761A ASSY STAND P-BASE;32,EXPORT,TEMPERED GLA 1 SA
...3 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 3 SA
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 SNA
...3 BN61-04731C BOSS-TAPE;AMBER,ACRYL,T1.1,W16.0mm,WHITE 0.29 SNA
...3 BN61-04855A BRACKET-SWIVEL BOTTOM;B650 40,SECC,T2.0 1 SNA
...3 BN61-05254A HOLDER-SWIVEL RING BOTTOM;LB700 40,POM H 1 SNA
...3 BN61-05653A BRACKET-STAND BOTTOM;B650 32,SECC,T2.0 1 SNA
...3 BN61-05826A BOSS-BOND;#760,Poly urethane,Black 2.4 SNA
...3 GSN01 BN61-05993A GUIDE-STAND NECK;32,LC650,PETG,V2,TP0003 1 SNA
....4 BN61-06078B GUIDE-NECK-INSERT;LC650 32,PETG HB,TP000 1 SNA
...3 CCM1 BN63-04755A COVER-SHEET;AMBER,PE,T0.05,W150mm,200M,6 1.1 SNA
...3 BN63-05530D COVER-STAND GLASS;32,LC650,GLASS,T8.0,2C 1 SNA
...3 T0527 BN68-01648B LABEL WARNING;WW,PET,T0.05,40,25,EXPORT 1 SNA
...3 M0126 BN73-00215A RUBBER-FOOT;40LB650,RUBBER,15*25,60,4.0, 4 SNA
...3 M0126 BN73-00217A RUBBER-FOOT;LB650,RUBBER,DIA30,7.5,Dark 4 SNA
...3 BN74-00031A GREASE;kanto-kasei FL-955,grease,wht 0.4 SNA
...3 T0056 BN63-06908A COVER-DECORATION;LB700 40,ABS+PMMA,HB,H/ 1 SNA
..2 T0920 BN61-06002A GUIDE-STAND;32,LC650,PC+G/F,20%,V2,BK000 1 SNA
0.1 R001A BN90-02446D ASSY COVER REAR;32,LC650,EO 1 SNA
..2 R001A BN96-12765D ASSY COVER P-REAR;32,LC650,EO,PCM,T0.5,B 1 SA
...3 R001 BN63-06392B COVER-REAR;32,LC650/630,EO,PCM,T0.5,BLK, 1 SNA
...3 T0071 BN64-01227A INLAY-TERMINAL;LC650 40,PS SHEET,T0.5,eu 1 SNA
...3 BN64-01269A INLAY-AV;LC650,PS SHEET,T0.5,EO 1 SNA
...3 T0139 BN65-00003A CLAMPER BAG;42C7,LDPE,HB,BLK 1 SNA
...3 AH358 BN61-06544A HOLDER-REAR;LC650 32,PP,BLK 1 SNA
...3 BN60-00162C SPACER-FOAM;FOAM,50000mm,Dark Gray,0.5T, 0.86 SNA
..2 SCREW 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 9 SA
0.1 BN91-04752D ASSY SHIELD;LE32C650L1WX* 1 SNA
..2 T0081 6001-002284 SCREW-MACHINE;BH,+,M4,L8,ZPC(WHT),SWRCH1 9 SA
..2 M0081 6003-000337 SCREW-TAPTYPE;BH,+,S,M4,L10,ZPC(BLK),SWR 6 SA
..2 M2893 BN39-01267A LEAD CONNECTOR;LA32B450,UL 2651 AWG#26,1 1 SA
..2 M2893 BN39-01274A LEAD CONNECTOR;LC5F,UL 1007 #26,14P,80mm 1 SA
..2 T0764 BN44-00339A SMPS-LCD TV;P3237F1_ASM,P3237F1_ASM,AC/D 1 SA
5-3
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
..2 BN61-05991A HOLDER-SIDE AV;40,LC650,EO,PC+ABS,V0,BK0 1 SNA
..2 FL06 BN96-12723A ASSY CABLE P-FPCB LVDS CABLE;120Hz-32inc 1 SA
..2 M0523 BN96-12973A ASSY BRACKET P-WALL;32,37,40,LC650,SECC, 4 SNA
...3 T0101 BN61-05996A BRACKET-WALL;LC650 40,SECC,T1.2 4 SNA
...3 BN60-00188B SPACER-FOAM;LCD,FELT,20,3.0,20,Center : 4 SNA
..2 T0910 BN96-13341A ASSY BRACKET P-STAND LINK;LC530 32,SECC, 1 SNA
...3 BN61-02429K STUD-PEM;PNB,M3.8,D7,L14.9,ZPC(SIL),SUM2 4 SNA
...3 M0115 BN61-06024A BRACKET-STAND LINK;LC550 32",SECC,T1.2 1 SNA
...3 BN61-05281A HOLDER-CLAMP;LCD,NYLON 66,WHT 2 SNA
..2 T0081 6001-002604 SCREW-MACHINE;BH,+,M4,L10,ZPC(WHT),SWRCH 2 SA
..2 BN61-06441A HOLDER-INLET;LC530,ABS,V0 1 SNA
..2 BN61-06559A HOLDER-GROUND;LC550,SUS304,0.3 2 SNA
