Image preview - the first page of the document
>> Download Wiring Diagram documenatation <<
Text preview - extract from the document
6-1
6. Wiring Diagram
PANEL
WOOFER CNM9401 CNM9402
SMPS
CNM802
CN1001
CN801S
CN2002
Main Board
CN7005
6-1. Wiring Diagram UB7W 40"
CN2001
POWER CORD
T- CON CN4001
6. Wiring Diagram
Function IR
Speaker Speaker
PANEL
WOOFER CNM9401 CNM9402 WOOFER
SMPS
CNM802
CN1001
CN801S
CN2002
Main Board
CN7005
6-2. Wiring Diagram UB7W 46/55"
CN2001
POWER CORD
T- CON CN4001
Function IR
Speaker Speaker
6. Wiring Diagram
6-2
6-3
6. Wiring Diagram
PANEL
WOOFER CNM9401 CNM9402
SMPS
CNM802
CN1001
CN801S
CN2002
Main Board
CN7005
6-3. Wiring Diagram UB8W 40"
CN2001
CN4001
POWER CORD
T- CON CN4901
Function IR RF module
Speaker Speaker
PANEL
WOOFER CNM9401 CNM9402
SMPS
CNM802
CN1001
CN801S
CN2002
Main Board
CN7005
6-4. Wiring Diagram UB8W 46"
CN2001
CN4001
POWER CORD
T- CON CN4901
Function IR RF module
Speaker Speaker
6. Wiring Diagram
6-4
6. Wiring Diagram
CN7005(to T-CON) CN2001(to Speaker)
1 GND 27 RE[0]- 1 R+
2 GND 28 GND 2 R-
3 SW_PVCC 29 RO[4]+ 3 L+
4 FRC_RESET 30 RO[4]- 4 L-
5 SDA 31 RO[3]+
6 SCL 32 RO[3]- CN2002(to Speaker)
7 LVDS opt 33 GND
1 SW+
8 H-Sync Out 34 ROCLK+
2 SW-
9 Panel_WP 35 ROCLK-
3 SW+
10 T_Con Check 36 GND
4 SW-
11 NC 37 RO[2]+
12 NC 38 RO[2]-
CN4001(to Function)
13 GND 39 RO[1]+
14 RE[4]+ 40 RO[1]- 1 IR 7 KEKY2
15 RE[4]- 41 RO[0]+ 2 GND 8 NCL
16 RE[3]+ 42 RO[0]- 3 A3.3V 9 A5V
17 RE[3]- 43 GND 4 LED_INDICAT 10 NC
18 GND 44 GND 5 BUZZER 11 LED_CTRL
19 RECLK+ 45 GND 6 KEY1 12 B5V
20 RECLK- 46 NC
21 GND 47 Panel_VCC CN4901(to RF Module)
22 RE[2]+ 48 Panel_VCC 1 A3.3V
23 RE[2]- 49 Panel_VCC 2 ZIGBEE_RESET
24 RE[1]+ 50 Panel_VCC 3 RDB_HOTEL
25 RE[1]- 51 Panel_VCC 4 GND
26 RE[0]+ 5 TDB_HOTEL
6 POWER_DET
CN3013(to HDMI1) CN3011(to PC_IN) CN7006 (to USB1)
1 HDMI1_RX2+ 11 DGND 1 PC_RED 9 PC_5V 1 USB0_VCC
2 DGND 12 HDMI1_RXCLK- 2 PC_GREEN 10 PC_IDENT 2 USB0_DM
3 HDMI1_RX2- 13 HDMI_CEC 3 PC_BLUE 11 DGND 3 USB0_DP
4 HDMI1_RX1+ 14 DGND 4 DGND 12 SDA_DOWN 4 DGND
5 DGND 15 HDMI1_DDC_SCL 5 DGND 13 PC_H_SYNC
6 HDMI1_RX1- 16 HDMI1_DDC_SDA 6 DGND 14 PC_V_SYNC CN7002 (to USB2)
7 HDMI1_RX0+ 17 DGND 7 DGND 15 SCL_DOWN
1 USB1_VCC
8 DGND 18 HDMI1_5V 8 DGND
2 USB1_DM
9 HDMI1_RX0- 19 HDMI1_HPD
3 USB1_DP
10 HDMI1_RXCLK+
4 DGND
6-5
6. Wiring Diagram
CN3016(to HDMI2)
1 HDMI2_RX2+ 11 DGND
2 DGND 12 HDMI2_RXCLK-
3 HDMI2_RX2- 13 HDMI_CEC
4 HDMI2_RX1+ 14 DGND
5 DGND 15 HDMI2_DDC_SCL
6 HDMI2_RX1- 16 HDMI2_DDC_SDA
7 HDMI2_RX0+ 17 DGND
8 DGND 18 HDMI2_5V
9 HDMI2_RX0- 19 HDMI2_HPD
10 HDMI2_RXCLK+
CN3015(to HDMI3)
1 HDMI3_RX2+ 11 DGND
2 DGND 12 HDMI3_RXCLK-
3 HDMI3_RX2- 13 HDMI_CEC
4 HDMI3_RX1+ 14 DGND
5 DGND 15 HDMI3_DDC_SCL
6 HDMI3_RX1- 16 HDMI3_DDC_SDA
7 HDMI3_RX0+ 17 DGND
8 DGND 18 HDMI3_5V
9 HDMI3_RX0- 19 HDMI3_HPD
10 HDMI3_RXCLK+
CN3010(to HDMI4)
1 HDMI4_RX2+ 11 DGND
2 DGND 12 HDMI4_RXCLK-
3 HDMI4_RX2- 13 HDMI_CEC
4 HDMI4_RX1+ 14 DGND
5 DGND 15 HDMI4_DDC_SCL
6 HDMI4_RX1- 16 HDMI4_DDC_SDA
7 HDMI4_RX0+ 17 DGND
8 DGND 18 HDMI4_5V
9 HDMI4_RX0- 19 HDMI4_HPD
10 HDMI4_RXCLK+
6-6
6. Wiring Diagram
6-5. Connector Functions
Connector Functions
CNM802<->CN1001 Supply power from SMPS to Main Board.
CN7005<->T-CON The LVDS signal transfered from Main Board to Panel.
6-6. Cables
Use Main-SMPS Main-Tcon Function Assy
UB7W, UB8X 40" : UB8X 40,46" : UB7W 40" : BN96-10736B
BN39-01099M(30P 150mm) BN39-01184B(51P 250mm) UB7W 46" : BN96-10736C
UB8X 46" : UB7W 40,46" : UB7W 55" : BN96-10736D
Code
BN39-01099L(30P 100mm) BN39-01184C(51P,300mm) UB8X 40" : BN96-10736H
UB7W 55" : UB8X 46" : BN96-10736J
BN39-01184A(51P 350mm)
6-7
