Image preview - the first page of the document



>> Download 03_disassembly_and_reassemble documenatation <<

Text preview - extract from the document

                                                                                       3. Disassembly and Reassembly

3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LED TV.
    WARNING: This LED TV contains electrostatically sensitive devices. Use caution when handling these components.

3-1. Disassembly and Reassembly
   Cautions: 1. Disconnect the LED TV from the power source before disassembly.
             2. Follow these directions carefully; never use metal instruments to pry apart the cabinet.

 UD5000_UD5500_UD5700(32", 37", 40", 46") / UD4000 (32")

                   Description                                  Picture Description                         Screws

  1    Place the TV face down on cushioned table.
       Remove 4 screws from the Stand.(machine
       type)
       Remove Stand.




                                                                                                           6001-002621
                                                                                                            (Machine)




  2    Remove the screws of Rear-Cover.
