Image preview - the first page of the document
![2232BW[3]](/pics/5c51344434e81.gif)
>> Download 2232BW[3] documenatation <<
Text preview - extract from the document
5. Exploded View and Parts List
5. Exploded View and Parts List
5-1. Exploded View
M0013
M0013
M0006
T0514
M0174
M0215
T0003
5-1
5. Exploded View and Parts List
5-1-2. LS20PEBSFV/EDC Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-05532A ASSY COVER P-FRONT;LS20PEW,ABS HB,BK26,H 1 S.A
M0215 BN07-00374A LCD-PANEL;CLAA201WA04,Doppler,6bit Hi-FR 1 S.A
M0174 BN44-00127R IP BOARD;PWI2004SP(A),PEBBLE 20",3.2~4.2 1 S.A
M0014 BN94-01340L ASSY PCB MAIN-PTZ,W/W;LS20PEBSF* 1 S.N.A
M0006 BN96-05533A ASSY SHIELD P-COVER;LS20PEW,SECC,T0.8 1 S.N.A
M0013 BN96-05534A ASSY COVER P-REAR;LS20PEW,ABS HB,BK26,H/ 1 S.A
M0013 BN96-04150D ASSY STAND P-BAR;PEBBLE17,ABS HB,BK26,SF 1 S.A
5-1-3. LS22PEBSFV/EDC Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 BN96-05536A ASSY COVER P-FRONT;LS22PEW,ABS HB,BK26,H 1 S.A
M0215 BN07-00427A LCD-PANEL;M220Z1-L03,Mendel,6bit Hi-FRC, 1 S.A
M0174 BN44-00127Q IP BOARD;IP-45130B,PEBBLE 22",3.0 ~5.0mA 1 S.A
M0014 BN94-01340Z ASSY PCB MAIN-CTZ,W/W;LS22PEBSF 1 S.N.A
M0006 BN96-05533A ASSY SHIELD P-COVER;LS20PEW,SECC,T0.8 1 S.N.A
M0013 BN96-05535A ASSY COVER P-REAR;LS22PEW,ABS HB,BK26,H/ 1 S.A
M0013 BN96-04150D ASSY STAND P-BAR;PEBBLE17,ABS HB,BK26,SF 1 S.A
5-2
5. Exploded View and Parts List
5-2. LS20PEBSFV/EDC Parts List
Level Location Code.No Item & Specification Q'ty SA/SNA Remark
LS20PEBSFV/EDC 2032BW,WSJ1/S20P0-LPE,20,LCD-MO,NETHERLA
0.1 M0001 BN90-01313A ASSY COVER FRONT;LS20PE 1 S.N.A
..2 T0003 BN96-05532A ASSY COVER P-FRONT;LS20PEW,ABS HB,BK26,H 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
...3 BN61-02829A GUIDE-PANEL;PEBBLE,SECC,0.5,LS19PEB 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.5 S.N.A
...3 M0112 BN63-03528A COVER-FRONT;LS20PEW,ABS,HB,BK26,H/GLOSSY 1 S.N.A
...3 M0130 BN67-00193A LENS LED;PEBBLE,ABS HB,CLR 1 S.N.A
...3 M0145 BN96-04363B ASSY BOARD P-FUNCTION;Pebble_2032_2232,S 1 S.A
...3 T0022 BN64-00534B KNOB CONTROL;PEBBLE,ABS,HB,BK26 1 S.N.A
...3 T0023 BN64-00597B KNOB POWER;PEBBLE,black highglossy 1 S.N.A
0.1 M0002 BN90-01314A ASSY COVER REAR;LS20PE 1 S.N.A
..2 M0013 BN96-05534A ASSY COVER P-REAR;LS20PEW,ABS HB,BK26,H/ 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 T0060 BN61-02830A SPRING ETC;PEBBLE,SK5,1.0,LS19PEB,HRC 45 1 S.N.A
...3 M0006 BN63-03530A COVER-REAR;LS20PEW,ABS,HB,BK26,H/GLOSSY 1 S.N.A
...3 M0014 BN63-02880B COVER-STAND BAR;PEBBLE,ABS HB,T2.6,BK26, 1 S.N.A
...3 BN63-02883B COVER-HINGE;PEBBLE,ABS HB,T2.6,BK26,HF-0 1 S.N.A
...3 T0102 BN73-00132B RUBBER-CAP;PEBBLE,ELASTOMER,BK07,HB 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.5 S.N.A
0.1 M0135 BN91-01517B ASSY LCD-PTZ;LS20MEW* 1 S.N.A
..2 M0215 BN07-00374A LCD-PANEL;CLAA201WA04,Doppler,6bit Hi-FR 1 S.A
0.1 M0017 BN91-01630A ASSY CHASSIS-PTZ,W/W;LS20PEBSF* 1 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 1 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 3 S.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 4 S.N.A
..2 M0174 BN44-00127R IP BOARD;PWI2004SP(A),PEBBLE 20",3.2~4.2 1 S.A
..2 M0014 BN94-01340L ASSY PCB MAIN-PTZ,W/W;LS20PEBSF* 1 S.N.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.003 S.N.A
...3 CN102 3701-001173 CONNECTOR-DVI;24P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 CN101 3701-001219 CONNECTOR-DSUB;15P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 HDCP BN97-00707A ASSY HDCP;BN46-00018A,BR20/21BS_CS,MSTAR 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-01626L ASSY SMD;LS20PEBSF* 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45,96.5Sn/ 0.799 S.N.A
....4 D100 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D101 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D102 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D103 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D104 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D105 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D106 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D107 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
5-3
5. Exploded View and Parts List
Level Location Code.No Item & Specification Q'ty SA/SNA Remark
....4 D108 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D109 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D110 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D600 0402-001614 DIODE-RECTIFIER;S1G,400V,1A,DO-214AC,TP 1 S.A
....4 D603 0402-001614 DIODE-RECTIFIER;S1G,400V,1A,DO-214AC,TP 1 S.A
....4 D111 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D112 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD100 0403-001411 DIODE-ZENER;-,5.49-5.73V,200mW,SOD-323,T 1 S.A
....4 ZD101 0403-001411 DIODE-ZENER;-,5.49-5.73V,200mW,SOD-323,T 1 S.A
....4 ZD102 0403-001411 DIODE-ZENER;-,5.49-5.73V,200mW,SOD-323,T 1 S.A
....4 D0254 0404-001020 DIODE-SCHOTTKY;BAT54C,30V,200mA,SOT-23,T 1 S.A
....4 D0254 0404-001020 DIODE-SCHOTTKY;BAT54C,30V,200mA,SOT-23,T 1 S.A
....4 ZD200 0406-001061 DIODE-TVS;MMQA5V6T3,5.32/5.6/5.88V,24W,S 1 S.A
....4 ZD201 0406-001061 DIODE-TVS;MMQA5V6T3,5.32/5.6/5.88V,24W,S 1 S.A