..2 SCREW 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 7 SA
0.1 BN91-04945A ASSY LCD-AUO;BN07-00827A 1 SNA
..2 PANEL BN07-00827A LCD-PANEL;T315HW04 V3,AU31H43,8bit,31.5, 1 SA
...3 TCON BN81-04408A A/S-T CON T315HW04_V3;T315HW04 V3 1 SA
...3 INVER BN81-04437A A/S-INV T315HW04 V3;T315HW04 V3 1 SA
0.1 M0017 BN91-05421A ASSY CHASSIS;LE32C650L1WX* 1 SNA
..2 M0014 BN94-03454A ASSY PCB MAIN-AAE;LE32C650L1WX* 1 SA
...3 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 SA
...3 CN906 3707-001096 CONNECTOR-OPTICAL;STRAIGHT W/L,SPDIF 1 SA
...3 3709-001601 CONNECTOR-CARD SLOT;68P W/L,1.27mm,PCMCI 1 SA
...3 3711-007302 HEADER-BOARD TO BOARD;BOX,18P,2R,2mm,ANG 1 SA
...3 3722-003037 JACK-USB;4P/1C W/L,AU/NI,BLK,ANGLE,A 2 SA
...3 JA330 3722-003038 JACK-PHONE;7P/1C W/L,SN,BLK 2 SA
...3 JA333 3722-003040 JACK-PIN;3P W/L,SN,BLK/YEL/WHT/RED,ANGLE 1 SA
...3 JA333 3722-003052 JACK-PIN;5P+Shield W/L,NI/SN,GN/BL/RD/WH 1 SA
...3 3722-003058 JACK-MODULAR;8P/8C W/L,Y,STRAIGHT,N,AU,1 1 SA
...3 3722-003063 JACK-SCART;42P W/L,SN,BLK 1 SA
...3 CIS3 BN40-00173A TUNER;DTOS40CVL081A,DVB-T/C,164CH,38.9MH 1 SA
...3 BN97-04241A ASSY CI PLUS;BN46-00027A,platform Euro C 1 SNA
....4 BN46-00027A KEY CODE-CI PLUS;CI PLUS KEY,TCTC,SERIAL 1 SNA
...3 BN97-04254A ASSY SMD;LE32C650L1WX*,BN94-03454A 1 SNA
....4 0202-001767 SOLDER-CREAM;LST-5710,D20~38,Sn-57Bi-1Ag 2.8 SNA
....4 DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 19 SA
....4 0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 5 SA
....4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8/6.6V,300mW,SO 22 SNA
....4 D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 4 SA
....4 T0139 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 2 SA
....4 T0139 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 9 SNA
....4 Q101 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 12 SA
....4 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 2 SA
....4 CEQ2 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 SA
....4 Q409 0505-000274 FET-SILICON;AO4435L,P,-30V,-11A,0.014ohm 1 SNA
....4 IC104 0801-002630 IC-CMOS LOGIC;74AHCT1G08,2-INPUT AND GAT 1 SA
....4 ND51C2 0801-002780 IC-CMOS LOGIC;74LVC1G17,SCHMITT-TRIGGER 1 SA
....4 IC104 0801-003330 IC-CMOS LOGIC;Octal buffer,DQFN,20P,4.5x 2 SA
....4 IC104 0802-001012 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,DQFN, 1 SNA
....4 IC106 1001-001177 IC-VIDEO SWITCH;TEA6425D,VIDEO SWITCH,SO 1 SA
....4 IC106 1001-001573 IC-VIDEO SWITCH;SiI9287BCNUTR,QFN,72P,10 1 SNA
....4 IC107 1002-001482 IC-D/A CONVERTER;WM8521H9GED/R,16bit,SOI 1 SA
5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 2 SA
....4 IC112 1103-001475 IC-EEPROM;M24256-BR,256Kbit,32Kx8,SOP,8P 1 SNA
....4 1105-001931 IC-DDR2 SDRAM;K4T51163Q,DDR2-800,512Mbit 2 SA
....4 1105-002058 IC-DDR2 SDRAM;K4T1G164QE-HCF8,DDR2,1Gbit 2 SA
....4 1105-002075 IC-DDR2 SDRAM;K4T1G084QE-HCF8,DDR2,1Gbit 4 SA
