Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LE32R71BX Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LE32R71BX/SML LE32R71B,Q62A/32R70-GBD,32,LCD-TV,ISRAEL 0
0.1 M0001 BN90-00840P ASSY COVER FRONT;32R71,EO(CMO),BORDEAUX 1 S.N.A
..2 T0003 BN96-03630A ASSY COVER P-FRONT;32R71,EO(CMO),ABS+PMM 1 S.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 CIS BN63-01151A FELT-NON WOVEN;MM17NS,T0.5,393,10,BLACK 2 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 1.48 S.N.A
...3 T0056 BN63-02320A COVER-DECORATION;32R71,HIPS,HB,GR503,BLM 1 S.N.A
...3 M0112 BN63-02595A COVER-FRONT;32R71,EO(CMO),ABS+PMMA HB,BK 1 S.N.A
...3 T0023 BN64-00342A KNOB POWER;ROME,40,PC,VIOLET 1 S.N.A
...3 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
...3 T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 S.N.A
...3 M0145 BN96-03404A ASSY BOARD P-FUNCTION&KNOB;Bordeaux,CT50 1 S.A
....4 T0022 BN64-00442A KNOB CONTROL;26,32,40R71,PC,BLK,ACRYL CL 1 S.N.A
....4 M0145 BN96-03045A ASSY BOARD P-FUNCTION;BORDEAUX,FUNCTION 1 S.A
...3 M0146 BN96-03405A ASSY BOARD P-POWER;BORDEAUX1,CT5000-4140 1 S.A
...3 T0069 BP60-00015D SPACER-FELT;617W,FELT,L760,T0.5,W10 2 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 T0175 BN96-04207A ASSY SPEAKER P;8ohm,VE Type,Left,10W,Hor 1 S.A
..2 T0175 BN96-04208A ASSY SPEAKER P;8ohm,VE Type,Right,10W,Ho 1 S.A
0.1 M0002 BN90-00841A ASSY COVER REAR;32R71,EO,BORDEAUX 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 13 S.A
..2 M0013 BN96-02997A ASSY COVER P-REAR;32R71,EO,-,ABS+PMMA,HB 1 S.A
...3 M0006 BN63-02319A COVER-REAR;32R71,EO,SO,CO,ABS+PMMA,HB,BK 1 S.N.A
...3 T0071 BN64-00444B INLAY-TERMINAL;32,37,40R71,PS SHEET,T0.5 1 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 0.7 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
...3 T0069 AA63-60131N SPACER-FELT;L2,FELT,280*10,BLK,T0.5 2 S.N.A
...3 BN61-02776A HOLDER-WALL;32R7,ABS,HB,BLK 2 S.N.A
0.1 M0216 BN90-00842A ASSY STAND;32R71,BORDEAUX 1 S.N.A
..2 M0013 BN96-02998A ASSY STAND P-BASE;32R71,-,ABS+PMMA,HB,BK 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 4 S.A
...3 T0920 BN61-02192A GUIDE-STAND;26,32R71,ABS,V0,BLK 1 S.A
....4 T0514 BN61-02367A BRACKET-SUPPORT;BORDEAUX 32,SECC,T1.2,-, 1 S.N.A
...3 BN61-02204A HOLDER-SWIVEL RING;26,32R71,ACETAL,BLK 1 S.N.A
...3 BN61-02232A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,T 1 S.N.A
...3 BN61-02233A HOLDER-SWIVEL RING;32R71,ACETAL NATUAL,B 1 S.N.A
...3 BN61-02235A BRACKET-STAND BOTTOM;BORDEAUX 32,SECC,T2 1 S.N.A
...3 BN61-02236A BRACKET-HINGE SWIVEL;BORDEAUX 32,SECC,T1 1 S.N.A
...3 T0004 BN63-02321A COVER-STAND BASE;32R71,ABS+PMMA,-,-,-,HB 1 S.N.A
...3 BN63-02322A COVER-STAND SUB;32R71,ABS+PMMA,HB,BK23,H 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 8 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.4 S.N.A
..2 T0524 6902-000520 BAG PE;HDPE/NITRON(DOUBLE),T0.015/T0.5(D 1 S.N.A
0.1 T0852 BN91-00875A ASSY LCD-CMO;A61J-CMO 1 S.N.A
..2 M0215 BN07-00207A LCD-PANEL;V320B1-L01,Duomo,8bit,760*450* 1 S.A
0.1 M0017 BN91-01054U ASSY CHASSIS-CMO;LE32R71BX/* 1 S.N.A
..2 M0014 BN94-01125A ASSY PCB MAIN-CMO;LE32R71BX/* 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 JA709 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 CN330 3711-004068 HEADER-BOARD TO CABLE;BOX,5P,1R,2MM,ANGL 1 S.A
...3 CN330 3711-004909 HEADER-BOARD TO CABLE;BOX,14P,2R,2MM,ANG 1 S.A
...3 CN330 3711-005609 HEADER-BOARD TO CABLE;BOX,30P,2R,2mm,ANG 1 S.A
...3 CN330 3711-005942 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,STR 1 S.A
...3 JA701_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA702_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 2 S.N.A
...3 CIS3 BN40-00079A TUNER;TCPW3001PD32S(H),TCPW3001PD32S(H), 1 S.A
...3 M0107 BN63-01847A SHIELD-COVER;ROME,SECC,T0.3,49.5,79.5,HE 1 S.N.A
...3 CIS8 BN73-00024C SILICON/RUBBER-BERGQUIST;VENUS 32,40",SI 1 S.N.A
...3 BN97-00964Z ASSY SMD-CMO;LE32R71BX/* 1 S.N.A
....4 CIS5 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
