5. Exploded View & Part List
5. Exploded View & Part List
5-1. LE46A956D Exploded View
M0027
T0764
M0013
T0175
M0560
M0014 M0017
M0115
T0136
M0020
M0107
M0146
T0447
M0215
T0003
5-1
5. Exploded View & Part List
5-1-1. LE46A956D Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-08308B ASSY COVER P-FRONT;46,L950,EO,PC(CLEAR)+ 1 S.A
M0215 BN07-00565A LCD-PANEL;LTF460HE04 1 S.A
M0014 BN94-02125A ASSY PCB MAIN-SQH;LE46A956D1MXXC 1 S.A
T0447 BN96-08317A ASSY BRACKET P-PANEL;46,L950,UO,DIAMOND 1 S.N.A
M0146 BN61-03056A BRACKET-PANEL TOP;TULIP52,SECC,T1.2 4 S.N.A
M0107 BN61-04457A BRACKET-PCB;L950 46",SECC,T1.2,EO 1 S.N.A
M0020 BN96-07396J ASSY BOARD P-SIDE HDMI AV;LN46A950D1F,CT 1 S.N.A
T0136 BN31-00019C FAN;KDB04112HB-WS03,DIAMOND,PBTP 1 S.A
M0115 BN61-03856A BRACKET-STAND LINK;RUBY 46",SECC,T1.6 1 S.N.A
M0560 BN96-07413A ASSY HOLDER P-WALL LEFT;46,L650,,PC V1 R 1 S.A
T0175 BN96-06824A ASSY SPEAKER P;8ohm,RUBY,LCD 40",10W,Dow 1 S.A
T0175 BN96-07565A ASSY SPEAKER P;8ohm,RUBY,LCD 40",10W,Rig 1 S.A
T0175 BN96-07567A ASSY SPEAKER P;8ohm,RUBY LCD 46",Sub-Woo 1 S.A
M0013 BN96-08313B ASSY COVER P-REAR;46,L950,EO,ABS+PMMA,HB 1 S.A
T0764 BN44-00246A SMPS-LCDTV;SL4626,SL4626,AC/DC,222W,AC10 1 S.A
M0027 BN96-08213C ASSY STAND P-BASE;46,L950,,TEMPERED GLAS 1 S.A
5-2
M0013
T0175
M0254
M0017
M0014
M0115
M0146
M0125
T0136
M0107
5-2. LE55A959D Exploded View
T0764
T0447
M0215
T0003 M0027
5. Exploded View & Part List
5-3
5. Exploded View & Part List
5-2-1. LE55A959D Parts List
Location No. Code No. Description & Specification Q'ty S.A/S.N.A Remark
T0003 BN96-08309B ASSY COVER P-FRONT;55,L950,EO,PC(CLEAR)+ 1 S.A
M0215 BN07-00567B LCD-PANEL;LTF550HF05 1 S.A
T0447 BN96-08319D ASSY BRACKET P-PANEL;55,L950,EO,DIAMOND, 1 S.N.A
M0107 BN61-04048A BRACKET-PCB;L950 46",SECC,T1.2 1 S.N.A
T0136 BN31-00019B FAN;AMBER,PBTP 1 S.A
M0125 BN61-04056B HOLDER-WALL;55,L950,HIPS,HB,BK500 2 S.N.A
M0146 BN61-03056A BRACKET-PANEL TOP;TULIP52,SECC,T1.2 4 S.N.A
M0115 BN61-03856A BRACKET-STAND LINK;RUBY 46",SECC,T1.6 1 S.N.A
M0014 BN94-02742W ASSY PCB MAIN;LE55A959D1MXKS 1 S.A
M0254 BN61-04537A HOLDER-SIDE AV;L950 55,PMMA+ABS,BLACK,EO 1 S.N.A
T0175 BN96-06824A ASSY SPEAKER P;8ohm,RUBY,LCD 40",10W,Dow 1 S.A
T0175 BN96-07565A ASSY SPEAKER P;8ohm,RUBY,LCD 40",10W,Rig 1 S.A
T0175 BN96-07568A ASSY SPEAKER P;8ohm,RUBY LCD 52",Sub-Woo 1 S.A
M0013 BN96-08315B ASSY COVER P-REAR;55,L950,EO,ABS+PMMA,HB 1 S.A
T0764 BN44-00243A SMPS-LCDTV;SL5526,SL5526,AC/DC,311W,AC10 1 S.A
M0027 BN96-08214C ASSY STAND P-BASE;55,L950,,TEMPERED GLAS 1 S.A
5-4
5. Exploded View & Part List
5-3. LE46A956D Parts List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
LE46A956D1MXBT LE46A956D1M,N59D/46AD1-GDA,46,LCD-TV,LAT
0.1 M0216 BN90-01541C ASSY STAND;46,L950,GLASS,,,BLACK PATTERN 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.N.A
..2 M0027 BN96-08213C ASSY STAND P-BASE;46,L950,,TEMPERED GLAS 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 5 S.N.A
...3 T0920 BN61-03844A GUIDE-STAND;L750 46,PC+G/F 20%,BLK 1 S.N.A
....4 BN81-00204H RESIN;Trirex,3025G20 BK,ABS+PC G/F 20%,4 278.5 S.N.A
...3 BN61-04423A BRACKET-STAND BOTTOM;L750 46,SECC,T2.0,R 1 S.N.A
...3 BN61-04428A BOSS-TAPE;AMBER,ACRYL,T0.4,W30.0mm,WHITE 0.08 S.N.A
...3 BN63-04885A COVER-STAND SUB;46L750,ABS+PMMA,HB,RD02, 1 S.N.A
....4 BN81-01328A RESIN;STAREX,SF0505,(40297),RD02,ABS+PMM 112.2 S.N.A
...3 M0003 BN96-08335B ASSY COVER P-STAND GLASS;46,L950,,TEMPER 1 S.A
....4 BN63-04897B COVER-STAND GLASS;DIAMOND 46,TEMPERED GL 1 S.N.A
....4 CCM1 BN63-05135A COVER-SHEET;Ruby40",RhcmPEVinyl,T0.5,120 0.66 S.N.A
....4 CCM1 BN63-05135B COVER-SHEET;Ruby46",RhcmPEVinyl,T0.5,140 0.66 S.N.A
...3 T0069 BP60-00005K SPACER-FELT;40L750,FELT,40.5,68.0,0.5 2 S.N.A
...3 T0132 BN73-00181A RUBBER FOOT;RUBY,CR Rubber,PI 25,T3.5,BL 7 S.N.A
...3 BN61-04425A BRACKET-SUPPORT STAND;40L750,SECC,T2.0,R 2 S.N.A
0.1 M0002 BN90-01785B ASSY COVER REAR;46,L950,EO 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 14 S.N.A
..2 C/R+H/WALL 6011-001610 BOLT-ETC;M8,L18,ZPC(BLK),SWRCH18A,WSP,PH 4 S.N.A
..2 M0013 BN96-08313B ASSY COVER P-REAR;46,L950,EO,ABS+PMMA,HB 1 S.A
0.1 M0001 BN90-01787B ASSY COVER FRONT;46,L950,EO 1 S.N.A
..2 T0003 BN96-08308B ASSY COVER P-FRONT;46,L950,EO,PC(CLEAR)+ 1 S.A
0.1 M0017 BN91-02625A ASSY CHASSIS;LE46A956D1MXXC,AMLCD 1 S.N.A
..2 T0137 BN94-02131A ASSY PCB MISC-LED_DRIVER;LN46A950D1FXZA 1 S.A
...3 T0245 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.003 S.N.A
...3 T0174 BN97-02560A ASSY SMD;LN46A950D1FXZA LED_DRIVER 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45um,96.5Sn/ 0.193 S.N.A
....4 D401 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D402 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D201 0402-001098 DIODE-RECTIFIER;SK34,40V,3A,SMC,TP 1 S.N.A
....4 D403 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 IC104 0801-002171 IC-CMOS LOGIC;74LCX125,BUS BUFFER,SOP,14 1 S.N.A
....4 IC104 0801-002393 IC-CMOS LOGIC;74VHC244,BUS BUFFER,TSSOP, 1 S.N.A
....4 IC104 0801-002393 IC-CMOS LOGIC;74VHC244,BUS BUFFER,TSSOP, 1 S.N.A
....4 IC104 0801-002393 IC-CMOS LOGIC;74VHC244,BUS BUFFER,TSSOP, 1 S.N.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 IC201 1203-005279 IC-DC/DC CONVERTER;MP2372DN,SOP,8P,4.9x3 1 S.A
....4 R203 2007-000092 R-CHIP;15Kohm,5%,1/10W,TP,1608 1 S.A
....4 R202 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 S.N.A
