Image preview - the first page of the document



>> Download 2232BW[8] documenatation <<

Text preview - extract from the document

                                                                  6. Wiring Diagram

6. Wiring Diagram
6-1. Wiring Diagram


       Lamp wire for Panel   LVDS for Panel




                                          VGA Input   DVI Input   Function
                                                                  Connector




                                                                               6-1
6. Wiring Diagram

6-1-1. Wiring Diagram (Photo)


          IP Connector                                         LVDS Connector
            (Connect to                                       (Connect to Panel)
              IP-Board)




                           DVI Connector    RGB Connector
                          (Connect to PC)   (Connect to PC)




6-2
                                                                                                  6. Wiring Diagram

6-2. Connector Functions
        Connector                                                Functions

CN201 <-> CN601        Supplies 14V from the power board to the main board and transmits the PWM output from the
                       power board to the inverter.
                       * Possible problems: The No Power and Blank Screen errors may occur.

CN1 ~ CN4              Transmits the lamp current (6mA ~ 7mA) generated in the inverter to the panel lamp.
                       * Possible problems: A Blank Screen error may occur.

CN1                    Transmits input power of 90V to 263V to the power board.
                       * Possible problems: The No Power error may occur.

CN101                  DVI signal input terminal
                       * Possible problems: The No DVI Output error may occur.

CN102                  VGA signal input terminal
                       * Possible problems: The No RGB Output error may occur.

CN200                  Connects the function board and the main board.
                       * Possible problems: The No Power, No LED Screen, No OSD Operation, and Abnormal OSD
                       Operation errors may occur.

CN400                  Transmits the LVDS signals from the main board to the panel.
                       * Possible problems: The Blank Screen and No Power errors may occur.


6-3. Cables
Use           Power Cable(9Pin)                    LVDS 30P FFC cable

Code          BN39-00785A                          BN96-005621








                                                                                                               6-3
6. Wiring Diagram

Memo
