Image preview - the first page of the document
02_specifications


>> Download 02_specifications documenatation <<

Text preview - extract from the document
                                                                                               2. Product specifications

2. Product specifications
2-1. Feature & Specifications
               Model                                      UE32D50** / UE32D55** / UE32D57**

                                                         Feature

 DTV/ATV (5700 : Satellite), 4-HDMI, 1-Component, 1-A/V, D-SUB, 1-SCART, 2-USB2.0
 Brightness : 300 cd/m2
 High Contrast Ratio : 6,000:1
 Response Time : 6.5ms

                                                      Specifications

               Item                                                    Description
LCD Panel                        32 inch FHD
Scanning Frequency               Horizontal : 50 kHz ~ 75 kHz (Automatic)
                                 Vertical : 47 Hz ~ 63 Hz (Automatic)
Display Colors                   16.7M color
Maximum resolution               Horizontal : 1920 Pixels
                                 Vertical : 1080 pixels
Input Signal                     Analog 0.7 Vp-p
