Image preview - the first page of the document
>> Download Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
-You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LE37M86BDX Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LE37M86BDX/XEE LE37M86BD,N30A/37M80-GTU,37,LCD-TV,SWEDE 0
0.1 M0001 BN90-01157B ASSY COVER FRONT;37M86,EO(IDTV),-,ABS+PM 1 S.N.A
..2 T0003 BN96-04637B ASSY COVER P-FRONT;37M86,EO(IDTV),-,ABS+ 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 1.983 S.N.A
...3 T0056 BN63-03035C COVER-DECORATION;40M81,ABS,-,-,-,HB,-,IV 1 S.N.A
...3 T0056 BN63-03036C COVER-DECORATION;40M81,ABS,-,-,-,HB,-,IV 1 S.N.A
...3 M0112 BN63-03186A COVER-FRONT;37M81,EO(IDTV),ABS+PMMA,-,-, 1 S.N.A
...3 T0066 BN96-04639B ASSY COVER P-DECORATION;37M81,-,ABS,HB,I 1 S.N.A
....4 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
....4 T0056 BN63-03037A COVER-DECORATION;40M81,ABS+PMMA,-,-,-,HB 1 S.N.A
....4 T0056 BN63-03187B COVER-DECORATION;37M81,ABS,-,-,-,HB,-,IV 1 S.N.A
....4 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
....4 T0023 BN64-00548A KNOB POWER;TULIP40,PC VIOLET,V0 1 S.N.A
....4 T0054 BN64-00549A KNOB-DECORATION;40M81,ABS,-,-,-,HB,IV-16 1 S.N.A
....4 BN61-03261C BOSS-TAPE;Tulip,ACRYL,T1.1,W24mm,GRAY,TA 0.72 S.N.A
....4 BN61-03261A BOSS-TAPE;Tulip,ACRYL,T1.1,W12mm,GRAY,TA 0.048 S.N.A
...3 M0146 BN96-04884E ASSY BOARD P-POWER & IR;LE37R86BD,CT5000 1 S.A
...3 M0145 BN96-04901A ASSY BOARD P-FUNCTION;LNT3771FD,CT5000-4 1 S.A
...3 T0069 AA60-00171V SPACER-FELT;BE46PS,FELT,500,T0.35,10 2 S.N.A
...3 BN63-01925A FELT-VIBRATION;42D5,FELT,T0.35,10,370 4 S.N.A
...3 T0022 BN64-00550A KNOB-CONTROL;40M81,ABS,-,-,-,HB,IV-16,-, 1 S.N.A
...3 T0069 AA60-00091J SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.5,- 2 S.N.A
...3 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 2 S.N.A
..2 T0175 BN96-04771A ASSY SPEAKER P;8ohm,4pin,Enclosure Type, 1 S.A
0.1 M0002 BN90-01162A ASSY COVER REAR;37M81,EO(IDTV),-,ABS+PMM 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 14 S.A
..2 M0013 BN96-04757A ASSY COVER P-REAR;37M81,EO(IDTV),ABS+PMM 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 BN61-02950A HOLDER-WALL;COMMON,ABS,V0,-,-,-,BK500,- 2 S.N.A
...3 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 0.99 S.N.A
...3 M0006 BN63-03189A COVER-REAR;37M81,EO(IDTV),ABS+PMMA,-,-,- 1 S.N.A
...3 T0071 BN64-00555B INLAY-TERMINAL;07,COMMON,EO(IDTV),PS SHE 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
0.1 M0216 BN90-01168A ASSY STAND;37,40M81,-,ABS+PMMA,HB,BK23,H 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
..2 M0013 BN96-04640A ASSY STAND P-BASE;37,40M81,-,ABS+PMMA,HB 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 8 S.A
...3 BN61-02248A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,T 1 S.N.A
...3 T0920 BN61-02877A GUIDE-STAND;TULIP,40,ABS,V0,-,-,-,-,- 1 S.N.A
....4 BN61-02981A BRACKET-SUPPORT STAND;40 BORDEAUX PLUS,S 1 S.N.A
....4 BN61-03045A BRACKET-SUPPORT STAND;40 BORDEAUX PLUS,S 1 S.N.A
...3 BN61-02883A BRACKET-STAND BOTTOM;BORDEAUX PLUS,40,SE 1 S.N.A
...3 BN61-02885A HOLDER-SWIVEL RING;MURANO40,ACETAL NATUR 1 S.N.A
...3 BN61-02886A BRACKET-HINGE SWIVEL;BORDEAUX PLUS,40,SE 1 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.5 S.N.A
...3 T0004 BN63-03030A COVER-STAND BASE;40R81,ABS+PMMA,-,-,-,HB 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 S.N.A
0.1 BN91-01342E ASSY LCD-AUO;LE37M87BDX/* 1 S.N.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
..2 M0215 BN07-00398A LCD-PANEL;T370HW02,8bit,37inch,16.7M,16: 1 S.A
0.1 M0017 BN91-01407A ASSY CHASSIS;LE37M86BDX/* 1 S.N.A
..2 M0014 BN94-01206A ASSY PCB MAIN;LE37M86BDX/* 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 JA1410_NSI 3701-001388 CONNECTOR-HDMI;20P,Phosphor Bronze,ANGLE 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 JA3201_OP 3709-001477 CONNECTOR-CARD SLOT;68P,1.27mm,ANGLE,AU, 1 S.A
...3 CN330 3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN 1 S.A
...3 CN906 3711-004182 CONNECTOR-HEADER;BOX,10P,1R,2MM,STRAIGHT 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
...3 CN330 3711-005842 HEADER-BOARD TO CABLE;BOX,24P,2R,2MM,STR 1 S.A
...3 JA330 3722-000143 JACK-PHONE;1P(VER),AG,BLK,ANGLE 1 S.A
...3 JA1601_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA1608_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA332 3722-001163 JACK-VHS;4P,AU,BLK,ANGLE 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002543 JACK-PIN;3P,Sn,RED/WHT/YEL,ANGLE 1 S.A
...3 CIS3 BN40-00096A TUNER;DNOS403MH261B(S),PAL Hyper,181CH, 1 S.A
...3 T0174 BN97-01420A ASSY SMD;LE37M86BDX/* 1 S.N.A
....4 D1204 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1208 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1209 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1210 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1211 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1212 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1213 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1214 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1218 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1219 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1640 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1641 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1101 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1403 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1404 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1407 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1410 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1411 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1412 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1424 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1425 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1426 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1434 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1435 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1450_NSID 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1451_NSID 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1472 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1473 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1474 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1475 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1476 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1477 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1478 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1479 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
6-2
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 D1482 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1483 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1484 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1485 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1486 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1487 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1488 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1489 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1492_NSID 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1493_NSID 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1494_NSID 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1495_NSID 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1496_NSID 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1497_NSID 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1498_NSID 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1499_NSID 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1603_OP 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1621_OP 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1624_OP 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1643 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1644 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1645 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1647 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1649 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1650 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1653 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1808 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D0254 0402-001019 DIODE-SCHOTTKY;MBRS340,40V,3000mA,DO-214 1 S.A
....4 D0254 0402-001019 DIODE-SCHOTTKY;MBRS340,40V,3000mA,DO-214 1 S.A
....4 D1215 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1217 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1429 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1430 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1431 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1432 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1433 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1452 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1453 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1454_NSID 0403-000620 DIODE-ZENER;RLZ5.6B,5.45-5.73V,500mW,LL- 1 S.A