....4 ZD202 0406-001061 DIODE-TVS;MMQA5V6T3,5.32/5.6/5.88V,24W,S 1 S.A
....4 Q201 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q203 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q204 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q601 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q401 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q402 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 U291 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q409 0505-001165 FET-SILICON;SI3443BDV,P,-20V,+-4.4A,65mo 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-001023 IC-EEPROM;24C08,8Kbit,1Kx8Bit,SOP,8P,5x4 1 S.A
....4 IC115 1107-001614 IC-FLASH MEMORY;MX25L1005,1Mbit,1Mx1Bit, 1 S.N.A
....4 IC603 1202-000164 IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL, 1 S.A
....4 IC204 1203-001824 IC-VOL. DETECTOR;7042,SOT-89,3P,-,PLASTI 1 S.A
....4 IC702 1203-002843 IC-DC/DC CONVERTER;AP1501-50K5A,TO-263-5 1 S.A
....4 T0087 1203-003695 IC-POSI.FIXED REG.;NCP1117ST33T3G,SOT-22 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 R608 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R245 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R259 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R274 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R275 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R276 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R277 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R100 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R101 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R102 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R103 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R104 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R105 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R106 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R107 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R204 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R205 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
5-4
5. Exploded View and Parts List
Level Location Code.No Item & Specification Q'ty SA/SNA Remark
....4 R111 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R113 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R114 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R117 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R118 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R120 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R132 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R202 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R203 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R206 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R207 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R212 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R213 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R216 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R250 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R251 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R252 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R255 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R401 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R108 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R123 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R270 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R208 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R209 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R218 2007-000083 R-CHIP;3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R229 2007-000083 R-CHIP;3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R219 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R220 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R223 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R230 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R234 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R729 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R600 2007-000088 R-CHIP;7.5Kohm,5%,1/10W,TP,1608 1 S.A
....4 R109 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R125 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R126 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R130 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R131 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R200 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R201 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R210 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R211 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R214 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R215 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R217 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R239 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R253 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R254 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R271 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
5-5
5. Exploded View and Parts List
Level Location Code.No Item & Specification Q'ty SA/SNA Remark
