Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
5 Exploded View & Parts List
5 Exploded View and Parts List
- You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
5-1 LE26S86BD/LE26S86BCX Exploded View
M0014
M0107
M0146
T0447
T0764 M0013
M0215
T0175
T0003
M0115
M0027
5-1
5 Exploded View & Parts List
5-2 LE26R86BD/LE26S86BCX Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04750C ASSY COVER P-FRONT;26S86,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-04769A ASSY SPEAKER P;16ohm,4pin,5W,Jasmine 23" 1 S.A
M0215 BN07-00364A LCD-PANEL;V260B1-L04,6bit+FRC,26inch,16. 1 S.A
T0447 BN96-04682C ASSY BRACKET P-PANEL;26S86,,EO(DTV),-,-, 1 S.N.A
M0146 BN61-02207A BRACKET-PANEL SIDE;Bordeaux 26,SECC,T1.2 4 S.N.A
M0014 BN94-01404N ASSY PCB MAIN-CMO;LE26S86BDX/* 1 S.N.A
M0107 BN63-03039A SHIELD-COVER;MURANO40,PCM,T0.5,IDTV 1 S.N.A
T0764 BN44-00156A SMPS-LCDTV;MK32P,SEM,AC/DC,180W,AC100 ~ 1 S.A
M0115 BN61-02931A BRACKET-STAND LINK;JASMINE 26,SECC,T1.6 1 S.N.A
M0027 BN96-04745A ASSY STAND P-BASE;23,26S81,ABS+PMMA,HB,B 1 S.A
M0013 BN96-04820B ASSY COVER P-REAR;26S86,EO,HIPS,HB,BK500 1 S.A
5-2
5 Exploded View & Parts List
5-3 LE32S86BD/LE32S86BCX Exploded View
M0014
M0107
M0146
T0447
T0764
M0013
M0215
T0175
T0003
M0115
M0027
5-3
5 Exploded View & Parts List
5-4 LE32S86BD/LE32S86BCX Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04694E ASSY COVER P-FRONT;32S86,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-04770A ASSY SPEAKER P;8ohm,4pin,10W,Jasmine 32" 1 S.A
M0215 BN07-00453A LCD-PANEL;LTA320WT-L06,8bit,32inch,16.7M 1 S.A
T0447 BN96-04681A ASSY BRACKET P-PANEL;32R81,-,-,-,-,AM,CM 1 S.N.A
M0146 BN61-03265A BRACKET-PANEL SIDE;JASMINE,SECC 1.2,AMLC 4 S.N.A
M0014 BN94-01404X ASSY PCB MAIN-AMLCD;LE32S86BDX/*AMLCD VE 1 S.A
M0107 BN63-03039A SHIELD-COVER;MURANO40,PCM,T0.5,IDTV 1 S.N.A
T0764 BN44-00156A SMPS-LCDTV;MK32P,SEM,AC/DC,180W,AC100 ~ 1 S.A
M0115 BN61-02947A BRACKET-STAND LINK;JASMINE 32",SECC,T1.6 1 S.N.A
M0027 BN96-04697A ASSY STAND P-BASE;32S81,-,ABS+PMMA,HB,BK 1 S.A
M0013 BN96-04698B ASSY COVER P-REAR;32S86,EO,HIPS,HB,BK500 1 S.A
5-4
5 Exploded View & Parts List
5-5 LE37S86BD Exploded View
M0014
M0107
M0146
T0447
T0764
M0013
M0215
M0146
T0175
T0003
M0115
M0027
5-5
5 Exploded View & Parts List
5-6 LE37S86BD Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04752C ASSY COVER P-FRONT;37S86,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-04770B ASSY SPEAKER P;8ohm,4pin,10W,600/1250mm, 1 S.A
M0215 BN07-00393A LCD-PANEL;T370XW02,8bit,37inch,16.7M,16: 1 S.A
T0447 BN96-04680E ASSY BRACKET P-PANEL;37S86,EO 1 S.N.A
M0146 BN61-02241A BRACKET-PANEL SIDE;Bordeaux 37,SECC,T1.2 1 S.N.A
M0146 BN61-02242A BRACKET-PANEL SIDE;Bordeaux 37,SECC,T1.2 1 S.N.A
M0014 BN94-01404U ASSY PCB MAIN-AUO;LE37S86BDX/* 1 S.A
M0107 BN63-03039A SHIELD-COVER;MURANO40,PCM,T0.5,IDTV 1 S.N.A
T0764 BN44-00157A SMPS-LCDTV;MK37,SEM,AC/DC,280W,AC100 ~ 2 1 S.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
M0027 BN96-04754A ASSY STAND P-BASE;37,40S81,ABS+PMMA,HB,B 1 S.A
M0013 BN96-04826B ASSY COVER P-REAR;37S86,EO,HIPS,HB,BK500 1 S.A
5-6
5 Exploded View & Parts List
5-7 LE40S86BD/LE40S86BCX Exploded View
M0014
M0107
M0146
T0447
T0764
M0013
M0215
M0146
T0175
T0003
M0115
M0027
5-7
5 Exploded View & Parts List
5-8 LE40S86BD/LE40S86BCX Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04753C ASSY COVER P-FRONT;40S86,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-04770B ASSY SPEAKER P;8ohm,4pin,10W,600/1250mm, 1 S.A
M0215 BN07-00370A LCD-PANEL;T400XW02,8bit,40inch,16.7M,16: 1 S.A
T0447 BN96-04679A ASSY BRACKET P-PANEL;BORDEAUX PLUS40 1 S.N.A
M0146 BN61-02972A BRACKET-PANEL TOP;40 BORDEAUX PLUS,SECC, 1 S.N.A
M0146 BN61-02256B BRACKET-PANEL SIDE;Bordeaux 40,SECC,T1.2 1 S.N.A
M0014 BN94-01324C ASSY PCB MAIN-AUO;LE40S86BCX/FID 1 S.A
M0107 BN61-03036A BRACKET-PCB;40 BORDEAUX PLUS,SECC,T1.2,S 1 S.N.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
M0027 BN96-04754A ASSY STAND P-BASE;37,40S81,ABS+PMMA,HB,B 1 S.A
M0013 BN96-04822B ASSY COVER P-REAR;40S86,EO,HIPS,HB,BK500 1 S.A
5-8
5 Exploded View & Parts List
5-9 LE46S86BD/LE46S86BCX Exploded View
M0013
M0014
M0107
M0174
M0215
T0003
T0447
M0027
5-9
5 Exploded View & Parts List
5-10 LE46S86BD/LE46S86BCX Parts list
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-04738C ASSY COVER P-FRONT;46S86,EO,ABS+PMMA,HB, 1 S.A
T0175 BN96-04770C ASSY SPEAKER P;8ohm,4pin,10W,750/1250mm, 1 S.A
M0215 BN07-00389A LCD-PANEL; LTA460WT-L11,8bit,46inch,16.7 1 S.A
T0447 BN96-05214D ASSY BRACKET P-PANEL;46S81,KO 1 S.N.A
T0531 BN63-03185B COVER-BOTTOM;46S81,HIPS,-,-,-,HB,-,BK500 1 S.A
M0014 BN94-01324D ASSY PCB MAIN-AMLCD;LE46S86BCX/FID 1 S.A
M0027 BN96-04743A ASSY STAND P-BASE;46S81,ABS+PMMA,HB,BK23 1 S.A
M0013 BN96-04825B ASSY COVER P-REAR;46S86,EO,HIPS,HB,BK500 1 S.A
5-10