....4 D1500 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D1501 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D1502_NSID 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D1503 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D1504 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D1505 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D1506 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 D1402 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D1428 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D1449_NSID 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D1804 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D1810 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D1608 0403-001169 DIODE-ZENER;RLZ16C,15.96-16.51V,500MW,LL 1 S.A
....4 D1636 0403-001169 DIODE-ZENER;RLZ16C,15.96-16.51V,500MW,LL 1 S.A
....4 D1105 0403-001425 DIODE-ZENER;BZX84C33,31-35V,350mW,SOT-23 1 S.A
....4 D1405 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1406 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1408 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1409 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1422 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1423 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1446 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1447 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
6-3
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 D1601_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1602_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1604_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1605 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1606_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1607 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1615 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1616_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1617_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1618_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1619 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1620_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1622_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1623_OP 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1630 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1631 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1632 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1633 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1634_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1635_EU 0406-001172 DIODE-TVS;CDS3C30GTH,48V,0W,SMD 1 S.A
....4 D1201 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D1801 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D1802 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 D1803_NSID 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 Q1201 0501-000280 TR-SMALL SIGNAL;KSA1182,PNP,150MW,SOT-23 1 S.A
....4 Q1202 0501-000280 TR-SMALL SIGNAL;KSA1182,PNP,150MW,SOT-23 1 S.A
....4 Q1101_LCD 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1102_LCD 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1104 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1203 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1204 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1205 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1206 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1207 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1208 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1209 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1210 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1211 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1602 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1603 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1604_RED 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1801 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1805 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1821 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q1823 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q2202_LCD 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q3003 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q3004 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q3001 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q3002 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
6-4
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000275 FET-SILICON;SI4435DY,P,-30V,+-8.0A,0.014 1 S.A
....4 IC104 0801-002095 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP 1 S.A
....4 IC104 0801-002095 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP 1 S.A
....4 IC104 0801-002172 IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI 1 S.A
....4 IC104 0801-002172 IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI 1 S.A
....4 IC104 0801-002172 IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI 1 S.A
....4 IC104 0801-002378 IC-CMOS LOGIC;74VHC04,HEX INVERTER,SOP,1 1 S.A
....4 IC104 0801-002617 IC-CMOS LOGIC;7S08,2-INPUT AND GATE,SOT- 1 S.A
....4 IC1802 0903-001488 IC-MICROCOMPUTER;M308A0SGP,LQFP,100P,14x 1 S.A
....4 IC1805 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 S.A
....4 IC106 1001-001440 IC-VIDEO SWITCH;SiI9185CTU,QFP,80P,3.3V, 1 S.A
....4 IC107 1002-001482 IC-D/A CONVERTER;WM8521H9GED/R,16bit,SOI 1 S.A
....4 IC110 1006-001076 IC-DRIVER/RECEIVER;MAX232ECWE+T,SOP,16P, 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-001385 IC-EEPROM;24C256,256Kbit,32Kx8,SOP,8P,5x 1 S.A
....4 IC112 1103-001385 IC-EEPROM;24C256,256Kbit,32Kx8,SOP,8P,5x 1 S.A
....4 IC113 1105-001712 IC-DRAM;HYB25D256163CE,DDR,256Mbit,16Mx1 1 S.A
....4 IC113 1105-001791 IC-DRAM;EM6A9320BI,DDR,128Mbit,4Mx32,FBG 1 S.A
....4 DU410 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 S.A
....4 T0124 1201-002430 IC-POWER AMP;NTP-3000,QFN,56P,8x8mm,DUAL 1 S.A
....4 IC012 1203-001519 IC-POSI.ADJUST REG.;LM317,SOT223,3P,274 1 S.A
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,-,PLA 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 T0087 1203-002855 IC-POSI.FIXED REG.;MC33269DTRK-5.0,DPRK, 1 S.A
....4 T0087 1203-002898 IC-POSI.FIXED REG.;G950T45R,T0-252,3P,6. 1 S.A
....4 T0087 1203-002974 IC-POSI.FIXED REG.;AP1117D-25A,TO-252,3P 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 IC1809 1203-004363 IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P, 1 S.A
....4 IC1303 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC3001 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC1113 1203-004379 IC-DC/DC CONVERTER;AP1530SA,SOP,8P,5x3.9 1 S.A
....4 IC3101 1204-002697 IC-DECODER;STx5105,PBGA,324P,23x23mm,PLA 1 S.A
....4 IC1202 1204-002719 IC-AUDIO PROCESSOR;SGTV5810,LQFP,100P,14 1 S.A
....4 IC118 1204-002729 IC-VIDEO PROCESS;S4LF119X01,PBGA,208P,17 1 S.A
....4 IC2002_WX 1205-003185 IC-RECEIVER;MST3560M-LF-170,PQFP,128P,20 1 S.A
....4 D1471 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1481 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1491_NSID 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1612 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1613 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1614 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1809 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 R1527 2007-000042 R-CHIP;499ohm,1%,1/10W,TP,1608 1 S.A
....4 R2139 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2226 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2227 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1903 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1904 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1905 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1906 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1907 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1908 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1909 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1910 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1941 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
6-5