....4 R400 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R404 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R405 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R601 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R602 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R612 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R610 2007-000091 R-CHIP;12Kohm,5%,1/10W,TP,1608 1 S.A
....4 R402 2007-000102 R-CHIP;100Kohm,5%,1/10W,TP,1608 1 S.A
....4 R605 2007-000134 R-CHIP;33Kohm,5%,1/10W,TP,1608 1 S.A
....4 R232 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R273 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 S.A
....4 R116 2007-000821 R-CHIP;390ohm,1%,1/10W,TP,1608 1 S.A
....4 R235 2007-000821 R-CHIP;390ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-001002 R-CHIP;510ohm,5%,1/10W,TP,1608 1 S.A
....4 R121 2007-001044 R-CHIP;56ohm,5%,1/10W,TP,1608 1 S.A
....4 R122 2007-001044 R-CHIP;56ohm,5%,1/10W,TP,1608 1 S.A
....4 R112 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R115 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 R119 2007-001164 R-CHIP;75ohm,1%,1/10W,TP,1608 1 S.A
....4 C215 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C223 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C723 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C724 2203-000189 C-CER,CHIP;100nF,+80-20%,25V,Y5V,1608 1 S.A
....4 C201 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C202 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C642 2203-000236 C-CER,CHIP;0.1nF,5%,50V,C0G,1608 1 S.A
....4 C109 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C216 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C217 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C218 2203-000257 C-CER,CHIP;10nF,10%,50V,X7R,1608 1 S.A
....4 C116 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 1 S.A
....4 C115 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
....4 C210 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
....4 C211 2203-000626 C-CER,CHIP;0.022nF,5%,50V,C0G,1608 1 S.A
....4 C100 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C101 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C103 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C106 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C107 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C108 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C110 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C111 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C112 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C117 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C118 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C119 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C121 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C122 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
5-6
5. Exploded View and Parts List
Level Location Code.No Item & Specification Q'ty SA/SNA Remark
....4 C123 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C124 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C125 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C200 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C203 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C204 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C205 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C206 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C209 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C212 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C213 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C214 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C436 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C600 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C601 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C603 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C604 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C605 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C612 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C613 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C614 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C615 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C617 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C618 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C619 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C620 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C621 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C622 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C623 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C626 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C627 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C628 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C630 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C631 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C635 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C636 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C637 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C640 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C718 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C726 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
