Image preview - the first page of the document
Product Specification


>> Download Product Specification documenatation <<

Text preview - extract from the document
                                                                                             2. Product specifications

2. Product specifications
2-1. Feature & Specifications
               Model                                                  UA40C6200UR

                                                        Feature

   RF, 4-HDMI, 1-Component, 1-AV, 2USB 2.0, D-SUB, D-SUB
   Brightness : 500cd/m2
   Contrast Ratio : 6,000:1
   Response time : 6ms
   Dynamic contrast, Super-PVA
   PIP(in HDMI 1, 2, 3, 4, Component1, PC Mode and Sub picture is available in TV analog mode)

                                                     Specifications

               Item                                                    Description
LCD Panel                      LTF400HJ03,SSDZJT,8bit,40,1.07B,16:9,0.46125(H)*0.15375(w,0 to +50,12V,SPVA
                               82%,LED,120Hz,SC
Scanning Frequency             Horizontal : 67.5KHz (TYP)
                               Vertical : 60Hz (TYP)
Display Colors                 1.07 billion colors
Maximum resolution             Horizontal : 1920 Pixels
                               Vertical : 1080 Pixels
Input Signal                   Analog 0.7 Vp-p
