6-1
6. Wiring Diagram
T-CON
Woofer Woofer
CN302 CN402
LD B'D
CN401
CN6105
CNM801
CNM803 CN1001
SMPS B'D Main B'D
6-1. Wiring Diagram 46"
CN105
CN3015
LED DRIVER
6. Wiring Diagram
B'D Side AV
CN3012
CN106
CN2001 CN2002
TOUCH FUNCTION & IR
SPEAKER SPEAKER
T-CON
CN402
Woofer
CN302 LD B'D
Woofer CN401
CNM802 CN6105
CN1001
CNM803
CNM804
Main B'D
6-2. Wiring Diagram 55"
SMPS B'D
LED DRIVER B'D
CN2001 CN2002
6. Wiring Diagram
TOUCH FUNCTION & IR
SPEAKER SPEAKER
6-2
6. Wiring Diagram
6-3
6. Wiring Diagram
6-3. Connector Functions
Connector Functions
1) CN100<->CNM801 Supply main power from SMPS to Main Board.
2) CON1<->CNM803 Supply main power from SMPS to Local Dimming Driver.
3) T-CON<->CN402 The LVDS signal transfered from Main Board to Panel.
4) CON103<->CN302 The information of local dimming is transfered.
5) CN401<->CN2001 The LVDS signal transfered from Main Board to LD Board.
6) CN406<->CN106 Supply power from Main Board to Side-AV.
7) CN403 <-> CN105 The signal transfered from Main Board to Side-AV.
6-4
6. Wiring Diagram
6-4. Cables
Use 1) Main<->SMPS (30p) 2) L/D Driver<->SMPS (14p) 3) L/D Board<->T-CON (FFC)
46": BN39-01099D(100mm) 46": BN39-00849G 250mm 46": BN96-08479D(100/120mm)
Code 55": BN39-01099B(800mm) 55": BN39-00849C(300mm) 55": BN96-08479E(450/200mm)
BN39-00849L(600mm)
Photo < 46">
< 55 ">
Use 4) L/D Driver<->L/D Board 5) Main Board<->L/D Board 6) FFC Cable
46":BN39-01113A 46"/55" : BN39-00825B 250mm 46" BN96-06678A (350mm)
(600mm, 15pin to 15pin)
Code
55":BN39-01116A
(600mm,15pin to 20pin)
< 46">
<55">
Use 7) Side Cable (3P-4P)
Code 46" BN39-00948E
6-5
6. Wiring Diagram
Memo
6-6