....4 T0085 1201-002487 IC-AUDIO AMP;MAX9728A,QFN,12P,3x3mm,DUAL 1 SA
....4 T0124 1201-002992 IC-POWER AMP;STA369BWS,PSSO,36P,10.3x7.5 1 SA
....4 T0087 1203-002519 IC-POSI.FIXED REG.;KIA7809AF,DPAK,3P,240 1 SA
....4 IC012 1203-003544 IC-POSI.ADJUST REG.;RT9173BPS,SOP-8,8P,5 1 SA
....4 1203-004363 IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P, 1 SA
....4 1203-006012 IC-DC/DC CONVERTER;MP8725EL,QFN14,14P,3x 1 SA
....4 1203-006017 IC-VOL. DETECTOR;RT9824GJ8,TSOT23,8P,2.9 1 SA
....4 1203-006104 IC-DC/DC CONVERTER;MP8707EN,SOIC8E,8P,4. 3 SA
....4 T0087 1203-006109 IC-POSI.FIXED REG.;S-1206B33-M3T1G,SOT-2 1 SA
....4 T0087 1203-006141 IC-POSI.FIXED REG.;S-1172B33-U5T1G,SOT-8 2 SA
....4 1203-006142 IC-DC/DC CONVERTER;BD8924G,5P,2.9x1.6x1. 1 SA
....4 1203-006167 IC-POSI.FIXED REG.;S-1172B12-U5T1G,SOT-8 1 SA
....4 IC118 1204-003085 IC-VIDEO PROCESS;SDP91-PS,PBGA,496P,23x2 1 SA
....4 1204-003100 IC-DECODER;SDP92,FCPBGAH,937P,35x35mm,PL 1 SA
....4 IC118 1204-003101 IC-VIDEO PROCESS;SDP94,PBGA,345P,19x19mm 1 SNA
....4 1205-003201 IC-BUS SWITCH;TC7WB125FK,SSOP,8P,2x2.3mm 1 SA
....4 1205-003479 IC-SWITCH;TPS2051BDBVR,SOT-23,5P,2.9x1.6 1 SA
....4 1205-003733 IC-SWITCH;AP2191MPG-13,MSOP-8L-EP,8P,2.9 1 SA
....4 1205-003735 IC-SWITCH;AP2151WG-7,SOT25,5P,2.9x1.6mm, 1 SA
....4 1205-003834 IC-ETHERNET CONTROLLER;RTL8201E-VC-GR,QF 1 SA
....4 1205-003840 IC-CODEC;WM8595GEFL/RS,QFN,48P,7x7x0.9mm 1 SA
....4 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 SA
....4 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 32 SA
....4 MR604 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 14 SNA
....4 R105 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 30 SA
....4 AR49 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 32 SNA
....4 MR306 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 5 SNA
....4 R319 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 53 SNA
....4 2007-000146 R-CHIP;6.8Kohm,5%,1/16W,TP,1005 2 SNA
....4 R104 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 21 SA
....4 R102 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 1 SA
....4 MR36 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 6 SNA
....4 AR43 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 3 SNA
....4 MR13 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 17 SNA
....4 DR39 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 14 SNA
....4 R509 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 4 SNA
....4 R111 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 65 SNA
....4 HDR17 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 6 SNA
....4 R338 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 41 SNA
....4 UR23 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 5 SNA
....4 2007-000231 R-CHIP;1.3Kohm,1%,1/10W,TP,1608 2 SA
....4 MR39 2007-000242 R-CHIP;1.5Kohm,5%,1/16W,TP,1005 1 SNA
....4 UR53 2007-000305 R-CHIP;10Mohm,5%,1/10W,TP,1608 1 SA
....4 HR12 2007-000591 R-CHIP;22ohm,1%,1/10W,TP,1608 1 SNA