....4 R304 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R305 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R306 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R307 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R308 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R312 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R321 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R328 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R335 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R336 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R401 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R402 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R404 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R405 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R406 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R407 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R408 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R409 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R410 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R411 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R412 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R413 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R414 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R415 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R416 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R417 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R418 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R419 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R420 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R421 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R422 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R423 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R424 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R425 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R426 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R427 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R439 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R440 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R441 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R442 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R309 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R201 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R330 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R204 2007-000583 R-CHIP;22Kohm,1%,1/10W,TP,1608 1 S.A
....4 R206 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R301 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R302 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R303 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R313 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R314 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R315 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R316 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R323 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
5-6
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R329 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R331 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R332 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R333 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 S.N.A
....4 R205 2007-007587 R-CHIP;3.6Kohm,1%,1/16W,TP,1005 1 S.N.A
....4 R338 2011-000585 R-NETWORK;47ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.N.A
....4 R339 2011-000585 R-NETWORK;47ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.N.A
....4 R340 2011-000585 R-NETWORK;47ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.N.A
....4 R341 2011-000585 R-NETWORK;47ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.N.A
....4 R342 2011-000585 R-NETWORK;47ohm,5%,1/16W,L,CHIP,8P,TP,3. 1 S.N.A
....4 C217 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C219 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C220 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C233 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C235 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C236 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C253 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C254 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C255 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C288 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C290 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C291 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C209 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C212 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C216 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C218 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C223 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C226 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C229 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C232 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C241 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C244 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C248 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C252 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C264 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C267 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C270 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C272 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C274 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C276 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C279 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C282 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C285 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C316 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C317 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C318 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C319 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.N.A
