Image preview - the first page of the document
>> Download 03_Exploded View & Part List documenatation <<
Text preview - extract from the document
Exploded View & Parts List
2. Exploded View & Parts List
2-1 SP43L2H1X/XEH
You can search for the updated part code through ITSELF web site.
URL : http://itself.sec.samsung.co.kr
M0045 T0112 Loc. Code No Description Specification Q'ty S.N.A
T0074 T0066 CIS1 BP94-00010A ASSY PCB MISC-SIDE KEY CONTROL;ALADDIN,3 1
CIS6 AA64-01791B CABINET-MIDDLE;43L2,HIPS,HB,G4309,SV-012 1 S.N.A
T0952 M0045 AA64-00546D CABINET BACK-TOP;43L2,HIPS,HB,GR503 1
T0264 T0264 T0003 AA64-01788L CABINET FRONT;43L2,HIPS,HB,GRY,SV012P,+D 1 S.N.A
T0505 T0134 T0267 T0053 BP67-00080A SCREEN FRESNEL;43W,MS,973*558,2T 1
T0054 BP67-00079A SCREEN LENTI;43W,MS,973*558,2.1T 1
T0951
T0053 T0057 BP64-00177A BADGE-BRAND;ALL,AL,T1.5,70,11.3,BLK,SILI 1 S.N.A
T0054 T0066 AA96-20130K ASSY POWER CORD;,CP2/NO(4.0R),H/S 700MM, 1
T0074 BN59-00378B REMOCON;L63A,TM77,55,3P LCD,SAMSUNG,EX,P 1
T0210 T0268
T0112 AA63-00599B COVER-BACK;43L2,HIPS,HB,GR503 1
T0503 CIS6 T0134 BP67-00040A MIRROR-FRONT,DM1;43",GLASS,810*472*434,F 1
T0501 T0158 BP96-00080R ASSY COVER P-MAIN;43L2,LCD,HIPS,V0,NEW S 1
T0909 T0186 BP96-00225B ASSY COVER P-GRILLE;43L2,HIPS,HB,G4309,S 1
T0003 T0210 AA61-01136A BRACKET-SCREEN,TOP;43",AL6063 EXTR,BLK 2 S.N.A
T0264 AA63-00021G SPACER-MIRROR;524J,434J,PVC,-,-,-,BLK,-, 3 S.N.A
T0511
T0264 AA63-00021J SPACER-MIRROR;43J6,PVC,-,-,-,BLK,-,-,L81 1 S.N.A
CIS1 T0267 AA61-00184B BRACKET-MIRROR,TOP;43J6,SECC-1,T1.6,-,-, 1 S.N.A
T0502 T0268 AA61-00182B BRACKET-MIRROR BOT;43J6,SECC-1,T1.6,-,-, 1 S.N.A
T0158 T0417 BP91-00838D ASSY MISC-ENINGE,MECHA;43/46 VE LCD ENGI 1 S.N.A
T0417 T0501 BP63-00031A COVER-DECO,TOP;43L2,ABS,HB,BLK,SVM-4704P 1 S.N.A
T0502 BP63-00033A COVER-DECO,L;43L2,ABS,HB,BLK,SVM-4704P, 1 S.N.A
T0503 BP63-00037A COVER-DECO,PAL;43L2,PAL,ABS,HB,BLK,SVM-4 1 S.N.A
T0505 AA61-00361B BRACKET- MIRROR SIDE;43J6,SECC-1,T1.0,-, 2 S.N.A
T0511 BP60-00044A SPACER-LENS;SP46L5H1,P/U FORM,GRAY,3.0 1 S.N.A
T0057 T0186 T0951 AA61-01137A BRACKET-SCREEN,SIDE;43",AL6063 EXTR,BLK 2 S.N.A
T0952 AA63-00157D COVER DUST;43L2,HIPS,HB,GR503 1 S.N.A
Samsung Electronics 2-1