....4 2007-000606 R-CHIP;240ohm,1%,1/10W,TP,1608 2 SA
....4 JR11 2007-000614 R-CHIP;24Kohm,1%,1/10W,TP,1608 2 SNA
5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R945 2007-000726 R-CHIP;300ohm,1%,1/10W,TP,1608 1 SA
....4 R19 2007-000763 R-CHIP;330ohm,1%,1/10W,TP,1608 1 SNA
....4 R124 2007-000775 R-CHIP;33Kohm,5%,1/16W,TP,1005 1 SNA
....4 DR37 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 2 SNA
....4 2007-000946 R-CHIP;47ohm,1%,1/10W,TP,1608 4 SA
....4 OTR1 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 12 SNA
....4 2007-001295 R-CHIP;39ohm,5%,1/16W,TP,1005 1 SA
....4 CER07 2007-001308 R-CHIP;200ohm,5%,1/16W,TP,1005 1 SNA
....4 R326 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 5 SNA
....4 2007-001333 R-CHIP;18Kohm,5%,1/16W,TP,1005 4 SNA
....4 2007-001335 R-CHIP;36Kohm,5%,1/16W,TP,1005 4 SA
....4 PR24 2007-002970 R-CHIP;56ohm,5%,1/16W,TP,1005 5 SA
....4 2007-003022 R-CHIP;62ohm,5%,1/16W,TP,1005 17 SNA
....4 R133 2007-007004 R-CHIP;12Kohm,1%,1/10W,TP,1608 2 SA
....4 2007-007008 R-CHIP;300ohm,5%,1/16W,TP,1005 1 SNA
....4 TR30 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 2 SNA
....4 R365 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 3 SNA
....4 2007-007132 R-CHIP;15Kohm,1%,1/16W,TP,1005 1 SA
....4 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 6 SNA
....4 2007-007137 R-CHIP;1.2Kohm,1%,1/16W,TP,1005 1 SA
....4 DR4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 11 SNA
....4 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 6 SNA
....4 2007-007197 R-CHIP;3.3ohm,5%,1/16W,TP,1005 1 SNA
....4 2007-007239 R-CHIP;31.6Kohm,1%,1/10W,TP,1608 1 SNA
....4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 17 SNA
....4 2007-007309 R-CHIP;12Kohm,1%,1/16W,TP,1005 1 SA
....4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 30 SNA
....4 2007-007469 R-CHIP;110ohm,1%,1/16W,TP,1005 1 SNA
....4 HDR44 2007-007470 R-CHIP;7.5Kohm,1%,1/16W,TP,1005 2 SNA
....4 2007-007617 R-CHIP;2.49Kohm,1%,1/10W,TP,1608 1 SA
....4 2007-007698 R-CHIP;5.1Kohm,1%,1/16W,TP,1005 2 SNA
....4 2007-007724 R-CHIP;40.2ohm,1%,1/10W,TP,1608 2 SA
....4 2007-007730 R-CHIP;6.8Mohm,1%,1/10W,TP,1608 1 SA
....4 2007-007947 R-CHIP;36ohm,1%,1/10W,TP,1608 1 SA
....4 MR11 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 21 SA
....4 2007-008134 R-CHIP;12.4Kohm,1%,1/16W,TP,1005 1 SC
....4 2007-008263 R-CHIP;3Kohm,1%,1/16W,TP,1005 1 SA
....4 2007-008391 R-CHIP;6.34Kohm,1%,1/16W,TP,1005 1 SA
....4 2007-008811 R-CHIP;1.5ohm,5%,1/16W,TP,1005 1 SA
....4 2007-009853 R-CHIP;1.6Kohm,1%,1/16W,TP,1005 1 SNA
....4 2011-001015 R-NETWORK;1Kohm,5%,1/16W,L,CHIP,8P,TP,3. 4 SA
....4 ZRN10 2011-001261 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2. 5 SA
....4 DAR09 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 29 SA
....4 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2. 6 SNA
....4 2011-001345 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,2 2 SA