....4 C310 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C311 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C312 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C313 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
5-7
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 C314 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C315 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C320 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C321 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C304 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 1 S.N.A
....4 C206 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C208 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C210 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C214 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C222 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C225 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C228 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C231 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C238 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C240 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C243 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C247 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C251 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C263 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C266 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C269 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C271 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C275 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C278 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C281 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C284 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C287 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C234 2203-001034 C-CER,CHIP;5.6nF,10%,50V,X7R,1608 1 S.A
....4 C205 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C207 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C211 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C215 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C221 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C224 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C227 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C230 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C239 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C242 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C246 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C250 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C262 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C265 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C268 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C273 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C277 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C280 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C283 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C286 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C289 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 1 S.N.A
....4 C237 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.N.A
....4 C402 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,1608 1 S.N.A
5-8
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 C301 2203-005929 C-CER,CHIP;10000nF,10%,16V,X7R,3225 1 S.N.A
....4 C405 2203-006024 C-CER,CHIP;2200nF,10%,10V,X7R,2012 1 S.N.A
....4 C406 2203-006024 C-CER,CHIP;2200nF,10%,10V,X7R,2012 1 S.N.A
....4 C256 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C303 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C404 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C407 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,1005 1 S.N.A
....4 C257 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.N.A
....4 C213 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,2012 1 S.A
....4 C245 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,2012 1 S.A
....4 C249 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,2012 1 S.A
....4 C201 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 ( 1 S.N.A
....4 C259 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 ( 1 S.N.A
....4 C260 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012 ( 1 S.N.A
....4 C258 2402-001174 C-AL,SMD;220UF,20%,10V,WT,TP,8X6.3MM 1 S.A
....4 C202 2402-001268 C-AL,SMD;100uF,20%,25V,WT,TP,8x6.3mm 1 S.A
....4 C203 2402-001268 C-AL,SMD;100uF,20%,25V,WT,TP,8x6.3mm 1 S.A
....4 C261 2402-001268 C-AL,SMD;100uF,20%,25V,WT,TP,8x6.3mm 1 S.A
....4 C401 2402-001268 C-AL,SMD;100uF,20%,25V,WT,TP,8x6.3mm 1 S.A
....4 T0052 2703-002916 INDUCTOR-SMD;10uH,20%,8080 1 S.A
....4 X301 2804-001521 OSCILLATOR-CLOCK;27MHz,50ppm,HCMOS,TP,3. 1 S.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001404 BEAD-SMD;30ohm,2012,TP,15.9OHM/30MHz 1 S.A
....4 T0568 3301-001412 BEAD-SMD;60ohm,2012,800mA,TP,65ohm/110MH 1 S.N.A
....4 T0568 3301-001412 BEAD-SMD;60ohm,2012,800mA,TP,65ohm/110MH 1 S.N.A
....4 CN330 3711-005925 HEADER-BOARD TO CABLE;BOX,51P,1R,0.5mm,S 1 S.N.A
....4 CN330 3711-006374 HEADER-BOARD TO CABLE;BOX,41P,2R,1.25mm, 1 S.N.A
....4 CN330 3711-006513 HEADER-BOARD TO CABLE;BOX,15,1R,1.25mm,S 1 S.N.A
....4 IC125 BN13-00018A IC ASIC;SDP77,208P,CORE(1.8V) IO(3.3V),- 1 S.A
....4 PCB1.0 BN41-01098A PCB;FR-4,6,1.6T,110x100 1 S.N.A
....4 M0018 BN97-02561A ASSY MICOM;EEPROM_2008XXXX,N58A,2008.05. 1 S.N.A