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R1944 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1993_LCD 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1111 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2206 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1266 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1311_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1331_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1332_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1341_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1342_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1343_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1418 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1456 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1464 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1501_HDMI 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1502 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1507_HDMI 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1519 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1524 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1525 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1526_NSID 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1542 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1543 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1550 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1553 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1554 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1555 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1556 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1557 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1558 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1559 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1574 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1575 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1576 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1578 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1581_NSID 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1584 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1585 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1586_HDMI 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1587_HDMI 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1621_EU 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1655 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1676_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1677_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1678_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1708_NMMS 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1709_NMMS 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1710_NMMS 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1805 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1826 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1827 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1828 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1830 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1831 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1834 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1837 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1838 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1839 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1840 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1844 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1879 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1895 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
6-6
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R1927 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1932 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1934 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1935 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1936 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1937 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1957 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1962_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1963_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1964_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1965_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1979_MMS 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1980_MMS 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2001_TEST 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2002_TEST 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2003_TEST 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2004 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2007 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2011 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2053 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2059 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2060 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2062 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2065 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2066 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2067 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2068 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2095_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2096_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2202 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2205 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2207 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2241 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2255_LCD 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2257_LCD 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2260_LCD 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2279_LCD 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2291_FBE 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2302_LCD 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2306_LCD 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2361_FBE 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2362_FBE 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2363_FBE 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2364_FBE 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2365_FBE 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2366_FBE 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2379_FBE 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R2380_FBE 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3013 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3018 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3023 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3030 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3102 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3103 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3107 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3122 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3123 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3124 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3125 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3126 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3127 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3128 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
6-7
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R3129 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3130 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3133 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3203 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3223 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3224 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3225 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3226 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3228 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3229 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3232 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3244 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3247 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3248 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3249 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3251 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3252 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3257 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3258 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3260 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3262 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3264 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R3265 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1345_WX 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1346_WX 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1413 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1414 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1451 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1462 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1468 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1469 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1498_OP 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1499_OP 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R2063 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R2149 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R2228 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R2229 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R2230 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R2231 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R2236 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R2281_OP 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R1205 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1206 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1405 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1406 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1450 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1452 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1460 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1461 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1493_NSID 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1494_NSID 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1864 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1960 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1961 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R2222 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R2223 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R1203 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1217 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1218 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1219 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1220 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1222 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