....4 DRP29 2011-001396 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, 2 SA
....4 2011-001427 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,2.0 3 SNA
....4 2011-001448 R-NETWORK;10ohm,5%,1/16W,L,4P,T,1010 16 SA
....4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 12 SA
....4 2011-001497 R-NETWORK;470ohm,5%,1/16W,L,CHIP,4P,TP,1 3 SNA
....4 2011-001527 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,4P,TP, 1 SNA
5-6
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 2011-001589 R-NETWORK;0ohm,5%,1/16W,L,CHIP-V,4P,TP,1 1 SNA
....4 C24 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 SNA
....4 AC1 2203-000125 C-CER,CHIP;1.2nF,10%,50V,X7R,TP,1608,- 4 SA
....4 PC43 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 7 SA
....4 DC54 2203-000278 C-CER,CHIP;.01nF,0.5pF,50V,C0G,TP,1005 2 SA
....4 RC34 2203-000280 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,1608 1 SA
....4 C3 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 2 SNA
....4 C304 2203-000405 C-CER,CHIP;0.18nF,5%,50V,C0G,1608 1 SNA
....4 MC302 2203-000425 C-CER,CHIP;.018nF,5%,50V,C0G,TP,1005 9 SA
....4 C254 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 12 SA
....4 V1233 2203-000575 C-CER,CHIP;220nF,10%,25V,X7R,TP,2012 8 SNA
....4 ZC14 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 2 SNA
....4 MC9 2203-000627 C-CER,CHIP;.022nF,5%,50V,C0G,TP,1005 1 SNA
....4 AD480 2203-000679 C-CER,CHIP;0.027nF,5%,50V,C0G,1005 4 SNA
....4 DC25 2203-000812 C-CER,CHIP;.033nF,5%,50V,C0G,1005 12 SA
....4 CK40B 2203-000838 C-CER,CHIP;0.39NF,5%,50V,C0G,TP,1608 2 SNA
....4 C132 2203-000854 C-CER,CHIP;0.039nF,5%,50V,C0G,1005 4 SA
....4 AC124 2203-000998 C-CER,CHIP;0.047nF,5%,50V,C0G,1608 2 SNA
....4 KAC5 2203-001126 C-CER,CHIP;0.68nF,10%,50V,X7R,1608 1 SNA
....4 AD480 2203-001851 C-CER,CHIP;0.016nF,5%,50V,NP0,TP,1608 2 SNA
....4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 15 SNA
....4 AVC08 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,1608 15 SNA
....4 AD480 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 2 SNA
....4 AD480 2203-002720 C-CER,CHIP;10nF,10%,25V,X7R,TP,1005 4 SNA
....4 DC108 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 3 SC
....4 DC18 2203-005138 C-CER,CHIP;1.8nF,10%,50V,X7R,1005 6 SA
....4 AAC1 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 16 SNA
....4 AD480 2203-005344 C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,- 23 SNA
....4 AD480 2203-005533 C-CER,CHIP;1000nF,20%,6.3V,X7R,TP,1608 2 SNA
....4 PC8 2203-005642 C-CER,CHIP;0.22nF,5%,50V,NP0,1005 1 SNA
....4 AD480 2203-005968 C-CER,CHIP;4.7NF,10%,50V,X7R,TP,1005 2 SNA
....4 AD480 2203-006104 C-CER,CHIP;1000nF,10%,50V,X7R,3225 1 SNA
....4 AD480 2203-006126 C-CER,CHIP;47nF,10%,16V,X7R,1005 3 SNA
....4 PC11 2203-006141 C-CER,CHIP;1000nF,10%,16V,X5R,1608 2 SNA
....4 C102 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 319 SNA
