Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LE32R32B Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LE32R32BX/XEH LE32R32B,Q62A/32R30-GRM,32,LCD-TV,HUNGAR 0
0.1 M0216 BN90-00688D ASSY STAND;ROME-III,32,BKM1502 1 S.N.A
..2 M0013 BN96-01733B ASSY STAND P-BASE;ROME3,32,HIPS,HB,GR503 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 3 S.A
...3 T0920 BN61-01519A GUIDE-STAND;ROME,32,ABS,HB,GR70 1 S.N.A
...3 BN61-01524A BRACKET-STAND BOTTOM;32,ROME,SECC,T2.0 1 S.N.A
...3 M0111 BN63-01673B COVER-STAND;ROME,32,HIPS,HB,GR503,BKM150 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 5 S.N.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,B,M4,L10,ZPC(YEL),SWR 3 S.A
...3 T0524 6902-000520 BAG PE;HDPE/NITRON(DOUBLE),T0.015/T0.5(D 1 S.N.A
0.1 M0001 BN90-01101A ASSY COVER FRONT;ROME-5,32EO,ABS,HB,BK23 1 S.N.A
..2 M0081 6006-001096 SCREW-TAPTITE;BH,+,WP,B,M4.0,L12,ZPC(BLK 4 S.N.A
..2 T0175 BN96-02453A ASSY SPEAKER P;8ohm,Left,10W,500mm,VE RO 1 S.A
..2 T0175 BN96-02454A ASSY SPEAKER P;8ohm,Right,10W,700mm,VE R 1 S.A
..2 T0003 BN96-04423A ASSY COVER P-FRONT;ROME-5,32EO,ABS,HB,BK 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 1 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M2893 BN39-00605A LEAD CONNECTOR;RE40**,UL2835#28,12/15P,4 1 S.A
...3 BN61-01489A GUIDE-CONTROL;ROME,40,ABS,HB,GR70 1 S.N.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 M0112 BN63-01878A COVER-FRONT;ROME-II,32EO,ABS,HB,BK23,STE 1 S.N.A
...3 T0069 BN63-01879C COVER-MIDDLE;ROME-5,32,HIPS,HB,GR503,BKN 1 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 1.48 S.N.A
...3 T0054 BN64-00340A KNOB-DECORATION;ROME,40,ABS,HB,GR515,AL 1 S.N.A
...3 T0022 BN64-00341B KNOB-CONTROL;ROME,40,PC+ABS,5V,BK07 1 S.N.A
...3 T0061 BN64-00343A WINDOW-REMOCON;ROME,40,PC,CLEAR 1 S.N.A
...3 T0023 BN64-00362B KNOB-POWER;ROME-5,32,ABS,HB,BK07,BKN3576 1 S.N.A
...3 T0059 BN64-00379A INDICATOR LED;ROME-II,23,PC,CLEAR 1 S.N.A
...3 M0145 BN96-01881A ASSY BOARD P-FUNCTION;ROME 32",CT5000-32 1 S.A
...3 M0145 BN96-01882A ASSY BOARD P-FUNCTION IR;ROME 32",CT5000 1 S.A
...3 T0382 BP61-00509C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W20.0mm 0.28 S.N.A
...3 T0069 AA60-00091J SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.5,- 2 S.N.A
...3 T0054 BN64-00363B KNOB-DECORATION;ROME-5,-,-,-,-,-,-,-,UND 1 S.N.A
..2 T0382 BP61-00495C HOLDER-CARE;PJT,ACRYL-FOAM,T0.25,W30.0mm 0.2 S.N.A
0.1 M0002 BN90-01102A ASSY COVER REAR;ROME-5,32EO,HIPS,HB,GR50 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 10 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 3 S.N.A
..2 M0013 BN96-04424A ASSY COVER P-REAR;ROME-5,32EO,HIPS,HB,GR 1 S.A
...3 M0081 6003-001321 SCREW-TAPTITE;BH,+,B,M4,L8,ZPC(BLK),SWRC 4 S.A
...3 M0081 6003-001321 SCREW-TAPTITE;BH,+,B,M4,L8,ZPC(BLK),SWRC 2 S.A
...3 M0114 BN61-01488A HOLDER-WIRE;ROME,40,ABS,HB,GR503 1 S.N.A
...3 M0113 BN61-02644A BRACKET-VESA;LN32M51BD,SECC,T1.2 1 S.N.A
...3 M0006 BN63-02961A COVER-REAR;ROME(2)-5,32,HIPS,-,-,-,HB,-, 1 S.N.A
..2 T0130 BN96-04426A ASSY COVER P-TERMINAL;ROME-5,32EO,HIPS,H 1 S.N.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.N.A
...3 BN61-01753A HOLDER-BOSS;ROME 26,32,ABS,V0,T3.0,14,63 1 S.N.A
...3 T0279 BN63-02959A COVER-JACK;ROME(2)-5,32,HIPS,T3.0,-,-,HB 1 S.N.A
0.1 BN91-00912K ASSY LCD-SPB;32",AM LCD,SKD 1 S.N.A
..2 M0215 BN07-00276A LCD-PANEL;CLAA320WA01,8bit/60Hz,743*447* 1 S.A
0.1 M0017 BN91-01251A ASSY CHASSIS;LE32R32BX/* 1 S.N.A
..2 M0014 BN94-01128A ASSY PCB MAIN;LE32R32BX/* 1 S.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 JA306 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 CN330 3711-004379 HEADER-BOARD TO CABLE;BOX,4P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-005606 HEADER-BOARD TO CABLE;BOX,30P,2R,2mm,STR 1 S.A
...3 CN330 3711-005942 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,STR 1 S.A
...3 JA202_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA207_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA332 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001903 JACK-PIN;2P,-,AU,WHT/RED,- 1 S.A
...3 JA333 3722-001938 JACK-PIN;3P,-,AU,GRN/BLU/RED,- 1 S.A
...3 JA333 3722-002063 JACK-PIN;3P,AU,YEL/WHT/RED,STRAIGHT 1 S.A
...3 CIS3 BN40-00079A TUNER;TCPW3001PD32S(H),TCPW3001PD32S(H), 1 S.A
...3 T0530 BN61-01521A SUPPORT-PCB;ROME,SPTE,T0.5,L11.0 1 S.N.A
...3 T0530 BN61-01521A SUPPORT-PCB;ROME,SPTE,T0.5,L11.0 1 S.N.A
...3 T0530 BN61-01521A SUPPORT-PCB;ROME,SPTE,T0.5,L11.0 1 S.N.A
...3 M0107 BN63-01847A SHIELD-COVER;ROME,SECC,T0.3,49.5,79.5,HE 1 S.N.A
...3 CCMM1 BN73-00024D SILICON/RUBBER;BORDEAUX,SILICON,28x28XT6 1 S.N.A
...3 HDCP BN97-00688A ASSY HDCP;BN46-00018A,PS-42V6S,D73A,GENE 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-01253A ASSY SMD;LE32R32BX/* 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