.....5 IC115 1107-001456 IC-FLASH MEMORY;39LV010,128Kx8,PLCC,32P, 1 S.N.A
..2 M0014 BN94-02125C ASSY PCB MAIN;LE46A956D1MXXC 1 S.A
...3 T0245 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 S.N.A
...3 CN3018 3701-001510 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 JA1201 3709-001508 CONNECTOR-CARD SLOT;68P,1.27mm,PIN,PCMCI 1 S.A
...3 CN330 3711-003848 HEADER-BOARD TO CABLE;BOX,11P,1R,2mm,ANG 1 S.A
...3 CN906 3711-004105 CONNECTOR-HEADER;BOX,8P,1R,2.5mm,ANGLE,S 1 S.A
...3 CN330 3711-004349 HEADER-BOARD TO CABLE;BOX,3P,1R,2mm,STRA 1 S.A
5-9
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
...3 CN330 3711-004379 HEADER-BOARD TO CABLE;BOX,4P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN1001 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 JA332 3722-001734 JACK-VHS;4P,SN,BLK,STRAIGHT 1 S.A
...3 JA333 3722-002751 JACK-PIN;2P+Shield,Ni,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002751 JACK-PIN;2P+Shield,Ni,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002754 JACK-PIN;3P+Shield,Ni,GRN/BLU/RED,STRAIG 1 S.A
...3 JA9001 3722-002757 JACK-MODULAR;8P/8C,N,STRAIGHT,GRN/YEL,AU 1 S.A
...3 JA330 3722-002758 JACK-PHONE;1P,BLK,STRAIGHT 1 S.A
...3 JA330 3722-002758 JACK-PHONE;1P,BLK,STRAIGHT 1 S.A
...3 CN3001 3722-002778 JACK-SCART;21P,SN,BLK 1 S.A
...3 CN3002 3722-002778 JACK-SCART;21P,SN,BLK 1 S.A
...3 T0562 6046-001015 STAND OFF;#4-40,L5,Ni PLT,C3601,M3 2 S.N.A
...3 CIS3 BN40-00126A TUNER;DNOS403SH101A(S),DNOS403SH101A(S), 1 S.A
...3 T0603 BN63-05040A SHIELD-PCB MAIN;L850,EO,MAIN,SPTE,T0.3 1 S.N.A
...3 HDCP BN97-00688B ASSY HDCP;MT8202 IC HDCP Key' 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-02549C ASSY SMD;LE46A956D1MXXC 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45um,96.5Sn/ 4.49 S.N.A
....4 D1004 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3009 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3010 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3011 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3019 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3020 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3021 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3023 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3024 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3026 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3032 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3044 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3050 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3051 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3052 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3057_4HDM 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3058_4HDM 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3060 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D3061 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D4004_CEC 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D5004 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D5005 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D5006 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D5010 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D5011 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D5012 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D5013 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D9003 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D9004 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D9005 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D9006 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1008 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
5-10
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 D1213 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D2001 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D2002 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D2003 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D3071 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D3072 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D3073 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D3074 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D3075 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D3076 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D3077 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D3078 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D3079 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.N.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D2004 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D3007 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D3017 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D3022 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D3046 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D3047 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D3048 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D3049 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D3053 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D3054 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D4007 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D5009 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D4010 0403-000584 DIODE-ZENER;VLZ3V6B,3.6/3.845V,500mW,SOD 1 S.N.A