6-8
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R1225 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1226 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1228 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1229 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1230 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1231 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1232 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1233 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1234 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1235 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1236 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1237 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1238 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1239 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1240 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1241 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1243 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1244 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1254 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1264 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1270 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1273 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1344 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1416 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1419 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1459 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1470 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1488 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1489 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1500_HDMI 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1547 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1603_OP 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1617 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1622_EU 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1631_OP 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1634 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1639_OP 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1666 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1668_EU 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1808 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1809 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1810 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1811 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1835 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1836 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1843 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1855 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1856 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1858 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1861 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1862 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1868 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1870 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1874 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1875 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1877 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1878 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1949 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1952 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R1955 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2005 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2006 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
6-9
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R2030 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2113_WX 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2114_WX 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2115_WX 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2123_WX 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2124_WX 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2203 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2243_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2285_LCD 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2292_LCD 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2381_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2382_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2383_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2384_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2385_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2386_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2387_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2388_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2389_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2390_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2391_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R2392_FBE 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3008 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3204 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3205 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3206 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3207 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3230 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3233 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3235 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3238 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3253 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3254 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3255 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3259 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3261 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3263 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3266 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3267 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R3016 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R3017 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R1101 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1267 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1268 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1582 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1583 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1604_EU 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1607_EU 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1654 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1659 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1891 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R3250 2007-000076 R-CHIP;330ohm,5%,1/10W,TP,1608 1 S.A
....4 R1347 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1403 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1404 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1407 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1412 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1442 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1444 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1605 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1613 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1628_OP 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
6-10
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 R1629_OP 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1657 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1661 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1688 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,1608 1 S.A
....4 R1691 2007-000077 R-CHIP;470ohm,5%,1/10W,TP,160◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