....4 AD480 2203-006307 C-CER,CHIP;1000nF,10%,25V,X5R,2012 8 SNA
....4 AD480 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 10 SNA
....4 AD480 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216 7 SA
....4 C125 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 26 SC
....4 HE4 2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,2012 9 SA
....4 HDC11 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 51 SNA
....4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,1608 4 SNA
....4 AD480 2203-006992 C-CER,CHIP;0.33nF,5%,50V,C0G,TP,1005 12 SNA
....4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 ( 4 SNA
....4 AD480 2203-007233 C-CER,CHIP;22000nF,10%,16V,X5R,TP,3216 3 SA
....4 AD480 2203-007270 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608 65 SNA
....4 T0052 2703-000125 INDUCTOR-SMD;10uH,10%,2012 8 SA
....4 T0052 2703-000158 INDUCTOR-SMD;1uH,10%,2012 6 SA
....4 T0052 2703-000222 INDUCTOR-SMD;560nH,10%,2012 3 SA
....4 T0052 2703-000296 INDUCTOR-SMD;680nH,10%,1608 1 SA
....4 T0052 2703-000392 INDUCTOR-SMD;10uH,5%,4532 1 SA
5-7
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 VL6 2703-000398 INDUCTOR-SMD;10uH,10%,3225 1 SA
....4 T0052 2703-001239 INDUCTOR-SMD;3.3uH,10%,1608 2 SA
....4 T0052 2703-002332 INDUCTOR-SMD;330nH,5%,1608 1 SA
....4 T0052 2703-002557 INDUCTOR-SMD;270NH,5%,1608 3 SNA
....4 T0052 2703-003150 INDUCTOR-SMD;4.7uH,20%,5050 4 SNA
....4 2703-003296 INDUCTOR-SMD;47uH,10%,2012 1 SNA
....4 T0052 2703-003713 INDUCTOR-SMD;1.5uH,20%,7366 1 SA
....4 X202 2801-003326 CRYSTAL-SMD;24MHz,30ppm,28-ABX,20pF,50oh 2 SA
....4 X202 2801-003773 CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50oh 1 SA
....4 X202 2801-003954 CRYSTAL-SMD;27MHz,30ppm,28-AAN,16pF,50oh 1 SA
....4 X202 2801-004629 CRYSTAL-SMD;27MHz,20ppm,12pF,50ohm,TP 1 SNA
....4 X202 2801-004734 CRYSTAL-SMD;25.000000MHz,20ppm,28-AAN,12 1 SA
....4 2804-001878 OSCILLATOR-CLOCK;49.152MHz,50ppm,10TTL/1 1 SA
....4 F103 2901-001506 FILTER-EMI SMD;5V,0.13A,0pF,2x1x0.5mm,TP 2 SA
....4 DR32 3301-000314 BEAD-SMD;120ohm,1.6x0.8x0.8mm,-,-,- 2 SNA
....4 T0568 3301-001236 BEAD-SMD;60ohm,1608 12 SA
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 37 SA
....4 T0568 3301-001526 BEAD-SMD;10ohm,1.6x0.8x0.8mm,1000mA,TP,, 20 SNA
....4 T0568 3301-002039 BEAD-SMD;26ohm,1608,TP 7 SA
....4 T0313 3404-001207 SWITCH-TACT;12V,50mA,160gf,6.2X6.2,SPST 1 SA
....4 3701-001591 CONNECTOR-HDMI;19P,2ROW,FEMALE,SMD-S,AU 3 SNA
....4 3701-001693 CONNECTOR-HDMI;19P,2ROW,FEMALE,SMD-A 1 SA
....4 AC510 3708-002777 CONNECTOR-FPC/FFC/PIC;82P,0.5mm/0.75mm,S 1 SA
....4 CON_US 3711-005616 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,SMD 1 SNA
....4 HB01A 3711-007336 HEADER-BOARD TO CABLE;B0X,4P,1R,2.5mm,SM 1 SA
....4 BN41-01443A PCB MAIN;C650 eu Valencia,FR-4,4,1.2T,19 1 SNA
....4 BN97-04194A ASSY MICOM-MAIN;T-VALDEUC-1007.5,2010.03 1 SNA
.....5 1107-001868 IC-NAND FLASH;KFG8GH6U4M-AIB6,1GByte,512 1 SNA