....4 D3043 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3055_4HDM 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3056 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3059 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3067 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3068 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3069_4HDM 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3100 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3101 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3102 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D3103 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D9002 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D5014 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D1005 0403-001425 DIODE-ZENER;BZX84C33,31-35V,350mW,SOT-23 1 S.A
....4 D0254 0404-001271 DIODE-SCHOTTKY;SSA34,40V,3000mA,SMA,TP 1 S.A
....4 D9001 0406-001217 DIODE-TVS;NUP4301MR6,6/-/-V,500W,TSOP-6 1 S.A
....4 IC3011 0406-001299 DIODE-TVS;CM1224-04MR,MSOP-10 1 S.A
....4 IC3012 0406-001299 DIODE-TVS;CM1224-04MR,MSOP-10 1 S.A
....4 IC3013 0406-001299 DIODE-TVS;CM1224-04MR,MSOP-10 1 S.A
5-11
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 IC3014 0406-001299 DIODE-TVS;CM1224-04MR,MSOP-10 1 S.A
....4 IC3015 0406-001299 DIODE-TVS;CM1224-04MR,MSOP-10 1 S.A
....4 IC3016 0406-001299 DIODE-TVS;CM1224-04MR,MSOP-10 1 S.A
....4 IC3017_4HD 0406-001299 DIODE-TVS;CM1224-04MR,MSOP-10 1 S.A
....4 IC3018_4HD 0406-001299 DIODE-TVS;CM1224-04MR,MSOP-10 1 S.A
....4 D2005 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D2007 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D2010 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D4003 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D4005 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D4006 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D4008 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D4009 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D7001 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D7002 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D7003 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D7004 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D7005 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 D7006 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.N.A
....4 Q3010 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q9001 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q9002 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q1003 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q1005 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q2002 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3001 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3008 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3009 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3011 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3012 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3013 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3016_4HDM 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3017 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3018 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q3022_SIDE 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q4002 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q4003 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q4004 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q5006 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q5007 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q5008 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q6001 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q2001 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q2003 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q3004 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q3005 0501-000669 TR-SMALL SIGNAL;KTA1505Y,PNP,150mW,SOT-2 1 S.A
....4 Q1002 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q1007 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q1008 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q1009 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q3002 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
5-12
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 Q3003 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q3006 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q3007 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-001165 FET-SILICON;SI3443BDV,P,-20V,+-4.4A,65mo 1 S.A
....4 Q409 0505-001957 FET-SILICON;NTR2101P,P,-8V,-3.7A,0.052oh 1 S.A
....4 IC104 0801-002095 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,TSSOP 1 S.A
....4 IC104 0801-002172 IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI 1 S.A
....4 IC104 0801-002172 IC-CMOS LOGIC;74LCX16244,BUFFER/LINE DRI 1 S.A
....4 IC104 0801-002237 IC-CMOS LOGIC;74V(A)HC1G04,INVERTER,SC-7 1 S.A
....4 IC104 0801-002237 IC-CMOS LOGIC;74V(A)HC1G04,INVERTER,SC-7 1 S.A
....4 IC104 0801-002378 IC-CMOS LOGIC;74VHC04,INVERTER,SOP,14P,8 1 S.N.A
....4 IC104 0801-002630 IC-CMOS LOGIC;74AHCT1G08,2-INPUT AND GAT 1 S.A
....4 IC104 0801-002633 IC-CMOS LOGIC;7WBD3125,2bit BUS SWITCH,S 1 S.A
....4 IC104 0801-002780 IC-CMOS LOGIC;74LVC1G17,SCHMITT-TRIGGER 1 S.N.A
....4 T0596 0904-002329 IC-USC;USB2514,QFN,36P,6.55x6.55mm,58.6K 1 S.A
....4 IC5001 1001-000164 IC-ANALOG MULTIPLEX;74HC4052,CMOS,SOP,16 1 S.A
....4 IC106 1001-001440 IC-VIDEO SWITCH;SiI9185CTU,QFP,80P,3.3V, 1 S.A
....4 IC106 1001-001513 IC-VIDEO SWITCH;TMDS351PAG,TQFP,64P,9x9m 1 S.A
....4 IC3001 1001-001523 IC-ANALOG MULTIPLEX;74HC4052PW,TSSOP,16P 1 S.A
....4 IC107 1002-001482 IC-D/A CONVERTER;WM8521H9GED/R,16bit,SOI 1 S.A
....4 IC2002 1002-001509 IC-A/D&D/A CONVERTER;MT8291,24bit,LQFP,4 1 S.A
....4 IC110 1006-001076 IC-DRIVER/RECEIVER;MAX232ECWE+T,SOP,16P, 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-001385 IC-EEPROM;AT24C256,256Kbit,32Kx8,SOP,8P, 1 S.A