....4 C208 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C220 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C222 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C309 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C606 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C610 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C641 2203-005065 C-CER,CHIP;1000nF,+80-20%,10V,Y5V,1608 1 S.A
....4 C207 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C221 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
5-7
5. Exploded View and Parts List
Level Location Code.No Item & Specification Q'ty SA/SNA Remark
....4 C602 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C611 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C616 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C624 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C625 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C632 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C633 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C634 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C638 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C722 2402-001081 C-AL,SMD;100uF,20%,25V,WT,TP,8.3x8.3x10 1 S.A
....4 C435 2402-001128 C-AL,SMD;100F,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C629 2402-001128 C-AL,SMD;100F,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C639 2402-001128 C-AL,SMD;100F,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C719 2402-001128 C-AL,SMD;100F,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C725 2402-001128 C-AL,SMD;100F,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 X1 2801-003667 CRYSTAL-SMD;14.31818MHz,30ppm,28-AAN,16p 1 S.A
....4 T0568 3301-001407 BEAD-SMD;30ohm,1608,300mA,TP,,,0.4ohm 1 S.N.A
....4 T0568 3301-001407 BEAD-SMD;30ohm,1608,300mA,TP,,,0.4ohm 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 CN330 3711-005503 HEADER-BOARD TO CABLE;BOX,9P,1R,2mm,SMD- 1 S.A
....4 CN330 3711-005509 HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S 1 S.A
....4 L701 BN27-00008A COIL CHOKE-SMD;SMD12*12*8.5,GH15/17PS,22 1 S.A
....4 MICOM BN97-01604W ASSY MICOM-PTZ,W/W;LS20PEBSF* 1 S.N.A
.....5 IC109 1205-003255 IC-LCD CONTROLLER;SE758MRH-LF,PQFP,128P, 1 S.A
....4 CN400 3708-001150 CONNECTOR-FPC/FFC/PIC;30P,1mm,SMD-A,SN,Y 1 S.A
....4 T0077 BN41-00890A PCB MAIN;PEBBLE,CM-3,4,1.0,1.6T,179.6mm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 IC104 0801-002478 IC-CMOS LOGIC;7SZ14,SCHMITT TRIGGER,SOT2 1 S.A
....4 R256 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R257 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R258 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
..2 M0006 BN96-05533A ASSY SHIELD P-COVER;LS20PEW,SECC,T0.8 1 S.N.A
...3 BN61-02429D STUD-PEM;PNB,M2.8,D7,L20,ZPC(SIL),SUM24L 1 S.N.A
...3 M0107 BN63-03531A SHIELD-COVER;LS20PEW,SECC,T 0.8 1 S.N.A
...3 M0131 BN63-03831A GASKET;PEBBLE,71TS-FK 10-2-110-15,2T,10m 3 S.N.A
..2 M2893 AB39-00119A LEAD CONNECTOR;ORION,UL1007#26,UL/CSA,9 1 S.A
..2 M0596 BN96-05621A ASSY MISC P-FLAT CABLE;Mendel,FLAT CABLE 1 S.A
..2 T0514 BN61-02784A BRACKET-SUPPORT;PEBBLE,SPTE,0.3 1 S.N.A
0.1 M0112 BN91-01638A ASSY SHIELD;LS20PE 1 S.N.A
..2 BN63-03532A SHIELD-LAMP;LS20PEW,SPTE,T 0.3 1 S.N.A
5-8
5. Exploded View and Parts List
Level Location Code.No Item & Specification Q'ty SA/SNA Remark
0.1 M0113 BN92-02621G ASSY P/MATERIAL;LS20PEJSFV/EDC 1 S.N.A
..2 T0376 6902-000061 BAG AIR;LDPE,T0.2,L1000,W500,TRP,,, 0.004 S.N.A
..2 T0524 6902-000241 BAG PE;NITRON/HDPE,T0.5/T0.012,W600,L600 1 S.N.A
..2 T0376 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,-,-- 0.001 S.N.A
..2 T0524 6902-000389 BAG PE;HDPE/NITRON/HDPE,T0.015/T0.5/T0.0 1 S.N.A
..2 T0003 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 1.11 S.N.A
..2 M0081 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,-,- 0.02 S.N.A
0.1 M0019 BN92-02653R ASSY LABEL;LS20EJSFV/EDC 1 S.N.A
0.1 M0045 BN92-02720Z ASSY ACCESSORY;LS20PEBSFV/EDC 1 S.N.A
..2 M0114 BN39-00244B CBF SIGNAL;MO15PS,15P/15P,20276-N,1830mm 1 S.A
..2 M0125 BN39-00246F CBF SIGNAL-DVI(D);1703FP,24P/24P,20276-D 1 S.A
..2 BN68-01115C MANUAL FLYER-QSG;COMM,SyncMaster,korean, 1 S.N.A
..2 M0013 BN96-04150D ASSY STAND P-BAR;PEBBLE17,ABS HB,BK26,SF 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
...3 T0524 6902-000023 BAG PE;LDPE,T0.08,L120,W150,TRP,,,PE MAR 1 S.N.A
...3 BN61-02783D STAND-BAR;PEBBLE,ABS HB,SL-414WH,BK26,SF 1 S.N.A
...3 BN61-02786A BRACKET-PLATE;PEBBLE,SECC,1.0 1 S.N.A
..2 M0027 BN96-04154B ASSY STAND P-BASE;PEBBLE19,ABS HB,BK26 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 4 S.A
...3 T0524 6902-000389 BAG PE;HDPE/NITRON/HDPE,T0.015/T0.5/T0.0 1 S.N.A
...3 CIS4 BN61-01717A HOLDER-STAND;BIZET,NI PLT,CH,+,M4,L11(5) 1 S.A
...3 BN61-02785A BRACKET-STAND BODY;PEBBLE,SECC,0.8 1 S.N.A
...3 CCM1 BN63-02183C COVER-SHEET;Rhcm,PE Vinyl,T0.05,200mm,20 0.3 S.N.A
...3 T0004 BN63-02882B COVER-STAND BASE;PEBBLE,ABS,2.6,HB,BK26 1 S.N.A
...3 T0132 BN73-00077A RUBBER FOOT;MATISSE,BUMPON,◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