....4 IC012 1203-006138 IC-POSI.ADJUST REG.;AP1117DGZ-13-89,TO-2 1 SA
....4 T0052 2703-003790 INDUCTOR-SMD;4.7uH,20%,8080 3 SA
....4 0501-002654 TR-SMALL SIGNAL;2PD601ASL,NPN,250mW,SOT- 2 SA
....4 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 SA
....4 BN97-04244A ASSY MICOM-SUB;T-VAL8DEUS-1003,2010.03.1 1 SNA
.....5 IC520 0903-001651 IC-MICROCONTROLLER;61P802-RG480WT,LQFP,4 1 SNA
...3 T0066 BN62-00071A HEAT SINK-ES;22*22*2.6,Ceramic,T2.6,TAPE 2 SNA
...3 BN62-00083A HEAT SINK-ES;27*15.5*5,Ceramic,T5,TAPE 1 SNA
...3 BN62-00084A HEAT SINK-ES;LE32C650L1WXXC,A6063,2.5,28 1 SNA
...3 T0066 BP62-00064B HEAT SINK-ES;ROBOCOP,A6063,T4.0,40,40,BL 1 SNA
...3 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 1 SNA
0.1 BN92-05642A ASSY LABEL;LE32C650L1WX*,37,40,46,55 1 SNA
..2 T0527 BP68-00052B LABEL-00,RATING;CCTV,TETRON PAPER,T0.05, 1 SNA
0.1 ACCE1 BN92-05643D ASSY ACCESSORY;LE32C650L1WXXH 1 SNA
..2 ACCE3 BN96-13042G ASSY ACCESSORY-MANUAL;LE32C650L1WXXH,37, 1 SNA
...3 AA69-02656A BAG ACCESSORY;PJTV,LDPE,T0,05,L400,W280, 1 SNA
...3 BN68-00514E MANUAL FLYER-05,WARRANTY CARD;comm,Samsu 1 SNA
...3 BN68-02186A MANUAL FLYER-TOC GUIDE;COMM,SAMSUNG,11 L 1 SNA
...3 BN68-02558C MANUAL USERS;C650,SAMSUNG,Eng/Hun/Pol/Gr 1 SNA
...3 BN68-02558L MANUAL USERS-01;C650,SAMSUNG,Cro/Cze/Slk 1 SNA
...3 AA68-03242V MANUAL FLYER-SAFETY GUIDE;comm,Samsung,1 1 SNA
...3 BN68-02766B MANUAL FLYER-STAND GUIDE;L550~L750,SAMSU 1 SNA
..2 ACCE2 BN96-13311T ASSY ACCESSORY-CABLE;LE32C650L1WX* 1 SNA
5-8
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
...3 T0268 3903-000456 CBF-POWER CORD;DT,EU/KR,CP3,IEC320 C13-R 1 SA
...3 T0120 4301-000121 BATTERY-MN;1.5V,R03,10.5x44.5m,HOLDER,7. 2 SNA
...3 T0524 6902-001107 BAG PE;LDPE,T0.05,W450,L400,TRP,0,3Separ 1 SNA
...3 REMO2 BN59-01039A REMOCON;TM1060,SAMSUNG,20PIN SINGLE,49KE 1 SA
...3 BN61-05596A HOLDER-WIRE CABLE;LED TV,LDPE,T0.8,L150, 1 SNA
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 SA
...3 T0531 BN63-06389B COVER-BOTTOM;32,LC530,HIPS,V0,BK0020 1 SA
...3 M0081 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 9 SA
...3 T0524 6902-000341 BAG PE;LDPE,T0.05,L90,W70,TRP,,,PE MARK 1 SNA
0.1 BN92-05849C ASSY BOX;32,LC650,EO 1 SNA
..2 BH68-00662A LABEL BOX-00;ALL MODEL,MOJO 90G,60,110,W 1 SNA
..2 BN69-05100B BOX-SET;32LC650-SEH,CB,A-01,DW3,YEL,W827 1 SNA
0.1 BN92-05854A ASSY P/MATERIAL;32,LC650 1 SNA
..2 6902-001104 BAG ROLL;HDPE/HDPE/NITRON,T0.5,W800,L175 1.9 SNA
..2 BN69-03934A WRAP STRETCH FILM;All,HDPE,0.012,500,300 5 SNA
..2 BN68-02422B LABEL-WARNING SHIPPING;ALL MODEL,A/P 100 1 SNA
..2 AA01-00004A FOIL;2000,2000,NTR,SEH 1 SNA
..2 T0214 BN74-00008A TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M, 2.3 SNA
..2 BN69-04998A CUSHION-SET;32LC550/570,630,650,670/653, 1 SNA
..2 BN69-04029A PAD PACKING-EDGE;CB,B800,W50x50,L2200,YE 1 SNA
..2 BN69-04822A PALLET-WOOD;2010 LCD 32,WOOD,W1020,D1190 1 SNA
5-9
◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