....4 IC112 1103-001410 IC-EEPROM;S-24CS08AFJ-TB-1GE,8Kbit,1Kx8, 1 S.A
....4 IC113 1105-001712 IC-DRAM;HYB25D256163CE,DDR,256Mbit,16Mx1 1 S.A
....4 IC113 1105-001712 IC-DRAM;HYB25D256163CE,DDR,256Mbit,16Mx1 1 S.A
....4 IC113 1105-001823 IC-DRAM;HYB25DC512160,DDR,512Mbit,32Mx16 1 S.N.A
....4 IC113 1105-001823 IC-DRAM;HYB25DC512160,DDR,512Mbit,32Mx16 1 S.N.A
....4 IC4002 1105-001862 IC-DDR2 SDRAM;K4T56163QI-ZCF7,DDR2 SDRAM 1 S.A
....4 IC4003 1105-001862 IC-DDR2 SDRAM;K4T56163QI-ZCF7,DDR2 SDRAM 1 S.A
....4 DU410 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 S.A
....4 T0124 1201-002677 IC-POWER AMP;NTP3100,QFN56,56P,8x8mm,DUA 1 S.A
....4 T0124 1201-002677 IC-POWER AMP;NTP3100,QFN56,56P,8x8mm,DUA 1 S.A
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,-,PLA 1 S.A
....4 T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,-,PLA 1 S.A
....4 T0087 1203-002842 IC-POSI.FIXED REG.;AP1117D-33A,TO-252,3P 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC012 1203-003038 IC-POSI.ADJUST REG.;LP2995,SO,8P,4.9x3.9 1 S.N.A
....4 IC012 1203-003038 IC-POSI.ADJUST REG.;LP2995,SO,8P,4.9x3.9 1 S.N.A
....4 IC7011 1203-003394 IC-POWER SUPERVISOR;MIC2544-1YM,SOP,8P,4 1 S.A
5-13
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 T0087 1203-003695 IC-POSI.FIXED REG.;NCP1117ST33T3G,SOT-22 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 IC4004 1203-004363 IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P, 1 S.A
....4 IC2004 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 T0170 1203-004868 IC-SWITCH VOL. REG.;MP2363,SOIC,8P,4.9x3 1 S.A
....4 T0170 1203-004868 IC-SWITCH VOL. REG.;MP2363,SOIC,8P,4.9x3 1 S.A
....4 T0170 1203-004868 IC-SWITCH VOL. REG.;MP2363,SOIC,8P,4.9x3 1 S.A
....4 T0170 1203-004868 IC-SWITCH VOL. REG.;MP2363,SOIC,8P,4.9x3 1 S.A
....4 IC118 1204-002779 IC-VIDEO PROCESS;S4LF122X01,PBGA,208P,17 1 S.A
....4 IC118 1204-002869 IC-VIDEO PROCESS;MT8226FJ,BGA,569P,31x31 1 S.A
....4 IC7001 1204-002888 IC-DECODER;SAM7103,FPBGA,716P,27x27mm,PL 1 S.A
....4 IC3019 1205-003201 IC-BUS SWITCH;TC7WB125FK,SSOP,8P,2x2.3mm 1 S.A
....4 IC4011 1205-003201 IC-BUS SWITCH;TC7WB125FK,SSOP,8P,2x2.3mm 1 S.A
....4 IC9001 1205-003444 IC-ETHERNET CONTROLLER;LAN8700-AEZG,QFN, 1 S.A
....4 P803T 1404-001223 THERMISTOR-PTC;45mohm,20,6V,-,40A,4A,TP 1 S.A
....4 IC3007 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 IC3009_4HD 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 IC3010 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 IC4008 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D3001 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3002 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3003 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3004 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3005 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3006 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3008 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3012 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3013 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3014 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3015 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3016 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3018 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3025 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3027 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3028 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3029 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3036 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3038 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3062 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3063 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3064 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 D3065 1405-001233 VARISTOR;30Vdc,5A,1.6x0.8x0.8mm,TP 1 S.A
....4 R3299 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216 1 S.N.A
....4 R3300 2007-000033 R-CHIP;0ohm,5%,1/4W,TP,3216 1 S.N.A
....4 R1252 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 R1253 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 R1035 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 R1041 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 R1121 2007-000067 R-CHIP;15Kohm,1%,1/10W,TP,1608 1 S.N.A
....4 R6025 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.N.A
....4 R7346 2007-000123 R-CHIP;1.5Kohm,5%,1/10W,TP,1608 1 S.N.A
5-14
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R1255 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608 1 S.A
....4 R5028 2007-000133 R-CHIP;330Kohm,5%,1/10W,TP,1608 1 S.A
....4 R1005 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2002 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2003 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2004 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2005 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2013 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2014 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2015 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2041 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2042 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2043 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2044 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2047 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2070_WO 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2074_WO 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2075_WO 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2076_WO 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R2079_WO 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3009 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3010 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3025 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3027 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3041 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3045 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3047 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3048 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3049 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3054 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3075 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3076 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3078 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3089 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3090 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3091 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3117 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3172 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3176 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3179 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3181 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3546_FAN 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3547_FAN 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R3612 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4018 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4019 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4066 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4082 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4083 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4089 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4090 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
5-15
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R4095 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4100 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4101 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4103 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4104 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4113 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4114 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4115 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4132 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4133 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4134 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4135 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4136 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4150 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4151 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4207 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R4208 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5073 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5074 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R5520 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6013 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6014 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6016 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6017 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6018 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6019 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6020 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6021 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6031 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6038 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6039 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6043 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6044 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6045 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R6046 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7021 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7022 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7023 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7024 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7025 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7026 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7027 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7028 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7037 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7049 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7054 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7055 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7056 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7057 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7058 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7059 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
5-16
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R7060 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7061 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7066 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7069 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7321 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7415 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7416 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7417 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7418 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 1 S.N.A
....4 R7419 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
