Image preview - the first page of the document
Product Specification


>> Download Product Specification documenatation <<

Text preview - extract from the document
                                                                                             2. Product specifications

2. Product specifications
2-1. Feature & Specifications
               Model                                                  LE32C63*

                                                        Feature

   Digital-TV, RF, 4-HDMI, 2Ext, Component, 1-A/V, 2USB2.0, D-sub
   Brightness : 500cd/m2
   Contrast Ratio : 6000:1
   Response time : 5ms
   Full HDTV (1920 x 1080 pixels)
   PIP(in HDMI1, 2, 3, 4, Component1, PC mode and Sub picture is available DTV/ATV, AV)

                                                     Specifications

               Item                                                   Description
LCD Panel                      LTF320HF01 ,32inch, 8bit_16.7M, 16:9, 0.36375(H)*0.36375(V),0 to 50, 12V,
                               SPVA, 72%, 32 inch FHD, 4U-Lamp (Second Panel : T315HW04 V3, 31.5 inch,
                               8bit+2FRC_1.07billion, 16:9, 0.36375(H)*0.36375(V), 0 to 50, 12V, SPVA, 72%, FHD)
Scanning Frequency             Horizontal : 100kHz~140kHz(DE only mode)
                               Vertical : 90Hz~125Hz(DE only mode)
Display Colors                 16.7 million colors
Maximum resolution             Horizontal : 1920 Pixels
                               Vertical : 1080 Pixels
Input Signal                   Analog 0.7 Vp-p
