Image preview - the first page of the document
>> Download 11_Electrical Part List documenatation <<
Text preview - extract from the document
6 Electrical Parts List
6 Electrical Parts List
You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LN46N71BX Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LN46N71BX/XAZ LN46N71B,E53A/46M70-GNM,46,LCD-TV,BRAZIL 0
0.1 M0001 BN90-00934H ASSY COVER FRONT;46N71,XAZ,ABS+PMMA,HB,B 1 S.N.A
..2 M0081 6006-001096 SCREW-TAPTITE;BH,+,WP,B,M4.0,L12,ZPC(BLK 2 S.N.A
..2 T0175 BN96-03591A ASSY SPEAKER P;8ohm,2way,2speaker,10W,Le 1 S.A
..2 T0175 BN96-03593A ASSY SPEAKER P;8ohm,2way,2speaker,10W,Ri 1 S.A
..2 T0003 BN96-04056B ASSY COVER P-FRONT;46N71(UO,XAZ),ABS+PMM 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M0162 6502-001067 CABLE CLAMP;DAFC-1300,ID2.2,T5.2,NYLIN6/ 1 S.N.A
...3 M2893 BN39-00609A LEAD CONNECTOR;VE20EO,UL1015#22 BLACK,1P 1 S.A
...3 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
...3 BN61-02666A HOLDER-BOSS;MOSEL 46,ABS,VO,TOP 2 S.N.A
...3 BN61-02672A HOLDER-BOSS;MOSEL 46,ABS,VO,BOTTOM,LEFT 1 S.N.A
...3 BN61-02673A HOLDER-BOSS;MOSEL 46,ABS,VO,BOTTOM,RIGHT 1 S.N.A
...3 BN61-02771A BOSS-BOND;MOSEL,ABS+PMMA,NATURAL,BOND 14 S.N.A
...3 CCM1 BN63-02183H COVER-SHEET;Rhcm,PE Vinyl,T0.05,1300mm,2 2.21 S.N.A
...3 M0112 BN63-02621J COVER-FRONT;46F71(UO,XAZ),ABS+PMMA,HB,BK 1 S.N.A
...3 T0056 BN63-02854A COVER-DECORATION;46" MOSEL,AL,Extruding 1 S.N.A
...3 T0023 BN64-00342A KNOB POWER;ROME,40,PC,VIOLET 1 S.N.A
...3 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
...3 T0054 BN64-00443A KNOB-DECORATION;32R71,ABS,HB,GR503,VACUU 1 S.N.A
...3 T0061 BN64-00453A WINDOW-REMOCON;32R71,PC,V0,VIOLET,DIFFUS 1 S.N.A
...3 M0145 BN96-03466B ASSY BOARD P-FUNCTION;LE40M71BX,CT5000-4 1 S.A
...3 M0146 BN96-04015B ASSY BOARD P-POWER & IR;LNS4695DX,CT5000 1 S.A
...3 T0022 BN64-00467D KNOB CONTROL;MOSEL32",40",46",ABS,V0,BK0 1 S.N.A
0.1 M0002 BN90-00937J ASSY COVER REAR;46M71,XAZ,HIPS,HB,BK500 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 2 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 12 S.A
..2 C/R+B/W 6011-001610 BOLT-ETC;M8,L18,ZPC(BLK),SWRCH18A,WSP,PH 4 S.N.A
..2 M0013 BN96-04226D ASSY COVER P-REAR;46N71,(UO,XAZ),HIPS,HB 1 S.A
...3 T0069 AA63-60122K SPACER-FELT;SPD-42P3S,FELT,L60,D20,T0.35 2 S.N.A
...3 M0006 BN63-02695D COVER-REAR;46N71,UO(XAZ),HIPS,HB,BK500,N 1 S.N.A
...3 T0071 BN64-00541A INLAY-TERMINAL;MOSEL 46,PS SHEET,T0.5 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
0.1 M0216 BN90-00940A ASSY STAND;46M7,-,-,-,MOSEL,ROUND 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
..2 M0013 BN96-03417A ASSY STAND P-BASE;46M7,-,ABS+PMMA,HB,BK2 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 7 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 7 S.A
...3 T0010 BN61-02532A HOLDER;46M7 EO,ACETAL,BLK,TOP 1 S.N.A
...3 BN61-02533A HOLDER-SWIVEL RING;46M7 EO,ACETAL,NATUAL 1 S.N.A
...3 BN61-02534A HOLDER-SWIVEL RING;46M7 EO,ACETAL,NATUAL 1 S.N.A
...3 BN61-02535A BRACKET-STAND BOTTOM;46M7 EO,HG,T3.0 1 S.N.A
...3 BN61-02536A BRACKET-HINGE SWIVEL;46M7 EO,HG,T3.0 1 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 0.45 S.N.A
...3 BN63-02625A COVER-STAND SUB;46M7 EO,ABS+PMMA,HB,BK23 1 S.N.A
...3 T0004 BN63-02626A COVER-STAND BASE;46M7 EO,ABS+PMMA,HB,BK2 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 10 S.N.A
...3 T0920 BN61-02531A GUIDE-STAND;46M7,ABS V0,-,-,-,BK07,- 1 S.N.A
....4 T0514 BN61-02537A BRACKET-SUPPORT;46M7,SECC,T2.0 2 S.N.A
0.1 T0852 BN91-01058Z ASSY LCD-SPN;LE46N71BX/* 1 S.N.A
..2 M0215 BN07-00345A LCD-PANEL;LTA460WT-LH2,8bit,46inch,16.7M 1 S.A
6-1
6 Electrical Parts List
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0.1 M0017 BN91-01225A ASSY CHASSIS;LN46N71BX/XAZ 1 S.N.A
..2 M0014 BN94-01118A ASSY PCB MAIN;LN46N71BX/XAZ 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 JA709 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004909 HEADER-BOARD TO CABLE;BOX,14P,2R,2MM,ANG 1 S.A
...3 CN4004 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 CN330 3711-005942 HEADER-BOARD TO CABLE;BOX,16P,1R,2mm,STR 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA333 3722-002143 JACK-PIN;5P,NI,GRN/BLU/RED/WHT/RED,STRAI 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002363 JACK-PIN;3P,Sn,YEL/WHT/RED,STRAIGHT 1 S.A
...3 CIS3 BN40-00091A TUNER;TCPN3081PA32S(H),TCPN3081PA32S(H), 1 S.A
...3 M0107 BN63-01847A SHIELD-COVER;ROME,SECC,T0.3,49.5,79.5,HE 1 S.N.A
...3 CIS8 BN73-00024C SILICON/RUBBER-BERGQUIST;VENUS 32,40",SI 1 S.N.A
...3 T0174 BN97-01225A ASSY SMD;LN46N71BX/XAZ 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
