Image preview - the first page of the document
![2232BW[6]](/pics/5c50bda1bd23b.gif)
>> Download 2232BW[6] documenatation <<
Text preview - extract from the document
5. Exploded View and Parts List
5. Exploded View and Parts List
5-1. Exploded View
5-1
5. Exploded View and Parts List
5-1-2. LS20PEBSFV/EDC Parts List
Location Code.No Item & Specification Q'ty SA/SNA Remark
T0003 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 1.11 S.N.A
M0215 BN07-00374A LCD-PANEL;CLAA201WA04,Doppler,6bit Hi-FR 1 S.A
M0014 BN69-01921C BOX-01,MONITOR;LS20PED(S/M2032BW),CB,SY- 1.02 S.N.A
M0013 BN96-04150D ASSY STAND P-BAR;-,PEBBLE17,-,ABS HB,BK2 1 S.A
5-2
5. Exploded View and Parts List
5-2. LS20PEJSFV/EDC Parts List
Level Location Code.No Item & Specification Q'ty SA/SNA Remark
LS20PEBSFV/
2032BW,WSJ1/S20P0-LPE,20,LCD-MO,NETHERLA
EDC
0.1 M0135 BN91-01517B ASSY LCD-PTZ;LS20MEW* 1 S.N.A
..2 M0215 BN07-00374A LCD-PANEL;CLAA201WA04,Doppler,6bit Hi-FR 1 S.A
0.1 M0113 BN92-02621S ASSY P/MATERIAL;PTS-LS20PEBSFV/EDC 1 S.N.A
..2 T0376 6902-000061 BAG AIR;LDPE,T0.2,L1000,W500,TRP,,, 0.004 S.N.A
..2 T0524 6902-000241 BAG PE;NITRON/HDPE,T0.5/T0.012,W600,L600 1 S.N.A
..2 T0376 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,-,-- 0.001 S.N.A
..2 T0003 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 1.11 S.N.A
..2 M0081 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,-,- 0.02 S.N.A
0.1 M0019 BN92-02653R ASSY LABEL;LS20EJSFV/EDC 1 S.N.A
0.1 M0003 BN92-02823M ASSY BOX;PTS-LS20PEBSFV/EDC,RUMANIA 1 S.N.A
..2 M0014 BN69-01921C BOX-01,MONITOR;LS20PED(S/M2032BW),CB,SY- 1.02 S.N.A
..2 T0081 BN96-02895A ASSY MISC P-HANDLE PACKING;ALL MODEL,BN6 1 S.N.A
...3 M0103 BN66-00007A LEVER-TOP;ALL MODEL,LDPE,WHITE 1 S.N.A
...3 M0102 BN66-00008A LEVER-BOTTOM;ALL MODEL,LDPE,WHITE 1 S.N.A
0.1 M0045 BN92-02825X ASSY ACCESSORY;PTS-LS20PEBSFV/EDC 1 S.N.A
..2 M0114 BN39-00244B CBF SIGNAL;MO15PS,15P/15P,20276-N,1830mm 1 S.A
..2 M0125 BN39-00246F CBF SIGNAL-DVI(D);1703FP,24P/24P,20276-D 1 S.A
..2 BN68-01115C MANUAL FLYER-QSG;COMM,SyncMaster,korean, 1 S.N.A
..2 M0013 BN96-04150D ASSY STAND P-BAR;-,PEBBLE17,-,ABS HB,BK2 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
...3 T0524 6902-000023 BAG PE;LDPE,T0.08,L120,W150,TRP,,,PE MAR 1 S.N.A
...3 BN61-02783D STAND-BAR;PEBBLE,ABS HB,SL-414WH,BK26,SF 1 S.N.A
...3 BN61-02786A BRACKET-PLATE;PEBBLE,SECC,1.0 1 S.N.A
..2 M0027 BN96-04154B ASSY STAND P-BASE;-,PEBBLE19,-,ABS HB,BK 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 4 S.A
...3 T0524 6902-000389 BAG PE;HDPE/NITRON/HDPE,T0.015/T0.5/T0.0 1 S.N.A
...3 CIS4 BN61-01717A HOLDER-STAND;BIZET,NI PLT,CH,+,M4,L11(5) 1 S.A
...3 BN61-02785A BRACKET-STAND BODY;PEBBLE,SECC,0.8 1 S.N.A
...3 CCM1 BN63-02183C COVER-SHEET;Rhcm,PE Vinyl,T0.05,200mm,20 0.3 S.N.A
...3 T0004 BN63-02882B COVER-STAND BASE;PEBBLE,ABS,2.6,HB,BK26 1 S.N.A
...3 T0132 BN73-00077A RUBBER FOOT;MATISSE,BUMPON,◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
