Image preview - the first page of the document
>> Download samsung_vc17eo_chassis_lw17m24c_lcd_tv_sm_332 documenatation <<
Text preview - extract from the document
TFT-LCD TV
Chassis Model
VC17EO LW17M24C
VE20EO LW20M21C
VT17EO LW17M24CU
GVE20KE LW20M21CU
SERVICE Manual
TFT-LCD TV CONTENTS
1. Precautions
2. Product Specifications
3. Disassembly & Reassembly
4. Alignment & Adjustments
5. Troubleshooting
6. Exploded View & Parts List
7. Electrical Parts List
8. Block Diagram
9. Wiring Diagram
10. PCB Layout
11. Schematic Diagrams
12. Panel Description
Samsung Electronics Co.,Ltd.
This Service Manual is a property of
416, Maetan-3Dong, Yeongtong-Gu, Suwon City, Gyeonggi-
Samsung Electronics Co., Ltd.
Do, Korea, 443-742
Any unauthorized use of Manual can be
Printed in Korea
punished under applicable International
P/N : BN82-00103P-02
and/or domestic law.
URL : http://itself.sec.samsung.co.kr/
2 Product Specifications
2 Product Specifications
2-1 Specifications
Description
Item
LW17M24C/LW17M24CU LW20M21C/LW20M21CU
LCD Panel TFT-LCD panel, RGB vertical stripe, normaly white, 17-Inch viewable, 0.264 (H) x 0.264(V)mm pixel pitch TFT-LCD panel, RGB vertical stripe, normaly white, 20-Inch viewable, 0.2125(H) x 0.6375(V) mm pixel pitch
Scanning Frequency Horizontal : 30 kHz ~ 80 kHz (Automatic) Horizontal : 28 kHz ~ 33 kHz (Automatic)
Vertical : 50 Hz ~ 75 Hz (Automatic) Vertical : 50 Hz ~ 70 Hz (Automatic)
Display Colors 16.2 Million colors
Maximum Resolution Horizontal : 1280 Pixels Horizontal : 640 Pixels
Vertical : 1024 Pixels Vertical : 480 Pixels
Input Video Signal Analog 0.7 Vp-p ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
